Block Pavements Construction and Design

1
Block PavementsConstruction and Design
SEPT-Workshop 2011

• Prof. Dr.-Ing. C. Koch

2
Structure

• Standards and Regulations
• Design and Construction of Concrete Block
  Pavements
• Upper Roadbase
• Laying Course
• Joints
• Block Pavement

3
Standards and Regulations
4
European Standards

• Aggregates for unbound and hydraulically bound
  mixtures (DIN EN 13242)
• Unbound mixtures (DIN EN 13285)
• Concrete paving blocks and flags (DIN EN 1338,
  DIN EN 1339)
• Kerb units (DIN EN 1340, DIN EN 1343)
• Forms and dimensions of concrete kerb units (DIN
  428)
• Clay pavers (DIN EN 1344)
• Clinker (DIN 18503)
• Setts and slabs of natural stone for external
  paving (DIN EN 1341, DIN EN 1342)

5
National technical requirements based on the EN

• Construction products
• Technische Lieferbedingungen für Bauprodukte zur
  Herstellung von Pflasterdecken, Plattenbelägen
  und Einfassungen TL Pflaster
  2006FGSVtechnical conditions for the delivery
  to the place of use

6
National technical requirements based on the EN

• Construction of block and flag pavements and of
  kerbs
• ATV DIN 18318 Verkehrswegebauarbeiten,
  Pflasterdecken, Plattenbeläge, Einfassungen -
  2010 german standard as state of the art

7
National technical requirements based on the EN

• Construction of block and flag pavements and of
  kerbs in public roads
• Zusätzliche Technische Vertragsbedingungen und
  Richtlinien zur Herstellung von Pflasterdecken,
  Plattenbelägen und Einfassungen - ZTV Pflaster -
  StB 2006, FGSVadditional technical conditions
  for the construction as part of the contract

8
Technical Regulations in Germany
TL Gestein-StBnational regulations for
aggregates for the layer course and joints
DIN ENProducts e.g. blocks, flags
Zusätzliche Technische Vertragsbedingungen und
Richtlinien zur Herstellung von Pflasterdecken,
Plattenbelägen und Einfassungen ZTV Pflaster -
StB 06 Ausgabe 2006
Technische Lieferbedingungen für Bauprodukte
zur Herstellung von Pflasterdecken,
Plattenbelägen und Einfassungen TL Pflaster -
StB 06 Ausgabe 2006
TL Pflaster-StB National regulations for products
ATV DIN 18318 Construction
ZTV Pflaster-StB Construction of public roads
9
Standardisation / Dimensions of pavements

• Richtlinien für die Standardisierung des
  Oberbaus von Verkehrsflächen RStO 2001code
  of practise for road and pavement construction

10
Further Regulations

• Hydraulically bound block pavements
• FGSV-working paper Nr. 618/2Flächenbefestigunge
  n mit Pflasterdecken und Plattenbelägen in
  gebundener Ausführung 2007
• Larger formats
• Information sheet in preparation published 2012?

11
Further Regulations

• Water permeable block pavements
• Information sheet for water permeable pavements
  of traffic areas 1998
• Changings and supplements for theinformation
  sheet for water permeable pavements of traffic
  areas 2009

12
Design and Construction of Contrete Block
Pavements
13
National RegulationBlocks ? Flags / Slabs
L D 4 1
B
L
D

• Use
• Blocks Roads and footways, Lmax 320 mm
• Flags / Slabs Areas without motor vehicle
  traffic, Lmax 600 mm

14
Classes of traffic resulting from the sum of
10-t-equivalent axle loadings in 30 years
table 1
15
Roads
16
Classes of traffic (without calculation)
table 2
Type of road class
high-speed road SV / I / II
major road, road in industrial areas or estates II / III
local distributor road, pedestrian area with cargo traffic III / IV
access road, pedestrian area (without bus traffic) V / VI
17
RStO Tafel 3
Pavement structure of block pavements
blocks and joints
class
line
bedding layer
gritty roadbase
gravel subbase
gravel roadbase
gravel subbase
gritty or gravel roadbase
asphalt roadbase
gravel subbase
concrete basecourse
18
RStO Tafel 3
Blocks and joints
Bedding layer
Gritty roadbase
gravel subbase
gravel roadbase
gravel subbase
Gritty or gravel roadbase
asphalt roadbase
gravel subbase
concrete roadbase
gravel subbase
19
Example for Roads
Joints Blocks 120 mm 3 5 mm Blocks gt120
mm 5 8 mm
Stiffness modulus min-Ev2 MN/m²
20
Example for footways and cycle tracks
cm
Stiffness modulus min-Ev2 MN/m²
21
Upper Roadbase
22
Usual Unbound Roadbase

• Adequate permeability of water required
• Material segregation must be avoided
• Fines lt 0,063 mm Maximum 7 M.-
• Filter stability between roadbase and layer
  course must be proofed

23
Filter stability
equations
D15/d85 5 D50/d50 25 d, D
Particle size of aggregates mm at 15 / 50
/ 85 passing the sieve d Layer course D
Roadbase
24
Bearing capacity of the upper roadbase

• BK III and IV
• Thickness 20 cm Ev2 180 MN/m² or
  Ev2 150 MN/m² Problems with water
  permeability!

25
Asphalt roadbase

• Adequate permeability of water required
• Material PA 22 T WDA
• Void content of the compacted asphalt 13
  Vol., (research project 16 Vol.-)

Changings and supplements for the information
sheet for water permeable pavements of traffic
areas
26
(No Transcript)
27
Laying Course (3 5 cm)
28
Bedding Materials

• Shape
• Roads crushed, sharp coarse, ECS35, C90/3
• Other areas no requirements
• Grading
• Block thickness lt 120 mm 0/4, 0/5, 0/8 mm
• Block thickness 120 mm 0/4, 0/5, 0/8, 0/11 mm
• Roads Category GU
• Others Category GN
• Content of fines max. 5 M.

E.g. Mixture 0/5 GU 0/2 between 30 60 M.-
2/5 between 40 70 M.- GN no requirement
29
Exception for e .g. private AreasATV DIN 18318

• Areas, which are not reachable for motor
  vehicles
• Possible alternative grading 0/2, 1/3, 2/5 mm

Prof. Dr.-Ing. C. Koch 29
30
Mechanical Behavior

• Aggregates, dependent on mineral and use
• SZ18, LA20
• SZ22, LA25
• SZ26, LA30
• Beddings in public roads
• Material with enough mechanical strength!
• Recommendation for BK III and IV SZ22, LA25 or
  better

31
Joint filling materials (Joints 3 5 mm)

• Shape
• Roads crushed, ECS35, C90/3
• Other areas no requirements
• Grading
• Block thickness lt 120 mm (0/2), 0/4, 0/5, 0/8 mm

• Block thickness 120 mm 0/4, 0/5, 0/8, 0/11 mm
• Roads Category GU
• Others Category GN
• Content of fines min. 2 M.-, max. 9 M.
• Mechanical strength SZ18, LA20 SZ22, LA25
  SZ26, LA30

32
Filter Stability / Erosion
Requirements between bedding and joint
material D15/d15 1 D15/d85
4 D50/d50 5 D15 D50 Particle size of
bedding material mm at 15 / 50
passing the sieve d50 d85 Particle size of
granular joint filling mm at 50
passing the sieve - particle top size of the
joint filling must not be smaller than 1 sieve
size less than the particle top size of the
bedding material
equations
33
D15/d85 4
D50/d50 5
D15/d15 1
Joint filling
Bedding material
Percentage passing the sieve M.-
Particle size mm
34
Granular material intended as seeling of joints

• The upper part of the joints can be filled with
  another material to prevent material loss as a
  result of traffic and surface cleaning
• Grading 0/2 mm
• High fines amount gt 9 M.-
• crushed shape
• No further material requirements

35
Bitumen intended as compound joint seeler
Only with joints gt 8 mm (e. g. natural stone
pavement) Bitumen 3 cm, lt 1/3 of stone thickness
36
Block Applying and Finishing of the Pavement

• e. g.
• Minimum transverse slope 2,5 at each layer
• Joints have to be regular

37
Crossing joints only for areas without car
traffic!
38
No filling block smaller than half a block

39
Filling of the joints and compacting
filling the joints by sweeping and washing
40
Maximum unevenness of the surface,
4-m-straightedge

• Upper roadbase
• general 2 cm
• recommendationunder block pavements 1
  cm(to be fixed in a contract)
• Road surface 10 mm
• Gutters 5 mm

end
41
Thank you for listening!
damage in front of an entrance to a bank, in
use severel days after damage

• carsten.koch_at_fh-koeln.de
