Project Report

1
Project Report

• CERN Collaboration Meeting
• 29 March 2004

2
Purpose of this talk

• Achievements
• Issues - not a MICE Review
• Technical Issues
• People Issues
• Money Schedule Issues
• What we need to achieve this week

3
Achievements

• Absorber Review
• Significant doing this right!
• Considerable Effort
• Collaboratively successful US/UK/JP
• Result - Highly Successful
• Must not lose sight of Safety Issues
• Gateway Review (UK)
• Survived!
• another hurdle to come Oct?
• US Funding Review (mid-May)

4
Achievements

• Tracker decision _at_ RAL
• Yet to be concluded with final reports
• Results in line with expectation
• New Collaborators from Daresbury
• Expertise Facilities (no extra cash)
• Technical Progress Since last October

5
Technical Board
7 meetings (1 abortive) Every two weeks by
phone Agenda Minutes http//www.eng-external.
rl.ac.uk/MICE-GEN/ The Technical Board oversees
all aspects of the experiment and infrastructure
design, time schedules, construction, cost,
installation and computing matters. It serves as
an advisory body for the Executive Board. It
will identify issues It should not try to solve
problems during the phone meetings but delegate
to the experts and later discuss their
conclusions It will manage the change
process ? Action List Meet every 4 weeks
after collaboration meeting Suggest this for
Integration and Executive Boards too!

• Chair
• Drumm
• Cooling channel
• Zisman
• Detectors
• Bross
• Palladino
• Simulation/Software
• Torun
• Integration
• Ivanyushenkov (secretary)
• Black
• Safety
• Baynham
• Ex officio
• Kaplan
• Blondel

6
Issues Raised

• Magnets
• encouraged MG/PF/EB discussions
• stay clear optical configuration
• Cryo-cooler option
• discussed assessed agreed to consider
• Will be a big issue at this meeting
• Cooling Channel
• No obvious big issues is Hydride Bed a risk?
• Detectors
• Shielding needs exercised change control
• Integration Issues
• Integration group EB, PD, MZ, ABr, YI
• Help separate integration from local issues
• Alignment and Survey Methods
• Discussions between physics and engineering
• Noted Issues of control, instrumentation and
  monitoring

7
Magnets Magnetic Fields

• Issues being examined
• Coils
• Currents
• Forces
• Shielding - detectors/people
• Thrown into turmoil (blame Mike Green!)
• Not time to react to this situation

8
Cooling Channel

• AFC
• Schedule
• WBS, Costs
• Interfaces
• AFC Cavity Module - RF
• Hydrogen - AFC Tracker
• cryocoolers

9
Cryocoolers

• Issues are
• Central plant Infrastructure cost 2M (loaded)
• Absolute cost!
• Devastates cash flow!
• Bulk of cooling is in the transfer lines
• Cryocoolers Part of equipment 0.75M (loaded)
• Compact, distributed, scaleable
• Lower power consumption less plant
• Cooldown is long (unless)
• supplement cooling power with LN2
• Meeting of magnet designers
• No decent encouraged
• Need to look at Absorber cooling
• VLPC cryostat benefits
• Cryocoolers appropriate for 8K
• Issue to be raised at Collaboration meeting
• Introduce concepts
• Get general approval for this as the new
  cryogenic baseline

10
Detectors

• ToF
• best placement
• Cherenkov
• US
• DS
• Calorimeter
• Tracker SiFi
• Interfaces
• Beam diffuser

11
Integration

• Consider Details
• Trivia 220 V, 50Hz
• Pumps can we standardise?
• Installation Plan
• Survey Alignment Systems
• Serious (e.g.)
• vacuum chamber pressure vessel
• Design reviews

12
Layout

• Best use of space in hall / roof
• Work in progress
• X-ray shielding access
• equipment
• people

13
RF Issues

• Clearly this is more in the air than any other
  part of MICE
• How to provide 8 MW?
• including drivers, low level RF
• HT supplies, controls
• How to configure ?
• How much will it cost ?
• and
• Who has the funds?

14
Alignment

• What does MICE need?
• Bravar et al
• Typical engineering standards?
• Lau
• Typical setup alignment?
• Yury

15
WBS

• Is available on the web
• http//www.isis.rl.ac.uk/accelerator/mice/wbs/98/s
  ummary98.mpp
• http//www.isis.rl.ac.uk/accelerator/mice/wbs/98/m
  ice_wbs.html
• http//www.isis.rl.ac.uk/accelerator/mice/wbs/98/m
  ice_app.html
• and a summary of costs
• http//www.isis.rl.ac.uk/accelerator/mice/wbs/98/m
  ice.xls
• All dated this Sunday morning

16
Milestones Phases
LBNL 2002 Aspirations

• 2004
• ISIS Shutdown no longer on critical path because
  of delays in funding
• comfortable
• Implies focus for RAL/UK activities

17
WBS
18
Unordered Events
Critical
Tentative Assessment Needs Discussion
Evaluation During this Collaboration Meeting
19
Ordered Milestones
Tentative Assessment Needs Discussion
Evaluation During this Collaboration Meeting
20
Costs
Tentative Assessment Needs Discussion
Evaluation During this Collaboration Meeting
21
WBS

• Caveats
• Schedule depends on funds!
• Includes no levelling in either staff or
  capital
• As long as we cut into ISIS this April/May the
  beam line should not in itself become a critical
  task

22
Importance of WBS

• Apart from justifying costs
• The basis of MICE planning
• The analysis is the basis of you knowing that
  your resources are sufficient
• How do we measure progress?
• Information has to come from the collaboration

23
Technical Reference Exercise

• As far as it got
•  http//www.isis.rl.ac.uk/accelerator/mice/tr/mice
  _tech_ref.html
• Control, Instrumentation, Monitoring
• Data Acquisition

24
Collaboration Meeting

• Tech Reference is not complete
• To review what is presented(clearly some late
  changes magnets)
• To identify what is missing and who is charged to
  prepare it
• To identify what is agreed (or not) as the
  baseline

25
What Else is Missing?

• Controls, Instrumentation Monitoring
• Data Acquisition
• Detailed WBS Cost review
• Money!

26
What Next?

• Important that each parallel session
• Considers its input to the Tech. Ref.
• What information is missing
• and who should generate it
• Does the information represent the consensus view
  of MICE?
• As a whole
• Does it hang together?

27
Executive board

• Review of base line by Executive Board
• Actions for next collaboration meeting
• Hopefully an easier task
• Id like to thank everyone for all the hard work
