PAIN

1
PAIN PAIN CONTROL THEORIES

• Managing Pain

2
What is Pain?

• An unpleasant sensory emotional experience
  associated with actual or potential tissue
  damage, or described in terms of such damage
• The International Association for the Study
  of Pain
• Subjective sensation
• Pain Perceptions based on expectations, past
  experience, anxiety, suggestions
• Affective ones emotional factors that can
  affect pain experience
• Behavioral how one expresses or controls pain
• Cognitive ones beliefs (attitudes) about pain
• Physiological response produced by activation of
  specific types of nerve fibers
• Experienced because of nociceptors being
  sensitive to extreme mechanical, thermal,
  chemical energy.
• Composed of a variety of discomforts
• One of the bodys defense mechanism (warns the
  brain that tissues may be in jeopardy)
• Acute vs. Chronic
• The total person must be considered. It may be
  worse at night when the person is alone. They
  are more aware of the pain because of no external
  diversions.

3
Where Does Pain Come From?

• Cutaneous Pain sharp, bright, burning can have
  a fast or slow onset
• Deep Somatic Pain stems from tendons, muscles,
  joints, periosteum, b. vessels
• Visceral Pain originates from internal organs
  diffused _at_ 1st later may be localized (i.e.
  appendicitis)
• Psychogenic Pain individual feels pain but
  cause is emotional rather than physical

4
Pain Sources

• Fast vs. Slow Pain
• Fast localized carried through A-delta axons
  in skin
• Slow aching, throbbing, burning carried by C
  fibers
• Nociceptive neuron transmits pain info to spinal
  cord via unmyelinated C fibers myelinated
  A-delta fibers.
• The smaller C fibers carry impulses _at_ rate of 0.5
  to 2.0 m/sec.
• The larger A-delta fibers carry impulses _at_ rate
  of 5 to 30 m/sec.
• Acute vs. Chronic

5
What is Referred Pain?

• Occurs away from pain site
• Example Kerrs sign
• Types of referred pain
• Myofascial Pain trigger points, small
  hyperirritable areas within a m. in which n.
  impulses bombard CNS are expressed at referred
  pain
• Active hyperirritable causes obvious complaint
• Latent dormant produces no pain except loss of
  ROM
• Sclerotomic Dermatomic Pain deep pain may
  originate from sclerotomic, myotomic, or
  dermatomic n. irritation/injury
• Sclerotome area of bone/fascia that is supplied
  by a single n. root
• Myotome m. supplied by a single n. root
• Dermatome area of skin supplied by a single n.
  root

6
Terminology

• Noxious harmful, injurious
• Noxious stimuli stimuli that activate
  nociceptors (pressure, cold/heat extremes,
  chemicals)
• Nociceptor nerve receptors that transmits pain
  impulses
• Pain Threshold level of noxious stimulus
  required to alert an individual of a potential
  threat to tissue
• Pain Tolerance amount of pain a person is
  willing or able to tolerate
• Accommodation phenomenon adaptation by the
  sensory receptors to various stimuli over an
  extended period of time (e.g. superficial hot
  cold agents). Less sensitive to stimuli.

• Hyperesthesia abnormal acuteness of sensitivity
  to touch, pain, or other sensory stimuli
• Paresthesia abnormal sensation, such as
  burning, pricking, tingling
• Inhibition depression or arrest of a function
• Inhibitor an agent that restrains/retards
  physiologic, chemical, or enzymatic action
• Analgesic a neurologic or pharmacologic state
  in which painful stimuli are no longer painful

7
Questions to Ask about Pain

• Pattern onset duration
• Area location
• Intensity level
• Nature description

• P-Q-R-S-T format
• Provocation How the injury occurred what
  activities ? ? the pain
• Quality - characteristics of pain Aching
  (impingement), Burning (n. irritation), Sharp
  (acute injury), Radiating within dermatome
  (pressure on n.)?
• Referral/Radiation
• Referred site distant to damaged tissue that
  does not follow the course of a peripheral n.
• Radiating follows peripheral n. diffuse
• Severity How bad is it? Pain scale
• Timing When does it occur? p.m., a.m., before,
  during, after activity, all the time

8
Pain Assessment Scales

• Visual Numeric Analog Scales
• None Severe
• 0 10
• Locate area of pain on a pictures
• McGill pain questionnaire
• Evaluate sensory, evaluative, affective
  components of pain
• 20 subcategories, 78 words

9
McGill Pain Questionnaire

• 78 words that describe pain are grouped into 20
  sets and divided into 4 categories representing
  dimensions of the pain experience

• Completion may take 20 minutes
• Administered every 2-4 weeks

10
(No Transcript)
11
Goals In Managing Pain

• To control acute pain and protect patient from
  further injury while encouraging progressive
  exercise in a supervised environment.
• Reducing pain is an essential part of treatment

12
Goals In Managing Pain

• Encourage body to heal through exercise designed
  to progressively increase functional capacity and
  to return the patient to work, recreational and
  other activities as swiftly and safely as
  possible

13
Transmission of Pain

• Types of Nerves
• Neurotransmitters

14
Types of Nerves

• Afferent (Ascending) transmit impulses from the
  periphery to the brain
• First Order neuron
• Second Order neuron
• Third Order neuron
• Efferent (Descending) transmit impulses from
  the brain to the periphery

15
First Order Neurons

• Stimulated by sensory receptors
• End in the dorsal horn of the spinal cord
• Types
• A-alpha non-pain impulses
• A-beta non-pain impulses
• Large, myelinated
• Low threshold mechanoreceptor respond to light
  touch low-intensity mechanical info
• A-delta pain impulses due to mechanical
  pressure
• Large diameter, thinly myelinated
• Short duration, sharp, fast, bright, localized
  sensation (prickling, stinging, burning)
• C pain impulses due to chemicals or mechanical
• Small diameter, unmyelinated
• Delayed onset, diffuse nagging sensation (aching,
  throbbing)

16
Neural Transmission (First Order Neurons)

• First order or primary afferents transmit
  impulses from the sensory receptor to the dorsal
  horn of the spinal cord

17
Afferent First Order Neurons
18
Second Order Neurons

• Receive impulses from the FON in the dorsal horn
• Lamina II, Substantia Gelatinosa (SG) -
  determines the input sent to T cells from
  peripheral nerve
• T Cells (transmission cells) transmission cell
  that connects sensory n. to CNS neurons that
  organize stimulus input transmit stimulus to
  the brain
• Travel along the spinothalmic tract
• Pass through Reticular Formation
• Types
• Wide range specific
• Receive impulses from A-beta, A-delta, C
• Nociceptive specific
• Receive impulses from A-delta C
• Ends in thalamus

19
Neural Transmission (Second Order Neurons)

• Second order afferent fibers carry sensory
  messages from the dorsal horn to the brain
• Second order afferent fibers are categorized as
  wide dynamic range or nociceptive specific

20
Neural Transmission(Second Order Neurons)

• Wide dynamic range second order afferents receive
  input from A?, A? and C fibers.
• Second order afferents serve relatively large,
  overlapping receptor fields
• Nociceptive specific second order afferents
  respond exclusively to noxious stimulation
• Receive input only from A? and C fibers

21
Third Order Neurons

• Begins in thalamus
• Ends in specific brain centers (cerebral cortex)
• Perceive location, quality, intensity
• Allows to feel pain, integrate past experiences
  emotions and determine reaction to stimulus

22
Neural Transmission(Third Order Neurons)

• All of these neurons synapse with third order
  neurons which carry information to various brain
  centers where the input in integrated,
  interpreted and acted upon

23
Descending Neurons

• Descending Pain Modulation (Descending Pain
  Control Mechanism)
• Transmit impulses from the brain (corticospinal
  tract in the cortex) to the spinal cord (lamina)
• Periaquaductal Gray Area (PGA) release
  enkephalins
• Nucleus Raphe Magnus (NRM) release serotonin
• The release of these neurotransmitters inhibit
  ascending neurons
• Stimulation of the PGA in the midbrain NRM in
  the pons medulla causes analgesia.
• Endogenous opioid peptides - endorphins
  enkephalins

24
Neurotransmitters

• Chemical substances that allow nerve impulses to
  move from one neuron to another
• Found in synapses
• Substance P - thought to be responsible for the
  transmission of pain-producing impulses
• Acetylcholine responsible for transmitting
  motor nerve impulses
• Enkephalins reduces pain perception by bonding
  to pain receptor sites
• Norepinephrine causes vasoconstriction
• 2 types of chemical neurotransmitters that
  mediate pain
• Endorphins - morphine-like neurohormone thought
  to ? pain threshold by binding to receptor sites
• Serotonin - substance that causes local
  vasodilation ? permeability of capillaries
• Both are generated by noxious stimuli, which
  activate the inhibition of pain transmission
• Can be either excitatory or inhibitory

25
Sensory Receptors

• Mechanoreceptors touch, light or deep pressure
• Meissners corpuscles (light touch), Pacinian
  corpuscles (deep pressure), Merkels corpuscles
  (deep pressure)
• Thermoreceptors - heat, cold
• Krauses end bulbs (? temp touch), Ruffini
  corpuscles (in the skin) touch, tension, heat
  (in joint capsules ligaments change of
  position)
• Proprioceptors change in length or tension
• Muscle Spindles, Golgi Tendon Organs
• Nociceptors painful stimuli
• mechanosensitive
• chemosensitive

26
Sensory Receptors
27
Nerve Endings

• A nerve ending is the termination of a nerve
  fiber in a peripheral structure. (Prentice, p.
  37)
• Nerve endings may be sensory (receptor) or motor
  (effector).
• Nerve endings may be
• Respond to phasic activity - produce an impulse
  when the stimulus is ? or ?, but not during
  sustained stimulus adapt to a constant stimulus
  (Meissners corpuscles Pacinian corpuscles)
• Respond to tonic receptors produce impulses as
  long as the stimulus is present. (muscle
  spindles, free n. endings, Krauses end bulbs)
• Superficial Merkels corpuscles/disks,
  Meissners corpuscles
• Deep Pacinian corpuscles,

28
Nerve Endings

• Merkels corpuscles/disks -
• Sensitive to touch vibration
• Slow adapting
• Superficial location
• Most sensitive
• Meissners corpuscles
• Sensitive to light touch vibrations
• Rapid adapting
• Superficial location
• Pacinian corpuscles -
• Sensitive to deep pressure vibrations
• Rapid adapting
• Deep subcutaneous tissue location

• Krauses end bulbs
• Thermoreceptor
• Ruffini corpuscles/endings
• Thermoreceptor
• Sensitive to touch tension
• Slow adapting
• Free nerve endings -
• Afferent
• Detects pain, touch, temperature, mechanical
  stimuli

29
Nociceptors

• Sensitive to repeated or prolonged stimulation
• Mechanosensitive excited by stress tissue
  damage
• Chemosensitive excited by the release of
  chemical mediators
• Bradykinin, Histamine, Prostaglandins,
  Arachadonic Acid
• Primary Hyperalgesia due to injury
• Secondary Hyperalgesia due to spreading of
  chemical mediators

30
Pain Control Theories

• Gate Control Theory
• Central Biasing Theory
• Endogenous Opiates Theory

31
Gate Control Theory

• Melzack Wall, 1965
• Substantia Gelatinosa (SG) in dorsal horn of
  spinal cord acts as a gate only allows one
  type of impulses to connect with the SON
• Transmission Cell (T-cell) distal end of the
  Second or neurons (SON)
• If A-beta neurons are stimulated SG is
  activated which closes the gate to A-delta C
  neurons
• If A-delta C neurons are stimulated SG is
  blocked which closes the gate to A-beta neurons

32
Gate Control Theory

• Gate - located in the dorsal horn of the spinal
  cord
• Smaller, slower n. carry pain impulses
• Larger, faster n. fibers carry other sensations
• Impulses from faster fibers arriving _at_ gate 1st
  inhibit pain impulses (acupuncture/pressure,
  cold, heat, chem. skin irritation).

Brain
Pain
Gate (T cells/ SG)
Heat, Cold, Mechanical
33
Gate Control Theory

• Sensory information coming from A? fibers is
  transmitted to higher centers in brain
• Pain message" carried along A? C fibers is not
  transmitted to second-order neurons and never
  reaches sensory centers

34
Central Biasing Theory

• Descending neurons are activated by stimulation
  of A-delta C neurons, cognitive processes,
  anxiety, depression, previous experiences,
  expectations
• Cause release of enkephalins (PAG) and serotonin
  (NRM)
• Enkephalin interneuron in area of the SG blocks
  A-delta C neurons

35
Endogenous Opiates Theory

• Least understood of all the theories
• Stimulation of A-delta C fibers causes release
  of B-endorphins from the PAG NRM
• Or
• ACTH/B-lipotropin is released from the anterior
  pituitary in response to pain broken down into
  B-endorphins and corticosteroids
• Mechanism of action similar to enkephalins to
  block ascending nerve impulses
• Examples TENS (low freq. long pulse duration)

36
Mechanisms of Pain Control

• The theories presented are only models
• Pain control is the result of overlapping
  mechanisms
• Useful in conceptualizing the perception of pain
  and pain relief

37
Pain Management

• Therapeutic modalities can be used to
• Stimulate large-diameter afferent fibers( TENS,
  massage, analgesic balms)
• Decrease pain fiber transmission velocity (cold,
  ultrasound)
• Stimulate small-diameter afferent fibers and
  descending pain control mechanisms (accupressure,
  deep massage, TENS)

38
Pain Management

• Therapeutic modalities can be used to
• Stimulate release of endogenous opioids through
  prolonged small diameter fiber stimulation with
  TENS

39
Goals in Managing Pain

• Reduce pain!
• Control acute pain!
• Protect the patient from further injury while
  encouraging progressive exercise

40
Other ways to control pain

• Encourage central biasing motivation,
  relaxation, positive thinking
• Minimize tissue damage
• Maintain communication w/ the athlete
• If possible, allow exercise
• Medications
