Title: Frame


1
(No Transcript)
2
Band
Inner Shield
Frame
3
Cold Rolled Steel for Frame
Characteristics
  • High quality products by the computer
    integrated
  • manufacturing system in Asan Bay Work
  • Excellent surface finish, flatness, formability
    and
  • thickness tolerance
  • Superior hardness and tensile strength
  • - The best combination of hardness and tensile
    strength has been
  • achieved to provide the customers with the
    advantages of working without
  • burring or powdering

4
Application
Frame
5
Mechanical Properties
Class Standard Specification Standard Specification Standard Specification Dongbu Dongbu Dongbu
Commercial Quality T.S (kg/mm2) EL min.() Hardness (HrB) T.S (kg/mm2) EL min.() Hardness (HrB)
Commercial Quality 28 and over 3637 and over 65 and under 28 and over 3637 and over 55 and under
? Please contact our representative regarding the
range of coil weight packing. ? We can
customized mechanical properties per demand.
6
Extra Thin Cold Rolled Steel for Inner Shield
Characteristics
  • Very thin thickness 0.15mm
  • Excellent flatness and thickness tolerance

Thickness(mm) Thickness(mm) Flatness(mm)
Rolling Direction Crosswise Flatness(mm)
0.01 0.01 max.3
7
Application
Inner Shield
8
Mechanical and Magnetic Properties-Dongbu
Class Mechanical Properties Mechanical Properties Magnetic Properties Magnetic Properties
Class T.S (kg/mm2) EL () Permeability Coercive Force(Oe)
Class T.S (kg/mm2) EL () ?(0.35) Coercive Force(Oe)
Ordinary 28 30 300 2.5
Medium permeability 25 20 500 1.8
High permeability 40 10 750 1.25
? Note 1 Mechanical properties As
received 2 Magnetic properties After
annealing(about 600?10minutes) ? Please contact
our representative if you have further question
9
ALCOT for Band
Characteristics
  • Excellent heat resistance

HEATING BEHAVIOR OF ALCOT
10
Characteristics
  • Available quality specification
  • Commercial, Drawing, and Structural
  • - KSD 3544, JIS G 3314, ASTM A 463-96a, EN 10154
  • Higher corrosion resistance

11
Application
? ALCOT is d Dongbu Steel brand name for hot-dip
aluminium coated steel sheets and coils.
12
ALCOT for Band
Scope Manufacturing Field
Thickness (mm) Width (mm) Coating Weight (g/m2) Post-treatment
0.42.3 min. 16 40160 Chromated, Oiled, No treatment
? Skelp of any width can be manufactured upon
demand.
13
SuperGalum for Band
Characteristics
  • Excellent heat resistance

Level of oxidation with continuous heating
Heat resistance
? Extensive use at temperatures of around 315? or
less causes very little change in ALCOT and does
not affect its attractive surface
brightness. ? Maintain surface attractiveness at
extensive temperatures up to 315? the surface
color changes slowly from grey to black at higher
temperature.
14
SuperGalum for Band
Characteristics
  • Excellent formability and durability
  • Economic advantages
  • - SuperGalum sheet provides more additional area
    per ton than galvanized
  • steel sheet.
  • Excellent flatness and
  • thickness tolerance

Thickness(mm) Flatness(mm)
0.03 max.3
15
SuperGalum for Band
Application
Brand
? SuperGalum is a Dongbu Steel brand name for 55
Aluminium-Zinc alloy coated steel sheets and
coils.
16
SuperGalum for Band
Scope of Manufacturing Field
Thickness (mm) Width (mm) Coating Weight (g/m2) Optimal Coating Weight for BAND (g/m2)
0.32.0 min.16 60200 90130
? Post-treatment Chromated, Oiled, No
treatment, Chromated Oiled
