GRANULOMATOUS LUNG DISEASE

1
GRANULOMATOUS LUNG DISEASEINTERSTITIAL LUNG
DISEASE
2
GRANULOMATOUS DISEASENecrotizing vs
non-necrotizing

• Most necrotizing granulomatous disease is
  infectious
• Responsible organism usually demonstrable in
  tissue
• All specimens should be cultured
• Non-infectious granulomatous inflammation
  sarcoidosis, Wegeners granulomatosis other
  angiitides

3
TUBERCULOSIS (Robert Koch 1882)

• The mycobacteria that cause TB in man
• Mycobacterium Tuberculosis droplet infection
  inhalation of infective droplets coughed or
  sneezed by a patient with TB
• Mycobacterium Bovis drinking milk from infected
  cows intestinal and tonsillar lesions
• M. Avium M. Intracellulare (MAC complex) cause
  opportunistic infection in IC

4
TUBERCULOSIS

• Mycobacteria are Aerobic organisms
• Difficult to stain - waxy cell wall
• - scanty in tissue
• - slow growth in culture
• - PCR
• Difficult to kill
• They have no toxins or histolytic enzymes
• they inhibit phagosome-lysosome fusion and
  killing by macrophages
• they induce delayed hypersensitivity

5
TUBERCULOSIS - Epidemiology

• Developed countries considerable fall in
  incidence and mortality in 20th century
• A disease of the elderly recrudescence of
  quiescent infection acquired in youth
• Recent resurgence AIDS, urban deprivation,
  immigrant refugee populations

6
TUBERCULOSIS - Epidemiology

• 1/3 world population infected (1700 million)
• 8 million new cases every year - 95 in
  developing countries
• 3 million deaths every year - largest cause of a
  death from a single pathogen
• TB kills twice as many adults as AIDS, malaria
  and other parasitic diseases combined
• gt 80 of TB toll in developing countries is in
  the economically most productive age-group
  (15-60 years)

7
TUBERCULOSIS The impact of HIV
infection

• Alarming resurgence, poorer communities, drug
  abuse
• Multidrug resistant strains have emerged
• 6 million people world-wide have dual infection,
  majority in sub-Saharan Africa
• HIV infection particularly aggressive TB
  widespread dissem. poor host response
• HIV infection promotes infection with
  opportunistic mycobacteria

8
TUBERCULOSIS

• Primary TB
• First time infection
• Formerly found mainly in children, now
  encountered in adults
• Postprimary TB
• Adult type
• Previously sensitized fresh infection or
  reactivation of a dormant primary lesion

9
PRIMARY TB - Ghon Focus

• Inhaled tubercle bacilli ingested by alveolar
  macrophages
• Macrophages with bacilli aggregate, forming
  microscopic nodules that deform architecture
• Development of T-cell mediated immunity CD4
  (helper) CD8 (cytotoxic)
• CD4 interferon secretory changes in
  macrophages epithelioid histiocytes
• CD8 kill macrophages resulting in caseous
  necrosis
• Fusion of macrophages to form Langerhans type
  giant cells
• Mantle of B lymphocytes

10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
GHON COMPLEX (1) Parenchymal subpleural lesion
at the subpleural fissure between upper and
lower lobes (2) the enlarged hilar /
mediastinal caseous lymph nodes draining the
parenchymal focus
16
PRIMARY TB Possible outcomes

• Resolution development of a fibrous capsule -
  eventually calcified scar
• Progression- erosion into bronchus cavitation
  dissemination within bronchial tree (galloping
  consumption!)
• Pleural spread effusion, TB empyema
• Compression by caseous nodes of bronchus or
  trachea collapse, compression, stridor
• Haematogenous dissemination Miliary TB
• cervical lymph nodes (scrofula), meninges
  (tuberculous meningitis), kidneys, adrenals,
  bones (tuberculous osteomyelitis) veterbral TB
  Potts disease, fallopian tubes, epididymis

17
POSTPRIMARY TB

• Endogenous vs Exogenous
• Associations - alcoholism, diabetes, silicosis,
  immunosuppression
• Pulmonary
• Apical disease
• Caseous pneumonia in lower lobes
• Cavities ca, colonization, bronchiectasis
• Pleural pulmonary fibrosis
• Obliterative endarteritis of pulmonary
  bronchial aa but Rasmussens aneurysm
• Extrapulmonary complications amyloid

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
Tuberculosis in the elderly immunocompromised

• TB in the elderly
• Disseminated miliary TB (non-reactive TB)
• little granulomatous response, necrosis, DAD
• TB in AIDS
• conventional morphology
• granulomas poorly formed
• opportunistic MAC from environment,
• spindle cell pseudotumours

24
TB Skin tests vaccinations

• Old tuberculin now purified protein derivative
  (ppd)
• Intradermal injection Mantoux
• Multi-pronged devices Heaf test
• Positive reaction indicates that a person has
  been infected by tubercle bacillus
• Prophyllactic immunization with strain of low
  virulence Bacillus Calmette Guerin (BCG)

25
Necrotizing Granulomas other infectious causes

• Brucellosis
• Fungi Histoplasma, Coccidioides
• Cryptococcus, Blastomyces
• Dirofilaria

26
(No Transcript)
27
(No Transcript)
28
SARCOIDOSIS

• A disease of unknown cause characterized by
  non-caseating granulomas in many tissues organs
• Lungs, lymph nodes, spleen, liver, bone marrow,
  skin, eye, salivary glands and less frequently
  heart, kidneys, CNS, endocrine glands pituitary
• Occurs worldwide, more prevalent at higher
  latitudes Scandinavia, northern Europe and
  North America
• BgtW, FgtM, but rare in American Indians, Eskimos
• Communicable agent suspected but as yet
  undiscovered

29
SARCOIDOSIS

• Enhanced cellular hypersensitivity at involved
  sites but depressed elsewhere
• Increased CD4 lymphocytes in the lung
• Clinical mild non-specific chest complaints,
  cough, dyspnoea
• 1/3 Erythema nodosum
• Increased serum Ca, ACE, gammaglobulins
• Radiographic Staging
• I Hilar adenopathy alone (best)
• II Hilar adenopathy parenchymal
  infiltrates
• III Parenchymal infiltrates
  alone (worst)

30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
SARCOIDOSIS in the lung

• Non-caseating granulomas
• Tight clusters of epithelioid histiocytes and
  occassional MNGCs
• Tight rim of concentric fibroblasts , scattered
  lymphocytes (naked granulomas)
• Laminated concretions Schaumann Bodies
• Stellate inclusions Asteroid Bodies
• Distribution along lymphatics (TBBx)
• Granulomatous vasculitis
• DDx infection, berylliosis, HP, IVDA, adjacent
  to tumour / lymphoma

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
INTERSTITIAL LUNG DISEASE

• A heterogeneous group of non-neoplastic disorders
  resulting from damage to the lung parenchyma by
  varying patterns of inflammation and fibrosis
• Interstitium (space between the epithelial and
  endothelial BM) - primary site of injury
• These disorders frequently also affect the
  airspaces, airways and vessels
• Clinical Radiology Pathology correlation NB
• Aetiology / associations idiopathic, collagen
  vascular disease, drugs toxins, environmental

41
(No Transcript)
42
(No Transcript)
43
INTERSTITIAL LUNG DISEASE

• Usual interstitial pneumonia (UIP)
• aka Cryptogenic fibrosing alveolitis (CFA)
• aka Idiopathic pulmonary fibrosis (IPF)
• Vs.
• The others
• Non-specific interstitial pneumonia (NSIP)
• Organizing pneumonia (OP)
• Respiratory bronchiolitis (RB)
• Desquamative interstitial pneumonitis (DIP)
• Lymphocytic interstitial pneumonitis (LIP)

44
Usual Interstitial Pneumonia

• Patchy lung involvement worst at bases,
  subpleural paraseptal distribution
• Dense fibrosis remodelling of lung architecture
  honeycombing
• Fibroblast foci
• Gradual onset of symptoms dyspnea, non-prod
  cough
• Median survival 2.5 3.5 years

45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
