Microarray experiments: Database and Analysis Tools.

1
Microarray experiments Database and Analysis
Tools.
Kate Milova cDNA Microarray Facility March
24, 2005
2
Outline.

• Microarray platforms and services at AECOM
• cDNA
• Long Oligo
• Affymetrix
• Database (cDNA Long Oligo) structure and
  content
• Printing information
• Chip layout
• Annotation
• Annotation algorithms and data mining
• On-line Analysis Tools
• Normalization
• Signal filtering
• Data sets comparison
• Statistical packages and Analysis software
• Summary

3
Microarray Platforms at AECOM.
4
How to choose a microarray platform.
5
Before starting your microarray experiment.
6
cDNA Microarray Facility. Home page.
Standart Custom Arrays. Description Prices
Hybridization, labeling, bioinformatics, workshops
Database for cDNA Long Oligo Arrays. Analysis
Pipeline
AECOM cDNA microarray facility. Supported
publications
Useful links of analysis tools
7
Database for Analysis of Microarrays at AECOM.
Contents.
Chip layout
Gene Annotation
Printing Information

• Accession
• Clone ID
• Clone end
• Vector name
• Clone name
• UniGene cluster ID
• Best blast hit
• Main blast parameters (score, E-value,
  identity, blast date, etc.)
• Gene ID
• Gene symbol
• Gene synonyms
• Chromosome
• Map location
• GO IDs
• GO Annotation

• Chip name
• Spot information (Accession or clone id or
  bacterial control)
• Spot location
• Library name
• Clone location on 384 plate
• Clone location on 96 plate

• Chip name
• Specie
• Number of spots
• Number of controls
• Number of pen domains
• Number of slides
• Printing pattern
• Distance between spots
• Number of rows
• Number of columns
• Printing date
• Master chip

8
Annotation sources NCBI.
UniGene ID ? Accession
UniGene
UniGene ID ? Blast against UniGene clusters
Entrez Gene
UniGene ID ? Gene ID ? GO ID
NCBI
Blast Software
Blast Search
Refseq NT databases ? Annotation
9
Annotation sources NCBI.
UniGene ID ? Accession
UniGene
UniGene ID ? Blast against UniGene clusters

• NCBI ? UniGene ? UniGene ID
• UniGene ID for cDNA arrays is obtained from the
  UniGene source file for each particular accession
  number of the clone.
• NCBI ? UniGene ? Blast
• UniGene ID for Long Oligo arrays is obtained
  from blast results
• Blast search was done with the set of oligo
  sequences against UniGene clusters with cutoff
  99 for sequence identity and 90 for
  overlapping.
• UniGene ID for the oligo hitting multiple
  UniGene clusters is marked as an Ambiguous
  cluster ID.

NCBI
10
Annotation sources NCBI.

• UniGene ID ? Gene ID
• All information retrieved from Enrez Gene
  project is based on the UniGene cluster ID and
  corresponding Gene ID.
• Gene ID is ambiguous in Gene ID to UniGene
  cluster ID connection.
• Parsing filter was used to eliminate ambiguous
  Gene IDs.

• Gene ID ? GO ID
• For each Gene ID corresponding Gene Ontology IDs
  were retrieved from Entrez Gene source file
• There might be a few or more then 10 different
  GO IDs for a Gene ID. All of them are collected.

11
Annotation sources NCBI.

• Blast Software package is installed on the
  microarray server.
• This software allows to format databases and run
  batch homology search for any combination of
  custom databases and query sequences.
• Refseq NT databases. Annotation
• Loaded formatted and periodically updated on the
  microarray server.
• When databases are updated we run blast search
  of cDNA and Long Oligo sequences.
• Blast results are parsed using our algorithm for
  annotation extraction.

NCBI
Blast Software
Blast Search
Refseq NT databases? Annotation
12
Annotation Extraction Algorithm
Raw Data
Sequences
Homology search against RefSeq NT
Alignment quality check
90
80
13
Annotation Extraction Algorithm
EDMUSDFMUSKULUSDETRIKENGLLCLONEJF
FPROTEINRFTYROSINEMNWZMKINASEJHMIW
Linguistic Filter
OUT
14
Annotation sources Gene Ontology.
Biological process
Molecular function
Gene Ontology

• Gene Ontology.
• Multiple GO IDs for each Gene ID are retrieved
  in the previous step from Entrez Gene ( if
  available).

Cellular compartment

• Gene Ontology annotation for all GO IDs is kept
  in three different information fields biological
  processes, molecular function and cellular
  compartment. For each of the fields all available
  annotation was prefiltered with redundancy check
  and concatenated.

15
cDNA Microarray Facility. Database.
16
Database Search.

• Database Annotation Search with
• Accession
• Gene annotation
• Gene symbol synonyms
• UniGene cluster ID
• Chromosome number
• Gene ID
• GO ID
• Function
• Cellular compartment

17
Microarray Data Analysis Pipeline.
18
Pipeline LOWESS Normalization.
19
Pipeline LOWESS Normalization.
20
Pipeline Filtering.
21
Pipeline Data set Comparison.
22
Statistical packages and Analysis software.

• Microarray Analysis Software
• GeneTraffic client-server systems for
  microarray data analysis. Iobion
• GeneSpring cutting-edge tools for expression
  analysis. Agilent Technologies
• GeneSifter. GeneSifter
• BASE. Lund University
• Data Mining
• PathwayAssist Interaction Explore Software.
  Stratagen
• Pathways Analysis. Ingenuity
• Tools for Statistical Analysis
• SAM Significance Analysis of Microarrays.
  Stanford
• R statistical package
• S-PLUS. Insightful

23
Summary

• Multiple microarray platforms are available at
  AECOM
• Affymetrix
• cDNA arrays
• Long Oligo
• Custom arrays
• Data analysis and annotation
• Database for Analysis of Microarrays containes
  all information about our arrays, cDNA and oligo
  sets
• Sequences annotation is updated and integrated
  into the database
• Web interface of the database makes it easy to
  search for a particular gene, synonyms, map
  location, function, etc
• Easy to use web based analysis pipeline get
  your results in just 5 minutes. List of Up,
  Down regulated genes with full gene annotation.
• We are here for help and consultation !

24
BACKUPS
25
cDNA Microarray Facility. Services.
26
cDNA Microarray Facility. Arrays.
27
cDNA Microarray Facility. Publications.
28
Gene Correspondence Tables.
29
Gene Correspondence Tables.
