Chapter 16: Recursion

1
C ProgrammingProgram Design IncludingData
Structures, Fifth Edition

• Chapter 16 Recursion

2
Objectives

• In this chapter, you will
• Learn about recursive definitions
• Explore the base case and the general case of a
  recursive definition
• Discover what is a recursive algorithm
• Learn about recursive functions
• Explore how to use recursive functions to
  implement recursive algorithms

3
Recursive Definitions

• Recursion solving a problem by reducing it to
  smaller versions of itself
• 0! 1 (1)
• n! n x (n-1)! if n gt 0 (2)
• The definition of factorial in equations (1) and
  (2) is called a recursive definition
• Equation (1) is called the base case
• Equation (2) is called the general case

4
Recursive Definitions (cont'd.)

• Recursive definition defining a problem in terms
  of a smaller version of itself
• Every recursive definition must have one (or
  more) base cases
• The general case must eventually reduce to a base
  case
• The base case stops the recursion

5
Recursive Definitions (cont'd.)

• Recursive algorithm finds a solution by reducing
  problem to smaller versions of itself
• Must have one (or more) base cases
• General solution must eventually reduce to a base
  case
• Recursive function a function that calls itself
• Recursive algorithms are implemented using
  recursive functions

6
Recursive Definitions (cont'd.)

• Think of a recursive function as having
  infinitely many copies of itself
• After completing a particular recursive call
• Control goes back to the calling environment,
  which is the previous call
• Execution begins from the point immediately
  following the recursive call

7
Direct and Indirect Recursion

• Directly recursive a function that calls itself
• Indirectly recursive a function that calls
  another function and eventually results in the
  original function call
• Tail recursive function function in which the
  last statement executed is the recursive call
• Example the function fact

8
Infinite Recursion

• Infinite recursion every recursive call results
  in another recursive call
• In theory, infinite recursion executes forever
• Because computer memory is finite
• Function executes until the system runs out of
  memory
• Results in an abnormal program termination

9
Infinite Recursion (cont'd.)

• To design a recursive function
• Understand problem requirements
• Determine limiting conditions
• Identify base cases and provide a direct solution
  to each base case
• Identify general cases and provide a solution to
  each general case in terms of smaller versions of
  itself

10
Problem Solving Using Recursion
11
Problem Solving Using Recursion (cont'd.)
12
Problem Solving Using Recursion (cont'd.)
13
Problem Solving Using Recursion (cont'd.)
14
Problem Solving Using Recursion (cont'd.)
15
Problem Solving Using Recursion (cont'd.)
16
Problem Solving Using Recursion (cont'd.)
17
Tower of Hanoi Analysis

• How long would it take to move 64 disks from
  needle 1 to needle 3?
• About 500 years (rate of 1 billion moves/sec)
• 264 ? 1 moves to move all 64 disks to needle 3
• If computer can generate 1 billion (109)
  moves/sec, the number of moves it can generate in
  one year is
• (3.2 107) 109 3.2 1016
• Computer time required for 264 moves
• 264 1.6 1019 1.6 1016 103 (3.2
  1016) 500

18
Recursion or Iteration?

• There are usually two ways to solve a particular
  problem
• Iteration (looping)
• Recursion
• Which method is betteriteration or recursion?
• Factors
• Nature of the problem
• Efficiency

19
Recursion or Iteration? (cont'd.)

• Whenever a function is called
• Memory space for its formal parameters and
  (automatic) local variables is allocated
• When the function terminates
• That memory space is then deallocated
• Every (recursive) call has its own set of
  parameters and (automatic) local variables

20
Recursion or Iteration? (cont'd.)

• Overhead associated with executing a (recursive)
  function in terms of
• Memory space
• Computer time
• A recursive function executes more slowly than
  its iterative counterpart

21
Recursion or Iteration? (cont'd.)

• On slower computers, especially those with
  limited memory space
• The slow execution of a recursive function would
  be visible
• Todays computers are fast and have inexpensive
  memory
• Execution of a recursion function is not
  noticeable

22
Recursion or Iteration? (cont'd.)

• Choice between the two alternatives depends on
  the nature of the problem
• Mission control systems or similar
• Efficiency is critical and dictates the solution
  method
• Sometimes iterative solution is more obvious and
  easier to understand
• If the definition of a problem is inherently
  recursive, consider a recursive solution

23
Programming Example Converting a Number from
Binary to Decimal

• Use recursion to convert a nonnegative integer in
  decimal format (base 10) into the equivalent
  binary number (base 2)
• Define some terms
• Let x be an integer
• Rightmost bit of x remainder of x after division
  by 2
• Rightmost bit of 33 is 1
• Rightmost bit of 28 is 0

24
Programming Example (cont'd.)

• To find the binary representation of 35
• Divide 35 by 2
• The quotient is 17 and the remainder is 1
• Divide 17 by 2
• The quotient is 8 and the remainder is 1
• Divide 8 by 2
• The quotient is 4 and the remainder is 0
• Continue process until quotient becomes 0
• Rightmost bit of 35 cannot be printed until we
  have printed the rightmost bit of 17

25
Programming Example (cont'd.)

• Binary representation of 35 is the binary
  representation of 17 (35/2) followed by the
  rightmost bit of 35

26
Summary

• Recursion process of solving a problem by
  reducing it to smaller versions of itself
• Recursive definition defines a problem in terms
  of smaller versions of itself
• Has one or more base cases
• Recursive algorithm solves a problem by reducing
  it to smaller versions of itself
• Has one or more base cases

27
Summary (cont'd.)

• The solution to the problem in a base case is
  obtained directly
• Recursive function function that calls itself
• Must have one or more base cases
• Recursive algorithms are implemented using
  recursive functions
• The general solution breaks the problem into
  smaller versions of itself

28
Summary (cont'd.)

• The general case must eventually be reduced to a
  base case
• The base case stops the recursion
• Directly recursive a function calls itself
• Indirectly recursive a function calls another
  function and eventually calls the original
• Tail recursive the last statement executed is
  the recursive call
