Regulation of Gene Expression

1
Regulation of Gene Expression
11
2
Chapter 11 Regulation of Gene Expression

• Key Concepts
• 11.1 Several Strategies Are Used to Regulate Gene
  Expression
• 11.2 Many Prokaryotic Genes Are Regulated in
  Operons
• 11.3 Eukaryotic Genes Are Regulated by
  Transcription Factors and DNA Changes
• 11.4 Eukaryotic Gene Expression Can Be Regulated
  after Transcription

3
Chapter 11 Opening Question

• How does CREB regulate the expression of many
  genes?

4
Concept 11.1 Several Strategies Are Used to
Regulate Gene Expression

• Gene expression is tightly regulated.
• Gene expression may be modified to counteract
  environmental changes, or gene expression may
  change to alter function in the cell.
• Constitutive proteins are actively expressed all
  the time.
• Inducible genes are expressed only when their
  proteins are needed by the cell.

5
Figure 11.1 Potential Points for the Regulation
of Gene Expression
6
Concept 11.1 Several Strategies Are Used to
Regulate Gene Expression

• Genes can be regulated at the level of
  transcription.
• Gene expression begins at the promoter where
  transcription is initiated.
• In selective gene transcription a decision is
  made about which genes to activate.
• Two types of regulatory proteinsalso called
  transcription factorscontrol whether a gene is
  active.

7
Concept 11.1 Several Strategies Are Used to
Regulate Gene Expression

• These proteins bind to specific DNA sequences
  near the promoter
• Negative regulationa repressor protein prevents
  transcription
• Positive regulationan activator protein binds to
  stimulate transcription

8
Figure 11.2 Positive and Negative Regulation
(Part 1)
9
Figure 11.2 Positive and Negative Regulation
(Part 2)
10
Concept 11.1 Several Strategies Are Used to
Regulate Gene Expression

• Acellular viruses use gene regulation to take
  over host cells.
• A phage injects a host cell with nucleic acid
  that takes over synthesis.
• New viral particles (virions) appear rapidly and
  are soon released from the lysed cell.
• This lytic cycle is a typical viral reproductive
  cyclein a lysogenic phase, the viral genome is
  incorporated into the host genome and is
  replicated too.

11
Concept 11.1 Several Strategies Are Used to
Regulate Gene Expression

• A bacteriophage may contain DNA or RNA and may
  not have a lysogenic phase.
• The lytic cycle has two stages
• Early stagepromoter in the viral genome binds
  host RNA polymerase and adjacent viral genes are
  transcribed
• Early genes shut down transcription of host
  genes, and stimulate viral replication and
  transcription of viral late genes.
• Host genes are shut down by a posttranscriptional
  mechanism.
• Viral nucleases digest the hosts chromosome for
  synthesis in new viral particles.

12
Concept 11.1 Several Strategies Are Used to
Regulate Gene Expression

• Late stageviral late genes are transcribed
• They encode the viral capsid proteins and enzymes
  to lyse the host cell and release new virions.
• The whole process from binding and infection to
  release of new particles takes about 30 minutes.

13
Figure 11.3 A Gene Regulation Strategy for Viral
Reproduction
14
Concept 11.1 Several Strategies Are Used to
Regulate Gene Expression

• Human immunodeficiency virus (HIV) is a
  retrovirus with single-stranded RNA.
• HIV is enclosed in a membrane from the previous
  host cellit fuses with the new host cells
  membrane.
• After infection, RNA-directed DNA synthesis is
  catalyzed by reverse transcriptase.
• Two strands of DNA are synthesized and reside in
  the hosts chromosome as a provirus.

15
Figure 11.4 The Reproductive Cycle of HIV
16
Concept 11.1 Several Strategies Are Used to
Regulate Gene Expression

• Host cells have systems to repress the invading
  viral genes.
• One system uses transcription terminator
  proteins that interfere with RNA polymerase.
• HIV counteracts this negative regulation with Tat
  (Transactivator of transcription), which allows
  RNA polymerase to transcribe the viral genome.

17
Figure 11.5 Regulation of Transcription by HIV
(Part 1)
18
Figure 11.5 Regulation of Transcription by HIV
(Part 2)
19
Concept 11.2 Many Prokaryotic Genes Are
Regulated in Operons

• Prokaryotes conserve energy by making proteins
  only when needed.
• In a rapidly changing environment, the most
  efficient gene regulation is at the level of
  transcription.
• E. coli must adapt quickly to food supply
  changes. Glucose or lactose may be present.

20
Concept 11.2 Many Prokaryotic Genes Are
Regulated in Operons

• Uptake and metabolism of lactose involve three
  proteins
• ?-galactoside permeasea carrier protein that
  moves sugar into the cell
• ?-galactosidasean enzyme that hydrolyses lactose
• ?-galactoside transacetylasetransfers acetyl
  groups to certain ?-galactosides
• If E. coli is grown with glucose but no lactose
  present, no enzymes for lactose conversion are
  produced.

21
Concept 11.2 Many Prokaryotic Genes Are
Regulated in Operons

• If lactose is predominant and glucose is low, E.
  coli synthesizes all three enzymes.
• If lactose is removed, synthesis stops.
• A compound that induces protein synthesis is an
  inducer.
• Gene expression and regulating enzyme activity
  are two ways to regulate a metabolic pathway.

22
Figure 11.6 Two Ways to Regulate a Metabolic
Pathway
23
Concept 11.2 Many Prokaryotic Genes Are
Regulated in Operons

• Structural genes specify primary protein
  structurethe amino acid sequence.
• The three structural genes for lactose enzymes
  are adjacent on the chromosome, share a promoter,
  and are transcribed together.
• Their synthesis is all-or-none.

24
Concept 11.2 Many Prokaryotic Genes Are
Regulated in Operons

• A gene cluster with a single promoter is an
  operonthe one that encodes for the lactose
  enzymes is the lac operon.
• An operator is a short stretch of DNA near the
  promoter that controls transcription of the
  structural genes.
• Inducible operonturned off unless needed
• Repressible operonturned on unless not needed

25
Figure 11.7 The lac Operon of E. coli
26
Concept 11.2 Many Prokaryotic Genes Are
Regulated in Operons

• The lac operon is only transcribed when a
  ?-galactoside predominates in the cell
• A repressor protein is normally bound to the
  operator, which blocks transcription.
• In the presence of a ?-galactoside, the repressor
  detaches and allows RNA polymerase to initiate
  transcription.
• The key to this regulatory system is the
  repressor protein.

27
Figure 11.8 The lac Operon An Inducible System
(Part 1)
28
Figure 11.8 The lac Operon An Inducible System
(Part 2)
29
Concept 11.2 Many Prokaryotic Genes Are
Regulated in Operons

• A repressible operon is switched off when its
  repressor is bound to its operator.
• However, the repressor only binds in the presence
  of a co-repressor.
• The co-repressor causes the repressor to change
  shape in order to bind to the promoter and
  inhibit transcription.
• Tryptophan functions as its own co-repressor,
  binding to the repressor of the trp operon.

30
Figure 11.9 The trp Operon A Repressible System
(Part 1)
31
Figure 11.9 The trp Operon A Repressible System
(Part 2)
32
Concept 11.2 Many Prokaryotic Genes Are
Regulated in Operons

• Difference in two types of operons
• In inducible systemsa metabolic substrate
  (inducer) interacts with a regulatory protein
  (repressor) the repressor cannot bind and allows
  transcription.
• In repressible systemsa metabolic product
  (co-repressor) binds to regulatory protein, which
  then binds to the operator and blocks
  transcription.

33
Concept 11.2 Many Prokaryotic Genes Are
Regulated in Operons

• Generally, inducible systems control catabolic
  pathwaysturned on when substrate is available
• Repressible systems control anabolic
  pathwaysturned on until product concentration
  becomes excessive

34
Concept 11.2 Many Prokaryotic Genes Are
Regulated in Operons

• Sigma factorsother proteins that bind to RNA
  polymerase and direct it to specific promoters
• Global gene regulation Genes that encode
  proteins with related functions may have a
  different location but have the same promoter
  sequencethey are turned on at the same time.
• Sporulation occurs when nutrients are
  depletedgenes are expressed sequentially,
  directed by a sigma factor.

35
Table 11.1 Transcription in Bacteria and
Eukaryotes
36
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Transcription factors act at eukaryotic
  promoters.
• Each promoter contains a core promoter sequence
  where RNA polymerase binds.
• TATA box is a common core promoter sequencerich
  in A-T base pairs.
• Only after general transcription factors bind to
  the core promoter, can RNA polymerase II bind and
  initiate transcription.

37
Figure 11.10 The Initiation of Transcription in
Eukaryotes (Part 1)
38
Figure 11.10 The Initiation of Transcription in
Eukaryotes (Part 2)
39
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Besides the promoter, other sequences bind
  regulatory proteins that interact with RNA
  polymerase and regulate transcription.
• Some are positive regulatorsactivators others
  are negativerepressors.
• DNA sequences that bind activators are enhancers,
  those that bind repressors are silencers.
• The combination of factors present determines the
  rate of transcription.

40
In-Text Art, Ch. 11, p. 216
41
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Transcription factors recognize particular
  nucleotide sequences
• NFATs (nuclear factors of activated T cells) are
  transcription factors that control genes in the
  immune system.
• They bind to a recognition sequence near the
  genes promoters.
• The binding produces an induced fitthe protein
  changes conformation.

42
Figure 11.11 A Transcription Factor Protein
Binds to DNA
43
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Gene expression can be coordinated, even if genes
  are far apart on different chromosomes.
• They must have regulatory sequences that bind the
  same transcription factors.
• Plants use this to respond to droughtthe
  scattered stress response genes each have a
  specific regulatory sequence, the dehydration
  response element.
• During drought, a transcription factor changes
  shape and binds to this element.

44
Figure 11.12 Coordinating Gene Expression
45
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Gene transcription can also be regulated by
  reversible alterations to DNA or chromosomal
  proteins.
• Alterations can be passed on to daughter cells.
• These epigenetic changes are different from
  mutations, which are irreversible changes to the
  DNA sequence.

46
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Some cytosine residues in DNA are modified by
  adding a methyl group covalently to the 5'
  carbonforms 5'-methylcytosine
• DNA methyltransferase catalyzes the
  reactionusually in adjacent C and G residues.
• Regions rich in C and G are called CpG
  islandsoften in promoters

47
Figure 11.13 DNA Methylation An Epigenetic
Change (Part 1)
48
Figure 11.13 DNA Methylation An Epigenetic
Change (Part 2)
49
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• This covalent change in DNA is heritable
• When DNA replicates, a maintenance methylase
  catalyzes formation of 5'-methylcytosine in the
  new strand.
• However, methylation pattern may be
  altereddemethylase can catalyze the removal of
  the methyl group.

50
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Effects of DNA methylation
• Methylated DNA binds proteins that are involved
  in repression of transcriptiongenes tend to be
  inactive (silenced).
• Patterns of DNA methylation may include large
  regions or whole chromosomes.

51
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Two kinds of chromatin are visible during
  interphase
• Euchromatindiffuse and light-staining contains
  DNA for mRNA transcription
• Heterochromatincondensed, dark-staining
  contains genes not transcribed

52
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• A type of heterochromatin is the inactive X
  chromosome in mammals.
• Males (XY) and females (XX) contain different
  numbers of X-linked genes, yet for most genes
  transcription, rates are similar.
• Early in development, one of the X chromosomes is
  inactivatedthis Barr body is identifiable during
  interphase and can be seen in cells of human
  females.

53
Figure 11.14 X Chromosome Inactivation
54
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Another mechanism for epigenetic regulation is
  chromatin remodeling, or the alteration of
  chromatin structure.
• Nucleosomes contain DNA and positively-charged
  histones in a tight complex, inaccessible to RNA
  polymerase.
• Histone acetyltransferases change the charge by
  adding acetyl groups to the amino acids on the
  histones tail.

55
In-Text Art, Ch. 11, p. 219 (1)
56
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• The change in charge opens up the nucleosomes as
  histone loses its affinity for DNA.
• More chromatin remodeling proteins bind and open
  the DNA for gene expression.
• Thus, histone acetyltransferases can activate
  transcription.

57
Figure 11.15 Epigenetic Remodeling of Chromatin
for Transcription
58
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Histone deacetylase is another kind of chromatin
  remodeling protein.
• It can remove the acetyl groups from the
  histones, repressing transcription.

59
Concept 11.3 Eukaryotic Genes Are Regulated by
Transcription Factors and DNA Changes

• Environment plays an important role in
  epigenetic modifications.
• Even though they are reversible, some epigenetic
  changes can permanently alter gene expression
  patterns.
• If the cells form gametes, the epigenetic changes
  can be passed on to the next generation.
• Monozygotic twins show different DNA methylation
  patterns after living in different environments.

60
Concept 11.4 Eukaryotic Gene Expression Can Be
Regulated after Transcription

• Eukaryotic gene expression can be regulated after
  the initial gene transcript is made.
• Different mRNAs can be made from the same gene by
  alternative splicing.
• As introns and exons are spliced out, new
  proteins are made.
• This may be a deliberate mechanism for generating
  proteins with different functions, from a single
  gene.

61
Concept 11.4 Eukaryotic Gene Expression Can Be
Regulated after Transcription

• Examples of alternative splicing
• The HIV genome encodes nine proteins, but is
  transcribed as a single pre-mRNA.
• In Drosophila the Sxl gene with four exons is
  spliced differently to produce different
  combinations in males and females.

62
Figure 11.16 Alternative Splicing Results in
Different Mature mRNAs and Proteins
63
Concept 11.4 Eukaryotic Gene Expression Can Be
Regulated after Transcription

• MicroRNAs(miRNAs)small molecules of noncoding
  RNAare important regulators of gene expression.
• In C. elegans, lin-14 mutations cause the larvae
  to skip the first stagethus the normal role for
  lin-14 is to be involved in stage one of
  development.
• lin-4 mutations cause cells to repeat stage one
  eventsthus the normal role for lin-4 is to
  negatively regulate lin-14, so that cells can
  progress to the next stage of development.

64
Concept 11.4 Eukaryotic Gene Expression Can Be
Regulated after Transcription

• lin-4 encodes not for a protein but for a 22-base
  miRNA that inhibits lin-14 expression
  posttranscriptionally by binding to its mRNA.
• Many miRNAs have been describedonce transcribed
  they are guided to a target mRNA to inhibit its
  translation and to degrade the mRNA.

65
Figure 11.17 mRNA Degradation Caused by MicroRNAs
66
Concept 11.4 Eukaryotic Gene Expression Can Be
Regulated after Transcription

• mRNA translation can be regulated.
• Protein and mRNA concentrations are not
  consistently relatedgoverned by factors acting
  after mRNA is made.
• Cells either block mRNA translation or alter how
  long new proteins persist in the cell.

67
Concept 11.4 Eukaryotic Gene Expression Can Be
Regulated after Transcription

• Three ways to regulate mRNA translation
• Inhibition of translation with miRNAs
• Modification of the 5' cap end of mRNA can be
  modifiedif cap is unmodified mRNA is not
  translated.
• Repressor proteins can block translation
  directlytranslational repressors

68
Figure 11.18 A Repressor of Translation
69
Figure 11.19 A Proteasome Breaks Down Proteins
70
Answer to Opening Question

• The CREB family of transcription factors can
  activate or repress gene expression by binding to
  the cAMP response element (CRE) sequence found in
  the promoter region of many genes.
• CREB binding is essential in many organs,
  including the brain, and has been linked to
  addiction and memory tasks as well as to
  metabolism.

71
Figure 11.20 An Explanation for Alcoholism?
