Loy Yang Power Station Control System Upgrade.

1
Loy Yang Power Station Control System Upgrade.
BARRY DUNGEY General Manager Engineering
Maintenance June 2008
2
Key Project Objectives

• Original control system is of mid 1970s design
  with circuit board, relay and wire wrap
  technology.
• The main driver for the project is the difficulty
  in supporting obsolete control equipment.( Our
  policy is to run for approx 5 years following
  withdrawal of support by our equipment supplier)
• The opportunity is also being taken to gain
  improvements in system performance and reduce
  business risk exposure.
• ( i.e. Alternative control room)
• Plant trip rates were increasing with a
  significant number due to control system faults.
• Upgrade will include the installation of a
  separate plant safety system.
• Complete unit cut over to be achieved in 35-40
  day outage duration

3
Number of Trips Trip Rate.
4
Project Timeline
5
Loy Yang Power Expectations

• The current control system is fairly tight as it
  is already being run on a digital platform, hence
  LYP are not expecting significant direct
  improvements in efficiency as a result. (Some
  studies indicate that up to 2 improvement is
  possible from older systems)
• The system will deliver flexibility to do things
  smarter, fault find easier, and implement future
  plant logic change easier.
• The supplier has provided a guarantee that they
  will support the new control system for 35 years,
  hence no further significant upgrades are
  expected in the remaining life of the plant.

6
Yokogawa Site Observations

• Site surveys noted that the current control
  strategies are sound.
• Boiler thermocouple dynamic response suitably
  fast to allow for quick movement in loads.
• Existing spray valves and actuators not
  significantly limiting performance
• Existing controls have some issues when limits
  are reached wind-up, excess output pull-back,
  etc

7
Benefits from Yokogawa control design

• Integration between steam temperature and
  combustion controls minimises interaction
• Over-firing minimised by using transient
  contribution of superheater sprays to main steam
  pressure control
• Contributes to wider operating range from milling
  plant
• Boiler thermal stress reduced
• Flexibility on turbine ramp rates possible
• On line efficiency tools improved.

8
Benefits (Continued)

• In summary, the current process is about
  achieving incremental improvements, particularly
  with
• Start up and shutdown sequences
• Better trim controls associated with excess air
  (oxygen).
• Maximising future flexibility with an open system
  which can accept third party products.
• Improved Operator information and diagnostics

9
Original Coal Handling Plant
10
Coal Handling Plant (Part)
11
Coal Handling Plant (Overview Screen)
12
Major Plant Drive Graphic
13
Future Control Room Layout
14
Simulation For Engineering and Training
15
Optimised Sootblowing

• Loy Yang Power has four superheater elements, 2
  reheater elements and an economiser within each
  furnace convection path.
• To manage boiler fouling, 74 sootblowers are used
  to clean the elements using high pressure steam
  from the Reheat Steam System.
• The original design used a time based operation
  system with two cleaning cycles per day.

16
Original Sootblower Control Panel
17
Optimised Sootblowing - NGISB

• An optimised sootblowing system (NGISB - Next
  Generation Intelligent Sootblowing System) has
  been installed on one unit as a trial. It uses a
  Synengco supplied NGISB system interfaced to PLC
  based sootblower controls supplied by Siemens.
• The NGISB gathers data from the plant historian
  at near real time and continuously calculates the
  ideal sootblower schedule using a thermal boiler
  model within business rule constraints.

18
Sootblower Optimisation System Aims

• Reduce sootblowing frequency
• Maintain boiler attemporator spray flows within
  the ideal valve control range
• Minimise Reheat Spray Flow
• Maintain Steam and Metal Temperatures close to
  target and minimise alarm conditions to maximise
  thermal efficiency.
• Set and Forget operation.

19
Siemens/Synengco Sootblower Control System
20
Optimised Sootblowing Results

• Sootblowing frequency reduced to 32.5 of the
  original time based schedule.
• Annualised Savings per Unit
• 24.7 TJ of energy
• 8.1 Ml of Cold Reheat Steam
• 4,900 Tonnes of CO2

21
(No Transcript)
22
Optimised Sootblowing Results (Continued)

• Reducing RH Spray Flow to a minimum has a
  positive impact on overall steam cycle efficiency
  estimated to be 0.3
• Reduced thermal excursions in the boiler due to
  sootblowing leading to a more stable boiler.
• Better than 12 month payback on current costs.

23
