Chapter 14 (part I) WSN: Coverage and Energy Conservation

1
Chapter 14 (part I)WSN Coverage and Energy
Conservation

• ?????? ?????
• ?????
• Prof. Yu-Chee Tseng

2
Research Issues in Sensor Networks

• Hardware (2000)
• CPU, memory, sensors, etc.
• Protocols (2002)
• MAC layers
• Routing and transport protocols
• Applications (2004)
• Localization and positioning applications
• Management (2008)
• Coverage and connectivity problems
• Power management
• etc.

3
Coverage Problems

• In general
• Determine how well the sensing field is monitored
  or tracked by sensors.
• Possible Approaches
• Geometric Problems
• Level of Exposure
• Area Coverage
• Coverage
• Coverage and Connectivity
• Coverage-Preserving and Energy-Conserving Problem

4
Review Art Gallery Problem

• Place the minimum number of cameras such that
  every point in the art gallery is monitored by at
  least one camera.

5
Review Circle Covering Problem

• Given a fixed number of identical circles, the
  goal is to minimize the radius of circles.

6
Level of Exposure

• Breach and support paths
• paths on which the distance from any point to the
  closest sensor is maximized and minimized
• Voronoi diagram and Delaunay triangulation
• Exposure paths
• Consider the duration that an object is monitored
  by sensors

7
Coverage and Connectivity

• Extending the coverage such that connectivity is
  maintained.
• A region is k-covered, then the sensor network is
  k-connected if RC ? 2RS

8
Coverage-Preserving and Energy-Conserving
Protocols

• Sensors' on-duty time should be properly
  scheduled to conserve energy.
• This can be done if some nodes share the common
  sensing region.
• Question Which sensors below can be turned off?

9
The Coverage Problems in 2D Spaces

• (ACM MONET, 2005)

10
Coverage Problems

• In general
• To determine how well the sensing field is
  monitored or tracked by sensors
• Sensors may be randomly deployed

11
Coverage Problems

• We formulate this problem as
• Determine whether every point in the service area
  of the sensor network is covered by at least a
  sensors
• This is called sensor acoverage problem.
• Why a sensors?
• Fault tolerance, quality of service
• applications localization, object tracking,
  video surveillance

12
The 2D Coverage Problem
So this area is not 1-covered!
This region is not covered by any sensor!
Is this area 1-covered?
This area is not only 1-covered, but also
2-covered!
What is the coverage level of this area?
1-covered means that every point in this area is
covered by at least 1 sensor
2-covered means that every point in this area is
covered by at least 2 sensors
Coverage level a means that this area is
a-covered
13
Sensing and Communication Ranges
1Honghai Zhang and Jennifer C. Hou, On deriving
the upper bound of a-lifetime for large sensor
networks,'' Proc. ACM Mobihoc 2004, June 2004
14
Assumptions

• Each sensor is aware of its geographic location
  and sensing radius.
• Each sensor can communicate with its neighbors.
• Difficulties
• There are an infinite number of points in any
  small field.
• A better way O(n2) regions can be divided by n
  circles
• How to determine all these regions?

15
The Proposed Solution

• We try to look at how the perimeter of each
  sensors sensing range is covered.
• How a perimeter is covered implies how an area is
  covered
• by the continuity of coverage of a region
• By collecting perimeter coverage of each sensor,
  the level of coverage of an area can be
  determined.
• a distributed solution

16
How to calculate the perimeter cover of a sensor?
Si is 2-perimeter-covered
17
Relationship between k-covered and
k-perimeter-covered

• THEOREM. Suppose that no two sensors are located
  in the same location. The whole network area A is
  k-covered iff each sensor in the network is
  k-perimeter-covered.

18
Detailed Algorithm

• Each sensor independently calculates its
  perimeter-covered.
• k mineach sensors perimeter coverage
• Time complexity nd log(d)
• n number of sensors
• d number of neighbors of a sensor

19
Simulation Results
20
A Toolkit
21
Summary

• An important multi-level coverage problem!
• We have proposed efficient polynomial-time
  solutions.
• Simulation results and a toolkit based on
  proposed solutions are presented.

22
The Coverage Problem in 3D Spaces

• (IEEE Globecom 2004)

23
The 3D Coverage Problem
What is the coverage level of this 3D area?
24
The 3D Coverage Problem

• Problem Definition
• Given a set of sensors in a 3D sensing field, is
  every point in this field covered by at least a
  sensors?
• Assumptions
• Each sensor is aware of its own location as well
  as its neighbors locations.
• The sensing range of each sensor is modeled by a
  3D ball.
• The sensing ranges of sensors can be non-uniform.

25
Overview of Our Solution

• The Proposed Solution
• We reduce the geometric problem
• from a 3D space to one in a 2D space,
• and then from a 2D space to one in a 1D space.

26
Reduction Technique (I)

• 3D gt 2D
• To determine whether the whole sensing field is
  sufficiently covered, we look at the spheres of
  all sensors
• Theorem 1 If each sphere is a-sphere-covered,
  then the sensing field is a-covered.
• Sensor si is a-sphere-covered if all points on
  its sphere are sphere-covered by at least a
  sensors, i.e., on or within the spheres of at
  least a sensors.

27
Reduction Technique (II)

• 2D gt 1D
• To determine whether each sensors sphere is
  sufficiently covered, we look at how each
  spherical cap and how each circle of the
  intersection of two spheres is covered.
• (refer to the next page)
• Corollary 1 Consider any sensor si. If each
  point on Si is a-cap-covered, then sphere Si is
  a-sphere-covered.
• A point p is a-cap-covered if it is on at least a
  caps.

28
Cap and Circle
29
k-cap-covered

• p is 2-cap-covered (by Cap(i, j) and Cap(i, k)).

30
Reduction Technique (III)

• 2D gt 1D
• Theorem 2 Consider any sensor si and each of its
  neighboring sensor sj. If each circle Cir(i, j)
  is a-circle-covered, then the sphere Si is
  a-cap-covered.
• A circle is a-circle-covered if every point on
  this circle is covered by at least a caps.

31
k-circle-covered

• Cir(i, j) is 1-circle-covered (by Cap(i, k)).

Cap(i, k)
Cir(i, j)
32
Reduction Technique (IV)

• 2D gt 1D
• By stretching each circle on a 1D line, the level
  of circle coverage can be easily determined.
• This can be done by our 2-D coverage solution.

33
Reduction Example
gt
34
Reduction Example
gt
35
Calculating the Circle Coverage
36
Calculating the Circle Coverage
gt
37
Calculating the Circle Coverage
gt
38
Calculating the Circle Coverage
gt
39
The Complete Algorithm

• Each sensor si independently calculates the
  circle coverage of each of the circle on its
  sphere.
• sphere coverage of si
• min circle coverage of all circles on Si
• overall coverage min sphere coverage of all
  sensors

40
Complexity

• To calculate the sphere coverage of one sensor
  O(d2logd)
• d is the maximum number of neighbors of a sensor
• Overall O(nd2logd)
• n is the number of sensors in this field

41
Short Summary

• We define the coverage problem in a 3D space.
• Proposed solution
• 3D gt 2D gt 1D
• Network Coverage gt Sphere Coverage gt Circle
  Coverage
• Applications
• Deploying sensors
• Reducing on-duty time of sensors

42
A Decentralized Energy-Conserving,
Coverage-Preserving Protocol

• (IEEE ISCAS 2005)

43
Overview

• Goal prolong the network lifetime
• Schedule sensors on-duty time
• Put as many sensors into sleeping mode as
  possible
• Meanwhile active nodes should maintain sufficient
  coverage
• Two protocols are proposed
• basic scheme (by Yan, He, and Stankovic, in ACM
  SenSys 2003)
• energy-based scheme (by Tseng, IEEE ISCAS 2005)

44
Basic Scheme

• Two phases
• Initialization phase
• Message exchange
• Calculate each sensors working schedule in the
  next phase
• Sensing phase
• This phase is divided into multiple rounds.
• In each round, a sensor has its own working
  schedule.
• Reference time
• Each sensor will randomly generate a number in
  the range 0, cycle_length as its reference
  time.

45
Structure of Sensors Working Cycles

• Theorem
• If each intersection point between any two
  sensors boundaries is always covered, then the
  whole sensing field is always covered.
• Basic Idea
• Each sensor i and its neighbors will share the
  responsibility, in a time division manner, to
  cover each intersection point.

46
An Example (to calculate sensor as working
schedule)

Round 1
Round 2
Round n
Sensing phase
Initial phase
Initial phase
Round i
47
more details

• The above will also be done by sensors b, c, and
  d.
• This will guarantee that all intersection points
  of sensors boundaries will be covered over the
  time domain.

48
Energy-Based Scheme

• goal based on remaining energy of sensors
• Nodes with more remaining energies should work
  longer.
• Each round is logically separated into two zones
• larger zone 3T/4
• smaller zone T/4.
• Reference time selection
• If a nodes remaining energy is larger than ½ of
  its neighbors, randomly choose a reference time
  in the larger zone.
• Otherwise, choose a reference time in the smaller
  zone.
• Work schedule selection
• based on energy (refer to the next page)

49
Energy-Based Scheme (cont.)

• Frontp,i and Backp,i are also selected based on
  remaining energies.

richer
rich
poor
Round i
50
Two Enhancements

• k-Coverage-Preserving Protocol
• (omitted)
• active time optimization
• Longest Schedule First (LSF)
• Shortest Lifetime First (SLF)

51
Simulation Results
52
Simulation Results (cont.)
53
Summary

• A distributed node-scheduling protocol
• Conserve energy
• Preserve coverage
• Handle k-coverage problem
• Advantage
• Distribute energy consumption among nodes

54
Conclusions

• a survey of solutions to the coverage problems
• Both in 2D and 3D spaces
• a survey of solutions to coverage-preserving,
  energy-conserving problems
• Fairly distribute sensors energy expenditure

55
References

1. C.-F. Huang and Y.-C. Tseng, The Coverage
   Problem in a Wireless Sensor Network, ACM Mobile
   Networking and Applications (MONET), Special
   Issue on Wireless Sensor Networks.
2. C.-F. Huang and Y.-C. Tseng, A Survey of
   Solutions to the Coverage Problems in Wireless
   Sensor Networks, Journal of Internet Technology,
   Special Issue on Wireless Ad Hoc and Sensor
   Networks.
3. C.-F. Huang and Y.-C. Tseng, The Coverage
   Problem in a Wireless Sensor Network, ACM Intl
   Workshop on Wireless Sensor Networks and
   Applications (WSNA) (in conjunction with ACM
   MobiCom), 2003.
4. C.-F. Huang, Y.-C. Tseng, and Li-Chu Lo, The
   Coverage Problem in Three-Dimensional Wireless
   Sensor Networks, IEEE GLOBECOM, 2004.
5. C.-F. Huang, L.-C. Lo, Y.-C. Tseng, and W.-T.
   Chen, Decentralized Energy-Conserving and
   Coverage-Preserving Protocols for Wireless Sensor
   Networks, Intl Symp. on Circuits and Systems
   (ISCAS), 2005.
