1Neurological assessment
2Anatomic and Physiologic Overview
- The nervous system consists of two divisions the
central nervous system (CNS) including the brain
and spinal cord - peripheral nervous system, which includes
cranial and spinal nerves. - The peripheral nervous system can be further
divided into the somatic, or voluntary, nervous
system, and the autonomic, or involuntary,
nervous system.
3- The function of the nervous system is control
of all motor, sensory, autonomic, cognitive, and
behavioral activities. - The nervous system has approximately 10
million sensory neurons that send information
about the internal and external environment to
the brain and 500,000 motor neurons that control
the muscles and glands.
4- The brain itself contains more than 100 billion
cells that link the motor and sensory pathways,
monitor the body's processes, respond to the
internal and external environment, maintain
homeostasis, and direct all psychological,
biologic, and physical activity through complex
chemical and electrical messages
5Anatomy of the Nervous System
- Cells of the Nervous System
- The basic functional unit of the brain is the
neuron It is composed of a cell body, a dendrite,
and an axon. - The axon is a long projection that carries
impulses away from the cell body. Nerve cell
bodies occurring in clusters are called ganglia
or nuclei.
6- Neurotransmitters
- Neurotransmitters communicate messages from one
neuron to another or from a neuron to a specific
target tissue . - (In fact, probably all brain functions are
modulated through neurotransmitter receptor site
activity, including memory and other cognitive
processes
7- Many neurologic disorders are due, at least in
part, to an imbalance in neurotransmittersthat
is - an increase in gamma-aminobutyric acid (GABA) in
alcohol withdrawal seizures - (a decrease in dopamine in Parkinson's disease
and a decrease in acetylcholine in myasthenia
gravis
8The Central Nervous System
- Brain
- The brain is divided into three major areas the
cerebrum, the brain stem, and the cerebellum. - The cerebrum is composed of two hemispheres, the
thalamus, the hypothalamus, and the basal
ganglia.
9- Each hemisphere has four lobes
- parietal, occipital, temporal, frontal. The
cerebral lobes control complex problem-solving
value judgments languageemotions
interpretation of visual images interpretation
of touch, pressure,temperature, position sense.
10- Each hemisphere sends and receives impulses from
the opposite sides of the body and consists of
four lobes "frontal, parietal, temporal and
occipital". The lobes are composed of a substance
known as gray matter, which mediates
higher-level-functions such as memory,
perception, communication, and initiation of
voluntary movements.
11- The brain stem includes the midbrain, pons,
medulla, Is a major sensory and motor pathway for
impulses running to and from the cerebrum.
Regulates body functions such as respiration,
auditory and visual reflexes, swallowing.
12- The cerebellum is located under the cerebrum and
behind the brain stem). - contains the major motor and sensory pathways. It
controls smooth, coordinated muscle movements and
helps to maintain equilibrium.
13- The brain accounts for approximately 2 of the
total body weight in an average young adult, the
brain weighs approximately 1,400 g whereas in an
average elderly person, the brain weighs
proximately 1,200g
14- The meninges (fibrous connective tissues that
cover the brain and spinal cord) provide
protection, support, and nourishment to the brain
and spinal cord. The layers of the meninges are
the dura, arachnoid, and pia mater .
15Cerebrospinal Fluid
- CSF, a clear and colorless fluid with a specific
gravity of 1.007, is produced in the ventricles
and is circulated around the brain and the spinal
cord through the ventricular system. There are
four ventricles the right and left lateral and
the third and fourth ventricles
16- CSF is produced in the choroid plexus of the
lateral, third, and fourth ventricles. The
ventricular and subarachnoid system contains
approximately 150 mL of fluid each lateral
ventricle normally contains 25 mL of CSF .
17- The composition of CSF is similar to other
extracellular fluids (such as blood plasma), but
the concentrations of the various constituents
are different. - The laboratory report of CSF analysis usually
contains information on color, specific gravity,
protein count, white blood cell count, glucose,
and other electrolyte levels Normal CSF contains
a minimal number of white blood cells and no red
blood cells .
18- Cerebral Circulation
- The cerebral circulation receives approximately
15 of the cardiac output, or 750 mL per minute.
The brain does not store nutrients and has a high
metabolic demand that requires the high blood
flow.
19- The brain's blood pathway is unique because it
flows against gravity its arteries fill from
below, and the veins drain from above. - In contrast to other organs that may tolerate
decreases in blood flow because of their good
collateral circulation, the brain has poor
collateral blood flow, which may result in
irreversible tissue damage when blood flow is
occluded for even short time periods
20(No Transcript)
21Spinal Cord
- The spinal cord is located in the vertebral canal
and extends from the medulla oblongata to the
first lumbar vertebra,and serving as the
connection between the brain and the periphery. - Approximately 45 cm (18 in) long and about the
thickness of a finger,
22- The spinal cord is an H-shaped structure with
nerve cell bodies (gray matter) surrounded by
ascending and descending tracts (white matter)
23- The spinal cord conducts sensory impulses up
ascending tracts to the brain, conducts motor
impulses down descending tracts to neurons that
stimulate glands and muscles throughout the body,
and is responsible for simple reflex activity.
Reflex activity involves various neural
structures.
24 Peripheral Nervous System
- The peripheral nervous system consists of 12
pairs of cranial nerves and 31 pairs of spinal
nerves - These nerves are categorized as two types of
fibers somatic and autonomic. autonomic nervous
system mediates unconsciousness, or involuntary
activities. -
25- Spinal Nerve
- The spinal cord is composed of 31 pairs of spinal
nerves 8 cervical, 12 thoracic, 5 lumbar, 5
sacral, and 1 coccygeal. Each spinal nerve has a
ventral root and a dorsal root
26- Autonomic Nervous System
- The autonomic nervous system regulates the
activities of internal organs such as the heart,
lungs, blood vessels, digestive organs, and
glands. Maintenance and restoration of internal
homeostasis is largely the responsibility of the
autonomic nervous system.
27- There are two major divisions the sympathetic
nervous system, with predominantly excitatory
responses, most notably the fight or flight
response . - and the parasympathetic nervous system, which
controls mostly visceral functions.
28Assessment The Neurologic Examination
- Health History
- An important aspect of the neurologic assessment
is the history of the present illness. The
initial interview provides an excellent
opportunity to systematically explore the
patient's current condition and related events
while simultaneously observing overall
appearance, mental status, posture, movement, and
affect.
29- Neurologic disease may be stable or progressive,
characterized by symptom-free periods as well as
fluctuations in symptoms - The nurse should be aware of any history of
trauma or falls that may have involved the head
or spinal cord. Questions regarding the use of
alcohol, medications, and illicit drugs are also
relevant.
30- The history-taking portion of the neurologic
assessment is critical and, in many cases of
neurologic disease, leads to an accurate
diagnosis. .
31Neurological assessment
- The Glasgow Coma Scale
- Best Eye-Opening Response
Score - Spontaneously
4 - To speech
3 - To pain
2 - No response
1 - Best Motor Response Score
- Obeys commands
6 - Localizes stimuli attempt to remove noxious
stimuli 5
- Withdrawal from stimulus to avoid noxious
stimuli 4 - Abnormal flexion (decorticate)
3 - Abnormal extension (decerebrate)
2 - No response - flaccid
1
32The Glasgow Coma Scale
- Best Verbal Response
Score - Oriented
5 - Confused conversation
4 - Answer not appropriate to question
- Inappropriate words disorganized ,random speech
-
3 - Incomprehensible sounds
2 - No response
1 - A total score of 3 to 8 suggests severe
impairment, 9 to 12 suggests moderate impairment,
and 13 to 15 suggests mild impairment.
33(No Transcript)
34Categories of consciousness
- Alert (full consciousness) normal
- Awake may sleep more than usual or be somewhat
confused on first awakening, but fully oriented
when Aroused. - Confused pt disoriented to time and place put
usually oriented to person ,with impaired
judgment and decision making. - Delirious pt disoriented to time and place and
person with loss of contact with reality and
often has auditory or visual hallucination. - Lethargic drowsy but follows simple
commands when stimulated, in which the pt needs
an increased stimulus to be awakened. - Comatose may have no response to any
stimulus.
35Clinical Manifestations
- Pain is considered an unpleasant sensory
perception and emotional experience associated
with actual or potential tissue damage or
described in terms of such damage - Seizures are the result of abnormal paroxysmal
discharges in the cerebral cortex, which then
manifest as an alteration in sensation, behavior,
movement, perception, or consciousness
36- Dizziness and Vertigo
- Dizziness is an abnormal sensation of imbalance
or movement.. About 50 of all patients with
dizziness have vertigo, which is defined as an
illusion of movement, usually rotation . Vertigo
is usually a manifestation of vestibular
dysfunction. It can be so severe as to result in
disorientation, loss of equilibrium (staggering),
and nausea and vomiting.
37- Visual Disturbances
- Lesions of the eye itself (eg, cataract), lesions
along the pathway (eg, tumor), or lesions in the
visual cortex (from stroke) interfere with normal
visual acuity. Abnormalities of eye movement can
also compromise vision by causing diplopia or
double vision.
38- Weakness
- Weakness, specifically muscle weakness, is a
common manifestation of neurologic disease. - Abnormal Sensation
- Numbness, abnormal sensation, or loss of
sensation is a neurologic manifestation of both
central and peripheral nervous system disease
39Diagnostic Evaluation
- Computed Tomography Scanning (CT). The images
provide cross-sectional views of the brain, with
distinguishing differences in tissue densities of
the skull, cortex, subcortical structures, and
ventricles.
40- Magnetic Resonance Imaging (MRI) uses a powerful
magnetic field (Can be performed through magnetic
waves which stimulates nuclei of the atoms in the
body ) to obtain images of different areas of the
body - An MRI scan can be performed with or without a
contrast agent and can identify a cerebral
abnormality earlier and more clearly than other
diagnostic tests .
41- It is used to detect CNS tumors, infectious
problem of the CNS - allowing the clinician to monitor a tumor's
response to treatment. It is particularly useful
in the diagnosis of multiple sclerosis .
42Cerebral angiography 1-conventional angiography.
For diagnosis of cerebral aneurysm,, vasospasm,
carotid artery disease. Complication cerebral
embolus, hemorrhage or hematoma at the site of
catheter insertion, vasospasm, thrombosis,
allergic reaction.
43Electrophysiology studies
Electroencephalogram( EEG) It is a
recording of electrical impulses generated by
brain. Purpose include detection of area of
abnormal electrical activity.
44lumber puncture(LP)
A lumbar puncture (spinal tap) is carried out by
inserting a needle into the lumbar subarachnoid
space . The purpose of lumber puncture is to
obtain CSF sample for analysis ( subarachnoid
hemorrhage and infection). It is performed by
insertion of 20 22 gauge needle into the
subarachnoid space at L3-L4 or L4 -L5 level by
putting patient in lateral recumbent position .
45- Usually, specimens are obtained for cell count,
culture, and glucose and protein testing. The
specimens should be sent to the laboratory
immediately because changes will take place and
alter the result .
46PostLumbar Puncture Headache
- Bed rest after procedure is very important to
prevent headache also preventing CSF. - analgesic agents, and hydration. Occasionally,
- Other Complications of Lumbar Puncture
Herniation of the intracranial contents results
from shifting of tissue from one compartment of
the brain to another, spinal epidural abscess,
spinal epidural hematoma
47Intracranial pressure (ICP)
The main components inside the cranium are -
brain tissue (80), blood (10), and
cerebrospinal fluid (CSF (10). So that any
increase in the size of brain tissue or increase
in the volume of the CSF or problem in the blood
vessel (E.g. bleeding into the cranium) will
cause increase in the ICP. The normal ICP in
patients should be less than 15mm Hg.
48- The effect of increase in ICP will cause
neurological deficit (sensory, motor, level of
consciousness) or other problem such as seizure
so that it is important in some patient to
monitor ICP.
49- Cerebral blood flow
- The normal cerebral blood flow (CBF) is 50ml /
100g of brain tissue. - Although brain makes up to 2 of the body
weight but it required 15 to 20 of the resting
cardiac output and 15 of the total bodys oxygen
demands. -
50Assessment and diagnosis
- The main signs and symptoms of increased in ICP
- 1- Decreased in the level of consciousness.
- 2- Cushings triad (bradycardia, systolic
hypertension, and bradypnea). - 3- Diminished brain stem reflexes.
- 4- Papilledema.
- 5- Decerebrate (extension to pain).
- 6- Decorticate (flexion to pain).
51- 7- Unequal pupil size.
- 8- Projectile vomiting.
- 9- Decreased pupillary reaction to light.
- 10- Altered breathing pattern.
- 11- Headache.
52Medical and Nursing management
- 1-positioning and other nursing activities
-
- A-Elevation of the bed up to 30 degree will help
to decrease ICP by encouraging the venous return. - B-Positions that should be avoided are
(trendelenberg, prone, extreme flexion of the hip
53- 2- hyperventilation -
- The rational to hyperventilate patient with high
ICP is to reduce the Paco2 from its normal range
(35-40mm Hg) to a range between 25 and 30
mmHg.wich lead to cerebral arteries
vasoconstriction which lead to decrease in the
CBF and increase in the venous return. - Also prolonged hyperventilation will lead to
ischemia and infarction, so that the new trend is
to maintain Paco2 in the lower side of the normal
(35 2 cm Hg).
54- 4- Blood pressure control -
- Maintenance of arterial blood pressure in the
high normal range is essential in head injured
patients. - Sedation is required to control blood pressure
in the initial phase. - If sedative fail to control blood
pressure, antihypertensive should be administered
(e.g.nitroprusside and nitroglycerin), also we
will use B- blockers (e.g. labetalol or
metoprolol) may be used to overcome the effect of
vasodilation of antihypertensive agent.
55- 3- temperature control
- Cerebral metabolic rate increases 7 per degree
centigrade of increase in the body temperature. - Fever should be avoided and treated aggressively
when occurred by using antipyretic and cooling
device until the cause of fever to be determined - Hypothermia 32to 35-degree C will decrease the
ICP
56- 5- Seizure control -
- The prophylactic use of anticonvulsant is
important in controlling the cerebral metabolic
needs. - The usual medication to be used are phenytoin and
Phenobarbital also lorazepam as a short and fast
acting.
57- 7-Cerebrospinal fluid drainage
- 8- diuretic
- a-Osmotic diuretic.
- The widely used medication is mannitol (it will
improve perfusion to ischemic areas of the brain
and decrease intracerebral edema that caused by
the injury by its osmotic effect. - Side effect electrolyte imbalance
58- Nonosmotic diuretic -
- The most widely used is furosemide
- Maintain euvolemic state to maintain and
optimize cerebral perfusion.
59- 9- control of metabolic demand
- There are some noxious stimuli that lead to
increase ICP pain, presence of end tracheal
tube, coughing suctioning, repositioning,
bathing. - There are many agent are used to decrease
metabolic demand benzodiazepines( midazolam.
Lorazepam), sedative hypnotic (propofol),
opioid narcotic (phentanyl and morphine), and
neuromuscular blocking agents (atracurium and
vecuronium)
60Stroke
Is a descriptive term for the onset of acute
neurological deficit persisting for more than
24 hours and caused by interruption of blood flow
to the brain.
61(No Transcript)
62(No Transcript)
63Ischemic Stroke
- An ischemic stroke, cerebrovascular accident
(CVA), or brain attack is a sudden loss of
function resulting from disruption of the blood
supply to a part of the brain.
64(No Transcript)
65(No Transcript)
66- Modifiable risk factors for ischemic stroke
include - Hypertension
- atrial fibrillation
- hyperlipidemia
- obesity
- smoking
- diabetes
67Clinical Manifestations
- Numbness or weakness of the face, arm, or leg,
especially on one side of the body - Confusion or change in mental status
- Trouble speaking or understanding speech
- Visual disturbances
- Difficulty walking, dizziness, or loss of balance
or coordination - Sudden severe headache
68- Motor, sensory, cranial nerve, cognitive, and
other functions may be disrupted - Motor Loss
- hemiplegia (paralysis of one side of the body)
caused by a lesion of the opposite side of the
brain. Hemiparesis, or weakness of one side of
the body, is another sign.
69Communication Loss
- Other brain functions affected by stroke are
language and communication. In fact, stroke is
the most common cause of aphasia. - Dysarthria (difficulty in speaking), caused by
paralysis of the muscles responsible for
producing speech - Dysphasia (impaired speech) or aphasia (loss of
speech), which can be expressive aphasia,
receptive aphasia, or global (mixed) aphasia
70- Apraxia (inability to perform a previously
- learned action)
- Visual-perceptual dysfunctions. hemianopsia (loss
of half of the visual field) - Sensory Loss
- Agnosias are deficits in the ability to
recognize previously familiar objects perceived
by one or more of the senses.
71Assessment and Diagnosis
1- The characteristics signs of an ischemic
stroke is a sudden onset of focal neurologic
signs persisting for more than 24 hours. 2-
Presence of hemiparesis, aphasia,
hemanopsia. 3-Change in level of
consciousness usually occur with brainstem or
cerebellar involvement ,seizure, hypoxia,
hemorrhage, increased ICP. 4-Brain CT
without contrast. 5- ECG, chest X-ray,
continuous cardiac monitoring, arterial blood
gases.
72Assessment and Diagnostic Findings
- Any patient with neurologic deficits needs a
careful history and a complete physical and
neurologic examination. - The characteristics signs of an ischemic stroke
is a sudden onset of focal neurologic signs
persisting for more than 24 hours
73- - Presence of hemiparesis, aphasia, hemanopsia.
- -Change in level of consciousness usually occur
with brainstem or cerebellar involvement ,seizure
,hypoxia, increased ICP.
74- Initial assessment focuses on airway patency,
which may be compromised by loss of gag or cough
reflexes and altered respiratory pattern
cardiovascular status (including blood pressure,
cardiac rhythm and rate) and gross neurologic
deficits -
75- Patients may present to the acute care facility
with temporary neurologic symptoms. - A transient ischemic attack (TIA) is a neurologic
deficit lasting less than 24 hours, with most
episodes resolving in less than 1 hour
76- . A TIA is manifested by a sudden loss of motor,
sensory, or visual function. The symptoms result
from temporary ischemia (impairment of blood
flow) to a specific region of the brain. - A TIA may serve as a warning of impending stroke.
Lack of evaluation and treatment of a patient who
has experienced previous TIAs may result in a
stroke and irreversible deficits
77- The initial diagnostic test for a stroke is a
noncontrast (CT) scan performed emergently to
determine if the event is ischemic or hemorrhagic
. - A 12-lead (ECG) and a carotid ultrasound are
standard tests
78(No Transcript)
79Medical Management
Thrombolytic agent( rt-PA)which is given
intravenously is recommended within 3 hours of
onset of ischemic stroke, also age should be
greater than 18 years old according to the
national institute of neurologic disorders and
stroke( NINDS). The recommended dose is
0.9 mg / Kg up to the maximum dose of 90 mg, 10
of the dose is administered as an initial
intravenous bolus over 1 minute, the remaining
90 is administered by intravenous infusion over
60 minute. Patient who receive
thrombolytic therapy for stroke should not
receive aspirin, heparin, warfarin, ticlodipine
for at least 24 hours after treatment.
80- Patients who have experienced a TIA or stroke
should have medical management for secondary
prevention. - Platelet-inhibiting medications, including
aspirin, clopidogrel (Plavix), and ticlopidine
(Ticlid), decrease the incidence of cerebral
infarction in patients who have experienced TIAs
and stroke from suspected embolic or thrombotic
causes .
81Therapy for Patients With Ischemic Stroke Not
Receiving t-PA
- Other treatments may include anticoagulant
administration (IV heparin or low-molecular-weight
heparin). - Interventions during this period include measures
to reduce ICP, such as administering an osmotic
diuretic (eg, mannitol), maintaining the partial
pressure of carbon dioxide (PaCO2) within the
range of 30 to 35 mm Hg, and positioning to avoid
hypoxia
82 Blood pressure in some cases must not
be lowered because it will affect the cerebral
perfusion pressure. antihypertensive
therapy is considered only if the diastolic blood
pressure is greater than 120 mmHg or the systolic
BP is greater than 220mmHg. Blood
pressure should be 180/105 mmHg to prevent
intracranial hemorrhage. Intravenous
labetalol and nitroprusside is used to achieve BP
control. Treatment should include
controlling cerebral edema or seizure activity.
but prophylaxis for these complication is not
recommended.
83Hemorrhagic Stroke
- Hemorrhagic strokes account for 15 to 20 of
cerebrovascular disorders and are primarily
caused by intracranial or subarachnoid
hemorrhage. Hemorrhagic strokes are caused by
bleeding into the brain tissue, the ventricles,
or the subarachnoid space .
84 Intracerebral hemorrhage
Is a bleeding directly into the brain
tissue. It will destroys cerebral tissue
causes cerebral edema, and
increaseICP. Causes
include . 1- the most important cause is
hypertension 2- rupture of AVM or aneurysm.
. 3-. rupture of small artery . 4-patients
who receive anticoagulant or thrombolytic
therapy. . 5-coagulation disorders. .
6-drug abuse . 7-hemorrhage into cerebral
infarct or brain tumor
85- An intracerebral hemorrhage (ICH) is bleeding
within brain tissue. - An ICH may be associated with other brain
injuries, particularly contusions .
86(No Transcript)
87Assessment and Diagnostic Findings
- Any patient with suspected stroke should undergo
a CT scan to determine the type of stroke, the
size and location of the hematoma, and the
presence or absence of ventricular blood and
hydrocephalus. - CT scan and cerebral angiography confirm the
diagnosis of an intracranial aneurysm or AVM
88Clinical Manifestations
- Clinical Manifestations
- The patient with a hemorrhagic stroke can present
with a wide variety of neurologic deficits,
similar to the patient with ischemic stroke.
89 Medical Management
1. airway , breathing, and circulation.
2. reduction of blood pressure is necessary
to decrease ongoing bleeding, but lowering
blood pressure too much or too rapid may
compromise cerebral perfusion pressure(CPP).
3. MAP should be below 130 mmHg in patients
with a history of hypertension, and 110 mmHg
after surgical treatment of ICH. 4. if
there is increase in ICP, recommended therapy is
mannitol, hyperventilation, neuromuscular
blockade with sedation.
90- . steroids are avoided.
- surgery is required in patient with hydrocephalus
associated with cerebellar hemorrhage that
compress brain stem or young patient with
moderate or large hemorrhage with clinical
deterioration
91Subarachnoid hemorrhage
- it is the bleeding into the subarachnoid space(
CSF circulation). - causes of subarachnoid hemorrhage-
- 1- rupture of cerebral aneurysm.
- 2- Arteriovenous malformation.
- 3- Trauma.
- Risk factors hypertension, smoking, alcohol
abuse , and stimulants use.
92Subarachnoid hemorrhage
- Traumatic subarachnoid hemorrhage (SAH) is caused
by bleeding into the subarachnoid space.
93(No Transcript)
94Etiology
- Cerebral aneurysm rupture account 85 of
subarachnoid hemorrhage. Also 90 of aneurysms
are congenital. - Rupture of cerebral aneurysm occur during the
fifth and sixth decades of life. - arteriovenous malformation(AVM) rupture is
responsible for less than 10 of subarachnoid
hemorrhage.
95- AVM are congenital tangled mass of arterial and
venous blood vessels that shunts blood directly
from the arterial side into the venous side
96 Assessment and diagnosis
- 1-HEADACHE( WORST HEADACHE IN MY LIFE)
- 2-BRIEF LOSS OF CONSCIOUSNESS.
- 3-NAUSEA AND VOMITING
- 4-FOCAL NEUROLOGICAL DEFICIT.
- 5-STIFF NECK
- 6-PHTOPHOBIA
97DIAGNOSTIC TESTS
- 1- CT scan initially done to verify diagnosis.
- 2- lumbar puncture to take CSF sample for
analysis if the CT scan is negative. - 3- magnetic resonance angiogram(MRA)and magnetic
resonance venogram(MRV). - 4- catheterization cerebral angiography.
98Medical management
- the goal of treatment is preservation
neurological function. - Airway management and ventilatory assistance may
be necessary. - Venticulostomy is performed to control ICP if the
patients develop deterioration in the level of
consciousness with hydrocephalus. - Control of blood pressure by maintaining systolic
blood pressure no greater than 150mmHg and
prevent hypotension.
99- prophylactic anticonvulsants must be prescribed.
- Maintain normal blood volume by giving
intravenous fluid to expand blood volume to
prevent vasospasm, and maintain adequate cerebral
perfusion. - Nimodipine cause vasodilatation of cerebral
vessel , in doses 60 mg every 4 hours for 21 days
100(No Transcript)
