CCNA Fast Track

1
C C N A FastTrack
2
AGENDA day one
CCNA FastTrack

• IOS review (using lab 1)

• OSI review and example questions

• VLSM and basic routing (lab 2)

• Network protocols review

• Routing review (lab4)

KCC 18th August 2002
3
AGENDA day two
CCNA FastTrack

• Switching and bridging (lab 6 and 7)

• Example questions

• More routing and access lists (lab 3)

• Example questions

• WAN technologies (lab 5)

• More example questions

KCC 18th August 2002
4
Progress
CCNA FastTrack
AFTER DAY ONE
BEFORE TRAINING
AFTER DAY TWO
IOS Fundamentals
OSI Layers
Bridges Switches
Network Protocols
Routing
Access Lists
WAN and design
Site specific items
KCC 18th August 2002
5
IOS REVIEW lab1
CCNA FastTrack
192.168.5.0/24
192.168.192.2/32
L0
E0
RTR-2
192.168.128.2/30
Static route for 192.168.0.0/24 via 192.168.128.1
Se0
192.168.128.1/30
L0
Se0
192.168.192.1/32
RTR-1
E0
Static route for 192.168.5.0/24 via 192.168.128.2
192.168.0.0/24
TFTP server 192.168.0.99
KCC 18th August 2002
6
IOS REVIEW
CCNA FastTrack

• CLI Password configuration
• For VTY, Console and Aux ports
• Key sequence for edit and buffer recall etc
• CDP defaults and configuration
• Banner MOTD command use and editing
• Router memory types and use
• Flash IOS and config file control etc
• Show commands for CCNA
• Logging messages
• Know defaults and how to change

KCC 18th August 2002
7
Example IOS questions
CCNA FastTrack
What is used to set the routers boot
procedure A command register B flash
register C config register D boot status
register
What is the command to enable CDP on an
interface A enable cdp B cdp enable C
cdp run D run cdp E cdp
What information can be obtained from CDP A
neighbor memory size B neighbor address C
neighbor platform D neighbor IOS version E
neighbor routing protocols
What is the command to remove the starting
configuration A clear start-up B write
erase C erase memory D erase
startup-config E clear memory
Which command would be used to copy IOS to
flash A copy flash tftp B copy tftp
flash C copy mem flash D write memory
Where are router syslog messages sent by
default A null B aux port and console
port C console port D syslog server
KCC 18th August 2002
8
OSI REVIEW
CCNA FastTrack
APPLICATION
PRESENTATION
SESSION
TRANSPORT
NETWORK
DATA
PHYSICAL
KCC 18th August 2002
9
Example OSI questions
CCNA FastTrack
Which layer of the OSI model covers Frame
Relay A Layer 5 (session) B Layer 2
(data) C Layer 3 (network) D Layer 4
(transport)
What OSI layer covers acknowledgement and
sequencing A Layer 5 (session) B Layer 3
(network) C Layer 2 (data) D Layer 4
(transport) E Layer 1 (physical)
NetBIOS operates at OSI layer A Layer 1
(physical) B Layer 2 (data) C Layer 3
(network) D Layer 4 (transport) E Layer 5
(session)
Which protocols are routable A NetBIOS B
IP C SNA D Appletalk E IPX
Which OSI layer does CDP operate A Layer 1
(physical) B Layer 2 (data) C Layer 3
(network) D Layer 4 (transport)
Which OSI layer does a bridge operate A Layer
6 (presentation) B Layer 5 (session) C
Layer 4 (transport) D Layer 3 (network) E
Layer 2 (data)
KCC 18th August 2002
10
VLSM Basic Routing lab 2
CCNA FastTrack
Ref Lab 2 diagram

• EIGRP CLASSLESS ROUTING
• Add loopbacks as per diagram
• Configure EIGRP 10
• Remove static routes
• Change EIGRP from default to enable
  connectivity
• Add other networks to EIGRP
• RIP Version 1 CLASSFULL ROUTING
• Add RIP v1 view routing table
• Remove EIGRP 10

KCC 18th August 2002
11
Network Protocols Reminder
CCNA FastTrack
0 4 8
16 19 24
32
total packet length
version
hdr length
TOS
identification
flags
fragment offset
IP PACKET
TTL
protocol
header checksums
source address
destination address
options (variable length)
padding
d a t a
FRAME
DATA
FRAME HEADER
TYPE 0800 IP content
TYPE FIELD if Ethernet DIX (Ethernet II)
header format LENGTH FIELD if IEEE Ethernet 802.3
KCC 18th August 2002
12
Network Protocols Reminder
CCNA FastTrack
FTP DATA
FTP HEADER
SEGMENT
TCP DATA
TCP HEADER
PORT 21 FTP content
PACKET
IP DATA
IP HEADER
PROTOCOL 6 TCP content
FRAME
DATA
FRAME HEADER
TYPE 0800 IP content
DATA SIGNAL
Preamble
KCC 18th August 2002
13
Network Routing Protocols Review
CCNA FastTrack
Protocol IPX-RIP RIP v1 RIP v2 IGRP EIGRP OSPF
Admin distance
VLSM
update
metric
method
Auto summary
Loop prevention
KCC 18th August 2002
14
Routing lab 4
CCNA FastTrack
Ref Lab 4

• Erase Configuration
• Password Recovery
• HSRP (Hot Standby Router Protocol)
• IGRP CLASSFULL ROUTING

KCC 18th August 2002
15
VLSM and Basic Routing REVIEW
CCNA FastTrack

• VLSM and network masks etc
• Routing configuration commands
• Classless routing (EIGRP, OSPF, RIP v2)
• Classfull routing (RIP v1, IGRP)
• Distance vector routing protocols defaults
• Administration distances
• Routing, static, connected, default route
• Routing tables, databases and ARP
• Password recovery
• Configuration register values

KCC 18th August 2002
16
Example VLSM routing questions
CCNA FastTrack
Auto summary can be disabled on A EIGRP B
RIP v1 C IGRP D RIP v2
What network would provide for 1022 nodes A
164.22.10.0/24 B 164.22.10.0/28 C
172.16.16.0/22 D 172.16.17.0/22 E
192.168.5.0/16
In a routing table, routes from EIGRP are
marked A E B O C E1 D E2 E D
Which command is used to enable RIP routing A
router rip 66 B enable rip C rip enable D
router rip E set rip enable
The default admin distance for IGRP routes is A
90 B 110 C 100 D 120 E 170
Which of the following is NOT on the same
subnet A 164.14.225.7/19 B
164.14.223.4/19 C 164.14.223.0/19 D
164.14.199.16/19 E 164.14.223.8/19
KCC 18th August 2002
17
Switching and Bridging (lab 6 7)
CCNA FastTrack
VTP DOMAIN CCNALAB
SW-1
SW-2
TFTP server 192.168.0.99
1900 or 2900 etc
1900 or 2900 etc
ISL TRUNKS
192.168.5.0/24
VLAN 2
VLAN 1
E0
E0
RTR-2
RTR-1
KCC 18th August 2002
18
Switching and Bridging Review
CCNA FastTrack

• VLANs
• Broadcast domains/Collision domains
• Spanning Tree (802.1d/DEC/IBM)
• VTP modes (server, client, transparent)
• Trunking (ISL, 802.1q, FDDI, ATM)
• 1900 IOS quirks
• Configuration and defaults
• Switching methods
• Store and forward
• Cut through
• Fragment free

KCC 18th August 2002
19
Example switching and bridging questions
CCNA FastTrack
When two VTP servers in the same domain have
different VLAN configurations.. A all
conflicting VLANS are disabled B VTP server
with highest configuration
register overwrites the other switch C VTP
server with lowest configuration
register over writes the other switch D the
domain is partitioned into two
What is the correct order for spanning tree
start A Forwarding, Listening, Learning,
Blocking B Blocking, Listening, Learning,
Forwarding C Listening, Blocking, Forwarding,
Learning D Learning, Listening, Blocking,
Forwarding
What is the default mode for VTP on a 1900
switch A client B transparent C
server D passive E none
Which of the following are true A Ethernet
addresses are non-canonical B Token Ring
address are non-canonical C Ethernet addresses
are canonical D Token Ring addresses are
canonical
In a network of 9 switches for 2 VLANs, how many
route bridges A 9 B 18 C 2 D 8 E
7
Broadcasts are automatically forwarded between
VLANs A true B false C depends
KCC 18th August 2002
20
Routing and Access Lists
CCNA FastTrack
Ref Lab 3

• OSPF
• IPX Routing
• SNMP
• Access Lists

KCC 18th August 2002
21
Access Lists Review
CCNA FastTrack

• Access Lists number range
• 1 - 99 _____________________
• 100 - 199 _____________________
• 800 - 899 _____________________
• 900 - 999 _____________________
• 1000 - 1099 _____________________
• ACL application commands
• TCP, UDP IPX port/socket numbers

KCC 18th August 2002
22
Example ACL questions
CCNA FastTrack
Valid access list for IPX extended use is. A
1 - 99 B 100 - 199 C 800 - 899 D 900
- 999
What command is used to apply an access list to
an interface A access-list apply B
access-class C access-group D access E
interface-access-list
Which line would block Telnet access A
access-list 101 deny ip any any eq 23 B
access-list 101 deny tcp any any eq 23 C
access-list 99 deny tcp any any eq 20 D
access-list 99 deny tcp any any eq 21 E
access-list 105 deny udp any any eq 23
Valid access list for ip extended is A 1 -
99 B 100 - 199 C 101 - 199 D 0 -
99 E 200 - 299
ACLs are processed in the order that they were
configured A true B false C depends
Which of the following are NOT valid A
access-list 801 permit 1 1 B access-list 101
deny ip any any eq 162 C access-list 801 deny
bad.0.0.1 1 D access-list 801 deny 1
bad.0.0.1 452 1 0 E access-list 199 perm tcp
any any eq www
KCC 18th August 2002
23
WAN
CCNA FastTrack
192.168.5.0/24
Ref Lab 5
ISDN switch type _____________
192.168.192.2/32
L0
E0
ISDN
10.10.1.1/28
L1
RTR-2
172.10.10.1/28
L2
Se0
192.168.128.0/___
DLCI 201
Se0
192.168.192.1/32
L0
DLCI 102
Se1
RTR-1
Frame Relay
L1
E0
10.10.2.1/28
L2
192.168.0.0/24
Frame Relay details
172.10.10.17/28
TFTP server 192.168.0.99
KCC 18th August 2002
24
Wan Review
CCNA FastTrack

• Serial defaults
• Bandwidth
• Encapsulation
• DTE/DCE clocking
• Frame Relay
• LMI type/DLCI
• Encapsulation
• RFC 1490
• ISDN
• BRI R/S/T/U/NT1/NT2
• Dialer-list for interesting traffic
• spid switch type
• Debug q921/q931
• PRI E1/T1

KCC 18th August 2002
25
Example WAN questions
CCNA FastTrack
Which authentication mode supports MD5 A
PPP B PAP C CHAP D super PAP
ISDN U interface is A complete with built in
NT1 B requires external NT1 C requires
external CSU/DSU D not available in the UK E
four wire RJ45
In PPP, what is used to identify a loopback A
PAP B CHAP C Link Quality Monitoring D
NCP E Magic Numbers
Which protocol manages the connection between
router and FR A DLCI B FR-manage C
LMI D ILMI E OAM
Which is/are NOT Frame Relay terms A BECN B
FECN C ILMI D DE E DLCI F X.121
What is the default encapsulation on a Cisco
serial interface A HDLC B PPP C SLIP D
Frame Relay E X.25
KCC 18th August 2002
26
Final Review
CCNA FastTrack
KCC 18th August 2002
