Modern Approaches to Application and Data Integration

1
Modern Approaches to Application and Data
Integration
2
Quantifying the Legacy Challenge

• The vast majority of the application portfolio
  will be custom and legacy systems. On average,
  users of EAI systems utilize 2.3 prebuilt
  adapters, but one year into the implementation
  they are connecting 5 or more systems. (Meta
  Group)
• 40 of all new application development is spent
  on accessing existing data sources. (IDC)
• It is estimated that 80 of corporate data is
  held in hierarchical and network DBMS. (Butler
  Group)
• Median number of databases within a company is
  14.7 (Gartner)

• Legacy application and data integration
  represents over 50 of the multi-billion dollar
  software integration market

3
Integration Drivers

• Web Services
• Standard interfaces to invoke application and
  data services regardless of underlying technology
  will ease integration
• J2EE Application Servers
• Functionality overlaps with integration brokers
  (e.g. messaging, transaction, security,
  transport)
• JCA Standard
• Proprietary application adapters a distant memory
  ala ODBC
• Process Integration
• Move from how to integrate to what to integrate
  and support assembly of services

4
Integration Evolution
Move from integration broker hubs

• Proprietary adapter frameworks
• All resources routed through IB
• Document-centric, emphasis on
  transformation

To service-oriented bus architecture

• Standard interfaces and registry
• Loosely-coupled integration
• Assembly of services to create automated
  business processes

5
Interoperability
Marketplaces
Customers
Suppliers
Partners
UDDI/ebXML
Integration Brokers
Application Servers
New Applications
HTTP/S SOAP JMS C-API
SOAP/JMS/JDBC
SOAP/JMS/JDBC
JMS/JCA/JDBC
BPI
COM CORBA RMI JMS JDBC JNDI JCA
XML JDBC ODBC
XML JCA SOAP
JCA
App Connect
Data Connect
JCA Adapters
JCA
JCA
RDB
Data/ NRBD
Files
Service
Legacy
ADK (3GL)
Packaged Apps
BPI
Packaged Apps
6
Service-Oriented Integration

1. Wrap services into the service repository (using
   wizards)

1. Assemble services into business functions or
   compound application (drag and drop)

1. Automate information flow (process designer)

1. Use multiple channels to expose services to
   consumers (internal/external)

1. Apply changes rapidly

CICS
COM/CORBA
JNDI/JMS
HTTP/SOAP
App Server
MF
SAP
Web
Inventory
OrderMgmt
Fin/Credit
Purchasing
7
Example
8
From Process to Web Service
9
Service-Oriented Integration Requirements

• Rapid process assembly and automation
• Modeling, design and implementation
• Wraps disparate services into a repository,
  making them seamlessly available and reusable
• Multiple interaction channels
• Service factories to a multitude of application
  and technology domains
• Portable and independent XML based programming
  model
• Distributed deployment (scalable, reliable,
  available)

10
The Integration
Spaghetti
11
One Data Bus
12
Bus Architecture
Virtual Database
Virtual Database
13
A Single Transparent Data Source
Virtual Database
14
Keep to the Standards

• Distributed bus architecture for data and
  application integration
• XML-based metadata, transformation and transport
• Heterogeneous data integration
• Virtual Database where single statement can
  span multiple data sources and platforms
• Unique query optimization and caching technology
• Transaction management
• Legacy application integration
• Adapters to CICS, IMS/DC, COM, Natural
• ADK to encapsulate C/Basic/Cobol/Fortran
  structures
• Standard Interfaces
• JDBC, ODBC, ADO, XML, JCA, BEA JCA, SOAP

15
Peer-to-peer Universal Integration
Client Application
JCA
JDBC
Windows
OpenVMS
Unix
Tandem
AS/400
OS/390
OS/390
Windows
OpenVMS
Unix
Tandem
AS/400
Windows
OpenVMS
Unix
Tandem
AS/400
OS/390
Client Application
Client Application
Client Application
16
Dual Architecture
Data Engine
Application Engine
Base Services
17
Two Kinds of Connections

• Application Connection
• Complex hierarchical data
• Procedural access
• No common language
• No accepted common model
• Emerging APIs XML, JCA, MS .NET / SOAP (ADO)

• Database Connection
• Simple data tables
• Declarative access
• Common language SQL
• Generally accepted common models (such as
  relational, network, hierarchical)
• Established APIs ODBC, ADO/OLEDB, JDBC

18
Connection Block Diagram
Client Interfaces
Data Application Interfaces
Application Engine
Data Engine
Distributed Communications
19
Client Interfaces

• Standard interfaces
• JDBC thin JDBC for pure Java client
• ODBC also as CLI on non-Windows
• ADO/OLE DB
• XML In XML out
• JCA
• SOAP

20
Connectivity Requirements

• Universal access to data and applications
• Transparent interfaces
• Heterogeneous and distributed joins
• XML capabilities
• Query optimization
• Peer-to-peer architecture
• Universal SQL

21
What is JCA for?

• "The J2EE Connector architecture is trying to
  extend what JDBC has done for Java and J2EE in
  terms of providing uniform and simplified
  connectivity with databases, to the world of
  heterogeneous EISs Enterprise Information
  Systems."
• Vijay Sarathy, product manager for Connectors
  and JDBC, Sun Microsystems, Inc.

22
What is JCA?

• J2EE Connector Architecture (JCA)
• Culmination of an industry wide effort
• Including BEA, IBM, Inprise, IPLanet, Motorola,
  Oracle, SAP, Sun, Sybase, Unisys
• Well woven into the J2EE framework
• Similar to the JDBC API
• Used to access relational databases
• JCA is standard architecture
• Use to integrate J2EE applications with EISs that
  are not relational databases
• Two main scenarios
• 3-tier (managed) scenario
• 2-tier (non-managed) scenario

23
3-Tier Scenario

• Thin client (the 1st tier) works against
  application component residing in application
  server using application adapter (the 2nd tier)
• The application adapter works with the EIS (the
  3rd tier)
• Application component (via JCA CCI interfaces)
• Activates interactions against the EIS
• Application server (via JCA SPI interfaces)
• Configuration
• Transactions
• Security
• Connection management

24
2-Tier Scenario

• Fat client works against application adapter
  directly (the 1st tier)
• Application adapter works against EIS (the 2nd
  tier)
• Client uses CCI and SPI interfaces
• Complete control over the entire operation of the
  application adapter

25
J2EE Connector Architecture (JCA) Overview
J2EE Application Server
Container-Component Contract
BEA WebLogic J2EE Application Server
Application Component
Component Contract
CCI
Connection Manager
JCA Adapter
Resource Adapter
System Contracts
Transaction Manager
SPI
Security Manager
EIS-SpecificInterfaces
Enterprise InformationSystem
26
Thank you.
