Alternative splicing: A playground of evolution

1
Alternative splicing A playground of evolution

• Mikhail Gelfand
• Research and Training Center for Bioinformatics
• Institute for Information Transmission Problems
  RAS,
• Moscow, Russia
• October 2006

2
of alternatively spliced human and mouse genes
by year of publication
Human (genome / random sample)
All genes
Human (individual chromosomes)
Only multiexon genes
Genes with high EST coverage
Mouse (genome / random sample)
3
Plan

• Evolution of alternative exon-intron structure
• mammals human, mouse, dog
• dipteran insects Drosophila melanogaster, D.
  pseudoobscura, Anopheles gambiae
• Evolutionary rate in constitutive and alternative
  regions
• human / mouse
• D. melanogaster / D. pseudoobscura
• human-chimpanzee / human SNPs

4
Elementary alternatives
Cassette exon
Alternative donor site
Alternative acceptor site
Retained intron
5
Alternative exon-intron structure in the human,
mouse and dog genomes

• EDAS a database of human alternative splicing
  (human genome GenBank EST data from RefSeq)
• consider casette exons and alternative splicing
  sites
• functionality potentially translated vs.
  NMD-inducing elementary alternatives
• Human-mouse-dog triples of orthologous genes
• We follow the fate of human alternative sites and
  exons in the mouse and dog genomes
• Each human AS isoform is spliced-aligned to the
  mouse and dog genome. Definition of conservation
• conservation of the corresponding region
  (homologous exon is actually present in the
  considered genome)
• conservation of splicing sites (GT and AG)

6
Caveats

• we consider only possibility of AS in mouse and
  dog do not require actual existence of
  corresponding isoforms in known transcriptomes
• we do not consider situations when alternative
  human exon (or site) is constitutive in mouse or
  dog
• of course, functionality assignments (translated
  / NMD-inducing) are not very reliable

7
Translated cassette exons
constitutive
8
NMD-inducing cassette exons
9
Observations

• Predominantly included exons are highly conserved
  irrespective of function
• Predominantly skipped translated exons are more
  conserved than NMD-inducing ones
• Numerous lineage-specific losses
• more in mouse than in dog
• Still, 40 of skipped (lt1 inclusion) exons are
  conserved in at least one lineage

10
Alternative donor and acceptor sites same trends

• Higher conservation of uniformly used sites
• Internal sites are more conserved than external
  ones (as expected)

11
Alternative exon-intron structure in fruit flies
and the malarial mosquito

• Same procedure (AS data from FlyBase)
• cassette exons, splicing sites
• also mutually exclusive exons, retained introns
• Follow the fate of D. melanogaster exons in the
  D. pseudoobscura and Anopheles genomes
• Technically more difficult
• incomplete genomes
• the quality of alignment with the Anopheles
  genome is lower
• frequent intron insertion/loss (4.7 introns per
  gene in Drosophila vs. 3.5 introns per gene in
  Anopheles)

12
Conservation of coding segments
constitutive segments alternative segments
D. melanogaster D. pseudoobscura 97 75-80
D. melanogaster Anopheles gambiae 77 45
13
Conservation of D.melanogaster elementary
alternatives in D. pseudoobscura genes

• blue exact
• green divided exons
• yellow joined exon
• orange mixed
• red non-conserved
• retained introns are the least conserved (are all
  of them really functional?)
• mutually exclusive exons are as conserved as
  constitutive exons

14
Conservation of D.melanogaster elementary
alternatives in Anopheles gambiae genes

• blue exact
• green divided exons
• yellow joined exons
• orange mixed
• red non-conserved
• 30 joined, 10 divided exons (less introns in
  Aga)
• mutually exclusive exons are conserved exactly
• cassette exons are the least conserved

15
CG1517 cassette exon in Drosophila, alternative
acceptor site in Anopheles
16
CG31536 cassette exon in Drosophila, shorter
cassette exon and alternative donor site in
Anopheles
17
Evolutionary rate in constitutive and alternative
regions

• Human and mouse orthologous genes
• Estimation of the dn/ds ratio higher fraction
  of non-synonymous (changing amino acid)
  substitutionsgt weaker stabilizing (or stronger
  positive) selection

18
Concatenates of constitutive and alternative
regions in all genes different evolutionary rates

• Relatively more non-synonimous substitutions in
  alternative regions (higher dN/dS ratio)

• Less amino acid identity in alternative regions

• Columns (left-to-right) (1) constitutive
  regions
• (24) alternative regions N-end, internal, C-end

19
Individual genes the rate of non-synonymous to
synonymous substitutions dn/ds tends to be larger
in alternative regions (vertical acis) than in
constitutive regions (horizontal acis)
20
Non-symmetrical histogram of dn/ds(const)dn/ds(a
lt)
Black shadow of the left half.In a larger
fraction of genes dn/ds(const)ltdn/ds(alt),
especially for larger values
21
The same effect is seen in N-terminal,
internal, C-terminal parts
22
Drosophilas less selection in alternative
regions?
More mutations in alt. regions
Similar level of mutations
More mutations in const. regions
In a majority of genes, both synonymous and
non-synonymous mutation rates are higher in
alternative regions than in constitutive regions
23
Different behavior of N-terminal, internal and
C-terminal alternatives
N-terminal alternatives most genes have higher
syn. substit. rate in alt. regions most genes
have higher stabilizing selection in alt. regions
Internal alternatives intermediate situation
C-terminal alternatives more non-synonymous
substitutions and less synonymous substitutions
gt lower stabilizing selection in alternative
regions
24
The MacDonald-Kreitman test evidence for
positive selection in (minor isoform) alternative
regions

• Human and chimpanzee genome mismatches vs human
  SNPs
• Exons conserved in mouse and/or dog
• Genes with at least 60 ESTs (median number)
• Fishers exact test for significance

Pn/Ps (SNPs) Dn/Ds (genomes) diff. Signif.
Const. 0.72 0.62 0.10 0
Major 0.78 0.65 0.13 0.5
Minor 1.41 1.89 0.48 0.1

• Minor isoform alternative regions
• More non-synonymous SNPs Pn(alt_minor).12 gtgt
  Pn(const).06
• More non-synonym. mismatches Dn(alt_minor).91
  gtgt Dn(const).37
• Positive selection (as opposed to lower
  stabilizing selection) a 1 (Pa/Ps) /
  (Da/Ds) 25 positions
• Similar results for all highly covered genes or
  all conserved exons

25
An attempt of integration

• AS is often genome-specific
• young AS isoforms are often minor and
  tissue-specific
• but still functional
• although unique isoforms may result from aberrant
  splicing
• AS regions show evidence for decreased negative
  selection
• excess non-synonymous codon substitutions
• AS regions show evidence for positive selection
• excess non-synonymous SNPs
• AS tends to shuffle domains and target functional
  sites in proteins
• Thus AS may serve as a testing ground for new
  functions without sacrificing old ones

26
What next?

• Multiple genomes
• many Drosophila spp.
• ENCODE data for many mammals
• Estimate not only the rate of loss, but also the
  rate of gain (as opposed to aberrant splicing)
• Control for
• functionality translated / NMD-inducing
• exon inclusion (or site choice) level major /
  minor isoform
• tissue specificity pattern (?)
• type of alternative N-terminal / internal /
  C-terminal
• Evolution of regulation of AS
• Splicing errors and mutations retained introns,
  skipped exons, cryptic sites

27
Acknowledgements

• Discussions
• Vsevolod Makeev (GosNIIGenetika)
• Eugene Koonin (NCBI)
• Igor Rogozin (NCBI)
• Dmitry Petrov (Stanford)
• Dmitry Frishman (GSF, TUM)
• Shamil Sunyaev (Harvard University Medical
  School)
• Data
• King Jordan (NCBI)
• Support
• Howard Hughes Medical Institute
• INTAS
• Russian Academy of Sciences (program Molecular
  and Cellular Biology)
• Russian Fund of Basic Research

28
Authors

• Andrei Mironov (Moscow State University)
• Ramil Nurtdinov (Moscow State University)
  human/mouse/dog
• Dmitry Malko (GosNIIGenetika)
  drosophila/mosquito
• Ekaterina Ermakova (Moscow State University,
  IITP) Kn/Ks
• Vasily Ramensky (Institute of Molecular Biology)
  SNPs
• Irena Artamonova (GSF/MIPS) human/mouse,
  plots
• Alexei Neverov (GosNIIGenetika) functionality
  of isoforms
