Pairwise Sequence Alignment and Scoring Matrices

1
Pairwise Sequence Alignmentand Scoring Matrices
Stat 115 Lecture 3

• Xiaole Shirley Liu
• And
• Jun Liu

2
Mol Bio Quick Facts

• Building block of DNA is deoxyribonucleic acid
• Building block of protein is amino acid
• Protein is a peptide, a long peptide
• Only exons can code for functional proteins or
  RNAs
• Introns are spliced out

3
Outline

• Motivation and introduction
• Dynamic programming
• Global sequence alignment
• Needleman-Wunsch
• 3 steps Initialize, fill matrix, trace back
• Gap penalties
• Local sequence alignment, Smith-Waterman
• Scoring matrices
• PAM
• BLOSUM

4
Pairwise Sequence Alignment

• Given two sequences, scoring for
  match/mismatch/gap
• Goal find pairing of letters in the two
  sequences that optimize the total score
• This is a hard example.
• That is another easy example.
• This is a --hard---- example.
• That is another easy example.

5
Align Biological Sequences

• DNA (4 nt gap)
• TTGATCAC
• TTTA-CAC
• Protein (20 aa gap)
• RKVA--GMAKPNM
• RKIAVAAASKPAV
• Sometimes gt 4 nt for DNA and gt 20 aa for proteins
• A word on IUPAC

6
IUPAC for DNA

• A adenosine
• C cytidine
• G guanine
• T thymidine
• U uridine
• R G A (purine)
• Y T C (pyrimidine)
• K G T (keto)
• M A C (amino)

• S G C (strong)
• W A T (weak)
• B C G T (not A)
• D A G T (not C)
• H A C T (not G)
• V A C G (not T)
• N A C G T (any)
• gap

7
IUPAC for Protein

• A Ala
• B Asp or Asn
• C Cys
• D Asp
• E Glu
• F Phe
• G Gly
• H His
• I Iso
• K Lys
• L Leu
• M Met
• N Asn

• P Pro
• G Gln
• R Arg
• S Ser
• T Thr
• U Sel
• V Val
• W Try
• Y Tyr
• Z Glu or Gln
• X Any
• Translation stop
• Gap

8
Why Align Two Sequences

• If two sequences are similar, they might share
  the same ancestor
• If two sequences are similar, they may share the
  same structure, therefore similar function
• In genome sequencing assembly, if two sequences
  have overlapping similar regions, they might be
  connected to represent longer sequenced region.

9
Scoring Schemes

• Match, mismatch, gap score determines the final
  alignment
• This is a --hard---- example.
• That is another easy example.
• Match OK, mismatch costly, gap cheap.
• This is a-- h-ard---- example.
• Th--at is anothe-r easy example.
• Match cheap, mismatch cheap, gap costly.
• This is a hard example.------
• That is another easy example.

10
Dot Matrix Approach

• Naïve algorithm
• Dot match, find diagonal lines
• Cant afford more complex scoring
• Visual analysis,
• hard to find
• optimal alignments

11
Dynamic Programming

• Essence of dynamic programming
• Store the sub-problem solutions for later use
• Best alignment at (i,j) is the best alignment
  previous to (i,j) plus aligning these two
• Earliest method, Needleman Wunsch 1969
• Still the best (sensitive and optimal) algorithm
  for pair-wise alignment

12
Dynamic Programming

• Best alignment at (i,j) is the best alignment
  previous to (i,j) plus aligning these two

Best previous alignment
i
j
13
Dynamic Programming

• Best alignment at (i,j) is the best alignment
  previous to (i,j) plus aligning these two
• Repeat the process until reaching the two
  sequences ends

New best alignment Best previous alignment
align (i,j)
i
j
14
Dynamic Programming Steps

• Initialize NxM matrix
• N, M are the length of the two sequences
• Fill the matrix
• Each element record the current best score, and
  pointer to the previous best alignment
• Always search the previous column and row for the
  best previous alignment
• Trace back to obtain optimal alignment

15
Fill the Matrix

• BestScorei, j maxBSi-1, j - ? BSi, j-1
  - ? BSi-1,j-1match(i,j)
• ? A A T G C
• ? 0 -1 -2 -3 -4 -5
• A
• G
• G
• C

16
Fill the Matrix

• BestScorei, j maxBSi-1, j - ? BSi, j-1
  - ? BSi-1,j-1match(i,j)
• ? A A T G C
• ? 0 -1 -2 -3 -4 -5
• A -1 1 0 -1 -2 -3
• G
• G
• C

17
Fill the Matrix

• BestScorei, j maxBSi-1, j - ? BSi, j-1
  - ? BSi-1,j-1match(i,j)
• ? A A T G C
• ? 0 -1 -2 -3 -4 -5
• A -1 1 0 -1 -2 -3
• G -2 0 1 0 0 -1
• G
• C

18
Fill the Matrix

• BestScorei, j maxBSi-1, j - ? BSi, j-1
  - ? BSi-1,j-1match(i,j)
• ? A A T G C
• ? 0 -1 -2 -3 -4 -5
• A -1 1 0 -1 -2 -3
• G -2 0 1 0 0 -1
• G -3 -1 0 1 1 0
• C

19
Fill the Matrix

• BestScorei, j maxBSi-1, j - ? BSi, j-1
  - ? BSi-1,j-1match(i,j)
• ? A A T G C
• ? 0 -1 -2 -3 -4 -5
• A -1 1 0 -1 -2 -3
• G -2 0 1 0 0 -1
• G -3 -1 0 1 1 0
• C -4 -2 -1 0 1 2

20
Fill the Matrix

• BestScorei, j maxBSi-1, j - ? BSi, j-1
  - ? BSi-1,j-1match(i,j)
• ? A A T G C
• ? 0 -1 -2 -3 -4 -5
• A -1 1 0 -1 -2 -3
• G -2 0 1 0 0 -1
• G -3 -1 0 1 1 0
• C -4 -2 -1 0 1 2

Trace back
AATGC -AGGC AATGC AG-GC
21
Alignment Recursion (linear gap penalty)
C A T T G
0
-1
-2
-3
-4
-5
T C ATG
-1
0
-1
0
1
-2
0
-1
E.g.,
-3
3
2
1
0
5
-4
-1
3
4
5
4
6
-5
-2
2
22
Affine Gap Penalty

• Gap penalty function
• Typically agtb (e.g., a12 b2)
• An order O(nm) algorithm.

Key keep 3 functions, each recording a
directional optimum.
23
Gap Penalty

• Gap penalty g l ? e
• A A T G C
• A 1 1 0 0 0
• G 0 1 1 1.4 0.3
• G
• C

g gap start l gap length e gap extend e.g.
g -0.5 e -0.1
24
Gap Penalty

• Gap penalty g l ? e
• A A T G C
• A 1 1 0 0 0
• G 0 1 1 1.4 0.3
• G 0 0.4 1 2 1.4
• C 0 0.3 0.4 1 3

g gap start l gap length e gap extend e.g.
g -0.5 e -0.1
25
End Gaps

• Should we penalize gaps at the ends?
• ATCCGCATACCGGA
• --CCGCATAC----
• If two sequences similar length and entire
  sequences are supposed to be similar, penalize.
• If two sequences have very different length, do
  not penalize (most of the time, ignore end gap
  penalties)

26
Global vs. Local Alignment

• Global Needleman-Wunsch
• Find best alignment for the whole 2 sequences
• Could have no penalty for mismatches/gaps
• Trace back from lower right corner to upper left
  corner
• Local Smith-Waterman
• Find high scoring subsequences
• E.g. Two proteins only share one similar
  functional domain
• Can be achieved by modifying global alignment
  method

27
Local Alignment Modifications

• Use negative mismatch and gap penalties
• The minimum score for i, j is 0
• If Si,j lt 0, rewrite it to 0, point to self
• If previous col/row is all 0, Si,j point to
  self
• The best score is sought anywhere in the matrix
• Not just last column and last row (should keep a
  global pointer to the best score)
• Trace back until a cell pointing to itself (not
  necessary to the beginning of the two sequences)

28
Global vs Local

• Needleman-Wunsch

• Smith-Waterman

29
Matrix Filling in Smith-Waterman
max k lt j S(i,j-k)
g(k) S(i,j) max
S(i-1,j-1) m(i,j) max l
lt i S(i-l,j) g(l) 0
S(i,j-2)
g(2)
S(i-1,j-1)
S(i,j)
S(i-3,j)
g(3)
30
Example
31
Finding suboptimal alignments
32
Smith-Waterman

• Negative mis-match negative gaps
• Scoring matrix gt 0
• Trace from maximum

33
Scoring Matrices

• For DNA, match 5, mismatch 4
• For proteins, different amino acid pairs receive
  different scores
• Consideration size, shape, electric charge, van
  der Waals interaction, ability to form salt,
  hydrophobic, and hydrogen bonds
• Substitution matrices
• Often symmetrical
• / scores
• functional similarity

34
PAM Matrices

• MO Dayhoff 1978
• PAM percent accepted mutations
• Database of 1572 changes in 71 groups of closely
  related proteins (gt 85 similar)
• Construct phylogenetic tree of each group,
  tabulate probability of amino acid changes
  between every pairs of aa
• For statistician Markov chain transition b/w aa
  pairs

35
PAM Matrix Family

• PAM-N
• PAM-0 1 on diagonal and 0 all the rest
• PAM-N what would happen if N out of 100 aa
  mutate
• For statisticians matrix multiplication N times
• Bigger N, more diverged substitution matrice
• Final matrix

36
PAM250

• 250 substitutions in 100 residues, only 1/5
  residue remain unchanged

37
BLOSUM Matrices

• BLOcks amino acid SUbstitution Matrices
• Henikoff and Henikoff, PNAS. 1992, 8910915-9
• Check gt500 protein families in the Prosite
  database (Bairoch 1991)
• Find 2000 blocks of aligned segments
• BLOCKS database
• Characterize ungapped patterns 3-60 aa long
• Check aligned columns for observed substitutions

38
BLOSUM Matrix Entry

• How frequently do aa appear
• How often do we expect to see i, j together
• How often do we actually see them together in all
  the alignments
• BLOSUM entry

39
BLOSUM62 Matrix
40
BLOSUM Matrices

• Blocks are grouped before looking at aa
  substitutions
• BLOSUMN if sequences gt N identical, their
  contributions are weighted to sum to 1
• Most widely used BLOSUM62 and PAM250

41
More About Dynamic Programming

• Example 1 Suppose I have x0 amount of savings at
  retirement, and also receive st amount of social
  security payment every year. Annual interest rate
  is qt , what is an optimal spending plan if I
  want to leave zero dollars at the end (say, year
  5)?

Maximizing total spending?
Year 0 Year 1 Year 2 Year 3 Year 4
x0 x1 x2 x3 x4
s0 s1 s2 s3 s4
u0 u1 u2 u3 u4

42
Example 2 Secretary Problem

• We get to observe the qualities of m
  secretaries X1,, Xm sequentially according to a
  random order. Our goal is to maximize the
  probability of finding the best candidate with
  no looking back!
• Heuristic We start our reasoning backwards.
  Suppose we have seen X1,, Xj, should we stop or
  go on?

43
Lets start reasoning ...

• What if we wait till the last person?
• What if we wait till having two people left?
• Strategy if m-1st person is better than previous
  ones, take her otherwise wait till the last one.
• Get a recursion? If we let go j-1 people, and
  take the best-person-so-far starting from jth
  person ...

Pj maximized at
44
Final answer

• We should reject the first 37 of the candidates
  and start to look recruit the first person who
  is the best among all that have been interviewed.

• The chance of getting the best one is 37 !

45
Summary

• Dynamic programming finds optimal alignment
  between two sequences
• Keep subproblem solution for later use
• Needleman Wunsch, global
• Smith Waterman, local
• Scoring sensitive to gap penalty and substitution
  matrices used
• Substitution matrices capture aa similarity
• PAM and BLOSUM matrices

46
Question for Thoughts

• Given a string of integers (both positive and
  negative)
• E.g. 3, -1, -5, 2, 4, -3, 6, -4, 2, 5, -8, 3, 1,
  -7, 6
• Can you read each number only ONCE, and tell from
  which number to which number you will get the
  largest sum?
• 3, -1, -5, 2, 4, -3, 6, -4, 2, 5, -8, 3, 1, -7,
  6, -2
• Largest sum 12
• Hint dynamic programming

47
Acknowledgement

• Russ Altman
• Theodor Hanekamp
• Eric Rouchka
