THREDDS and Digital Library Searching

1
THREDDS and Digital Library Searching
2
IDD Data Push
IDD Data
Local Data Manager (LDM)
Decoders
McIDAS Application
Files
GEMPAK Application
Other Applications
3
Pull Servers
Files
McIDAS Application
ADDE Server (SSEC)
Archival data
OPeNDAP (UnivRI)
NetCDF Application
4
THREDDS Goals

• Funded through NSDL initiative
• Make real scientific data available in Digital
  Libraries
• Work closely with NSDL, DLESE
• have them provide the search interface
• NASA Global Change Master Directory (GCMD)
  furthest along

5
Challenges

• No description of what data is available from the
  servers
• Digital Libraries want text records, not binary
  datasets
• What are users searching for?
• What can users do once they find what they are
  looking for?

6
Collections vs. Inventory

• Too many inventory files, eg in IDD
• NCEP models 28 collections, 6000 files
• NEXRAD level 3 files 8M files
• Real-time datasets are never current
• DLs (GCMD, DLESE) dont want them

7
THREDDS Catalogs

• XML documents over HTTP
• Hierarchical listing of online resources
  (datasets)
• Inventory files are contained in collection
  datasets
• Collection search in DL, browse inventory on
  server.
• Container for arbitrary search metadata
• Standard set maps to DC, GCMD, ADN
• Metadata can be inherited
• Design goal Make it easy for data providers

8
catalog.xml
9
Motherlode catalog example
10
Further Development

• Serve the data, too
• Tackle granularity problem by creating logical
  datasets
• Aggregations of files
• Harvest DL records directly from catalogs
• Put links in DL records back to the catalog
• User can start up helper app (IDV) to visualize
  data

11
THREDDS Data Server
HTTP Tomcat Server
catalog.xml
Application
THREDDS Server

• WCS

• OPeNDAP

• HTTPServer

• NetcdfSubset

NetCDF-Java library
motherlode.ucar.edu
Datasets
IDD Data
12
THREDDS OPeNDAP Server

• Current version 2.0 NASA ESE standard
• Working on new 4.0 protocol spec
• Based on Java-OPeNDAP library
• shared development by Unidata/opendap.org
• Any CDM dataset can be served
• Server4 (Hyrax)
• latest version of opendap.org C library
• uses THREDDS catalog generation code
• THREDDS Catalogs replace dods_dir

13
THREDDS WCS Server

• Open Geospatial Consortium (OGC) specification
  for GIS clients
• Ongoing merging with ISO
• For gridded data only
• Return formats
• GeoTIFF floating point, greyscale
• NetCDF / CF-1.0 (same as NetcdfSubset Service)

14
(No Transcript)
15
Common Data Model
HTTP Tomcat Server
catalog.xml
Application
THREDDS Server

• WCS

• OPeNDAP

Then a miracle happens

• HTTPServer

• NetcdfSubset

NetCDF-Java library
hostname.edu
Datasets
IDD Data
16
Application
Scientific Datatypes
Datatype Adapter
NetCDF-Java version 2.2 architecture
NetcdfDataset
CoordSystem Builder
ADDE
NetcdfFile
I/O service provider
OPeNDAP
NetCDF-3
NIDS
GRIB
NetCDF-4
NcML
HDF5
GINI
Nexrad
DMSP

17
I/O Service Provider Implementations

• General NetCDF, HDF5, OPeNDAP
• Gridded GRIB-1, GRIB-2
• Radar NEXRAD level 2 and 3, DORADE, Chinese
  NEXRAD
• Point BUFR, ASCII
• Satellite DMSP, GINI, McIDAS AREA
• In development / tentative
• NOAA CLASS legacy files
• Barrowdale DataBlade

18
Payoff N M instead of N M things on your TODO
List!
File Format 1
Visualization Analysis
NetCDF file
File Format 2
OpenDAP Server
File Format N
WCS Service
Web Service
19
Digital Library (OAI) Harvesting
OAI Harvester
HTTP Tomcat Server
OAI Provider
DL Records
Catalog.xml
THREDDS Server
Application
NetCDF-Java (CDM) library

• OPeNDAP

• HTTPServer

• WCS

Datasets
otherhost.gov
OPeNDAP Server
hostname.edu
20
(No Transcript)
21
(No Transcript)
22
Forecast Model Run Collection (FMRC)
23
Current Status

• THREDDS Data Server
• A good framework for pull data services
• Focus on dataset aggregation
• Small number of datasets currently available on
  motherlode (30)
• Other TDS early adopters have a few hundred more
• Metadata quality uneven

24
How to deliver the data?

• What data protocols will users need?
• OPeNDAP has a fair amount of current use in
  atmospheric/ocean community
• OGC still immature, but EU insisting on formal
  standards
• ADDE use restricted to McIDAS community
• What data formats do users need?
• Strategy is to promote netCDF/CF-1.0

25
What to do next?

• Community annotation of datasets
• Datapedia
• Unidata Data Czar
• Domain expert
• Add metadata to known datasets
• We will need a search strategy
• DLESE, NSDL probably wont solve this
• GCMD probably useful
• Working with International partners
• NCAR Community Data Portal
• British Atmospheric Data Center
