Chapter 12
Database Administration
(With Modifications)
2
Once upon a time, the typical IS Organization
appeared as
CEO
Why ???

• It made perfect sense

• Information Systems were applied where they were
  most needed

• Accounting Systems

• Other standardized, routine applications

3
As information became used for more purposes and
across more functions, the IS Organization
changed
CEO

• Information Systems were applied everywhere

• Information Systems were recognized as an
  Organizational Resource

4
Basic Definitions

• Data Administrator (DA)

• A high-level function that is responsible for the
  overall management of data resources in an
  organization

• May be the CIO

• Database Administrator (DBA)

• A technical function that is responsible for the
  physical database design and such issues as
  security enforcement and database performance

• Database Steward

• A administrative function that is responsible for
  assuring that organizational applications meet
  the enterprise goals

5
Data Administration Functions

• Data Policies

• Explicit statement of goals, objectives, and
  targets

• Goal To Support Cost-Effective Use of the
  computer environment

• Objective To improve sharing of information
  across organizational units

• Target Linking of all departmental databases
  within 2 years

• Data Procedures

• Written Statement of actions to be taken for a
  certain activity

• In the event of a database failure, the DBA will

• Data Standards

• Explicit statement of conventions to be followed
  in data usage

• All table names will be prefaced by their
  physical location

• All fields containing age, weight, . Will
  contain the data type short

6
Data Administration Functions

• Planning

• Development of the Organizations IT Strategy

• Must correspond to the Organizations Business
  Strategy

• E.g., Consider the Difference between UTEP and
  Harvard

• Development of the enterprise model

• Top-Down versus Bottom-Up Viewpoint

• Development of cost/benefit model

• Targets must be measurable

• Design of the database environment

• Centralized, distributed, Decentralized?? How??

• Develop the data administration plan

• A lower-level plan for database implementation,
  maintenance and growth

7
Data Administration Functions

• Data Analysis

• Define and model data requirements

• Define and model business rules

• Define operational requirements

• Maintain corporate data dictionary

• Data Conflict Resolution

• Who owns the data?

• The department, the business subunit, the
  corporation?

• NOT a trivial question.

• Procedures MUST be established in advance

8
Data Administration Functions

• Internal Marketing

• Information Systems are political entities

• The DA must sell their arguments

• Recall the Systems Trinity

• The Manager The person in charge of the
  functional department

• The System Developer The person developing the
  system

• The User The person who will use the system

• Recall why systems fail

• Lack of Top management support

• Lack of user Acceptance

• Bad system Design

• It is the DAs job to make sure that ALL
  stakeholders are happy

9
Data Administration Functions

• Managing the Data Repository

• Used by the DA to manage the information-processin
  g environment

• Contain metadata that describes the
  organizations data and data processing resources

• Replacing Data Dictionaries (simple data-element
  documentation tools)

• Provides information about

• What users must know what

• What automated CASE tools that are used to
  specify and develop information systems

• All Applications that access and manipulate data

• DBMS that maintain the repository and update
  system privileges, passwords, and other
  information

10
Database Administration Functions

• Selection of Hardware and Software

• Difficult to keep abreast of current technology

• Difficult to predict future changes

• Emphasis on established off-the-shelf products

• Managing Data Security and Privacy

• Firewalls

• Establishment of user privileges

• Complicated by use of distributed systems

• Managing Data Integrity

• Data consistency

• Maintaining data relationships

11
Database Administration Functions

• Database Backup

• We must assume that a database will eventually
  fail

• Establishment of procedures

• How often should the data be back-up?

• What data should be backed-up more frequently?

• Who is responsible for the back-ups?

• Database Recovery

• Application of proven strategies for
  reinstallation of database after crash

12
Shared Administration Activities

• Database Design

• DA

Logical Design

• DBA

• External Model Design (Subschemas)

• Physical Design/Construction

• Design Integrity Controls

• Database Implementation

• DBA

• Establish Security Controls

• Supervise Database Loading

• Specify Test Procedures

• Develop Programming Standards

• Establish Back-up/Recovery Procedures

• Both

• Specify Access Policies

• USER TRAINING

13
Shared Administration Activities

• Operations and maintenance

• DBA

• Monitor database performance

• Tune and reorganize databases as needed

• Enforce standards and procedures

• Both

Support Users

• Growth and Change

• Both

• Implement Change-Control Procedures

• Plan for growth and change

• Evaluate new technologies

14
Data Warehouse Administration

• New function due to increased use of data
  warehousing

• (Massively) Integrated decision support databases
  from various sources

• Emphasis on integration and coordination of data
  and metadata from multiple databases

• Specific Functions

1. Support decision-oriented applications
2. Manage data warehouse (exponential) growth
2. Establish service level agreements
15
Data Dictionaries and Repositories

• Data Dictionary

• Documents data and metadata elements of a database

• Systems Catalog

• System-generated database that describes all
  database objects

• Information Repository

• Stores metadata describing data and data
  processing resources

• Information Repository Dictionary System (IRDS)

• A software tool managing and controlling access
  to the Information Repository

16
Data Dictionaries and Repositories

• Components of the repository system architecture

A schema of the repository information
Software that manages the repository objects
Where repository objects are stored
17
Database performance tuning

• DBMS Installation

• Setting installation parameters

• Memory Usage

• Setting cache-levels

• Choosing background processes

• Input/Output Contention

• Deciding who gets what and when

• How to distribute heavily accessed files

• CPU usage

• Monitoring of CPU loads

• Application Tuning

• Modification of SQL code in applications

18
Database Security

• Protection of data against accidental or
  intentional loss, destruction, or misuse

• Increased difficulty due to internet access and
  client-server technologies

19
Threats to Data Security

• Accidental Losses

• Human Error

• Software Failure

• Hardware Failure

• Theft and Fraud

• Establishment of firewalls

• Monitoring of activities

• Be careful of disgruntled employees

• Improper data access

• Loss of Privacy (Personal data)

• Loss of Confidentiality (Corporate data)

20
Threats to Data Security

• Loss of data integrity

• Data may be compromised due to database crashes

• Improper recovery can be costly

• Loss of Availability

• Through Sabotage/Data Misplacement

• Viruses/Worms

21
Managing Data Security

• Data Integrity Controls

• Default Values Entered

• Minimization of user data entry

• Domain Restrictions

• Only certain values can be entered

• Probability Checks

• Echoing of input to user for confirmation

• Self-checking routines

• E.g., Check-digits

22
Managing Data Security

• Views and Subschemas

• Views are not only useful, but can also restrict
  user access to data

• Recall our Physician/Patient Database View

CREATE VIEW drugs_given AS SELECT physname,
patient.name, illness.name, prescription.drugcod
e FROM physician, patient, treatment, illness,
prescription WHERE physician.physid
patient.physid AND patient.patid
treatment.patid AND treatment.illcode
illness.illcode AND treatment.drugcode
prescription.drugcode ORDER BY physname

• The user might be restricted from using the view

• The user might be restricted from seeing the
  views code

(And hence seeing the physical relationships)
23
Managing Data Security

• Authorization Rules

• Rules to Restrict Access

24
Managing Data Security

• Statistical Databases

1. The Conceptual Model

• Only the datasets with common attributes and
  their statistics are made available

• No data manipulation language is allowed to merge
  and intersect populations

2. Query Restriction

• Query-set Size controls (large only)

• Number of over-lapping entities among successive
  queries

• Auditing User Queries

• Clustering individual entities in mutually
  exclusive subsets

25
Managing Data Security

• Statistical Databases

3. Output Perturbation

• Queries made on actual data

• Output perturbed so that statistical
  characteristics remain but individual data is
  non-sensical

4. Data Perturbation

• The entire database is first perturbed

• All statistical relations are maintained in the
  perturbed dataset

• User allowed to make all queries on the perturbed
  data set (individual data entities show no
  relationship to the real data)

26
Managing Data Security

• Authentication Schemes

• Problem Passwords are flawed

• Users Share them

• Sometimes easy to determine

• User write them down and they get copied

• Automatic logon scripts make it unnecessary to
  enter them manually

• Unencrypted passwords travel the internet

• Goal Verify User Identity

27
Managing Data Security

• Authentication Schemes

• Potential Solutions

• Randomly Assigned Passwords

• Forced Password Changes

• Secondary Passwords

• Biometric Devices

• Thumbprint

• Hand Geometry

• Retinal Scan

• Voice Recognition

• Facial Recognition

• Future

• Body Odor

• Multi-attribute

28
Managing Data Security

• Encryption (The Second Oldest Profession)

• The earliest recorded use of cryptography is 1900
  BC in Egypt.

• The scribes who sketched the hieroglyphs telling
  the story of the life of Khnumhotep II in the
  town of Menet Khufu used a substitution cipher to
  encrypt the names and titles of individuals in
  the story.

29
Managing Data Security

• Encryption (The Second Oldest Profession)

• Substitution Ciphers

• The Original symbols are substituted for other
  symbols

• Plain Text ABCDEFGHIJKLMNOPQRSTUVWXYZ

Cipher Text XYZABCDEFGHIJKLMNOPQRSTUVW
30
Managing Data Security

• Encryption

• Public/Private Keys

• Pretty Good Privacy (PGP)

• Should the Government have the right to a Master
  Key?

• Target of 3-year investigation that he violated
  export laws

31
Database Recovery

• Mechanisms for restoring a database quickly and
  accurately after loss of damage

• Recovery Facilities/Components

1. Back-up Facilities

• Periodic back-up copies of the entire database

2. Journalizing Facilities

• To maintain audit trails of transactions and logs
  of database changes

3. Checkpoint Facilities

• When the DBMS temporarily halts all activities
  and synchronizes all files and journals

4. Recovery Manager

• A DBMS component that restores the database to a
  correct condition and restarts processing
  activities

32
Database Recovery

• Ongoing Facilities

Backup Facility Automatic periodic duplication
of entire Database

• Before and after images of records that have been
  changed

DBMS
Journalizing Facility Logging of Transactions
and Database Changes

• Logging of every transaction along with
  timestamps

33
Database Recovery

• Periodic/On Demand Facilities

Checkpoint Facility The processing is stopped
and database synchronized
Recovery Manager Upon crash, the database is
rebuilt using the Database backup, DB Change log,
and Transaction Log
34
Database Recovery

• Back-up Facilities

• How long between backup (hourly, daily, weekly)
  is a policy determined by the DA

• Frequent back-ups increase reliability BUT each
  takes some time

• Back-ups should be stored off-site

• Approaches

• Cold Backup

• Database shut down during back-up

• More secure BUT transactions delayed

• Hot Backup

• Selected portion of database is shut down during
  back-up

• Not as disruptive BUT more complicated

35
Database Recovery

• Journalizing Facilities

• Every transaction is stored to the transaction
  log as well as the database

• Transaction Log

• Record of essential data for each transaction
  processed against the database

• Database Change Log

• Before-Images of records (before transaction)

• After-Images of records (After modification)

• Needed for

• Transaction Audits

• Database Recovery

36
Database Recovery
(Recap)

• Journalizing Facilities

DBMS
Transaction
Effect of transaction added to current database
Copy of record affected by transaction stored
Copy of transaction stored
(In case of database failure)

• Before transaction

• After transaction

37
Database Recovery

• Checkpoint Facilities

• At some specified point in time (by the DA) the
  DBMS refuses all transactions

(The system is in a Quiet state)

• The database and the transaction logs are
  synchronized

DBMS
Transaction
38
Database Recovery

• Recovery Manager

• Module of DBMS that restores the database to a
  correct position when a failure occurs

Why do databases Fail?

• Aborted Transactions

• The transaction terminates abnormally due to
  human error, input of invalid data, loss of
  transmission, hardware failure, deadlock, etc.

• Incorrect Data

• Incorrect, but valid, data entered

• E.g., incorrect account number, customer payment

• System Failure

• E.g., Power loss, operator error, systems
  software failure

• The database is NOT damaged

• Database Destruction

• The database is lost, destroyed, or can not be
  read

• Often due to disk failure

39
Database Recovery

• Recovery and Restart Procedures

• Switch

• 2 mirror-image databases maintained

• All transactions stored/updated in both databases

• Upon failure, the database is switched for the
  mirror image

• Generally stored across distributed databases

• Fastest/most secure

• Expensive

• Does not protect against power failures or
  catastrophes

40
Database Recovery

• Recovery and Restart Procedures

• Restore/Run

• The previous transactions are reprocessed (up to
  the point of the failure) against the backup copy
  of the database

• The most recent copy of the database is mounted
  and the latest transactions rerun

• Simple/Cheap

• May take considerable time to reprocess

• Resequencing errors may occur

41
Database Recovery

• Recovery and Restart Procedures

• Backward Recovery (Rollback)

• Unwanted changes are undone through the use of
  Before images (in the Database Change Log)

42
Database Recovery

• Recovery and Restart Procedures

• Forward Recovery (Rollforward)

• After images (in the Database Change Log) are
  applied to the Database Backup

43
Database Recovery
What Strategy should be applied?

• That depends on the type of failure

• Aborted Transactions

• Preferred Rollback

• Alternative Rollforward (To a state just prior
  to the abort)

• Incorrect Data

• Preferred First correct data (if possible) then
  rollback and rollforward with corrected data

• Alternative Compensating transactions (debit
  then re-credit)

• System Failure (Database intact)

• Preferred Switch

• Alternatives (1) Rollback (2) Restart from
  Checkpoint

• Database Destruction

• Preferred Suicide (unless you can Switch)

• Alternatives (1) Rollforward (2) Reprocess
  transactions

44
Transaction Management

• Transaction

• A logical unit of work that must be either
  entirely completed or aborted

• No intermediate states are acceptable.

• Most real-world database transactions are formed
  by two or more database requests.

• A database request is the equivalent of a single
  SQL statement in an application program or
  transaction

• A transaction that changes the contents of the
  database must alter the database from one
  consistent database state to another.

• To ensure consistency of the database, every
  transaction must begin with the database in a
  known consistent state.

45
Transaction Management

• Transaction Properties

• Atomicity

• A transaction is a SINGLE (indivisible),
  invisible, logical unit of work

• A database request and ALL related operations
  MUST be completed

• If ALL requirements are not, the transaction is
  aborted

• Durability

• A transaction must be PERMANENT

• When a transaction is completed, it has reached
  (and must remain) in a permanent state

• Once in a permanent state, it can not be lost

• Even if the database fails, the transaction
  remains

46
Transaction Management

• Transaction Properties

• Serializability

• Each concurrent transaction is treated as thought
  they were received and executed in a serial (one
  after the other) fashion

• This is true even in a multi-user or distributed
  database

• If transactions do occur simultaneously, one is
  assigned precedence over the other

• Isolation

• Data/Information provided/updated by a
  transaction can not be used by another (later
  transaction) until the first transaction is
  complete (i.e., accepted)

47
Transaction Management

• Suppose that we wish to withdraw items from
  inventory

Bye!
IF we sell 25 Erasers
1. Find the part Number
2. Read the number onhand
3. If the number onhand is lt 25, ABORT the
transaction
4. If the number onhand is gt 25, calculate the
new number onhand quantity
500 - 25 475
5. Enter (update) the new number onhand quantity
(The DBMS will update the Transaction log and
Database Change Log)
48
Transaction Management

• The SQL Commands needed are (sort-of)
  straight-forward

SELECT onhand FROM inventory
WHERE part 02
UPDATE inventory SET onhand 475
OR Maybe
SELECT onhand FROM inventory
WHERE descrip Erasers
UPDATE inventory SET onhand onhand - 25
COMMIT
49
Transaction Management
Why did you say sort-of ??

• Notice we didnt check to see if there were 25
  Erasers available

• If there were not, we could not complete the
  transaction

How do we do that ??

• That is why we are going to learn SQL/PL

(Structured Query Language/Programming Language)

• Stay Tuned

50
Transaction Management

• Of course, even simple transactions are sometimes
  problematic

• Suppose that Dr. Mary Smith (physid 123456789)
  Transfers all her patients to Dr. Von Bulow
  (physid 374659201)

• The command

UPDATE patient SET patient.physid
374659201 WHERE patient.physid 123456789

• Will NOT be accepted unless we first enter the
  command

INSERT INTO patient VALUES (374659201, Von
Bulow, Klaus, )
51
Transaction Management

• Consider the following Statement

A credit card transaction is a ternary
relationship between a customer, a merchant, and
a bank
Given 1 merchant and 1 bank, how many customers?
Given 1 customer and 1 bank, how many Merchants?
Mandatory?
Mandatory?
Given 1 customer and 1 Merchant, how many banks?
Which Makes the relationship?

• An Associative Entity

Mandatory?
52
Transaction Management

• Assume that the following attributes apply

Too Simple?
Probably!!
53
Transaction Management

• Our actual tables might appear as

Table Transaction
Table Customer
Table Merchant
Table Bank
54
Transaction Management

• A few Activities need to be carried out

• When a transaction takes place, all of the
  attributes in the associative entity TRANSACTION
  must be recorded

• At the same time, the customers CreditLim and
  balance must be checked

• If CredLim Balance TransAmt lt 0, the purchase
  is denied (Aborted)

• If CredLim Balance TransAmt gt 0, the
  purchase is Accepted

• IFF the purchase is accepted

• Customer Balance Must be updated

• MerchantBal Must be updated

• IFF the purchase is denied

• The entire TRANSACTION is deleted

55
Transaction Management
(A Quick and Dirty Review)

• Transaction Logs

• The DBMS uses transaction logs (A Table) to keep
  track of all transactions on a database

• Intended as an organizational record of
  transactions

• Necessary if a ROLLBACK is issued

• Necessary in case of a database failure/crash

• In case of failure, the transaction log is used
  to ROLLFORWARD

• Transactions added since the previous COMMIT are
  added and COMMITted to the database

56
Transaction Management

• Transaction Logs

• Consider a Sample Transaction Log for our
  Previous Problem

Assigned by DBMS
NOTE Only Information about affected Tables
Included
57
Transaction Management

• Transaction Logs

• If the transaction is aborted, we can rollback
  with the transaction log

(Before)
(After)
58
Concurrency Control

• Problem

• In a multi-user environment, simultaneous access
  to data can result in interference and data loss

Concurrency Control

• Solution

• The process of managing simultaneous operations
  against a database so that data integrity is
  maintained and the operations do not interfere
  with each other in a multi-user environment.

59
Concurrency Control

• Issues in Concurrency Control

• Lost Updates

• Assume that there are two individuals sharing a
  checking account with a present balance of 400

• One of the individuals deposits 200

• Shortly afterward, one withdraws 150

Balance if Deposit is Lost
Time
Event
Process
Balance
110400
READ BAL
400.00
Deposit
110401
BAL BAL 200
600.00
WRITE BAL
110412
600.00
Withdrawl
111026
READBAL
600.00
400.00
BAL BAL - 150
111112
450.00
250.00
111152
WRITE BAL
450.00
250.00
Inaccurate Balance
60
Concurrency Control

• Issues in Concurrency Control

• Uncommitted Data

• If A ROLLBACK is to take place, it must occur
  BEFORE any New Transactions

• Consider our previous example With the proper
  ROLLBACK

Time
Event
Process
Balance
110400
READ BAL
400.00
Deposit
110401
BAL BAL 200
600.00
WRITE BAL
110412
600.00
110449
ROLLBACK
Withdrawl
111026
READBAL
400.00
BAL BAL - 150
250.00
111112
111152
WRITE BAL
250.00
61
Concurrency Control

• Issues in Concurrency Control

• Uncommitted Data

• Now consider what would occur if the rollback
  takes place AFTER the second withdrawl

Time
Event
Process
Balance
110400
READ BAL
400.00
Deposit
110401
BAL BAL 200
600.00
WRITE BAL
110412
600.00
Withdrawl
111026
READBAL
600.00
BAL BAL - 150
450.00
111112
111139
ROLLBACK
111152
WRITE BAL
400.00
62
Concurrency Control

• Issues in Concurrency Control

• Inconsistent retrievals

• Occur when a transaction calculates results while
  another operation is taking place

Time
Event
Process
Balance
110400
READ BAL
400.00
Deposit
110401
BAL BAL 200
600.00
Withdrawl
BAL BAL - 150
110415
250.00
110432
600.00
WRITE BAL
Withdrawl Occurs while Deposit Update taking place
63
Concurrency Control

• Transaction Scheduling

• Establishes the order in which concurrent
  transactions are processed

• Interleaves (meshes) the execution of database
  operations to ensure serializability

• Bases actions on time stamping and locking
  techniques (to be explained)

• Attempts to Optimize CPU usage by not having the
  CPU wait for a WRITE to occur after a READ

• In our previous examples, transactions would be
  written to the log, and a read/write would not be
  processed until the previous transactions write
  was processed

64
Concurrency Control

• Locking

• Most common technique to achieve serialization

• Guarantees exclusive use of data items to a
  current transaction

• The Lock denies access (update) to another
  transaction until the previous transaction is
  committed

• Locks prevent another transaction from reading
  inconsistent data

• DBMSs automatically enforce locking procedures
  through the use of a Lock Manager

65
Concurrency Control

• Locking

• Lock Granularity

• The level at which the data is locked

• Database Level

• Entire database is locked

• No transaction can access the data until the
  previous transaction has been committed

• Preferable for batch operations

• Inadequate for multi-user databases

User A requests data from Table 1
User B requests data from Table 2
(Database Locked)
(Wait ---- Database Locked)
User A Commits or aborts
(Database Unlocked)
User B Transaction initiated
66
Concurrency Control

• Locking

• Lock Granularity

• Table Level

• Only the table accessed by a transaction is locked

• Less restrictive, but still inadequate for
  multi-user databases

User B requests data from Table 1
User A requests data from Table 2
(OK ---- Table Available)
(Table 2 Locked)
User C requests data from Table 2
(Wait ---- Table Locked)
User A Commits or aborts
(Table 2 Unlocked)
User C Transaction initiated
67
Concurrency Control

• Locking

• Lock Granularity

• Page Level

• A Page is a pre-specified amount of data (4K, 8K,
  etc.) which is read into memory from the database
  (stored on the disk)

• Allows for some multi-user transactions, but
  requires detailed checking

(i.e., are the records requested by a transaction
being used by a previous transaction)
68
Concurrency Control

• Locking

• Lock Granularity

• Record Level

• ONLY the record requested is locked

• All other records are available for subsequent
  transactions

• Generally suitable for most multi-user systems

• Field Level

• Only the individual field accessed is locked

• Excellent for multi-user systems

--- BUT ----

• Requires involved programmatic checking

69
Concurrency Control

• Locking

• Lock Types

• All locks are Binary They are either locked or
  unlocked

• Regardless of level of granularity, if locked the
  data is unavailable to other transactions

• Shared Locks (S-Locks)

• Multiple users can read, but NOT update, data

• If data is S-Locked, an X-Lock (Below) can not be
  placed on it

• Exclusive Locks (X-Locks)

• Data can NOT be accessed, even for reading, by
  other users

• If X-Locked, no other lock type can be placed on
  it

70
Concurrency Control

• Deadlock

• Impasse resulting from two or more transactions
  locking the same data at the same time

• Each must wait for the other to unlock the data

• Assume 2 people share a checking account and both
  try to withdraw money from an ATM at the same
  time

71
Concurrency Control

• Deadlock Management

• Deadlock Prevention

• When accessed, all records necessary are X-Locked

• Other users must wait for the records to be
  released

• Deadlock Detection/Resolution

• The DBMS periodically scans for deadlocks

• If detected, one of the transactions is
  backed-out

• Any transactions made during the deadlock are
  aborted

• When he resources become unlocked, the process is
  restarted

(Note that this requires additional Computer
Resources)
72
Concurrency Control

• Deadlock Management

• Time Stamping

• UNIQUE, MONOTONIC (i.e., increasing) time applied
  to each transaction

• One time stamp for last read

• One time stamp for last update

(additional record fields required)

• Read time stamp can not precede update time stamp

• Transaction is aborted and rescheduled

• Transaction submitted for processing in order of
  time stamp

73
Concurrency Control

• Versioning (Optimistic Management)

• Assumes that in most cases the same record will
  NOT be accessed concurrently OR will simply be
  read

• Each time a record is requested, the DBMS creates
  a new record version

• Any changes made are made to the DB version

• The changed version is compared to the original

• If no conflicts exist, the version is accepted

• Otherwise, the changes are aborted, and the
  system is rolled-back

74
Concurrency Control

• Versioning (Optimistic Management)

• Consider our previous example

Check Against Original
Withdraw 300 New Balance 400
Check Against (new) Original
75
??? Any Questions ???
76
(No Transcript)
