Bloodstain Pattern Analysis

1
Bloodstain Pattern Analysis
2
Summary

• What is Blood?
• Determining Distance of Blood
• Determining Direction of Blood
• Types of Blood Stain Patterns

3
What is Blood?
4
Introduction to Blood
5
Blood Spatter (or splatter)

• Blood drops form different shapes and sizes

Blood spatter analysis uses the shapes and sizes
to reconstruct the crime scene.
6
Blood Spatter gt Distance

• Determining Distance Blood Falls

Blood drops fall as small spheres
7
Blood Spatter gt Distance

• Determining Distance Blood Falls

• Drops form circle when hitting surface
• Size depends on speed of blood drop

8
Blood Spatter gt Distance

• Determining Distance Blood Falls

Faster drop larger diameter (size) Higher
distance larger diameter
Due to air resistance, speed maxes out at
distances above about 7 feet
9
Blood Spatter gt Distance

• Determining Distance Blood Falls

However, size of drop also depends on the volume
of the drop.
Volume depends on the object blood originated
from (needle small bat large).
10
Blood Spatter gt Distance

• Determining Distance Blood Falls

Since the volume of blood is unknown
The distance a drop has fallen cannot be measured.
11
Blood Spatter

• Effect of Surface

• Smooth surface smooth sphere
• Rough surface may cause some splatter

12
Blood Spatter gt Direction

• Determining Direction of Blood

Narrow end of a blood drop will point in the
direction of travel.
13
Blood Spatter gt Direction

• Determining Direction of Blood

If more than one drop (from spatter) results, the
point of origin can be determined
14
Blood Spatter gt Direction

• Determining Direction of Blood

If more than one drop (from spatter) results, the
point of origin can be determined
15
Blood Spatter gt Direction

• Determining Direction of Blood

This is a 2-dimensional point of origin. It is
possible to determine the 3-D point of origin
16
Blood Spatter gt Direction

• Determining Direction of Blood

• The angle can be determined mathematically.
• Width/Length, then take the inverse sin (sin-1).
• This number is the impact angle (90
  perpendicular to surface lt10 at a sharp angle)

17
Blood Spatter gt Direction

• For each blood drop, a string can be guided back
  to the point of origin.

18
Blood Spatter

• Types of Spatter

• Spattered Blood random distribution of
  bloodstains that vary in size

• Amount of blood and amount of force affect the
  size of blood spatter.

• Can result from gunshot, stabbing, beating

19
Blood Spatter

• Spattered Blood can

• Help determine the location of the origin of the
  blood source.

• Help determine the mechanism which created the
  pattern.

20
Blood Spatter

• Spattered Blood

In general, for higher impacts, the pattern is
more spread out and the individual stains are
smaller.
Low impact beating High impact gunshot
21
Blood Spatter

• Types of Spatter

Gunshot Spatter can result in a mist-like
spatter that indicates a gunshot.

• Not all gunshots will result in misting.

• If misting is present, it is most likely a
  gunshot.

22
Blood Spatter

• Gunshot Spatter

Gunshots result in back spatter (where bullet
enters) and forward spatter (where bullet exits).
23
Blood Spatter

• Types of Spatter

Beating and Stabbing Spatter larger individual
stains
First blow usually doesnt result in spatter
since there is not yet any exposed blood.
24
Blood Spatter

• Types of Spatter

Satellite Spatter free falling drops of blood
that fall onto a spatter pattern.

• These drips are usually much larger than impact
  spatter.

• However, blood dripping into blood can create a
  spatter.

25
Blood Spatter

• Types of Spatter

Castoff Pattern Blood flung off of swinging
object.
Can reconstruct where assailant and victim were
positioned.
26
Blood Spatter

• Types of Spatter

Expirated Bloodstain Pattern Blood can
accumulate in lungs, sinuses, and airway.
Forcibly exhaled.

• Can appear like beating or gunshot pattern.

• May be mixed with saliva or nasal secretions.

27
Blood Spatter

• Alteration of bloodstain over time

• Blood dries and clots over time.
• Difficult to estimate the time the blood exited
  the body.
• Clotted smears can indicate time of movement.
