Brief Overview of UML Diagrams with a Simple
Example
ECE 417/617Elements of Software Engineering
Stan Birchfield Clemson University
2
A Simple Problem
switch
1 W
5 V
light
3
1. Use Case Diagram
SimpleCircuit
FlipOn
FlipOff
ViewLight
User
Functionality from users point of view
4
2. Class Diagram
Switch
Resistor
Light
Battery 5V
Structure of system (objects, attributes,
associations, operations)
5
3. Interaction Diagram (a) Sequence Diagram
Resistor
Switch
Battery
Light
User
FlipOn()
HeatUp()
Drain()
Shine()
Messages between objects
6
3. Interaction Diagram (b) Collaboration Diagram
User
1. FlipOn()
1.1 HeatUp()
Resistor
Switch
1.2 Shine()
1.3 Drain()
Battery
Light
More compact, but harder to interpret
7
4. Statechart Diagram
flipSwitchOn
Light Off
Light On
flipSwitchOff
Transitions between states of one
object (Extension of Finite State Machine (FSM)
model)
8
4. Statechart Diagram (different objects)
flipSwitchOn
flipSwitchOn
Not Draining
Cold
Hot
Draining
flipSwitchOff
flipSwitchOff
(Resistor)
(Battery)
9
5. Activity Diagram
Flip Switch Off
Flip Switch On
Actions are states
10
Summary

• We have looked at five diagrams
• Use case diagrams Functional Model-- models
  functionality from users point of view
• Class diagrams Object Model-- models
  structure of system using objects
• Interaction diagrams Dynamic Model(sequence
  and collaboration)-- models messages passed
  between objects
• Statechart diagrams Dynamic Model-- models
  transitions between states
• Activity diagrams Dynamic Model-- models
  flow control as transitions between activities
• The actual UML spec has 12 diagrams, but these
  five will be sufficient for us.
