Biologically Inspired Computing: Optimisation

1
Biologically Inspired Computing Optimisation

• This is the additional material for week one of

• Biologically Inspired Computing
• Contents
• Optimisation hard problems and easy problems
  computational complexity trial and error search

2
This Material

• A formal statement about optimisation, and
  explanation of the close relationship with
  classification.
• About optimisation problems formal notions for
  hard problems and easy ones.
• Formal notions about optimisation algorithms
  exact algorithms and approximate algorithms.
• The status of EAs (and other bio-inspired
  optimisation algorithms) in this context.
• The classical computing alternatives to EAs

3
What to take from this material
A clear understanding of what an optimisation
problem is, and an appreciation of how
classification problems are also optimisation
problems What it means, technically, for an
optimisation problem to be hard or easy What it
means, technically, for an optimisation algorithm
to be exact or approximate What kinds of
algorithms, technically speaking, EAs are. An
appreciation of non-EA techniques for
optimisation A basic understanding of when an EA
might be applicable to a problem, and when it
might not.
4
Search and Optimisation

• Imagine we have 4 items as follows
• (item 1 20kg item2 75kg item 3
  60kg, item4 35kg)
• Suppose we want to find the subset of items with
  highest total weight

0000 0100 1000 1100 0001
0101 1001 1101 0010 0110
1010 1110 0011 0111 1011
1111
Here is a standard treatment of this as an
optimisation problem. The set S of all possible
solutions is indicated above, The fitness of a
solution s is the function total_weight(s) We can
solve the problem (I.e. find the fittest s) by
working out the fitness of each one in turn. But
any comments?
5

• Of course, this problem is much easier to solve
  than that. We already know that 1111 has to be
  the best solution.
• We can prove, mathematically, that any problem of
  the form find heaviest subset of a set of k
  things, is solved by the all of them subset,
  as long as each thing has positive weight.
• In general, some problems are easy in this sense,
  in that there is a proven way to construct an
  optimal solution. Sometimes it is less obvious
  than in this case though.

6
Search and Optimisation

• In general, optimisation means that you are
  trying to find the best solution you can (usually
  in a short time) to a given problem.

S
We always have a set S of all possible solutions
In realistic problems, S is too large to
search one by one. So we need to find some other
way to search through S. One way is random
search. E.g. in a 500-iteration random search, we
might randomly choose something in S and evaluate
its fitness, repeating that 500 times.

s1
s2
s3
7
The Fitness function

• Every candidate solution s in S can be given a
  score, or a fitness, by a so-called fitness
  function. We usually write f(s) to indicate the
  fitness of solution s. Obviously, we want to find
  the s in S which has the best score.
• Examples
• timetabling f could be no. of
  clashes.
• wing design f could be aerodynamic drag
• delivery schedule f will be total distance
  travelled

8
An Aside about Classification

• In a classification problem, we have a set of
  things to classify, and a number of possible
  classes.
• To classify s we use an algorithm called a
  classifier. So, classifier(s) gives us a class
  label for s.
• We can assign a fitness value to a classifier
  this can be simply the percentage of examples it
  gets right.
• In finding a good classifier, we are solving the
  following optimisation problem Search a space
  of classifiers, and find the one that gives the
  best accuracy.
• E.g. the classifier might be a neural network,
  and we may use an EA to evolve the NN with the
  best connection weights.

9
Searching through S

• When S is small (e.g. 10, 100, or only
  1,000,000 or so items), we can simply do
  so-called exhaustive search.
• Exhaustive search Generate every possible
  solution, work out its fitness, and hence
  discover which is best (or which set share the
  best fitness)
• This is also called Enumeration

10
However

• In all interesting/important cases, S is much
  much much too large for exhaustive search (ever).

• There are two kinds of too-big problem
• easy (or tractable, or in P)
• hard (or intractable, or not known to be in
  P)
• There are rigorous mathematical definitions of
  the two types.
• Important (for you) is that almost all important
  problems are technically hard.

11
About Optimisation Problems

• To solve a problem means to find an optimal
  solution. I.e. to deliver an element of s whose
  fitness is guaranteed to be the best in S.
• An Exact algorithm is one which can do this
  (i.e. solve a problem, guaranteeing to find the
  best).
• Is 500-iteration random search an Exact
  algorithm?

12
Problem complexity

• This is all about characterising how hard it is
  to solve a given problem. Statements are made in
  terms of functions of n, which is meant to be
  some indication of the size of the problem. E.g.
• Correctly sort a set of n numbers
• Can be done in around n log n steps
• Find the closest pair out of n vectors
• Can be done in O(n2) steps
• Find best design for an
  n-structural-element bridge .
• Can be done in O(10n) steps

13
Polynomial and Exponential Complexity

• Given some problem Q, with size n, imagine
  that A is the fastest algorithm known for solving
  that problem exactly. The complexity of problem Q
  is the time it takes A to solve it, as a function
  of n.
• There are two key kinds of complexity
• Polynomial the dominant term in the expression
  is polynomial in n. E.g. n34, n.log.n,
  sin(n2.2), etc
• Exponential the dominant term is exponential in
  n. E.g. 1.1n, nn2 , 2n,

14
Polynomial and Exponential Complexity

n
50
2
3
4
5
6
10
20
100
1.1n 1.21 1.33 1.46 1.61 1.77 2.59 6.73 117 13,780
n1.1 2.14 3.35 4.59 5.87 7.18 12.6 27.0 73.9 159
Problems with exponential complexity take too
long to solve at large n
15
Hard and Easy Problems

• Polynomial Complexity these are called
  tractable, and easy problems. Fast algorithms are
  known which provide the best solution. Pairwise
  alignment is one such problem. Sorting is
  another.
• Exponential Complexity these are called
  intractable, and hard problems. The fastest known
  algorithm which exactly solves it is usually not
  significantly faster than exhaustive search.

16
exponential
An exponential curve always takes over a
polynomial one.

E.g. time needed on fastest computers to search
all protein structures with 500 amino acids
trillions of times longer than the current age of
the universe.
polynomial
Increasing n
17
Example Minimum Spanning Tree Problems

• This is a case of an easy problem, but not as
  obvious as our first easy example.
• Find the cheapest tree which connects all (i.e.
  spans) the nodes of a given graph.
• Applications Comms network backbone design
  Electricity distribution networks, water
  distribution networks, etc

18

• A graph, showing the costs of building each
  pair-to-pair link

12
4
14
6
7
9
3
5
8
6
What is the minimal-cost spanning tree? (Spanning
Tree visits all nodes, has no cycles cost is
sum of costs of edges used in the tree)
19

• Heres one tree

12
14
7
3
With cost 36
20

• Heres a cheaper one

4
6
7
3
With cost 20
21

• The problem find the minimal cost spanning tree
  (aka the MST) is easy in the technical sense.

12
4
14
6
7
9
3
5
8
6
Several fast algorithms are known which solve
this in polynomial time Here is the classic one
Prims algorithm Start with empty tree (no
edges) Repeat choose cheapest edge which
feasibly extends the tree Until n 1
edges have been chosen.

22

• Prims step 1

12
4
14
6
7
9
3
5
8
6

23

• Prims step 2

12
4
14
6
7
9
3
5
8
6

24

• Prims step 3

12
4
14
6
7
9
3
5
8
6

25

• Prims step 4

12
4
14
6
7
9
3
5
8
6

26

• Prims step 4

4
6
3
5

Guaranteed to have minimal possible cost for this
graph i.e. this is the (or a) MST in this case.
27

• But change the problem slightly
• We may want the degree constrained MST (I.e.
  the MST, but where no node in the tree has a
  degree above 4)
• Or we may want the optimal communication spanning
  tree which is the MST, but constrained among
  those trees which satisfy certain bandwith
  requirements between certain pairs of nodes
• There are many constrained/different forms of the
  MST. These are essentially problems where we seek
  the cheapest tree structure, but where many, or
  even most, trees are not actually feasible
  solutions.
• Heres the thing These constrained versions are
  almost always technically hard. and Real-world
  MST-style problems are invariably of this kind.

28
Approximate Algorithms

• For hard optimisation problems (again, which
  turns
• out to be nearly all the important ones), we
  need
• Approximate algorithms .
• These
• deliver solutions in reasonable time
• try to find pretty good (near optimal)
• solutions, and often get optimal ones.
• do not (cannot) guarantee that they have
• delivered the optimal solution.

29
Typical Performance of Approximate Methods

Evolutionary Algorithms turn out to be the most
successful and generally useful approximate
algorithms around. They often take a Long time
though its worth getting used to the following
curve which tends to apply across the board.
Sophisticated method, slow, but better solutions
eventually
Quality
Simple method gets good solutions fast
Time
30
So

• Most real world problems that we need to solve
  are hard problems
• We cant expect truly optimal solutions for
  these, so we use approximate algorithms and do as
  well as we can.
• EAs (and other BIC methods we will see) are very
  successful approximate algorithms

31
Next Time

• A general introduction to Evolutionary Algorithms

32
Week 1 Quiz Questions

• On one of these slides is the question Is
  500-iteration random search an Exact algorithm?.
  The answer is generally No. Briefly explain why
  this is the case. However, there is a certain
  circumstance in which it is an exact algorithm
  can you say what this circumstance is?
• Clearly showing your working, use Prims
  algorithm to find the maximal-cost spanning tree
  for the network example in these slides.
