1AWIPS Continuous Technology Refresh (CTR)AWIPS
Software CTR
- AWIPS TO11-Slice 3 ReadMe
- June 3, 2009
2AWIPS TO11-D3 ReadMe
- Install and minimum hardware requirements
(Supported System Configs) - How To configure information
- Architecture and Software Design Update
- Programmers Update
- Build Status
- Future Slice Capabilities for Early Evaluation
3AWIPS Installers for Standalone Workstation
Simplest, Complete AWIPS environment (limited
dataflow)
Install
AWIPS_Standalone_Deployment_FlowTag_RevTO11d3.doc
- Developers Standalone Workstation
- 2G minimum memory (4G recom.)
- Graphics OpenGL 2.0 or better with 256Mb RAM
- 80G Disk Space
Note Assumes Standard AWIPS Workstation running
RHEL 5u2 with RPMs and configuration as per OB9.1
Note Slice 3 Requires RPM for python
numpy compat-libf2c-34-3.4.6-4.i386.rpm Goes away
in Slice 4 with libraries rebuild.
Eclipse IDE
PostgreSQl
terraCotta
EDEX_esb
CAVE
Install Flow Tags
ade-installer.jar
/home/awips/workspace /home/awips/cave /home/awips
/caveData
cave-installer.jar
Edex Logs /awips/edex/logs
radarserver-installer.jar
/RadarServer /awips/ /awips/fxa/bin
edex-installer.jar
cli-installer.jar
4AWIPS Installers for Servers Minimum to support
continuous WFO data flow
Install
AWIPS_Standalone_Deployment_FlowTag_RevTO11d3.doc
AWIPS_Cluster_Deployment_FlowTag_RevTO11d3.doc TO1
1d3_Install.pdf
- Server (AWIPS PX equivalent)
- 4G minimum memory (4G recom.)
- 200G Disk Space
Note Assumes Standard AWIPS Server running RHEL
5u2 with RPMs and configuration as per OB9.1
Note Slice 3 Requires RPM for python
numpy compat-libf2c-34-3.4.6-4.i386.rpm Goes away
in Slice 4 with libraries rebuild.
PostgreSQl
terraCotta
EDEX_esb
Disk Partitions
Edex Logs /awips/edex/logs
Install Flow Tags
radarserver-installer.jar
/RadarServer /awips/ /awips/fxa/bin
edex-installer.jar
cli-installer.jar
5T011-D3 How To Configure
How To Configure
- Instructions on how to localize WarnGen and
WarnGen Templates - Documents included on Resources Disk
- AWIPS II Warngen Localization,
WarnGen_Localization.pdf - AWIPS II Warngen Templates, WarnGen_Templates.pd
f
6AWIPS-II Reference ArchitectureBased on Plug In
extensible services
Architecture / SW Design Update
AWIPS-II Reference Architecture
Enterprise Service Bus (ESB)
ltltService Framework gtgt EDEX
ltltVisualization Framework gtgt CAVE
Core Generic Services
Eclipse RCP PlugIns Data Animation
GIS Raster Rendering Data Editing
GIS Vector Rendering Data Analysis
GIS Point Rendering Drawing
Ingest Service Persist Service
Metadata Service Subscription Service
Request/Transform Service Adapter Service
Collaboration Service Disseminate
Plug In Pattern
VIZ Plugins
Meta Data
VIZ Scipts
Data
Core Libraries
Data Types
Custom Displays
Libraries
Libraries
Scripts
Scripts
7AWIPS Services and Plug InsESB SOA Plug In
Adaptable TO11-D3 Set
Architecture / SW Design Update
Future
Eclipse RCP Visualization Plug Ins
Dissemination
Improved for T011-D3
SmartInit
Index
HdfHttp
Subsribe
New for T011-D3
purge
VTEC
Persist
ScriptRun
TextDB
Notify
GfeSrv
GFE
Utility
AutoBld
Product
py
CAVE
Proxy
Camel-Spring AWIPS Services
Thick /Light Client Mode
/Light
SOA Data Type Plug Ins
Enterprise Service Bus
8T011-D3 WarnGen WarnGen Backup
Build Status
Life Cycle Rules
DisseminationSrv
Warning
WarnGen GUI
templates.vm
config-files.cfg
DisseminationManager
GIS Capabilities Warning by PolyGon
UPDATE LIST
TextDB
VTEC Database
Store
Set VTEC
Generate Text
Send to TextWS
Text Workstation Editor
- Practice mode available for life cycle testing
9T011-D3 HydroView XNAVTimeseries and Point
Data Control
Build Status
HydroBase Dam Catalog River Monitor
Common Maps with D2D, GFE, MPE .
Reuses CAVEs common graphics infrastructure
10T011-D3 ACARSPoint decoder and profile builder
Build Status
- Decodes and stores the basic point data into the
PostgreSQL metatdata database (Com.raytheon.uf.ede
x.plugin.acars) - Wired to run periodically off a quartz timer to
develop sounding profiles from ingested ACARS
data (Com.raytheon.uf.edex.plugin.acarsounding) - Soundings are inserted into metadata database
tables - Rendering is included in D5 as part of Volume
Browser - Variance suggested to make data more useable
- Clickable map display of aircraft tracks - bring
up the Skew-T profile - Known issue with data prep, rest of system
unaffected
11AWIPS SOA Datatype Plug In
Build Status
Plug In Name Metoc Data Types Metadata Tables HDF5
plugin-acars.jar acars parsed aircraft acars
plugin-acarssounding.jar acars sounding acarssounding, acarsbuilder, acarssoundinglayer
plugin-airep.jar airep parsed aircraft airep
plugin-binlightning.jar bin lighting binlighting hdf5/binlighting
plugin-bufrmos.jar bufr MOS bufrmos hdf5/bufrmos
plugin-bufrua.jar bufr RAOB bufrua, bufrua_obs_level0
plugin-ccfp.jar ccfp text ccfp
plugin-gfe.jar gfe gribs gfe, gfe_spatial, gfegridhistory, gfelocktable hdf5/gfe
plugin-goessounding.jar goes sounding goessounding, goessoundinglevel
plugin-grib.jar grib models grib, grib1_parameters, grib2_parameters, grib_levels, grib_models, grib_spatial hdf5/grib
plugin-mesowest.jar meso net mesowest
plugin-modelsounding.jar model soundings modelsounding, modelsoundinglevels, modelsoundingsoillevels
plugin-obs.jar metars parsed obs, obs_sky_cover, obs_weather
plugin-pirep.jar pirep parsed aircraft pirep, pirep_anc_data
plugin-poessounding.jar poes sounding poessounding, poessoundinglevel
12AWIPS SOA Datatype Plug In Continued
Build Status
Plug In Name Metoc Data Types Metadata Tables HDF5
plugin-profiler.jar profiler profiler, profiler_levels
plugin-qpf.jar quantitative precip forecast qpf
plugin-radar.jar Radar radar, radar_spatial hdf5/radar
plugin-recco.jar recco recco
plugin-redbook.jar redbook graphics redbook hdf5/redbook
plugin-satellite.jar satellite satellite, satellite_creating_entities, satellite_physical_elements, satellite_sector_ids, satellite_sources, satellite_spatial, satellite_units hdf5/satellite
plugin-sfobs.jar synoptic, maritime sfcobs, sfcobs_anc_cloud, sfcobs_anc_precip, sfcobs_anc_pressure, sfcobs_anc_temp, sfcobs_anc_wave, sfcobs_anc_wind
plugin-shef.jar shef hydro Posts to IHFS directly
plugin-taf.jar taf parsed taf, taf_change_groups, taf_icing_layers, taf_sky_cover, taf_temperature_forecasts, taf_turbulence_layers, taf_weather_conditons
plugin-text.jar raw text Post to TextDB direcly
plugin-warning.jar warnings warning, warning_ugczone
13T011-D3 AWIPS RadarLevel 3 products decoded and
renderable from Classic Browser
Build Status
Radar Product Name (Mnemonic, Code) TO11 Slice Comment
Reflectivity (Z, 19) D1 Planned for D5
Velocity (V, 27) D1 Planned for D5
Storm Rel Velocity (SRM, 56) D1 Planned for D5
Composite Ref (CZ, 37, 38) D1 Planned for D5
Lyr Comp Ref Max (LRM, 65) Level 1 D1 Planned for D5
Lyr Comp Ref Max (LRM, 66) Level 2 D1 Planned for D5
Lyr Comp Ref Max (LRM, 90) Level 3 D1 Planned for D5
Lyr Comp Ref MAX (APR, 67) D1 Planned for D5
Echo Tops (ET,41) D1 Planned for D5
Vert Integ Liq (VIL, 57) D1 Planned for D5
One Hour Precip (OHP, 78) D1 Planned for D5
Storm Total Precip (STP, 80) D1 Planned for D5
VAD Wind Profile (VWP, 48) D1 X-Y Graphic of wind barbs Planned for D5
Digital Precip Array (DPA, 81) D1 Hydro has its own DPA decoder delivered in TO10 Planned for D5
Velocity (V, 25) D1 Planned for D5
Base Spectrum Width (SW, 28, 30) D1 Planned for D5
Severe Weather Probability (SWP, 47) D2 Ingested Decoded but not rendered Planned for D5
14AWIPS Radar ContinuedLevel 3 products decoded
and renderable from Classic Browser
Build Status
Radar Product Name (Mnemonic, Code) TO11 Slice Comment
Storm Tracking Information (STI, 58) D1 With special graphical rendering Planned for D5
Hail Index (HI, 59) D1 With special graphical rendering Planned for D5
Mesocyclone (M, 60) D1 Planned for D5
Mesocyclone (MD, 41) D1 Echo Tops Planned for D5
Tornadic Vortex Signature (TVS, 61) D1 Planned for D5
Storm Structure (SS, 62) D2 Planned for D5
Supplemental Precipitation Data (SPD, 82) D5 Text product
Reflectivity (Z, 94) D1 Planned for D5
Velocity (V, 99) D1 Planned for D5
Super Res Reflectivity (Z, 53) D3 Planned for D5
Super Res Velocity (V, 54) D3 Planned for D5
Super Res Spec Width (SW, 55) D3 Planned for D5
Spectrum Width (SW, 30) D5
Digital Vert Integ Liq (DVL, 34) D1 Planned for D5
Digital Hybrid Scan Refl (DHR, 32) D5
Enhanced Echo Tops (EET, 35) D2 Planned for D5
Digital Meso Detection (DMD, 49) D2 Planned for D5
15AWIPS Radar ContinuedLevel 3 products decoded
and renderable from Classic Browser
Build Status
Radar Product Name (Mnemonic, Code) TO11 Slice Comment
TVS Rapid Update (TRU, 43) D2 Planned for D5
User Selectable Lyr Refl (ULR, 37) D1 Planned for D5
Storm Total Precip (STP, 38) D2 Planned for D5
1-Hour Snow Water Equiv (OSW, 44) D2 Planned for D5
1-Hour Snow Depth (OSD, 45) D2 Planned for D5
Storm Tot Snow Depth (SSD, 47) D1 Planned for D5
Storm Tot Snow-Water Equiv (SSW, 46) D5
Text Products to TextDB D5
Status Message to AlertViz D5
Radar Mosaic D5
Radar Menu Hook Up D3D5 First Cut in D2 using new CAVE menu add pattern Planned for D5
Note New CAVE menu-add-pattern simplifies
building large menu systems such as radar (gt500
items). Also, enables the same menu system to be
used for all radars by passing in parameters.
(Planned for Slice 5)
16Deliverables Checklist Update
Build Status
- See Separate Spreadsheet TO11 Deliverables
Checklist v21-D3.xls
17Future Slice Capabilities for Early Evaluation
Early Evaluation
Raytheon requests an evaluation of the progress
were making on several key application(s)
scheduled for future slices. Please keep in mind
that the applications below are not complete at
this time.
Application Capability Del. Slice DRs/MDM Sections to Test
GFE 5 1260, 1455, 1462, 1935
D2D/CAVE/Radar 4-5 955, 2273
Observations 4 2225, 2338 MDM sections 2.1.7.1-2.1.7.6
Satellite 4 2215, 2409
DR summaries, descriptions, and test procedures
are included in the daily DR report
