Title: Grids generation methods and adaptive meshes


1
Grids generation methods and adaptive meshes
Pawel Cybulka Finite element method
2
Plan presentation
  • Grid generation
  • mesh types,
  • grids generation methods.
  • Adaptive finite element method
  • phadaptivity,
  • error estymator,
  • hierarchical grids.

3
Mesh types
  • Mesh types are varied as the numerical
    methodologies they support, and can be classified
    according to
  • conformality
  • surface or body alignment
  • topology
  • element type.

4
Conformality
  • Conformal meshes are characterized by a perfect
    match of edges and faces between neighbouring
    elements.
  • Non-conforming meshes exhibit edges and faces
    that do not match perfectly between neighbouring
    elements, giving rise to so-called hanging nodes
    or overlapped zones.
  • Figure 1. a) conforming mesh, b) non-conforming
    mesh.

5
Surface or body alignment
  • Surface or body alignment is achieved in those
    meshes whose boundary faces match the surface of
    the domain to be gridded perfectly. If faces are
    crossed by the surface, the mesh is denote as
    being non-aligned.
  • Figure 2. a)surface aligned, b)non-surface aligned

6
Mesh topology
  • Mesh topology denote the structure or order of
    the elements. There are three possibities
  • Micro-structured, each points has the same number
    of neighbours .
  • Micro-unstrutured, each point can have arbitrary
    number of neighboures
  • Macro-unstrutured, micro-structured, where the
    mesh is assembled from groups of micro-structured
    subgrids

7
Element type
  • Typical element types for 2D domains are
    triangles and quads, and tetrahedra, prisms and
    brick for 3D domains.
  • Figure 3. Element types

8
Description of the domain to be gridded
  • There are two possible ways of describing the
    surface of a computational domain.
  • Using analytical functions. This is the preferred
    choice if a CAD-CAM database exists for the
    description of the domain. Typical data types
    splines, B-splines, non-unifom rational B-splines
    (NURBS) surfaces. Important characteristic of
    this approach is that the surface is continuous,
    there are no holes in the information.
  • Via discrete data. When we get a cloud of points
    or an already existing surface triangulation
    describes the surface of the computational
    domain. Examples are remote sensing data, medical
    imaging data, data sets from computer games.

9
Typical grid generation methods
  • Structured mesh
  • simple mappings
  • multiblock.
  • Unstructured mesh
  • quadtree(2D) and octree(3D)
  • the advancing front technique (AFT)
  • Delaunay triangulation.

10
Simple mappings
  • The computational domain can be mapped into the
    unit square or cube. The distribution of points
    and elements in space is controlled either by an
    algebraic function, or by solution of a partial
    differential equation in the transformed space.
  • Figure 4. Structured meshes built on the base of
    various coordinate system a) Cartesian
    coordinate system, b) cylindrical system, c)
    combination of various coordinate system

11
Multiblock grid
  • Multiblock grid is based on division of
    difficult to discretization area into several
    areas which are simpler to discretization and,
    then proper connection of these areas. There are
    some variations of this strategy including
    overset method, patched multiblock, composite
    multiblock. These methods differ depending on the
    way of connection of the subareas into the whole.
  • Figure 5. Grids generated by various multiblock
    methods a) overset mesh combination b) composite
    mesh combination.

12
Quadtree and octree mesh methods
  • Quadtree and octree are a simple method where all
    domain is mapping by quads(2D) or bricks(3D). In
    the next step all quads containing the boundary
    points are divided into four parts whereas bricks
    are divided into eight parts. This process is
    repeated by the moment when all boundary points
    are closed in the least quads or bricks. The size
    of the least quads is given by a user. In the
    last step all quads are transformed into
    triangles.
  • Figure 6. Scheme of grid generation by quadtree
    method, a)quadtree grid after thicken, b) quatree
    grid after division of quads into triangles.

13
The advancing front technique (AFT)
  • The principle of this method is based on the
    so-called front created with the points located
    on discretized boundary of domain. Properly
    connected points form sides so that continuous
    area boundary is replaced by a set of sides ( the
    line segments in the case of 2D and triangles in
    the case of 3D) creating a closed loop. Then,
    elements are built in accordance with the
    established direction in loop on the basis of
    existing set of sides and possibly added points.
    How will create another element (figure 7)
    depends on a angle between two following sides
    from the front.

14
The advancing front technique (AFT)
  • How to combine elements depending on a angle
  • a lt 90 a new element is built (created from
    existing points),
  • 90 lt a lt 120 a new point is added and two
    elements are created,
  • 120 lt a a new point is added and one element is
    created.
  • Figura 7. The principle of conduct during the
    construction of the grid by AFM

15
Delaunay triangulation
  • Delaunay algorithm for triangulation starts by
    forming the super triangle enclosing all the
    points from set V that has to be triangulated.
    Then, incrementally, a process of inserting the
    points p into the set V is performed. After every
    insertion step a search is made to find the
    triangles whose circumcircles enclose p.
    Identified triangles are then deleted from the
    set. As a result, an insertion polygon containing
    p is created. Edges between the vertices of the
    insertion polygon and p are inserted and form the
    new triangulation.
  • Figure 8. The Delaunay triangulation technique

16
Convergence of FEM
  • Using the FEM computation approximate results are
    received. The accuracy of the approximation can
    be computed using the formula
  • u ua lt Chp u
  • u accurate solution,
  • ua FEM solution ( approximate),
  • h the size of elements,
  • p the degree of approximation.
  • Therefore the accuracy of the FEM solution
    depends on the
  • size of elements,
  • the degree of the function approximation.

17
Influence of the number of elements and the
degree of approximation of functions on the
accuracy of the FEM calculations
18
Adaptive finite element method
  • The idea behind AFEM is to make local
    hp-adaptivity based on local error analysis.
  • The aim is to obtain sufficient accuracy of the
    result at the smallest computation cost.

19
H - adaptivity
  • H - adaptation is the process of changing the
    concentration of elements in the area calculation
    in order to change the accuracy of the
    computation carried out there.
  • Typically, h-adaptation is associated with
    thickening of areas of high variability of the
    analyzed qualities by what the calculation error
    is minimized in this area.
  • Figure 9. H-adaptation elements on the grain
    boundaries.

20
P - adaptivity
  • The accuracy of the results obtained in the
    domain increases or decreases by increasing or
    decreasing the degree of approximation of
    function of shape in the elements.
  • In the case of p-adaptivity we need to draw
    attention to the proper connection of elements
    with higher degree of approximation with
    neighbouring elements with a lower degree of
    approximation. Provided the correct computation
    is the continuity of approximation. Therefore,
    approximation of the function corresponding to
    the side of element adjacent to the element with
    a higher degree of approximation should be raised
    to the same degree.

21
Error estimation
  • Error estimation is a way to evaluate the error
    occurs in a given computation domain.
  • Error estimation includes a criterion defining
    the degree of adaptivity that must be used in
    order to obtain the assumed accuracy of
    computation.
  • The criterion of adaptation Ei may be defined as
    the second derivative normalized after medium
    gradient test variable value.
  • Ui - test variable value
  • cn depends on chosen algorithm for the
    solution of the physical problem

22
Error estimation
  • One of the simpler and more frequently used error
    estimations is estimation as shown in Figure 10.
    In the first step of the algorithm gradients
    value in each element is computed. Then we
    compare the values of the adjacent elements. If
    the difference between neighbouring elements
    exceeds the determined threshold the elements are
    divided.
  • Figure 10. Schematics of a simple error estimator

23
Hierarchical grids
  • Hierarchical grids were formed for adaptive
    finite element methods. Their structure
    corresponds to all needs associated with
    hp-adaptivity.
  • The algorithm of hierarchical grids reminds
    quadtree (2D) and octree (3D) methods.
  • The starting point for hierarchical grids are
    grids created by the grid generator. The elements
    of this grid are called parents. Each of the
    parent can be divided into proper number of
    identical in terms of the shape children. Each
    child can be a parent. Thus we have possibility
    of any compacting the grid.
  • Each element in the hierarchical grid knows its
    parent and its children by what the grid can be
    easily thicken and thin.

24
Hierarchical grid
  • Figure 11. The schema of the hierarchical
    structure of an adaptive numerical grid

25
Summary
  • The grids are a very important element in the
    computation using finite element method. They
    determine the accuracy of the computations
    carried out and the time of their performance.
  • Adaptive finite element method based on
    hierarchical meshes and local error estimation
    enables to carry out of an approximation only in
    these areas where it is required. Thanks to it
    accurate results are obtainedat the smallest
    cost computation.

26
LITERATURE
  • Löhner R., 2008, Applied Computational Fluid
    Dynamics Techniques An Introduction Based on
    Finite Element Methods, Second Edition, John
    Wiley Sons, Ltd, Chichester.
  • Joe F. Thompson, Bharat K. Soni, Nigel P.
    Weatherill, Handbook of Grid Generation, CRC
    Press, 1998.
  • Banas K. Metoda Elementów Skonczonych, Seminarium
    BJT CM UJ, 2006.

27
