UNIT FIVE: Electricity and Magnetism

1
(No Transcript)
2
UNIT FIVE Electricity and Magnetism

• Chapter 16 Electricity
• Chapter 17 Magnetism

3
(No Transcript)
4
Chapter Sixteen Electricity

• 16.1 Charge and Electric Circuits
• 16.2 Current and Voltage
• 16.3 Resistance and Ohms Law
• 16.4 Types of Circuits

5
Chapter 16.4 Learning Goals

• Build and analyze series and parallel circuits.
• Apply Ohms law to calculate the current in a
  circuit.
• Compare and contrast series and parallel circuits.

6
Investigation 16C
Electric Circuits

• Key Question
• What are the different types of circuits?

7
16.4 Types of circuits

• In a series circuit, current can only take one
  path, so the current is the same at all points in
  the circuit.

8
16.4 Series circuits

• Inexpensive strings of holiday lights are wired
  with the bulbs in series.
• If you remove one of the bulbs from its socket,
  the whole string of mini bulbs will go out.

9
16.4 Current and resistance in series circuits

• Everything has some resistance, even wires.

10
16.4 Current and resistance in series circuits

• If you know the resistance of each device, you
  can find the total resistance of the circuit by
  adding up the resistance of each device.

11
16.4 Current and resistance in series circuits

• Think of adding resistances like adding pinches
  to a hose.
• Each pinch adds some resistance.

12
(No Transcript)
13
Solving Problems

• A series circuit contains a 12-V battery and
  three bulbs with resistances of1O, 2 O, and 3 O.
• What is the current in the circuit?

14
Solving Problems

• Looking for
• current (amps)
• Given
• Voltage 12V resistances 1O, 2 O, 3 O.
• Relationships
• Rtot R1R2R3
• Ohms Law I V R
• Solution
• Rtot 6 O
• I 12 V 6 O 2 amps

15
16.4 Voltage drop

• As each device in series uses power, the power
  carried by the current is reduced.
• As a result, the voltage is lower after each
  device that uses power.
• This is known as the voltage drop.

16
16.4 Voltage drop

• The law of conservation of energy also applies to
  a circuit.
• In this circuit, each bulb has a resistance of 1
  ohm, so each has a voltage drop of 1 volt when 1
  amp flows through the circuit.

17
(No Transcript)
18
16.4 Voltage drop and Ohms law

• The voltage drop across a resistance is
  determined by Ohms law in the form V IR.
• The voltage drop (V) equals the current (I)
  multiplied by the resistance (R) of the device.

19
16.4 Kirchhoffs Voltage Law

• Kirchhoffs voltage law states that the total of
  all the voltage drops must add up to the
  batterys voltage.

20
Solving Problems

• The circuit shown contains a 9-volt battery, a
  1-ohm bulb, and a 2-ohm bulb.
• Calculate the circuits total resistance and
  current.
• Then find each bulbs voltage drop.

21
Solving Problems

• Looking for
• total resistance voltage drop each bulb
• Given
• Voltage 9V resistances 1O, 2 O.
• Relationships
• Rtot R1R2R3
• Ohms Law I V R
• Solution- part 1
• Rtot 3 O
• I 9 V 3 O 3 amps

22
Solving Problems

• Solution- part 2
• Use resistance to find current
• I 9 V 3 O 3 amps
• Solution- part 3
• Rearrange Ohms law to solve for voltage
• Use current to find each voltage drop
• V I x R
• V1 (3 A) x (1 O) 3 volts
• V2 (3 A) x (2 O) 6 volts (3 6 ) 9 V

23
16.4 Parallel Circuits

• In parallel circuits the current can take more
  than one path.

24
16.4 Kirchhoffs Current Law

• All of the current entering a branch point must
  exit again.
• This is known as Kirchhoffs current law.

25
(No Transcript)
26
16.4 Voltage and parallel circuits

• If the voltage is the same along a wire, then the
  same voltage appears across each branch of a
  parallel circuit.

27
16.4 Voltage and parallel circuits

• Parallel circuits have two advantages over series
  circuits.
• Each device in the circuit has a voltage drop
  equal to the full battery voltage.
• Each device in the circuit may be turned off
  independently without stopping the current in the
  other devices in the circuit.

28
16.4 Current and parallel circuits

• Each branch works independently so the total
  current in a parallel circuit is the sum of the
  currents in each branch.

29
16.4 Calculating in circuits

• In a series circuit, adding an extra resistor
  increases the total resistance of the circuit.
• In a parallel circuit, more current flows so the
  total resistance decreases.

30
Solving Problems

• All of the electrical outlets in Jonahs living
  room are on one parallel circuit.
• The circuit breaker cuts off the current if it
  exceeds 15 amps.
• Will the breaker trip if he uses a light (240 O),
  stereo (150 O), and an air conditioner (10 O)?

31
Solving Problems

• Looking for
• whether current exceeds 15 amps
• Given
• resistances 240 O 150 O 10 O
• Relationships
• Assume voltage for each branch 120 V
• Ohms Law I V R
• Kirchhoffs Current Law Itotal I1 I2 I3
• Solution
• Ilight 120 V 240 O 0.5 amps
• Istereo 120 V 150 O 0.8 amps
• Ia/c 120 V 10 O 12 amps

0.5 0.8 12.0 13.3
Breaker will not trip
32
You are Wired!

• Your nervous system uses specialized cells called
  neurons to transfer electrical signals from one
  part of your body to another. A neuron has three
  basic parts the cell body a long, thin portion
  called the axon and fingerlike projections
  called dendrites.
