Query Evaluation

1
Query Evaluation
2
SQL to ERA

• SQL queries are translated into extended
  relational algebra.
• Query evaluation plans are represented as trees
  of relational operators, with labels identifying
  the algorithm to use at each node.
• Thus, relational operators serve as building
  blocks for evaluating queries.
• Implementation of these operators is carefully
  optimized for good performance.
• Algorithms for individual operators can be
  combined in many ways to evaluate a query.
• The process of finding a good evaluation plan is
  called query optimization.

3
Running Example Airline

• Employees (sin INT, ename VARCHAR(20), rating
  INT, age REAL)
• Maintenances (sin INT, planeId INT, day DATE,
  descCode CHAR(10))
• Assume that
• each tuple of Maintenances is 40 bytes long
• a block can hold 100 Maintenances tuples (4K
  block)
• we have 1000 blocks of such tuples.
• Assume that
• each tuple of Employees is 50 bytes long,
• a block can hold 80 Employees tuples
• we have 500 blocks of such tuples.

4
An SQL query and its RA equiv.

• SELECT name
• FROM Employees, Maintenances
• WHERE Employees.SIN Maintenances.SIN AND
• Maintenances.planeId 100 AND
• Employees.rating gt 5
• ?ename (?planeId100 AND ratinggt5 (Employees
  Maintenances))

RA expressions can be represented by an
expression tree.
An algorithm is chosen for each node in the
expression tree.
5
Notions of clustering

• Clustered file e.g. store movie tuples together
  with the corresponding studio tuple.
• Clustered relation tuples are stored in blocks
  mostly devoted to that relation.
• Clustering index tuples (of the relation) with
  same search key are stored together.

6
Algorithms for selection

• Given a selection ?R.attr value (R), if there
  is no index on R.attr, we have to scan R.
• How many disk accesses if R is the Maintenances
  relation?
• On average 1000/2 block (pages) reads.
• If there is an index we have to typically do 3
  disk accesses
• This is, assuming a non-clustering B-Tree with 3
  levels, with the root in main memory.
• Given a selection ?R.attr lt value (R)
• Even when there is an non-clustering index we
  might better scan the relation ignoring the
  index. Why?
• Of course, if we have a clustering index, we use
  it.

7
Algorithms for projections

• Given a projection we have to scan the relation
  and drop certain fields of each tuple.
• Thats easy.
• However, if we need to do a set projection (as
  opposed to bag projection) specified with the
  DISTINCT keyword in SQL, we need to remove
  duplicates.
• This is more expensive.
• Usually done by sorting, in order to co-locate
  the duplicates and then remove them.
• Can be combined with the final pass of sorting.

8
Algorithms for joins

• Joins are expensive operations and very common.
• They have been widely studied, and systems
  typically support several algorithms to carry out
  joins.
• Consider the join of Maintenances and Employees,
  with the join condition Employees.SINMaintenance.
  SIN.
• Suppose that one of the tables, say Employees,
  has an index (B-Tree) on the sin column.
• We can scan Maintenances and, for each tuple, use
  the index to probe Employees for matching tuples.

• This approach is called index nested loops join.
• It takes about 3 I/Os on average to retrieve the
  appropriate page of the index.
• For each of the 100,000 maintenance records we
  try to access the corresponding employee with 3
  I/Os.
• So, 100,0003 300,000 I/Os on average!!

9
Algorithms for joins (sort-merge)

• Another algorithm is to sort both tables on the
  join column, and then scan them to find matches.
  This is called sort-merge join.
• Assuming that we can sort Maintenances in two
  passes, and Employees in two passes as well, let
  us consider the cost of sort-merge join.
• Because we read and write Maintenances in each
  pass, the sorting cost is 2 2 1000 4000
  I/Os.
• Similarly, we can sort Employees at a cost of 2
  2 500 2000 I/Os.
• In addition, the second phase of the sort-merge
  join algorithm requires an additional scan of
  both tables.
• Thus the total cost is 4000 2000 1000 500
  7500 I/Os. (Much better!!)

10
Algorithms for joins (sort-merge)

• So, we have
• nested loops join 300,000 I/Os
• sort-merge join 7,500 I/Os.
• Why bother with nested loops join?
• Index nested loops method has the nice property
  that it is incremental.
• The cost of our example join is incremental in
  the number of Maintenances tuples that we
  process.
• Therefore, if some additional selection in the
  query allows us to consider only a small subset
  of Maintenances tuples, we can avoid computing
  the join of Maintenances and Employees in its
  entirety.
• For instance, suppose that we only want the
  result of the join for the plane 101, and there
  are very few such maintenances.
• For each such Maintenances tuple, we probe
  Employees, and we are done.
• If we use sort-merge join, on the other hand, we
  have to scan the entire Maintenances table at
  least once, and the cost of this step alone is
  likely to be much higher than the entire cost of
  index nested loops join.

11
Query Optimization

• Observe that the choice of index nested loops
  join is based on considering the query as a
  whole, including the extra selection on
  Maintenances, rather than just the join operation
  by itself.
• This leads us to the next topic, query
  optimization, which is the process of finding a
  good plan for an entire query.
• Query optimization is one of the most important
  tasks of a relational DBMS.
• One of the strengths of relational query
  languages is the wide variety of ways in which a
  user can express and the system can evaluate a
  query.
• Although this flexibility makes it easy to write
  queries, good performance relies greatly on the
  quality of the query optimizer
• The optimizer generates alternative plans and
  chooses the plan with the least estimated cost.

12
Query evaluations plans

• Recall A query evaluation plan consists of an
  extended relational algebra tree, with additional
  annotations at each node indicating the
  implementation method to use for each relational
  operator.

Sometimes it might be possible, to pipeline the
result of one operator to another operator
without creating a temporary table for the
intermediate result. This saves in cost. When
the input to a unary operator (e.g. ? or ?) is
pipelined into it, we say the operator is applied
on-the-fly.
Method to use
13
Alternative query evaluation plans

• Lets look at two (naïve plans)

?ename (on the fly)
?ename (on the fly)
?planeId100 AND ratinggt5 (on the fly)
?planeId100 AND ratinggt5 (on the fly)
(nested loops join)
(sort merge join)
Employees (file scan)
Maintenances (file scan)
Maintenances (file scan)
Employees (file scan)
Cost for this plan 300,000 I/Os for the join. ?
and ? are done in the fly no I/O cost for them.
Cost for this plan 7,500 I/Os for the join. ?
and ? are done in the fly no I/O cost for them.
We dont consider the cost for writing the final
result, since it is the same for any plan.
14
Plan Pushing selections I

• Good heuristic for joins is to reduce the sizes
  of the tables to be joined as much as possible.
• One approach is to apply selections early if a
  selection operator appears after a join operator,
  it is worth examining whether the selection can
  be 'pushed' ahead of the join.
• As an example, the selection planeId100 involves
  only the attributes of Maintenances and can be
  applied to Maintenances before the join.
• Similarly, the selection ratinggt5 involves only
  attributes of Employees and can be applied to
  Employees before the join.

15
Plan Pushing selections II

• The cost of applying planeId100 to Maintenances
  is
• the cost of scanning Maintenances (1000 blocks)
  plus
• the cost of writing the result to a temporary
  table Tl.
• To estimate the size of T1, we reason as follows

• if we know that there are 100 planes, we can
  assume that maintenances are spread out uniformly
  across all planes and estimate the number of
  blocks in T1 to be 1000/100 10.
• I.e. 100010 1010 I/Os.

16
Plan Pushing selections III

• The cost of applying ratinggt 5 to Employees is
• the cost of scanning Employees (500 blocks) plus
• the cost of writing out the result to a temporary
  table, say, T2.
• If we assume that ratings are uniformly
  distributed over the range 1 to 10, we can
  approximately estimate the size of T2 as 250
  blocks.
• I.e. 500 250 750 I/Os

17
Plan Pushing selections IV

• To do a sort-merge join of T1 and T2, they are
  first completely sorted and then merged.
• Assume we do that in two passes for each one.
  Thus,
• the cost of sorting T1 is 2 2 10 40 I/Os.
• the cost of sorting T2 is 2 2 250 1000
  I/Os.
• To merge (for the join) the sorted versions of T1
  and T2, we need to scan these tables
• the cost of this step is 10250260 I/Os.
• The final projection is done on-the-fly, and by
  convention we ignore the cost of writing the
  final result.
• The total cost of the plan shown is
• (1010750)(401000260) 3060 I/Os

And this is much better compared to the other
previous plans.
18
Pushing projections

• A further refinement is to push the projection,
  just like we pushed the selections past the join.

• Observe that only the SIN attribute of T1 and the
  SIN and ename attributes of T2 are really
  required.
• When we scan Maintenances and Employees to do the
  selections, we could also eliminate unwanted
  columns.
• This on-the-fly projection reduces the sizes of
  the temporary tables T1 and T2.
• The reduction in the size of T1 is substantial
  because only an integer field is retained.
• In fact, T1 now fits within three blocks (and be
  all can be in MM), and we can perform a block
  nested loops join with a single scan of T2.
• The cost of the join step drops to under 250 page
  I/Os, and the total cost of the plan drops to
  about 2000 I/Os.

19
Plan using Indexes I

• If indexes are available, even better query
  evaluation plans may be available.
• Suppose that we have a clustering B-Tree index on
  planeId field of Maintenances and another B-Tree
  index on the SIN field of Employees.
• We can use the plan in the figure.

20
Plan using Indexes II

• Assume that there are 100 planes and assume that
  the maintenances are spread out uniformly across
  all planes.
• We can estimate the number of selected tuples to
  be 100,000/1001000.
• Since the index on planeId is clustering, these
  1000 tuples appear consecutively and therefore,
  the cost is
• 10 blocks I/Os 2 I/Os for finding the first
  block via the index.

21
Plan using Indexes III

• For each selected tuple, we retrieve matching
  Employees tuples using the index on the SIN
  field
• The join field SIN is a key for Employees.
  Therefore, at most one Employees tuple matches a
  given Maintenances tuple.
• The cost of retrieving this matching tuple is 3
  I/Os.
• So, for the 1000 Maintenances tuples we get 3000
  I/Os.
• For each tuple in the result of the join, we
  perform the selection ratinggt5 and the projection
  of ename on-the-fly.
• So, total 3012 I/Os.

22
Plan using Indexes IV

• Why didnt we push the selection ratinggt5 ahead
  of the join?
• Had we performed the selection before the join,
  the selection would involve scanning Employees
  (since no index is available on the rating field
  of Employees).
• Also, once we apply such a selection, we have no
  index on the SIN field of the result of the
  selection.
• Thus, pushing selections ahead of joins is a good
  heuristic, but not always the best strategy.
• Typically, the existence of useful indexes is the
  reason a selection is not pushed.

23
Plan using Indexes V

• What about this different plan?
• The estimated size of T would be the number of
  blocks for the 1,000 Maintenances tuples that
  have planeId100.
• I.e. T is 10 blocks.
• The cost of ?planeId100 as before is 12 I/Os to
  retrieve plus 10 additional I/Os I/Os to write T.

• Then, sort T on the SIN attribute. 2passes 40
  I/Os.
• Employees is already sorted since it has a
  clustering index on SIN.
• The merge phase of the join needs a scan of both
  T and Employees. So, 10500510 I/Os.
• Total (1210)40510 572 I/Os

?ename (on the fly)
?ratinggt5 (on the fly)
(sort-merge join)
(Use clustered index, write results to temp T)
?planeId100
Employees (clustered index on SIN)
Maintenances (clustered index on planeId)
This improved plan also demonstrates that
pipelining is not always the best strategy.
