Programming and Problem Solving with C , 2/e

1
Chapter 14 Object-Oriented Software Development
Dale/Weems/Headington
2
Chapter 14 Topics

• Structured Programming vs. Object-Oriented
  Programming
• Using Inheritance to Create a New C class Type
• Using Composition (Containment) to Create a New
  C class Type
• Static vs. Dynamic Binding of Operations to
  Objects
• Virtual Member Functions

3
OOP vs. Structured Programming
4
Two Programming Paradigms
Structural (Procedural) Object-Oriented
PROGRAM PROGRAM
5
Object-Oriented Programming Language Features

• 1. Data abstraction
• 2. Inheritance of properties
• 3. Dynamic binding of operations to objects
• Also Encapsulation, Polymorphism

6
Abstraction

• "A view of a problem that extracts the essential
  information
• relevant to a particular purpose and ignores the
  remainder of
• the information."
• -- IEEE, 1983
• "The essence of abstraction is to extract
  essential properties
• while omitting inessential details."
• -- Ross et al, 1975
• "Abstraction is a process whereby we identify
  the important
• aspects of a phenomenon and ignore its details."
• -- Ghezzi et al, 1991
• "Abstraction is generally defined as 'the
  process of
• formulating generalized concepts by extracting
  common qualities
• from specific examples.'"

7
OOP Terms C Equivalents

• Object Class object or class instance
• Instance variable Private data member
• Method Public member function
• Message passing Function call ( to a public
  member function )

8
What is an object?
OBJECT
set of methods (public member functions) interna
l state (values of private data members)
Operations Data
9
Inheritance
10
Inheritance Hierarchy Among Vehicles
Every car is a wheeled vehicle.
11
Inheritance

• is a mechanism by which one class acquires
  (inherits) the properties (both data and
  operations) of another class
• the class being inherited from is the Base Class
  (Superclass)
• the class that inherits is the Derived Class
  (Subclass)
• the derived class is then specialized by adding
  properties specific to it

12
Time Class
13
class Time Specification

• // SPECIFICATION FILE ( time.h )
• class Time
• public
• void Set ( int hours , int minutes ,
  int seconds )
• void Increment ( )
• void Write ( ) const
• Time ( int initHrs, int initMins, int
  initSecs ) // constructor
• Time ( ) // default
  constructor
• private
• int hrs
• int mins
• int secs

14

Class Interface Diagram
Time class
Set
Private data hrs mins secs
Increment
Write
Time
Time
15
Using Inheritance to Add Features

• // SPECIFICATION FILE ( exttime.h)
• include time.h
• enum ZoneType EST, CST, MST, PST, EDT, CDT,
  MDT, PDT
• class ExtTime public Time
  // Time is the base class
• public
• void Set ( int hours, int minutes,
  int seconds ,
•
  ZoneType timeZone )
• void Write ( ) const
• ExtTime ( int initHrs , int initMins ,
  int initSecs ,
• ZoneType initZone )
  // constructor
• ExtTime ( ) // default
  constructor
• private
• ZoneType zone // added data member

16
class ExtTime public Time

• says class Time is a public base class of the
  derived class ExtTime
• as a result, all public members of Time (except
  constructors) are also public members of ExtTime
• in this example, new constructors are provided,
  new data member zone is added, and member
  functions Set and Write are overridden

17

Class Interface Diagram
ExtTime class
Set
Set
Private data hrs mins secs
Increment
Increment
Write
Write
Time
ExtTime
Time
ExtTime
Private data zone
18
Client Code Using ExtTime

• include exttime.h
• .
• .
• .
• ExtTime thisTime ( 8, 35, 0, PST )
• ExtTime thatTime // default
  constructor called
• thatTime.Write( ) // outputs
  000000 EST
• cout ltlt endl
• thatTime.Set (16, 49, 23, CDT)
• thatTime.Write( ) // outputs
  164923 CDT
• cout ltlt endl
• thisTime.Increment ( )
• thisTime.Increment ( )
• thisTime.Write ( ) // outputs
  083502 PST
• cout ltlt endl

19
Constructor Rules for Derived Classes

• at run time, the base class constructor is
  implicitly called first, before the body of the
  derived classs constructor executes
• if the base class constructor requires
  parameters, they must be passed by the derived
  classs constructor

20
Implementation of ExtTime Default Constructor

• ExtTime ExtTime ( )
• // Default Constructor
• // Postcondition
• // hrs 0 mins 0 secs
  0
• // (via an implicit call to base
  class default constructor )
• // zone EST
• // Time( )
• zone EST

21
Implementation of Another ExtTime Class
Constructor

• ExtTime ExtTime ( / in / int
  initHrs,
• / in / int
  initMins,
• / in / int
  initSecs,
• / in /
  ZoneType initZone )
• Time (initHrs, initMins, initSecs)
  // constructor initializer
• // Precondition 0 lt initHrs lt 23 0
  lt initMins lt 59
• // 0 lt initSecs lt 59 initZone is
  assigned
• // Postcondition
• // zone initZone Time set by base class
  constructor
• zone initZone

22
Implementation of ExtTimeSet function

• void ExtTime Set ( / in / int
  hours,
• / in / int
  minutes,
• / in / int
  seconds,
• / in /
  ZoneType time Zone )
• // Precondition 0 lt hours lt 23 0 lt
  minutes lt 59
• // 0 lt seconds lt 59 timeZone is
  assigned
• // Postcondition
• // zone timeZone Time set by base class
  function
• Time Set (hours, minutes,
  seconds)
• zone timeZone

23
Implementation of ExtTimeWrite Function

• void ExtTime Write ( ) const
• // Postcondition
• // Time has been output in form HHMMSS ZZZ
• // where ZZZ is the time zone
  abbreviation
• static string zoneString8
• EST, CST, MST, PST, EDT,
  CDT, MDT, PDT
• Time Write ( )
• cout ltlt ltlt zoneString zone

24
Avoiding Multiple Inclusion of Header Files

• often several program files use the same header
  file containing typedef statements, constants, or
  class type declarations--but, it is a
  compile-time error to define the same identifier
  twice
• this preprocessor directive syntax is used to
  avoid the compilation error that would otherwise
  occur from multiple uses of include for the same
  header file
• ifndef Preprocessor_Identifier
• define Preprocessor_Identifier
• .
• .
• .
• endif

25
CompositionContainmentLayering

• Has-a
• NOT
• Is-a

26
Composition / Containment / Layering

• is a mechanism by which
• the internal data of one class
• includes an object of another class
• The process of building one class on top of
  another class
• having the layering class
• contain an object of the layered class
• as a data member

27
A TimeCard object has a Time object

• include time.h
• class TimeCard
• public
• void Punch ( / in / int hours,
• / in / int
  minutes,
• / in /
  int seconds )
• void Print ( ) const
• TimeCard ( / in / long idNum,
• / in / int initHrs,
• / in / int initMins,
• / in / int
  initSecs )
• TimeCard ( )
• private
• long id
• Time timeStamp

28

TimeCard Class
TimeCard has a Time object
Private data id timeStamp
Print . . .
Private data hrs mins secs
Set
Increment
Write . . .
TimeCard
TimeCard
29
Implementation of TimeCard Class Constructor

• TimeCard TimeCard ( / in / long idNum,
• / in / int initHrs,
• / in / int initMins,
• / in
  / int initSecs )
• timeStamp (initHrs, initMins, initSecs)
  // constructor initializer
• // Precondition 0 lt initHrs lt 23 0
  lt initMins lt 59
• // 0 lt initSecs lt 59 initNum is
  assigned
• // Postcondition
• // id idNum timeStamp set by its
  constructor
• id idNum

30
Order in Which Constructors are Executed

• Given a class X,
• if X is a derived class its base class
  constructor is executed first
• next, constructors for member objects (if any)
  are executed (using their own default
  constructors if none is specified)
• finally, body of Xs constructor is executed
• See g\cp2\cpp\timecard

31
Dynamic Binding

• Virtual Functions

32
In C . . .

• When the type of a formal parameter is a
• parent class, the argument used can be
• the same type as the formal parameter,
• or,
• any descendant class type.

33
Static Binding

• is the compile-time determination of which
  function to call for a particular object based on
  the type of the formal parameter
• when pass-by-value is used, static binding occurs


34
Static Binding Is Based on Formal Parameter Type

• void Print ( / in / Time someTime )
• cout ltlt Time is
• someTime.Write ( )
• cout ltlt endl
• CLIENT CODE OUTPUT
• Time startTime ( 8, 30, 0 ) Time is
  083000
• ExtTime endTime (10, 45, 0, CST) Time is
  104500
• Print ( startTime )
• Print ( endTime )

35
Dynamic Binding

• is the run-time determination of which function
  to call for a particular object of a descendant
  class based on the type of the argument
• declaring a member function to be virtual
  instructs the compiler to generate code that
  guarantees dynamic binding

36
Virtual Member Function

• // SPECIFICATION FILE ( time.h )
• class TimeType
• public
• . . .
• virtual void Write ( ) const
  // for dynamic binding
• . . .
• private
• int hrs
• int mins
• int secs

37
Dynamic binding requires pass-by-reference

• void Print ( / in / Time someTime )
• cout ltlt Time is
• someTime.Write ( )
• cout ltlt endl
• CLIENT CODE OUTPUT
• Time startTime ( 8, 30, 0 )
  Time is 083000
• ExtTime endTime (10, 45, 0, CST)
  Time is 104500 CST
• Print ( startTime )
• Print ( endTime )

38
Using virtual functions in C

• dynamic binding requires pass-by-reference when
  passing a class object to a function
• in the declaration for a virtual function, the
  word virtual appears only in the base class
• if a base class declares a virtual function, it
  must implement that function, even if the body is
  empty
• a derived class is not required to re-implement a
  virtual function. If it does not, the base class
  version is used see g\cp2\cpp\virtual

39
Virtual Functions Inheritance
Function Type Interface (prototype) inherited? Implementation Inherited?
Non-Virtual (normal) Yes Yes Base class implementation cannot be changed
Virtual Yes Yes Base class impl. is default but can be changed.
Pure Virtual virtual int f()0 Yes No. No impl. is given.
40
Polymorphism

• In object-oriented programming, the ability of
  different objects to respond, each in its own
  way, to the same message.developer.apple.com/tech
  pubs/macosx/Cocoa/ObjectiveC/7objc_glossary/chapte
  r_9_section_1.html
• The ability of different object to respond to the
  same message in specific ways Objects can have
  very different implementations of the same
  message. In Smalltalk polymorphic behavior in
  response to messages is independent of
  inheritance.www.object-arts.com/EducationCentre/G
  lossary.htm
• With regards to an object-oriented programming
  language, such as C, polymorphism refers to an
  object's ability to behave differently depending
  on its type. This provides a powerful means for
  making extensions to objects.www.davidgould.com/B
  ooks/Glossary.htm

41
(No Transcript)
