Electrochemistry

1
Electrochemistry

• Electrons in Chemical Reactions

2
REDOX REACTIONS

• Examples
• Car Battery
• Electrolysis of water
• Rusting of an old Chevette
• Cellular respiration
• What do all these things have in common?
• Electrochemistry is the study of how electrons
  are transferred in chemical reactions
• The chemical changes that occur when electrons
  are transferred between reactants are known as
  reduction-oxidation (REDOX) reactions
• The of e- gained by one entity the of e-
  lost by another
• Example 2Na (s) Cl2(g) 2NaCl (s)

3

• Writing Half- Reactions
• Redox reactions can be separated into an
  oxidation reaction and a reduction reaction which
  are called half-reactions because they involve
  only one-half of the redox reaction taking place
• The half-reaction must be balanced by adding
  electrons to the side with the more positive
  charge
• Elements have a charge of zero
• The charge of an ion is written as part of the
  symbol ! eg. charge on N3- is -3

4
Reduction Half-Reactions

• Electrons are GAINED in a reduction reaction and
  are written on the REACTANT side of the equation
• Reduction
• Fe 3 3 e- Fe (s)
• Cl2 2 e- 2Cl-
• REDUCTION is a GAIN in electrons(RIG)

5
Oxidation Half-Reactions

• Electrons LOST in oxidation are placed on the
  PRODUCT side of the equation
• Oxidation
• Mg Mg 2 2e-
• 2F 1- F2 (g) 2e-
• OXIDATION is a LOSS in electrons(OIL)

6
Remembering Half-Reactions

• Oxidation OIL
• Reduction RIG
• So ... OIL RIG

7

• Now try these
• Sulfur to sulphide ions
• Sodium ion to sodium metal
• Nickel to nickel ions (2 answers)

8
Reactivity of Metals and Their Ions
The more stable a metal atom is, the more
reactive it is as an ion. The more stable a
metal ion is, the more reactive it is as a
metal. If you create a list that organizes metal
ions from most reactive to least reactive, you
end up creating a list that organizes metal atoms
from least reactive to most reactive as shown in
the table below. The resulting table is a table
of reduction half-reactions based on the
reactivity of atoms or ions, or an activity
series.
9
Activity Series for Metals and Metal Ions(page
80 in text, page 5 in data booklet)
10
Using the Activity Series

• The ranking of the reactivity of metal ions is
  shown on the left-hand side of the table, with
  the most reactive metal ions placed higher than
  less reactive metal ions.
• Which is more reactive tin ions or iron ions?
• The right side of the table lists metals in order
  of reactivity. Metals lower in the series are
  more reactive than the metals higher in the
  series.
• Which is more reactive copper or zinc?

11
Using the Activity Series

• The table is most useful for determining if a
  redox reaction is
• Spontaneous a chemical reaction that occurs
  without the addition of external energy
• or
• Nonspontaneous a chemical reaction that does
  not occur without the addition of external energy
• How do we tell if a reaction is spontaneous or
  nonspontaneous

12
Using the Activity Series
13
Spontaneous Redox Reaction Example
14
Zinc copper reaction in real life !
15
Potato Clock
Two potatoes are pierced by zinc and copper
electrodes. A small clock runs on the voltage
produced.
16
Voltaic Cells

• Applying our understanding of Redox Reactions

17
Voltaic Cells

• also called GALVANIC cells.
• electrochemical cells that are used to convert
• chemical energy into electrical energy
• energy produced by SPONTANEOUS redox reactions
• In a spontaneous redox reaction, electrons are
  transferred from the substance oxidized to the
  substance reduced
• If reactants are arranged in a certain way, these
  electrons can be made to move through a wire
• The reactants must be separated and yet in
  contact with each other so that the reaction will
  occur s l o w l y
• They can be separated by a salt bridge or a
  porous cup

18
Salt Bridge containing unreactive sodium sulfate
19
Porous Cup Unglazed porcelain cup
Allows for ion transfer just like a salt bridge
does!
20
Parts of a Voltaic Cell

• Half-cell - one part of a voltaic cell in which
  either oxidation or reduction occurs contains a
  solid (electrode) and a solution (electrolyte)
• Electrodes - solid conductors that connect the
  electrolyte solution to the external circuit
• Anode oxidation occurs here, electrons are
  produced
• negative (-) terminal
• Cathode reduction occurs here, electrons are
  used
• positive () terminal
• Electrolytes solutions that conduct electricity
  must contain ions!
• Salt bridge or porous cup - allows the passage of
  electrons without contamination of the two
  half-cells

21
How does the electricity flow?How does a voltaic
cell work?

• The electrons move from the anode to the cathode
  through a wire. This is the external circuit.
• Another circuit keeps the charges moving the
  internal circuit is the flow of ions in the
  solutions through the salt bridge or porous cup.
• Cations (positively-charged ions) move to the
  cathode
• Anions (negatively-charged ions) move to the
  anode

22

• Voltaic cells consist of
• Anode Zn(s) ? Zn2(aq) 2e (loses
  mass)
• Cathode Cu2(aq) 2e- ? Cu(s) (gains
  mass)
• As oxidation occurs, Zn is converted to Zn2 and
  2e-. The electrons flow towards the cathode
  where they are used in the reduction reaction.

23
Cell Notation
24
Identify the anode and cathode!
25
(No Transcript)
26
Batteries

• A BATTERY is a self-contained VOLTAIC CELL.
• 1. Primary Batteries
• converts stored chemical potential energy into
  electrical energy when the two half cells within
  the battery are connected by an external circuit.
• usually the container is the anode and the
  graphite center is the cathode.
• the two are separated by a thick moist paste,
  which is the electrolyte.
• are not rechargeable

27
(No Transcript)
28
(No Transcript)
29
2. Secondary Batteries

• are rechargeable by passing a direct current
  through it.
• Hg and Pb are often used in these batteries, are
  an environmental concern.
• cathode grill is filled with lead (IV) oxide, the
  anode grill is filled with spongy lead.

30
Electrolytic Cells
31
The Electrolytic Plant, which is the size of four
football fields, consumes the same amount of
power as a city of 250,000 people.
32
Copper is electroplated onto a strip of silver.
33
Note the differences.
