Body Composition Assessment

1
Chapter 4
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Body Composition Assessment

2
Key Terms
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Body composition The fat and nonfat components
  of the human body important in assessing
  recommended body weight
• Percent body fat Proportional amount of fat in
  the body based on the persons total weight
  includes both essential and storage fat

• Lean body mass Body weight without body fat
• Recommended body weight Body weight at which
  there seems to be no harm to human health
  (healthy weight)

3
Key Terms
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Overweight Excess body weight against a given
  standard such as height or recommended percent
  body fat less than obese
• Obesity A chronic disease characterized by
  excessive body fat in relation to lean body mass
  usually at least 30 above recommended body weight

• Essential fat Minimal amount of body fat needed
  for normal physiological functions constitutes
  about 3 of total weight in men and 12 in women
• Storage fat Body fat in excess of essential fat
  stored in adipose tissue

4
Typical Body Composition of an Adult Man and Woman
4.1

• Essential fat constitutes about 3 of the total
  weight in men and 12 in women

5
Critical Thinking
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Jessica is a gymnast whose coach has asked her to
  decrease her total body fat to 7. Can Jessicas
  performance increase at this lower percent body
  fat?
• How would you respond to this coach?

6
Assessing Body Composition
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Research/medical facility techniques
• Dual energy X-ray absorptiometry (DEXA)
• Magnetic resonance imaging (MRI)
• Computed tomography (CT)
• Total body electrical conductivity (TOBEC)

7
Assessing Body Composition
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• More common techniques
• Hydrostatic weighing
• Air displacement
• Skinfold thickness
• Girth measurements
• Bioelectrical impedance

8
DEXA
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Procedure is simple takes only 15 minutes to
  administer
• Not readily available to most fitness participants

• Dual energy X-ray absorptiometry (DEXA)
• Frequently used by research and medical
  facilities
• Considered by many as the standard technique for
  body composition assessment
• Uses low-dose beams of X-ray energy
• Measures fat mass, fat distribution pattern, and
  bone density

9
Hydrostatic Weighing
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Underwater weighing
• Most common technique used for decades
• A persons regular weight is compared with
  underwater weight
• Fat is more buoyant than lean tissue
• Almost all other indirect techniques have been
  validated against hydrostatic weighing

10
Hydrostatic Weighing Drawbacks
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Time consuming
• Not feasible to test large number of people
• Requires measurement of residual lung volume (if
  unknown, can be estimated)
• Difficult to perform on the aquaphobic

11
Air Displacement
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Individual sits inside small chamber
• Computerized pressure sensors determine the
  amount of air displaced by the person
• Body volume is calculated by subtracting the air
  volume with the person inside the chamber from
  the volume of the empty chamber (air in the lungs
  is taken into consideration)
• Body density and percent body fat are then
  calculated
• Less cumbersome to administer
• Takes only about 5 minutes

12
Skinfold Thickness
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Based on the principle that approximately half of
  the bodys fatty tissue is directly beneath skin
• Reliable measurements of this tissue give a good
  indication of percent body fat
• Skinfold test is done with pressure calipers
• Several sites are measured and percent fat is
  estimated from the sum of the three sites using
  Tables 4.1 (women) and 4.2 or 4.3 (men)
• All measurements should be taken on the right
  side of the body

13
Anatomical Landmarks for Skinfold Measurements
4.3
Chest
Abdomen
Suprailium
Triceps
Thigh
14
Skinfold Thickness
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight
15
Skinfold Technique Percent Fat Estimates for
Women
4.1
16
Skinfold Technique Percent Fat Estimates for Men
under 40
4.2
17
Girth Measurements
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Requires a standard measuring tape
• Women Upper arm, hip, and wrist measurements
  (cm)
• Look up constants on Table 4.4 based on
  measurements and determine body density and
  percent fat according to predicting equations
• Men Waist and wrist measurements (inches)
• Use Table 4.5 for percent body fat estimate

18
Girth Measurement Conversion Constants to
Calculate Body Density for Women
4.4
19
Girth Measurement Estimated Percent Body Fat for
Men
4.5
20
Bioelectrical Impedance
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Simpler to administer, but accuracy is
  questionable
• Sensors are applied to the skin and a weak
  electrical current is run through the body to
  estimate body fat, lean body mass, and body water
• Based on the principle that fatty tissue is a
  less-efficient conductor of an electrical current
• The easier the conductance, the leaner the
  individual
• Body weight scales with special sensors on the
  surface may also be used to perform this procedure

21
Body Composition Classification according to
Percent Body Fat
4.10
22
Body Mass Index (BMI)
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Incorporates height and weight to estimate
  critical fat values at which disease risk
  increases
• BMI Body Weight (lbs) x 705 (height in
  inches)2
• Example
• Body Weight 172 lbs Height 67 inches
• BMI 172 x 705 (67)2
• BMI 27

23
Disease Risk according to BMI
4.7
24
Disease and Mortality Risk Based on BMI
4.6

• Even though the risk for premature illness and
  death is greater for those who are overweight,
  the risk also increases for individuals who are
  underweight

25
Overweight and Obesity Trends inthe United States
4.7
26
Waist Circumference
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Predicts disease risk according to the way people
  store fat (waist versus other areas)

27
Waist-to-Hip Ratio
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Predicts disease risk according to apple or
  pear shape

28
Body Composition Changes for Adults in the U.S
15.8

• Because of the typical reduction in physical
  activity, each year the average person gains 1.5
  lbs of body fat and loses a half a pound of lean
  tissue

29
Recommended Body Weight Determination
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Determine pounds of body weight that are fat
  (FW)multiply body weight (BW) by current
  percent fat (F)(FW BW x F)
• Determine lean body mass (LBM)subtract weight
  in fat from total body weight(LBM BW FW)
• Select a desired body fat percentage (DFP) based
  on health or high fitness standards given in
  Table 4.9
• Compute recommended body weight (RBW) according
  to the formulaRBW LBM (1.0 DFP)

30
Recommended Body Weight Determination Example
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• Sex female
• Age 19
• BW 160 lbs
• F 30 (.30 in decimal form)

• FW BW x FFW 160 x .30 48 lbs
• LBM BW FWLBM 160 48 112 lbs
• DFP 22 (.22 in decimal form)
• RBW LBM (1.0 DFP)RBW 112 (1.0
  .22)RBW 112 .78 143.6 lbs

31
Critical Thinking
Essential andStorage Fat
Techniques to Assess Body Composition
Determining Recommended Body Weight

• How do you feel about your current body weight
  and what influence does society have on the way
  you perceive yourself in terms of your weight?
• Do your body composition results make you feel
  any different about the way you see your current
  body weight and image?

32
Effects of a 6-Week AerobicsExercise Program on
Body Composition
4.9

• Loss of lean body mass can be offset or
  eliminated by combining a sensible diet with
  physical exercise

33
End of Chapter
