Contribution of Leaf-Surface Fungi to the Air Spora

1
Contribution of Leaf-Surface Fungi to the Air
Spora

• Estelle Levetin and Kip Dorsey

2
Air Spora and Leaf Surfaces

• Phylloplane fungi considered major contributors
  to air spora
• In Tulsa leaves appear by mid-April and remain on
  the trees till November
• High concentration of airborne spores occur
  during this same period
• Few studies have compared taxa on leaf surfaces
  with those in the atmosphere

3
Leaf Surfaces

• Leaf surfaces colonized by many types of bacteria
  and fungi
• Both saprobic and pathogenic species
• Leaf surfaces can also serve as traps for
  airborne fungi that settle on surface
• Both colonizers and settled spores may become
  entrained (or reentrained) into the atmosphere

4
Purpose of Study

• Examine the phylloplane fungi on two common trees
  in the Tulsa area
• Look for patterns in the communities on leaves
  throughout the growing season
• Compare these taxa to those appearing in the
  atmosphere
• Look for possible parallels in changes of air
  spora and leaf surface fungi

5
Daily Air Sampling

• Air sampling was carried out with a Burkard Spore
  Trap on the roof of biology building on the
  University of Tulsa campus
• Sample drums were changed every 7 days and cut
  into 24 hour segments
• Slides were examined at 1000x using the single
  longitudinal transverse method

6
Tree Types

• Quercus (Oak) and Ulmus (Elm) are two dominant
  tree types in eastern Oklahoma
• Quercus palustris and Ulmus americana were chosen
  for this studies

7
Leaf Surface Fungi

• Leaves collected weekly from Apr. 18 - Nov. 23
• Three leaves from each tree were aseptically
  picked, placed in sterile plastic bags and
  immediately taken to the Aerobiology Lab
• Various methods tested for fungal isolation from
  leaf surfaces
• 4cm2 areas on both adaxial and abaxial surfaces
  were separately wiped with sterile cotton swabs
  that were dampened with sterile distilled water
• Swabs were each put in a sterile tube with 1ml of
  sterile distilled water and vortexed for 30
  seconds
• Swabs were removed and 0.5ml of each spore
  suspension was pipetted onto petri dishes
  containing malt extract agar plus streptomycin

8
Leaf Surface Fungi

• 12 plates were prepared each week total 360
  plates
• Cultures were incubated at room temperature for 5
  to 7 days
• Colonies were counted and fungi identified to
  genus level with standard keys

9
Airborne Fungal Spore Concentration
10
23 Taxa identified Cladosporium, Ascospores,
Basidiospores, and Alternaria Comprised 90 of
Total
11
Results of leaf surface cultures

• 21,624 colonies isolated from leaf surfaces
• 23 taxa identified
• 15 taxa appeared on first sample, April 18
• Most prevalent taxa (over 90)
• Yeast 62.3
• Phoma-type 12.3
• Cladosporium 10.8
• Alternaria 4.7

12
Fungi Identified from Leaf Surfaces
Acremonium Drechslera Pithomyces
Alternaria Epicoccum Rhizopus
Arthrinum Fusarium Seimatosporium
Aspergillus Geotrichum Sporothrix
Aureobasidium Hyalodendron Trichoderma
Choanephora Nigrospora Yeast
Cladosporium Penicillium Non-sporulating
Curvularia Phoma-type
13
(No Transcript)
14
Leaf Surface Concentrations

• Generally there was a greater number of colonies
  isolated from the abaxial surface but no
  significant difference
• Generally there was a greater number of colonies
  isolated from elm leaves but no significant
  difference between oak and elm
• Mean concentrations of leaf surface fungi
  (CFU/cm2)

Oak Adaxial Oak Abaxial Elm Adaxial Elm Adaxial
22.3 31.7 32.7 34.6
15
Yeasts

• A general term to describe unicellular fungi that
  reproduce by budding
• No attempt was made to identify yeast other than
  Aureobasidium
• Several different types of yeasts were routinely
  isolated based on pigmentation and cell shape
• Yeasts generally dispersed by rain splash
  however, Taylor recently reported that
  Aureobasidium was the most abundant taxa
  identified on Burkard air samples from a southern
  California location

16
Phoma

• A large genus (223 spp) of anamorphic fungi in
  the Ceolomycetes that are characterized by
  conidia formation in a pycnidium spore
  dispersal by rain splash
• Many common ascomycetes have a Phoma anamorph
  including species in
• Leptosphaeria
• Didymella
• Mycosphaerella
• Pleospora
• Phaeosphaeria
• Diaporthe
• Phoma - like genera Phomopsis, Plenodomus,
  Peyronellaea, etc
• Some Epicoccum isolates have a Phoma synanamorph

17
Concentrations of Leaf Surface Fungi and Airborne
Spores
18
Correlation of Airborne Spores and Leaf Surface
Fungi

• When individual genera examined there was no
  significant correlation between leaf surface
  fungi and airborne concentration
• Phoma did show a significant correlation with
  airborne ascospore levels
• Nine fungal taxa were found on both leaf surface
  cultures and the airborne samples
• The mean concentrations for the season were
  compared using a Spearman Correlation
• There was a significant correlation between leaf
  surface fungi and airborne fungi (r0.74,
  p0.035)

19
Comparison of Airborne Ascospore Concentration to
Leaf Surface Phoma
Positive correlation r 0.41, plt0.05
20
Correlation with meteorological variables

• Temperature was the most important factor of
  airborne spore levels
• Airborne spore concentrations were significantly
  related to average daily temperature during the
  April to November study period
• Rainfall was the most important factor for leaf
  surface fungal concentrations
• Several taxa showed significant correlations with
  weekly rainfall totals

21
Comparison of total weekly rainfall and number
of colonies from leaf surfaces
22
Correlation of Leaf Surface Fungi and Rainfall
Spearman R P Value
Total Colonies 0.557 0.001
Yeast 0.554 0.001
Phoma 0.481 0.007
Cladosporium 0.131 0.489
Alternaria -0.232 0.217
23
Leaf Surface Significance

• The leaf surface concentrations
• Oak 27.00 CFU/cm2
• Elm 33.68 CFU/cm2
• Approximate surface area of elm and oak leaves
• Oak 50 cm2
• Elm 23 cm2
• Total number of leaves per tree estimated using
  average branch-to-branchlet technique
• Oak 100,000 leaves
• Elm 325,000 leaves
• Surface area estimate for trees
• Oak 5.0 x 106 cm2
• Elm 7.5 x 106 cm2
• Estimate of CFU per tree
• Oak 1.35 x 108 CFU
• Elm 2.53 x 108 CFU

24
Possible Atmospheric Output on Peak Leaf Surface
Days
Fungi Peak Date Conc. CFU/cm2 Possible Oak total Possible Elm total
Cladosporium 6-Sep 6.67 3.34 x 107 5.00 x 107
Alternaria 13-Nov 3.58 1.79 x 107 2.69 x 107
Curvularia 22-Aug 0.78 3.9 x 106 5.85 x 106
Drechslera 18-Nov 1.00 5.0 x 106 7.5 x 106
Epicoccum 1-Nov 1.04 5.2 x 106 7.8 x 106
Pithomyces 25-Jul 1.08 5.4 x 106 8.1 x 106
Penicillium 22-Aug 1.13 5.65 x 106 8.48 x 106
Aspergillus 18-Aug 0.33 1.65 x 106 2.48 x 106
Nigrospora 3-Oct 0.50 2.5 x 106 3.75 x 106
25
Conclusion

• Leaf surface fungi include taxa with airborne
  dispersal and those with rain splash dispersal
• Leaf surface fungi with airborne dispersal can be
  major contributors to the air spora
• Questions remain about
• Population changes on leaf surface
• Contribution of Phoma-complex and yeast to the
  air spora

26
Acknowledgments

• Assistance of Claudia Owens for help with air
  sample analysis is greatly appreciated.
