Chapter 25: Indoor Air Pollution

1
Chapter 25 Indoor Air Pollution
2
(No Transcript)
3
Sources of Indoor Air Pollution

• Secondhand smoke
• Most hazardous common indoor air pollutant
• Legionella pneumophila
• Bacterium that causes a type of pneumonia called
  Legionnaires disease when inhaled.
• Some molds (fungal growths) in buildings release
  toxic spores.
• Cause chronic inflammation and scarring of lungs

4
Sources of Indoor Air Pollution

• Radon gas
• seeps up naturally from soils and rocks below
  buildings
• Thought to be the second most common cause of
  lung cancer.
• Pesticides
• Deliberately or inadvertently applied in
  buildings to control pest
• Are toxic to people as well

5
Sources of Indoor Air Pollution

• Some varieties of asbestos
• Known to cause a particular type of lung cancer
• Formaldehyde
• A VOC, used in many materials found in homes and
  offices.
• Emit formaldehyde as a gas into buildings.
• Dust mites and pollen
• irritate the respiratory system, nose, eyes, and
  skin of people who are sensitive to them.

6
(No Transcript)
7
Dust mite
8
Pollen grains
9
(No Transcript)
10
(No Transcript)
11
Sources of Indoor Air Pollution

• Common indoor air pollutants are often highly
  concentrated compared with outdoor levels.
• Why?
• There are so many potential indoor sources of
  pollutants. (Furniture, beds, carpet, plastics)
• The effectiveness of the steps we have taken to
  conserve energy in buildings (ie, weather
  stripping) has led to the trapping of pollutants
  inside.

12
(No Transcript)
13
Heating, Ventilation, and Air-Conditioning Systems

• Systems are designed to provide a comfortable
  indoor environment for people.
• Design depends on a number of variables
• Including the activity of people in the building,
  air temperature and humidity, and air quality.
• Done correctly it will
• Provide thermal comfort for people inhabiting the
  building.
• Provide the necessary ventilation (utilizing
  outdoor air)
• Remove common air pollutants via exhaust fans and
  filters

14
Pathways, Processes, and Driving Forces

• Many air pollutants originate within buildings
  and may be concentrated there because of lack of
  proper ventilation.
• Other air pollutants may enter by infiltration,
• Through cracks and other openings in the
  foundations and walls (Radon, VOCs)
• Or by way of ventilation systems. (proximity to
  roads)

15
Pathways, Processes, and Driving Forces

• A chimney effect (or stack effect)
• Occurs when there is a temperature differential
  between the indoor and outdoor environments.
• Warmer air rises in the building to the upper
  levels, it is replaced in the lower portion of
  the building by outdoor air.
• Secondhand smoke, may also be drawn into a
  building by the chimney effect.

16
Building Occupants

• People living or working in particular indoor
  environments react to pollutants in different
  ways
• Some groups of people are particularly
  susceptible to indoor air pollution problems.
• The symptoms reported by people in a particular
  environment vary.
• In some cases, the symptoms reported result from
  factors other than air pollution.

17
Particularly Susceptible People

• A persons susceptibility to a particular air
  pollutant also depends on genetic factors,
  lifestyle, and age.
• Sometimes a matter of concentration rather than
  susceptibility.
• Older people and children are generally more
  sensitive.
• People suffering from chronic lung or respiratory
  diseases are more susceptible.
• Individuals who have suppressed immune systems.
• Some people, when exposed to chemicals, develop
  multiple chemical sensitivity (MCS).

18
Symptoms of Indoor Air Pollution

• A great variety of symptoms can result from
  exposure to indoor air pollutants.
• Nosebleeds, chronic sinus infections, headaches,
  and irritation of the skin or eyes, nose, and
  throat.
• More serious problems include loss of balance and
  memory, chronic fatigue, difficulty in speaking,
  and allergic reactions, including asthma.
• Other pollutants cause dizziness or nausea.
• Radon, asbestos, and chemicals such as benzene,
  may have long-term chronic health effects
  (cancer).

19
Sick Buildings

• There are two types of sick buildings
• Buildings w/ identifiable problems
• Occurrences of toxic molds or bacteria known to
  cause disease.
• Diseases are known as building-related illnesses
  (BRI).
• Buildings w/ sick building syndrome (SBS)
• Symptoms people report cannot be traced to any
  one known cause.

20
Sick Buildings

• When the cause is not detected. A number of
  things may be happening
• The complaints result from the combined effects
  of a number of contaminants present in the
  building.
• Environmental stress from another source is
  responsible.
• Employment-related stress may be leading to the
  symptoms reported.
• Pollutants or toxins may be present but not
  identified.

21
Environmental Tobacco Smoke

• Environmental tobacco smoke (ETS)
• Secondhand smoke
• Comes from two sources
• smoke exhaled by smokers
• smoke emitted from burning tobacco in cigarettes,
  cigars, or pipes.
• People who are exposed to ETS are referred to as
  passive smokers.

22
Environmental Tobacco Smoke

• It is hazardous for the following reasons
• Tobacco smoke contains several thousand
  chemicals, many of which are irritants.
• Studies of nonsmoking workers exposed to ETS
  found that they have reduced airway functions,
  suffer more illnesses, and lose more work time
  than those not exposed to ETS.
• In the US, about 3,000 deaths from lung cancer
  and 40,000 deaths from heart disease a year are
  thought to be associated with ETS.

23
Radon Gas

• Radon is a naturally occurring radioactive gas
  that is colorless, odorless, and tasteless.
• Radioactive decay chain from radiogenic uranium
  to stable lead
• Radon-222 has a half-life of 3.8 days, is the
  product of radioactive decay of radium-226.
• Radon decays with emission of an alpha particle
  to polonium-218, which has a half-life of 3
  minutes

24
(No Transcript)
25
Geology and Radon Gas

• The concentration of radon gas that reaches the
  surface of the Earth and thus can enter our
  dwellings is
• Related to the concentration of radon in the
  rocks (generally granitic rock) and soil.
• Some regions in the United States contain bedrock
  with an above-average natural concentration of
  uranium.

26
How Does Radon Gas Enter Building?

• Radon gas enters homes and other buildings in
  three main ways
• 1. It migrates up from soil and rock into
  basements and lower floors.
• 2. Dissolved in groundwater, it is pumped into
  wells and then into homes.
• 3. Radon-contaminated materials, such as building
  blocks that are used in construction.

27
(No Transcript)
28
Radon Resistant Techniques for Homes and Other
Building

• Protection is straightforward and relatively
  inexpensive.
• Techniques are variable depending on the type of
  foundation a particular home has,
• The basic strategy is to prevent radon from
  entering
• And to safely ensure that radon is removed from
  the home site.

29

• A. Gas Permeable Layer
• Allow the soil gas to move freely underneath the
  house.
• B. Plastic Sheeting
• Help prevent the soil gas from entering the home.

• C. Sealing and Caulking
• Openings in the concrete foundation floor are
  sealed to reduce soil gas entry into the home.

30

• D. Vent Pipe
• A PVC pipe runs from the gas-permeable layer
  through the house to the roof to safely vent
  radon above the house.
• E. Junction Box
• An electrical junction box is installed if an
  electric venting fan is needed.

31
Indoor Air Pollution and Green Buildings

• Building green.
• The processes involves using building designs
  that result in less pollution and better use of
  resources.
• Providing for a good indoor environmental quality
  is a significant part.
• Designing, constructing, and maintaining
  buildings that minimize indoor air pollutants.
• Ensuring that fresh air is supplied and
  circulated, and managing moisture content to
  remove the threat of moisture-related problems
  such as mold.

32
Control of Indoor Air Pollution

• There are strong financial incentives to provide
  workers w/ a clean air environment.
• A good starting point would be passing
  environmental legislation requiring minimum
  indoor air quality standards.
• Including increases in the inflow of fresh air
  through ventilation. This concept is at odds
  with the principles of Energy Efficiency.

33
(No Transcript)
34
Control of Indoor Air Pollution

• One of the principal means for controlling
  quality is by dilution
• Fresh outdoor air mixed via a ventilating
  air-conditioning system and windows that can be
  opened.
• Various types of air-cleaning systems reduce
  potential pollutants
• Such as particles, vapors, and gases.
• Can be installed as part of the heating,
  ventilation, and AC system or as stand-alone
  appliances.

35
Control of Indoor Air Pollution

• Education also plays an important role
• May involve deciding not to install unvented or
  poorly vented appliances.
• Educated people are more aware of their legal
  rights with respect to product liability and
  safety.
• Education provides people with the information
  necessary to make decisions concerning exposure
  and strategies to avoid potentially hazardous
  conditions in the home and workplace.
