Real Time High-Resolution NWP _at_ McGill University

• J. Gyakum1, R. McTaggart-Cowan1, P. Sisson2

1 McGill University
2 National Weather Service
2
Objectives

• Implementation of a real time MC2 system
• Data collection for stat-istical analysis and
  case studies
• Investigate impacts of high-resolution modelling
  on QPF and near-surface winds

3
Outline

• Need for mesoscale modelling
• Description of NWP system
• Validation case study
• (27 September 2002)
• Project timeline and ongoing upgrades

4
High Resolution (3km)

• Accurate topography
• Improved wind fields and fluxes
• Model terrain-induced confluence

5
Mesoscale Orography
High resolution (6 km)
Degraded resolution (100 km)
6
Model Description

• MC2 version 4.9.5
• Non-hydrostatic, semi-implicit time step,
  semi-Lagrangian advection
• Full physics version 3.72
• Three one-way nest domains

7
Nesting Strategy
8
Computational Platform

• NEC SX-6/8M10 super-computer maintained by
  RPN/CMC
• 10x8 PE nodes
• Theoretical peak performance 10x64 GFlop

9
Performance Timeline
Domain 1 (36km)
Domain 2 (12km)
Domain 3 (3km)
0000 UTC
0300 UTC
0600 UTC
0900 UTC
CMC Regional Forecast
McGill Real Time Mesoscale Cascade
All runs completed by 0330 Eastern Standard Time
10
Production Suite

• Synoptic

• Mesoscale

Traditional upper-level forcings and QG dynamics
Visualization of processes and forcings occurring
at small scales
11
Production Suite

• Synoptic

Traditional upper-level forcings and QG dynamics
dynamic tropopause potential temperature
12
Production Suite

• dynamic tropopause ?

• Synoptic

Traditional upper-level forcings and QG dynamics
isentropic potential vorticity
13
Production Suite

• dynamic tropopause ?
• isentropic potential vorticity

• Synoptic

Traditional upper-level forcings and QG dynamics
coupling index ?dt - ?e(bl)
14
Production Suite

• dynamic tropopause ?
• isentropic potential vorticity
• coupling index

• Synoptic

Traditional upper-level forcings and QG dynamics
moisture transport
15
Production Suite

• dynamic tropopause ?
• isentropic potential vorticity
• coupling index
• moisture transport

• Synoptic

Traditional upper-level forcings and QG dynamics
moisture flux divergence
16
Production Suite

• dynamic tropopause ?
• isentropic potential vorticity
• coupling index
• moisture transport
• moisture flux divergence

• Synoptic

Traditional upper-level forcings and QG dynamics
Non-standard synoptic output available on 36 and
12 km domains (1 2)
17
Production Suite

• Mesoscale

Visualization of processes and forcings occurring
at small scales
frontogenesis function and terms
18
Production Suite

• frontogenesis function

• Mesoscale

Visualization of processes and forcings occurring
at small scales
high-resolution convective and explicit
precip-itation
19
Production Suite

• frontogenesis function
• high resolution precipitation

• Mesoscale

Visualization of processes and forcings occurring
at small scales
high resolution vertical motion fields
20
Production Suite

• frontogenesis function
• high resolution precipitation
• high resolution vertical motion

• Mesoscale

Visualization of processes and forcings occurring
at small scales
cross-sectional plots of various thermodynamic
variables
21
Production Suite

• frontogenesis function
• high resolution precipitation
• high resolution vertical motion
• thermodynamic cross-sections

• Mesoscale

Visualization of processes and forcings occurring
at small scales
cross-sectional plots of frontal circulations
22
Production Suite

• frontogenesis function
• high resolution precipitation
• high resolution vertical motion
• thermodynamic cross-sections
• frontal circulations

• Mesoscale

Visualization of processes and forcings occurring
at small scales
Mesoscale visualization tools available on 12 and
3 km domains (2 3)
23
Case Study (2 May)
GOES-East Water vapour 0000UTC 2 May
24
Precipitation Structure
Radar Observations
Model Rain Rate
0900 UTC 2 May 2002 (initialized 0000 1 May)
25
Precipitation Structure
Radar Observations
Model Rain Rate
1200 UTC 2 May 2002 (initialized 0000 1 May)
26
Project Timeline
model implementation
McGill-side storage structure
analysis tool construction
visualization design
web interface construction
gridded data transfers
AWIPS implementation
real time modelling
completed
in progress
planned
27
Case Study (27 Sept)
GOES-East Water vapour (0000 UTC 27 Sept)
28
Precipitation
Domain 1 (36km) total 24 hour rainfall ending
1200 UTC 28 Sept
29
Precipitation
Observed total 24 hour rainfall ending 1200 UTC
28 Sept
30
Precipitation
Domain 2 (12km) total 24 hour rainfall ending
1200 UTC 28 Sept
31
Precipitation
Domain 3 (3km) total 24 hour rainfall ending 1200
UTC 28 Sept
32
Precipitation
Domain 3 (3km) total 24 hour rainfall ending 1200
UTC 28 Sept
33
500mb Height/Vorticity
34
325K Potential Vorticity
35
Dynamic Tropopause
McGill 24h forecast
RUC analysis 00Z 28
Potential Temperature
36
Project Timeline
model implementation
McGill-side storage structure
analysis tool construction
web interface construction
visualization design
real time modelling
March
June
September
December
2002
2003
completed
in progress
planned
37
Case Study (30 March 03)
38
Dynamic Tropopause
39
Dynamic Tropopause
40
Coupling Index
41
Radar Imagery
0814 UTC 31 March
42
Precipitation Bands
43
IBL Development
YUL
BTV
Lake Champlain
44
Summary

• Implementation of real time mesoscale NWP is
  under way at McGill
• High resolution (3 km) will enhance mesoscale
  flow and QPF forecasts for the St. Lawrence / NE
  states region

45
Data Access

• http//132.206.43.1515080
• Grib files available to ftp servers upon request
  to
• rmctc_at_zephyr.meteo.mcgill.ca
