Title: AE 2303 AERODYNAMICS-II


1
AE 2303AERODYNAMICS-II
  • Dr.S.Elangovan

2
Introduction
  • Review of prerequisite elements
  • Perfect gas
  • Thermodynamics laws
  • Isentropic flow
  • Conservation laws
  • Speed of sound
  • Analogous concept
  • Derivation of speed of sound
  • Mach number

3
Review of prerequisite elements
  • Perfect gas
  • Equation of state
  • For calorically perfect gas

Entropy
Entropy changes?
4
Review of prerequisite elements Cont.
  • Forms of the 1st law

The second law
5
Review of prerequisite elements Cont.
For an isentropic flow
If dso
6
Review of prerequisite elements Cont.
Conservation of mass (steady flow)
Rate of mass enters control volume
Rate of mass leaves control volume

7
Review of prerequisite elements Cont.
Conservation of momentum (steady flow)
8
Review of prerequisite elements Cont.
Conservation of energy for a CV (energy balance)
  • Basic principle
  • Change of energy in a CV is related to
  • energy transfer by heat, work, and energy in
  • the mass flow.

9
Review of prerequisite elements Cont.
  • Analyzing more about Rate of Work Transfer
  • work can be separated into 2 types
  • work associated with fluid pressure as mass
    entering or leaving the CV.
  • other works such as expansion/compression,
    electrical, shaft, etc.
  • Work due to fluid pressure
  • fluid pressure acting on the CV boundary creates
    force.

10
Review of prerequisite elements Cont.
11
Review of prerequisite elements Cont.
Conservation laws
Conservation of mass (compressible
flow) Conservation of momentum (frictionless
flow) Conservation of energy (adiabatic)
12
Group Exercises 1
  1. Given that standard atmospheric conditions for
    air at 150C are a pressure of 1.013 bar and a
    density of 1.225kg, calculate the gas constant
    for air. Ans R287.13J/kgK
  2. The value of Cv for air is 717J/kgK. The value of
    R287 J/kgK. Calculate the specific enthalpy of
    air at 200C. Derive a relation connecting Cp, Cv,
    R. Use this relation to calculate Cp for air
    using the information above. Ans
    h294.2kJ/kgK,Cp1.004kJ/kgK
  3. Air is stored in a cylinder at a pressure of 10
    bar, and at a room temperature of 250C. How much
    volume will 1kg of air occupy inside the
    cylinder? The cylinder is rated for a maximum
    pressure of 15 bar. At what temperature would
    this pressure be reached? Ans V0.086m2, T1740C.

13
Speed of sound
Sounds are the small pressure disturbances in the
gas around us, analogous to the surface ripples
produced when still water is disturbed
Sound wave moving through stationary gas
Gas moving through stationary sound wave
14
Derivation of speed of sound
Speed of sound cont.
Combination of mass and momentum
Conservation of mass
For isentropic flow
Conservation of momentum
Finally
15
Mach Number
MV/a
Mlt1 Subsonic M1 Sonic Mgt1 Supersonic Mgt5 Hyperson
ic
Distance traveled speed x time 4at
Distance traveled at
Source of disturbance
Zone of silence
Region of influence
If M0
16
Mach Number cont.
Original location of source of disturbance
Source of disturbance
If M0.5
17
Mach Number cont.
Original location of source of disturbance
ut
ut
ut
ut
Direction of motion
Source of disturbance
Mach wave
If M2
18
Normal and Oblique Shock
  • A shock wave (also called shock front or simply
    "shock") is a type of propagating disturbance.
    Like an ordinary wave, it carries energy and can
    propagate through a medium (solid, liquid, gas or
    plasma) or in some cases in the absence of a
    material medium, through a field such as the
    electromagnetic field.

19
  • Shock waves are characterized by an abrupt,
    nearly discontinuous change in the
    characteristics of the medium. Across a shock
    there is always an extremely rapid rise in
    pressure, temperature and density of the flow. In
    supersonic flows, expansion is achieved through
    an expansion fan. A shock wave travels through
    most media at a higher speed than an ordinary
    wave.

20
  • Unlike solutions (another kind of nonlinear
    wave), the energy of a shock wave dissipates
    relatively quickly with distance. Also, the
    accompanying expansion wave approaches and
    eventually merges with the shock wave, partially
    canceling it out. Thus the sonic boom associated
    with the passage of a supersonic aircraft is the
    sound wave resulting from the degradation and
    merging of the shock wave and the expansion wave
    produced by the aircraft.

21
  • Thus the sonic boom associated with the passage
    of a supersonic aircraft is the sound wave
    resulting from the degradation and merging of the
    shock wave and the expansion wave produced by the
    aircraft.

22
  • When a shock wave passes through matter, the
    total energy is preserved but the energy which
    can be extracted as work decreases and entropy
    increases. This, for example, creates additional
    drag force on aircraft with shocks.

23
(No Transcript)
24
(No Transcript)
25
Oblique Shock
  • An oblique shock wave, unlike a normal shock, is
    inclined with respect to the incident upstream
    flow direction.
  • It will occur when a supersonic flow encounters a
    corner that effectively turns the flow into
    itself and compresses.

26
  • The upstream streamlines are uniformly deflected
    after the shock wave. The most common way to
    produce an oblique shock wave is to place a wedge
    into supersonic, compressible flow. Similar to a
    normal shock wave, the oblique shock wave
    consists of a very thin region across which
    nearly discontinuous changes in the thermodynamic
    properties of a gas occur. While the upstream and
    downstream flow directions are unchanged across a
    normal shock, they are different for flow across
    an oblique shock wave.

27
  • It is always possible to convert an oblique shock
    into a normal shock by a Galilean transformation.

28
(No Transcript)
29
(No Transcript)
30
EXPANSIONWAVES,RAYLEIGH AND FANNO FLOW
  • A Prandtl-Meyer expansion fan is a centered
    expansion process, which turns a supersonic flow
    around a convex corner.
  • The fan consists of an infinite number of Mach
    waves, diverging from a sharp corner. In case of
    a smooth corner, these waves can be extended
    backwards to meet at a point.

31
  • Each wave in the expansion fan turns the flow
    gradually (in small steps). It is physically
    impossible to turn the flow away from itself
    through a single "shock" wave because it will
    violate the second law of thermodynamics. Across
    the expansion fan, the flow accelerates (velocity
    increases) and the Mach number increases, while
    the static pressure, temperature and density
    decrease. Since the process is isentropic, the
    stagnation properties remain constant across the
    fan.

32
Prandtl-Meyer Function
  • ?2 - ?1 ?(M2) - ?(M1)

33
Rayleigh flow
  • Rayleigh flow refers to diabetic flow through a
    constant area duct where the effect of heat
    addition or rejection is considered.
    Compressibility effects often come into
    consideration, although the Rayleigh flow model
    certainly also applies to incompressible flow.
    For this model, the duct area remains constant
    and no mass is added within the duct. Therefore,
    unlike Fanno flow, the stagnation temperature is
    a variable.

34
Rayleigh flow
35
  • The heat addition causes a decrease in stagnation
    pressure, which is known as the Rayleigh effect
    and is critical in the design of combustion
    systems. Heat addition will cause both supersonic
    and subsonic Mach numbers to approach Mach 1,
    resulting in choked flow. Conversely, heat
    rejection decreases a subsonic Mach number and
    increases a supersonic Mach number along the
    duct. It can be shown that for calorically
    perfect flows the maximum entropy occurs at M
    1. Rayleigh flow is named after John Strutt, 3rd
    Baron Rayleigh.

36
  • Solving the differential equation leads to the
    relation shown below, where T0 is the stagnation
    temperature at the throat location of the duct
    which is required for thermally choking the flow.
  • These values are significant in the design of
    combustion systems. For example, if a turbojet
    combustion chamber has a maximum temperature of
    T0 2000 K, T0 and M at the entrance to the
    combustion chamber must be selected so thermal
    choking does not occur, which will limit the mass
    flow rate of air into the engine and decrease
    thrust.
  • For the Rayleigh flow model, the dimensionless
    change in entropy relation is shown below.

37
Fanno flow
  • Fanno flow refers to adiabatic flow through a
    constant area duct where the effect of friction
    is considered.Compressibility effects often come
    into consideration, although the Fanno flow model
    certainly also applies to incompressible flow.
    For this model, the duct area remains constant,
    the flow is assumed to be steady and
    one-dimensional, and no mass is added within the
    duct. The Fanno flow model is considered an
    irreversible process due to viscous effects. The
    viscous friction causes the flow properties to
    change along the duct. The frictional effect is
    modeled as a shear stress at the wall acting on
    the fluid with uniform properties over any cross
    section of the duct.

38
Fanno flow
39
  • For a flow with an upstream Mach number greater
    than 1.0 in a sufficiently long enough duct,
    deceleration occurs and the flow can become
    choked. On the other hand, for a flow with an
    upstream Mach number less than 1.0, acceleration
    occurs and the flow can become choked in a
    sufficiently long duct. It can be shown that for
    flow of calorically perfect gas the maximum
    entropy occurs at M  1.0. Fanno flow is named
    after Gino Girolamo Fanno.

40
DIFFERENTIAL EQUATIONS OF MOTION FOR STEADY
COMPRESSIBLE FLOWS
41
TRANSONIC FLOW OVER WING
  • In aerodynamics, the critical Mach number (Mcr)
    of an aircraft is the lowest Mach number at which
    the airflow over a small region of the wing
    reaches the speed of sound.

42
Critical Mach Number (Mcr)
43
  • For all aircraft in flight, the airflow around
    the aircraft is not exactly the same as the
    airspeed of the aircraft due to the airflow
    speeding up and slowing down to travel around the
    aircraft structure. At the Critical Mach number,
    local airflow in some areas near the airframe
    reaches the speed of sound, even though the
    aircraft itself has an airspeed lower than Mach
    1.0. This creates a weak shock wave. At speeds
    faster than the Critical Mach number

44
  • drag coefficient increases suddenly, causing
    dramatically increased drag
  • in aircraft not designed for transonic or
    supersonic speeds, changes to the airflow over
    the flight control surfaces lead to deterioration
    in control of the aircraft.

45
  • In aircraft not designed to fly at the Critical
    Mach number, shock waves in the flow over the
    wing and tail plane were sufficient to stall the
    wing, make control surfaces ineffective or lead
    to loss of control such as Mach tuck. The
    phenomena associated with problems at the
    Critical Mach number became known as
    compressibility. Compressibility led to a number
    of accidents involving high-speed military and
    experimental aircraft in the 1930s and 1940s.

46
Drag Divergence Mach Number
  • The drag divergence Mach number is the Mach
    number at which the aerodynamic drag on an
    airfoil or airframe begins to increase rapidly as
    the Mach number continues to increase. This
    increase can cause the drag coefficient to rise
    to more than ten times its low speed value.

47
  • The value of the drag divergence Mach number is
    typically greater than 0.6 therefore it is a
    transonic effect. The drag divergence Mach number
    is usually close to, and always greater than, the
    critical Mach number. Generally, the drag
    coefficient peaks at Mach 1.0 and begins to
    decrease again after the transition into the
    supersonic regime above approximately Mach 1.2.

48
  • The large increase in drag is caused by the
    formation of a shock wave on the upper surface of
    the airfoil, which can induce flow separation and
    adverse pressure gradients on the aft portion of
    the wing. This effect requires that aircraft
    intended to fly at supersonic speeds have a large
    amount of thrust.

49
  • In early development of transonic and supersonic
    aircraft, a steep dive was often used to provide
    extra acceleration through the high drag region
    around Mach 1.0. In the early days of aviation,
    this steep increase in drag gave rise to the
    popular false notion of an unbreakable sound
    barrier, because it seemed that no aircraft
    technology in the foreseeable future would have
    enough propulsive force or control authority to
    overcome it. Indeed, one of the popular
    analytical methods for calculating drag at high
    speeds, the Prandtl-Glauert rule, predicts an
    infinite amount of drag at Mach 1.0.

50
  • Two of the important technological advancements
    that arose out of attempts to conquer the sound
    barrier were the Whitcomb area rule and the
    supercritical airfoil. A supercritical airfoil is
    shaped specifically to make the drag divergence
    Mach number as high as possible, allowing
    aircraft to fly with relatively lower drag at
    high subsonic and low transonic speeds. These,
    along with other advancements including
    computational fluid dynamics, have been able to
    reduce the factor of increase in drag to two or
    three for modern aircraft designs

51
swept wing
  • A swept wing is a wing platform with a wing root
    to wingtip direction angled beyond (usually aft
    ward) the span wise axis, generally used to delay
    the drag rise caused by fluid compressibility.

52
swept wing
53
  • Unusual variants of this design feature are
    forward sweep, variable sweep wings , and
    pivoting wings. Swept wings as a means of
    reducing wave drag were first used on jet fighter
    aircraft. Today, they have become almost
    universal on all but the slowest jets (such as
    the A-10), and most faster airliners and business
    jets. The four-engine propeller-driven TU-95
    aircraft has swept wings.

54
  • The angle of sweep which characterizes a swept
    wing is conventionally measured along the 25
    chord line. If the 25 chord line varies in sweep
    angle, the leading edge is used if that varies,
    the sweep is expressed in sections (e.g., 25
    degrees from 0 to 50 span, 15 degrees from 50
    to wingtip).

55
Transonic Area Rule
  • Within the limitations of small perturbation
    theory, at a given transonic Mach number,
    aircraft with the same longitudinal distribution
    of cross-sectional area, including fuselage,
    wings and all appendages will, at zero lift, have
    the same wave drag.
  • Why Mach waves under transonic conditions are
    perpendicular to flow.
  •

56
  • Implication
  • Keep area distribution smooth, constant if
    possible. Else, strong shocks and hence drag
    result.
  • Wing-body interaction leading to shock formation

57
  • Observed cp distributions are such that maximum
    velocity is reached far aft at root and far
    forward at tip. Hence, streamlines curves in at
    the root, compress, shock propagates out.

58
Transonic Area Rule
59
Transonic Area Rule
60
  • In fluid dynamics, potential flow describes the
    velocity field as the gradient of a scalar
    function the velocity potential..

61
  • As a result, a potential flow is characterized by
    an irrotational velocity field, which is a valid
    approximation for several applications. The
    irrotationality of a potential flow is due to the
    curl of a gradient always being equal to zero

62
  • In the case of an incompressible flow the
    velocity potential satisfies Laplace's equation.
    However, potential flows also have been used to
    describe compressible flows. The potential flow
    approach occurs in the modeling of both
    stationary as well as nonstationary flows.
  • Applications of potential flow are for instance
    the outer flow field for aerofoils, water waves,
    and groundwater flow. For flows (or parts
    thereof) with strong vorticity effects, the
    potential flow approximation is not applicable.

63
Mach wave
  • In fluid dynamics, a Mach wave is a pressure wave
    traveling with the speed of sound caused by a
    slight change of pressure added to a compressible
    flow.

64
Mach stem or Mach front
  • These weak waves can combine in supersonic flow
    to become a shock wave if sufficient Mach waves
    are present at any location. Such a shock wave is
    called a Mach stem or Mach front.

65
Mach angle µ
  • Thus it is possible to have shock less
    compression or expansion in a supersonic flow by
    having the production of Mach waves sufficiently
    spaced (cf. isentropic compression in supersonic
    flows). A Mach wave is the weak limit of an
    oblique shock wave (a normal shock is the other
    limit). They propagate across the flow at the
    Mach angle µ .

66
  • where M is the Mach number.
  • Mach waves can be used in schlieren or
    shadowgraph observations to determine the local
    Mach number of the flow. Early observations by
    Ernst Mach used grooves in the wall of a duct to
    produce Mach waves in a duct, which were then
    photographed by the schlieren method, to obtain
    data about the flow in nozzles and ducts. Mach
    angles may also occasionally be visualized out of
    their condensation in air, as in the jet
    photograph below.

67
  • U.S. Navy F/A-18 breaking the sound barrier. The
    white halo is formed by condensed water droplets
    which are thought to result from an increase in
    air pressure behind the shock wave(see
    Prandtl-Glauert Singularity). The Mach angle of
    the weak attached shock made visible by the halo,
    is seen to be close to arcsine (1) 90 degrees.
Write a Comment
User Comments (0)
About PowerShow.com
