AV

1
AV VGA Detachable Cabling System

• Audio/video base cables, pigtails, and wallplates

2
Reviewing the RapidRun system

• Detachable interconnect system for A/V VGA
  cables
• Save termination hassle during installation
• Opens new opportunities for contractors
  installers
• Flexiblemany connector options, signals can be
  combined over one cable
• Modulareasy to upgrade as applications change
• Attractive pricinggood opportunity for profit

3
Who can use RapidRun?

• A/V installers
• Contractors/builders requiring pre-wired VGA or
  A/V cabling
• Data installers wishing to cross-over into A/V
• Types of end-users
• Educational institutions
• Conference rooms
• Training facilities
• Retail stores
• Houses of worship
• Residential home theaters

4
How to identify potential RapidRun customers

• Anyone who is buying the following
• Bulk VGA/UXGA cable
• Bulk 5 coax/3 coax cable
• Plenum VGA cables
• Raw AV connectors (RCA, HD15)
• A/V or VGA wallplates
• Any long-length AV cables
• RCA
• S-video
• Component video
• VGA
• These are candidates for RapidRun instead!

5
Why do we need this product?

• Less termination headaches
• High performance
• Saves installers time on large projects
• No need to field-terminate VGA and AV connections
• Time !!
• Flexibility
• Connections can change with applications

6
Without RapidRun

• A/V and VGA bulk cable pulled without connectors,
  then terminated at each drop
• Field terminations might be difficult
• Solder
• Screw-down terminals
• Field terminations may also affect performance
• Inconsistent shielding, grounding practices
• If applications change, new cable must be run

7
With RapidRun

• Installer pulls base cable
• Includes pulling cap on each end
• Protection
• Ease of use
• ¾ conduit with 90 sweep
• 15 lbs of pulling tension
• Then, terminates to pigtail or wallplate with
  easy-to-use MUVI connector
• Termination is clean, sturdy, and takes only
  seconds

8
How does it work?

• The system consists of two major components
• Base cable
• Break-Away
• Pigtail or wallplate
• Installer plans wiring strategy, decides which
  signals will be used
• Select base cable
• Choose the proper Break-Aways accordingly
• MUVI connectors make termination easy

9
What kind of signals?

• A/V
• Composite video (VCR, camera)
• S-video (DVD, PC)
• Component video (DVD, HD tuner)
• Line-level audio (Stereo)
• Digital audio (SP/DIF)
• VGA/UXGA
• HD15 connector (PC monitor)
• 5 BNC connector (RGBHV)

10
Base cables

• Available in two versions
• UXGA 3 Mini-coax, 3 Twisted-pair, 2 conductors
  PVC
• 15 pin connector
• Dual foil and braid shield
• 5 Mini-coax PVC
• 12 pin connector
• Dual foil and braid shield
• Plenum jackets also available
• Stock lengths
• 15ft
• 25ft
• 35ft
• 50ft
• 75ft
• 100ft
• 125ft
• 150ft

11
Which base cable do I use?

• Determine the type of signals that will be
  carried
• A/V applications
• Use 5 Mini-coax base cable
• VGA applications
• Use UXGA base cable
• Future-proofing
• Run one of each

Base Cable Base Cable Pigtail/Wallplate
Application 5 Coax UXGA
UXGA Video X HD15
RGBHV X X 5 BNC
Component Video Audio X X 5 RCA (RGBRW)
S-Video Audio X X 2 RCA S-Video
Composite Video Audio X X 3 RCA (YRW)
Component Video X X 3 RCA (RGB)
Component Video Digital Audio X 4 RCA (RCBBI)
Component Video S-Video X 3 RCA S-Video
12
Break-aways (pigtails /wallplates)

• RapidRun connector on one end
• Different connector combos available on other end
• HD15
• RCA
• S-video (4-pin Mini DIN)
• BNC

13
The RapidRun MUVI connector

• Multiple Use Versatile Interconnect
• Solder terminations
• Brass contact terminals
• Bright nickel plated finish
• Precision CNC machined connectors
• Extremely simple to attach with unique locking
  mechanism that tightens from either end
• Loss-less connection without compromising the
  characteristic impedance or properties of the
  signal
• Pulling eye cap also protects connectors from
  dirt, dust and oil during installations.

14
What it means for you

• Flexibility
• Base cables can be used with many
  connector/signal types
• Affordability
• Your customer sees very attractive pricing vs.
  substitute solutions
• Convenience ease of use
• MUVI connectors eliminate complicated field
  termination
• Lets any data installer get started with A/V
• Unique in marketplace
• Offers your customers an efficient, one-of-a-kind
  solution
• Award-winning productCEA TechHome Mark of
  Excellence
• Repeat business
• Break-aways can be upgraded as applications
  change

15
FAQs

• What kind of connector is that?
• This is a proprietary circular DIN-style
  connector. It can be referred to as a MUVI
  Connector.
• Can I get custom lengths?
• Yes, custom-lengths will be available.
• What about plenum jackets?
• Some plenum-jacketed cables will be stocked, in
  various lengths. Custom-built lengths will also
  be available.
• How is the connector terminated?
• The conductors of the cable are soldered securely
  to the RapidRun connector. This is standard
  practice for factory-assembled cables, and
  results in a high-performance, highly stable
  connection.

16
More FAQs

• How large of a conduit can I put it in?
• 3/4 conduit, with a factory 90 sweep.
• How long of a cable can I have?
• Many factors can affect maximum cable length.
  For most applications, picture quality is
  maintained up to 150 feet. Analog A/V
  (composite, S-video, YPbPr), applications can
  sometime exceed this, going to 200 feet and
  beyond. The longest base cables that will be
  stocked are 150-footers.
• Does it support Hi-Def?
• Supports UXGA YPbPr analog video, both of which
  support HD resolutions (including 720p and1080i).
  Length considerations should always be taken
  into account.

17
THE LAST OF THE FAQs

• How strong is the pulling eye?
• The factory has tested the strength of the ring
  on the pulling eye, and pulling force should not
  exceed 15 lbs. If stronger pulling force is
  needed, a pulling aid that attaches to the wire
  itself can be used.
• Who needs the RapidRun system?
• Hotels, banquet centers, exhibition halls,
  convention centers, training rooms, presentation
  areas, houses of worship, conference rooms,
  classrooms, high-end home theater installations,
  auditoriums, transportation terminals, retail
  stores, etc.
• ANYWHERE WHERE A/V OR VGA SIGNALS NEED TO GO A
  LONG DISTANCE, THROUGH A SMALL SPACE, AND WITH A
  MINIMAL AMOUNT OF TERMINATION WORK!!!

18
Thank you!
