Understanding LIDAR Technology

1
Understanding LIDAR Technology

• Brian Mayfield, CP, GISP, GLS
• Timothy A. Blak, GS, PLS, CFM

2
Brief Introductions

• Brian Mayfield, CP, GISP, GLS
• Dewberry Program Manager to VGIN
• Tim Blak, GS, PLS, CFM
• Appendix A of the Map Modernization Guidelines
  (http//www.fema.gov/pdf/fhm/frm_gsaa.pdf)
• NDEP (National Digital Elevation Program)
  Guidelines for Digital Elevations Data
  (http//www.ndep.gov/NDEP_Elevation_Guidelines_Ver
  1_10May2004.pdf)

3
Our Role in the Industry

• Trusted Advisor
• North Carolina
• Maryland
• Mapping Solutions Provider
• USGS GPSC
• NOAA CSC
• FEMA Regional IDIQ Study Contractor
• Not a Mapping Firm
• No Acquisition Resources (not tied to any
  specific technologies or brands)
• Industry Leading QA/QC Services
• NOAA
• Statewides

4
What is LIDAR

• LIght Detection And Ranging
• Active Sensing System
• Uses its own energy source
• Measures range distances
• Based on time between emission, reflection and
  receive time
• Direct terrain measurements, unlike
  photogrammetry which is inferred
• Day or night operation except when coupled with
  digital camera
• LiDAR provides a point cloud with X.Y,Z positions

5
What LIDAR is NOT

• All-weather
• Target must be visible within the selected EM
  spectrum
• No rain or fog
• Must be below clouds
• Able to penetrate vegetation
• LIDAR can penetrate openings in the vegetation
  cover but cannot see through closed canopies

6
Animation
7
LIDAR Components

• Three major components of a LIDAR system
• GPS
• Inertial Measurement Unit
• Laser Range Finder

8
Laser Returns

• First
• Ideal for surface models
• Last
• Ideal for generating bare-earth terrain models
• Intermediate
• Ideal for determining vegetation structure

9
Laser Returns
10
LIDAR data points - X, Y, Z
Courtesy of Terrapoint
11
Intensity Images

• Measures the amount of light returning to the
  sensor
• Developing technology infancy stage
• Can now be used for stereo-compilation to
  generate 3D breaklines (LIDARgrammetry)

12
Intensity Imagery
13
Full Point Cloud Surface Model
14
Surface Model
15
Cityscape Surface Model
16
Cityscape Ground Model
17
Full Point Cloud Surface Model
18
LIDAR Uses
Courtesy of Terrapoint
19
LIDAR Uses
20
Accuracy Standards

• FEMA Guidelines and Specification for Flood
  Hazard Mapping Partners Appendix A Guidance for
  Aerial Mapping and Surveying
• NDEP Guidelines For Digital Elevation Data

21
FEMAs Criteria for Topographic Data

• For either photogrammetry or LIDAR
• Accuracy equivalent to 2 contours or better for
  flat terrain (Accuracyz 1.2 at 95 confidence
  level)
• Vertical accuracy at 95 confidence level
  Accuracyz 1.9600 x RMSEz
• Accuracy equivalent to 4 contours or better for
  rolling to hilly terrain (Accuracyz 2.4 at 95
  conf level)

22
Accuracy Equivalencies
NMAS Contour Interval NMAS 90 Conf NSSDA 95 Conf NSSDA RMSEz
2 1 1.2 0.6 18.5 cm
4 2 2.4 1.2 37.0 cm
23
Quantitative Verification NDEP Standards as of
Jan. 2003

• Fundamental Vertical Accuracy. For open terrain
  only, compute RMSEz. Report Accuracyz as
  Tested __ (meters, feet) Fundamental Vertical
  Accuracy at 95 confidence level in open terrain
  based on RMSEz x 1.9600.
• Supplemental Vertical Accuracy. For all other
  land cover categories, determine 95th percentile
  error(s). Report Accuracyz as Tested __
  (meters, feet) Supplemental Vertical Accuracy at
  95th percentile in weeds, crops, scrub, forests,
  urban areas, etc. and document outliers. AND/OR
• Consolidated Vertical Accuracy. Report Accuracyz
  as Tested __ (meters, feet) Consolidated
  Vertical Accuracy at 95th percentile in open
  terrain, weeds, crops, scrub, forests, urban
  areas, etc. and document outliers.

24
Contours

• Once the elevation model is created - contours
  are just a click awayor are they?
• The key to creating good contours is to control
  their behavior
• Controlling their behavior can be expensive using
  traditional methods
• New methodologies are being developed for LIDAR
  such as hydro-enforced contours or by
  LIDARgrammetry

25
Contours

• Two Types of Contours
• Engineering
• Topographic

26
LIDAR Contours
27
Breaklines

• Linear features that control surface behavior
• Can be 2D or 3D
• Traditionally derived from stereo photogrammetry
  or from surveys
• Can use LIDAR and Intensity to create breaklines
  or can use Hydro-enforced method

28
Pricing
29
Questions?
