Subantral Option 1 : Conventional Implant Placement

1
MAXILLARY SINUS AUGMENTATION
2

• Maxilla is 35 times more edentulous than mandible
• Maxillary sinus continues pneumatization
  throughout life.
• The available bone is lost from the inferior
  expansion of the sinus after tooth loss,
  involving the residual ridge region
• The bone density in this region is also decreases
  rapidly an on average is the least dense of any
  oral region

3
Neurovascular supply

• Blood supply is mainly derived from nose
• Sphenopalatine artery
• Anterior posterior nasal artery
• Infraorbital artery
• Posterior middle superior alveolar artery
• Facial artery
• Palatine artery

4

• Venous drainage
• Anterior facial vein
• Pterygoid veinous plexus
• Lymphatic drainage
• Submandibular lymphnode
• Nerve supply
• Maxillary division of trigeminal nerve (V2)

5
Maxillary Sinus Anatomy

• Pyramidal shape
• Roof floor of orbit
• Floor alveolar bone and
  palatine process
• Anterior wall facial surface of
  maxilla
• Posterior wall infratemporal
  surface
• Medial wall lateral wall of
  nasal cavity

6
Sinus membrane

• Schneiderian membrane
• Mucoperiosteum cansists 3 layers
• 1.Epithelium lining pseudostratified columnar
  ciliated epithelium
• 2.Lamina propria can stripped easily
  from
• 3.periosteum underlying bone
• There are numerous globlet cell
• Most of the serous and mucous glands found in the
  lining are located near the maxillary ostium

7
(No Transcript)
8

• The maxillary ostium
  opening in the medial wall
  and near the superior
  aspect of the sinus
• The cilia beat toward the
  ostium at 15 cycles/minute
• Adequate manipulation of the membrane and
  placement of graft material are possible without
  impeding the drainage of the sinus

9
Treatment planning for edentulous posterior
maxilla
10
Patient evaluation

• The SA-2 to SA-4 surgical procedures the sinus
  should be free of infection
• In addition, a thorough history and clinical
  evaluation of the maxillary sinus are conducted.
• Potential infection in the region of the sinuses
  may result in extremely severe complication

11

• Physical examination
• Radiography
• Conventional OPG, waters view
• CT
• MRI
• CT is currently the modality of choice
• Any sign of acute sinusitis, root tips, cysts or
  tumors complicate the procedure and mandate
  further evaluation
• Known diseases of the antrum should be treated
  before sinus grafts

12
Premedications
13
Surgical technique

• Patient sedation, local anesthesia, and
  preparation of an aseptic environment
• Antiseptic mouth rinse Chlorhexidine scrub and
  rinse may be used
• Iodophor compounds ( Betadine ) are a most
  effective antiseptic, but inhibit the
  osteoinduction of demineralized bone

14

• Regional anesthesia
• Blocking maxillary nerve (v2 ) 1.8 ml
• Hemimaxilla, side of nose, cheek, lip, sinus area
• Long-acting anesthetic Bupivacaine 0.5 or
  Etidocaine 1.5 with EPI 1200,000
• Local infiltration
• Labial mucosa and palatal region
• Complete hemostasis
• Lidocaine 2 with EPI 1100,000

15
Bone density classification

• 1. dense compact (D-1) bone
• 2. dense to thick porous compact and coarse
  trabecular (D-2) bone
• 3. porous compact and fine trabecular
  (D-3) bone
• 4. fine trabecular (D-4) bone

16
Division of available bone
17
Subantral Option 1 Conventional Implant
Placement

• Height gt 12 mm.
• An improved compressive thread design implant (4
  mm. diameter) implants may accommodate
• 11 mm. of bone height in D2,
• 12 mm. in D3,
• 13 mm. in D4
• In division A, root form implants are placed for
  prosthetic support
• Division B bone, osteoplasty or augmentation to
  increase the width to Division A

18

• Then reevaluated to determine the proper
  treatment plan classification
• Remain 1-2 mm. short of the sinus floor is not
  indicated in the posterior maxilla
• Endosteal implantation in the SA-1 category are
  left to heal in a nonfunctional environment for
  approximately 4 to 8 months before the abutment
  posts are added for prosthodontic reconstruction

19
Subantral Option 2 Sinus lift and Simultaneous
Implant Placement

• Height 10 12 mm.
• When the available bone is 0 to 2 mm.
  Insufficient in length for ideal implant length
• Incision and Reflection
• A full thickness incision is made on the crest of
  the ridge from the tuberosity to the distal of
  the canine region and vertical incision 5 mm.

20

• Osteotomy and Sinus lift ( SA-2 )
• The depth of the osteotomy is approximately 1 to
  2 mm. short of the floor of the antrum
• Reduced speed of the hand piece ( slower than
  1000 rpm ) enhances the tactile sense and feel
  the cortical plate of the antral floor

21

• The osteotome is inserted and tapped firmly into
  final position up to 2 mm.
• The apical portion of the implant engages the
  cortical floor, with bone over the apex, and an
  intact sinus membrane

22
(No Transcript)
23

• The patients prosthodontic treatment is similar
  to that in the SA-1 category
• The implant body should not have an apical hole,
  which also may fill with mucous and be a source
  of further sinus infections

24
Subantral Option 3 Sinus graft with delayed
endosteal implant placement

• Height 5 10 mm.
• Incision line and reflection
• Awareness of the greater palatal artery, in the
  severe atrophic maxilla
• A relief incision enhance access and vision
• Aggressive reflection of the flap may cause
  damage to infraorbital nerve

25

• Access window
• 6 round diamond bur
• Copious sterile saline
• The outline is scored on the bone with a rotary
  instrument

26

• The corners of the access window are usually
  round
• paintbrush stroke approach until a bluish hue or
  hemorrhage from the site is observed
• A flat-ended metal punch or mirror handle and
  mallet are used to gently separate the lateral
  window from the surrounding bone, while still
  attached to the thin sinus membrane

27

• A soft tissue curette is introduced along the
  margin of the window
• The curette is never blindly placed into the
  access window
• The periosteal elevators and curettes further
  reflect the membrane off, to a height of at least
  16 mm from the crest of the ridge

28
(No Transcript)
29
(No Transcript)
30
Sinus graft materials

• Several graft materials have been studied
• Autogenous bone any debris from implant
  osteotomies, the tuberosity region, exostoses,
  cores from the symphysis or ramus region
• Demineralized freeze-dried bone (DFDB)
• Beta tricalcium phosphate
• Xenograft hydroxyapatite
• Combinations

31
A layered-type graft

• 1. dense HA antibiotic
• 2. cacium phosphate (usually xenograft
  microporous HA such as Osteograft N-300 or
  Bio-Oss) DFDB PRP from whole blood
  antibiotic
• 3. autogenous bone

32

• Graft materials not mixed with blood or
  anesthetic solution
• The toxic byproducts of blood catabolism and the
  acidic pH of anesthetic both may decrease bone
  formation
• A resorbable membrane may be placed over the
  lateral access window

33

• The 5 to 8 mm of initial bone height may
  stabilize the implant and permit its rigid
  fixation
• An endosteal implant may be inserted at this
  appointment

34

• Several advantages tend toward the decision to
  delay implant placement for approximately 4
  months
• Disadvantage of delaying the implant placement is
  the need for an additional surgery
• The implant may be inserted after 2 months yet
  reducing considerably the risk of infection

35

• Primary closure using interrupted horizontal
  mattress or a continuous suture
• Sinus incision line opening may contribute to
  infection, contamination, or loss of graft
  materials

36

• Healing for implants placed into sinus grafts
• The main variables appear to be the time healing
• The volume of the subantral graft
• The distance from the lateral to medial wall
• The amount of autologous bone
• The health status of the patient Diabetics,
  postmenopausal women
• All of which relate to the amount of new bone
  formation

37

• Autogenous bone (4-6 months)
• Autogenous bone porous HA DFDB (6-10 months)
• Alloplasts only as tricalcium phosphate (24
  months)

38
Subantral Option 4 Sinus graft and extended
delay of endosteal implant placement

• Height lt 5 mm
• There for the fewer bony walls, less favorable
  vascular bed, minimal local autologous bone, and
  larger graft volume
• Sinus graft is performed as in the previous SA-3
  procedure

39

• Additional bone harvest site is usually required
  ascending ramus of mandible
• The implant does offer an advantage if coated
  with HA
• The time interval for rigid osseous fixation is
  dependent on the density of bone

40
Postoperative instructions

• Do not
• blow your nose
• Tobacco use
• Drinking with straw
• lift or pull on lip to look at sutures
• Sneezing with closed mouth
• Take your medication as directed
• Aware of small granules in your mouth

41

• Notify the office if
• You feel granules in your nose
• Your medications do not relieve your discomfort

42
Perioperative complications

• Window
• Bleeding bone wax, electrocautery
• Septum make two windows seperated by septum
• Perforation repair after membrane elevation

43

• Membrane
• Perforation repair
• Small collagen membrane (Collatape)
• Large slow resorbable membrane (Biomend)
• Thick
• Polyp curette out
• Mucocele drain
• Delay sinus graft

44
Possible Complication - Small Perforation
45
Possible Complication - Large Perforation
46
(No Transcript)
47
Postoperative complicationShort-term
complications

• Incision line opening assess need to restore
• Bleeding (from nose) do not blow nose, do not
  lower head
• Graft escape through perforation, assess amount
  swelling/infection
• Antibiotic oral, IV
• Drain, remove graft
• Assess progression culture and sensitivity test
  anaerobes/aerobes
• Reassess antibiotic choice
• Refer

48
Suggest pharmacologic protocal for sinus graft
infection

• Amoxicillin 2 g stat, 500 mg qid
• Metronidazole 500 mg stat, 250 mg tid
• or
• Clindamycin 300 mg stat, 150 mg qid

49
Reference

1. Misch CE. Contemporary implant dentistry. Mosby
   1999.
2. Spiekermann H. Color atlas of dental medicine
   implantology, Thieme 1995.
3. ?????????????????????????? ???????????????? ???
   ?????????????????? ??. ??????? ????????
4. ?????????????????????????? Diagnosis and
   management of maxillary sinus ??? ?.??.
   ????????? ?????????????
5. www.google.com
