IT 244 Database Management System

1
IT 244 Database Management System

• Lecture 1 14 / 02 /07
• Course Information
• Introduction to Database DBMS

2
Topic 1 Introduction

• Evolution of Database Systems
• Data gtgt Database vs Database Management
• Compare ways DATA is organized
• Word processor (document production)
• Spreadsheets (numerical analysis)
• Traditional File Management (mini computers
  storage retrieval)
• Database (data management)
• Advantages and Disadvantages

3
Ways data is organized in
4
Spreadsheet Format Store data in rows and
columns

• Several things to note about the above table
• Data to be stored has uniform format. Same kind
  of information about each patient
• File size will increase as the number of patient
  records increases
• Frequently accessing the table for new or
  existing patients
• Table will be useful for all like the doctor or
  administrators
• Other people may need print out of the
  information .

5
Potential problems that can arise

• Patients increase file size too so access to
  the table will become slower and slow when access
  concurrently
• Takes time to manipulate the table ie. Get
  specific information, correct an error,
  repetition of data will have to be dealt with.

6
Traditional File Systems

• Information system specialist became aware of the
  problems
• So they devised ways of managing them.
• Rather then keeping data in a single large file,
• Data was separated into many different files
  according to the nature of the information to be
  stored.
• Then special software programs were written to
  manage the files.
• These programs could perform tasks such as
• add new records
• update old ones
• search for selected data within files
• and deleted unwanted records.

7
Traditional File System

• Thus The data about the Hospital patients in the
  spreadsheet can be separated into the following
  files under the traditional file system.
•
• File Information Stored
• Patients - Surname, First name, age, date
  admitted, date discharged
• Doctor - Surname, First name, Phone contact
• Ward - Ward number, number of rooms
• Room - Room number, beds, ward number

8
Traditional method of file management
9
Traditional method of file management

• Although this is an improvement over the
  spreadsheet method of storing and accessing data,
  there are still some problems.
• For instance, information about the wards is
  closely related to the information about rooms
  but they are in different files. How do you link
  them ? Often extra programming effort.
• Not every organization can afford to have a
  programmer
• Getting access to the required information often
  takes a number of steps.
• To speed up the retrieval of information you can
  create indexes for the file and/or split it up to
  avoid repetition of information and reduce the
  total size of the file.

10
Disadvantages of TFM

• Since data is stored in many related files you
  can end up with
•
• Data redundancy keeping many copies of the same
  type of data
• Data inconsistency updating some of the copies
  but not the others
• Data Dependency data access is tied to the
  program so change in data will also change in
  programs
• Excessive maintenance and upgrade costs
  Modifying the programs and structure of the data
  files require a lot of effort.

11
The Evolution of Database System

• What is a database- is nothing more than a
  collection of information that exists over a long
  period of time.
• The term database refers to a collection of data
  that is managed by a DBMS

12
DATABASE

• A collection of data that is managed and
  organized by a DBMS. Not all collection of data
  are databases. Databases have the following
  characteristics
•  They represent some aspects of the real world
• Hospital patients
• They are logically coherent and have some meaning
• Related in some way
• Information has some meaning.
• They are created for specific purposes.
• Information for a specific purposes.

13
Database Approach
User 1
Database Management System
Patients
User 3
Doctors
User 6
Ward
User 9
Room
User 12
Data are all in one database but kept in a
separate logical units or tables. The DBMS
provides users with one interface to access the
database and present the database information to
each users according to preferences.
14
Advantages of Database approach

• Data independence data items no longer tied to
  the programs
• Reduction of data redundancy and inconsistency
  Only one copy of each data item is stored
• Consolidation of data management Just one
  software program DBMS to manage access to the
  database
• Can be used in multi-user environment More
  people can used at once
• Security restrictions can be applied. Security
  features can be build into the DBMS to restrict
  and protect the data.
• The integrity of the data can be maintained
  accuracy and reliability of the data
• Standard can be enforced adhere to
  organizational policies

15
What is a Database Management System (DBMS)

• A Database Management System (DBMS) is a software
  system designed to store, manage, and facilitate
  access to databases.
• In other words
• A collection of programs that enables you to
  store, modify, and extract information from a
  database. (Webopedia Computer Dictionary)

16
DBMS

• DBMS is a powerful tool for creating and managing
  large amounts of data efficiently and allowing
  it to keep over long periods of time safely
• These systems are among the most complex types of
  software available.

17
Capabilities that a DBMS provides

• Persistent Storage like a file system support
  very large amounts of data that exists
  independently of any processes that are using the
  data.
• - DBMS goes far beyond the file system in
  providing flexibility, such as data structures
  that support efficient access to very large
  amounts of data

18
Capabilities that a DBMS provides

• Programming Interface - DBMS allows the user or
  an application program to access and modify data
  through a powerful query language
• - Again the advantage of a DBMS over a file
  system is the flexibility to manipulate stored
  data in much more complex ways than the reading
  and writing of files.

19
Capabilities that a DBMS provides

• Transaction Management - DBMS support concurrent
  access to data i.e. simultaneous access by many
  distinct processes (called transactions) at once

20
DBMS was expected to-

• Allow user to create new database and specify
  schema
• Give users the ability to query the data
• Support the storage of very large amount of data
• Control access to data from many users at once

21
Early Database Management System

• First commercial database management systems
  appeared in the late 1960s
• These systems evolved from file system (File
  systems store data over a long period of time and
  they allow the storage of large amounts of data)

22
Application of DBMS

• Airline Reservation Systems
• In this type of System, the item of data
  include-
• - Reservations by customers
• Information about flights (airports they fly
  from and to, departure and arrival time, aircraft
  flown etc)
• Information about tickets (such as prices,
  requirements and availability)

23
Application of DBMS

• Banking Systems
• - Include names and addresses of customers,
  accounts, loans etc.
• - as with airlines reservation system, we expect
  many tellers and staff or customers querying and
  modifying the banks data at once

24
Summary

• Course administrative matters
• How the concept of Database approach developed
• Files structure
• Users
• Database
• DBMS

25

• End of Lecture

26
Problems EDBMS

• File systems do not generally guarantee that data
  can not be lost if it is not backed up
• They do not support efficient access to data
  items whose location in a particular file is not
  known
• File systems do not directly support a query
  language for the data files

27
Problems EDBMS

• Their support for a schema for the data is
  limited to the creation of directory structures
  for files
• File system do not satisfy concurrent access to
  files by several users or processes

28
Simultaneous access

• Avoiding consequences of simultaneous access DBMS
  support
• i) isolation - the appearance that
  transactions execute one at a time
• ii) atomicity- the requirement that
  transactions either completely or not at
  all
• iii) durability- the ability to recover from
  failure or errors of many types

29
Application of DBMS

• The first important applications of DBMS were one
  where-
• - Data was composed of many small items
• - Many queries or modifications were made

30
Application of DBMS

• IT IS VITAL THAT SIMULTANEOUS ACCESSES TO AN
  ACCOUNT NOT CAUSE THE EFFECT OF A TRANSACTION TO
  BE LOST.
• FAILURE CANNOT BE TOLERATED.

31
Relational Database Systems

• Following a famous paper written by Ted Codd in
  1970s
• Database system changed significantly
• Codd proposed that database systems should
  present the user with a view of data organized as
  tables called relations

32
Relational Database Systems

• Behind the scenes, there might be a complex data
  structure that allow rapid response to a variety
  of queries. But unlike the user of earlier
  database systems, the user of a relational system
  would not be concern with the storage structure.
  Queries could be expressed in a very high-level
  language, which greatly increased the efficiency
  of database programmers

33
Relational Database Systems

• Relations and Tables
• - Columns are headed by attributes which
  describe the entries in the column
• Eg. A relation named Accounts recording Bank
  Account, Balance and Type might look like

Acc No Balance Type
123 100.00 Sav
456 2000.00 Check

34
Relational Database Systems

• Heading the columns are the attributes
• - Account No
• - Balance
• -Type

35
Relational Database Systems

• Below the attributes are the Rows or Tuples
• The table show two tuples of the relation
  explicitly, and the dots below them suggest that
  there would be many more tuples.

36
Relational Database Systems

• Suppose we want to know the balance of account
  456. We could ask this query in SQL as follows
• SELECT account No
• FROM Accounts
• WHERE accountNo 456

37
Relational Database Systems

• Do NOT expect that this example is enough to make
  you an expert SQL programmer, but it should
  convey the high-level nature of the SQL
  Select-From-Where statement

38
Relational Database Systems

• In principle, they ask the DBMS to
• 1. Examine all the tuples of the Relation
  Accounts mentioned in the FROM clause
• 2. Pick out those tuples that satisfy some
  criterion indicated in the WHERE clause and
• 3. Produce as an answer certain attributes of
  those tuples as indicated in the SELECT clause
• In practice, the system must optimize the
  query and find an efficient way to answer the
  query, even though the relations involved in the
  query may be very large.

39
Smaller and Smaller Systems

• Originally, DBMS were large, expensive software
  running on large computers
• Size was necessary because to store large amount
  of data require large computer system
• To day many gigabytes fit on a single disk
• Size Decrease, Capacity and power increases.

40
Bigger and Bigger Systems

• On the other hand, a gigabyte isnt much data.
• Corporate database often occupy hundreds of
  gigabyte
• As storage become cheaper people find new reasons
  to store greater amount of data
• Database no longer focus on storing simple data
  item (integer or short string of characters)
  but can store images, audio and video and many
  other kind of data.

41
Bigger and Bigger Systems

• Handling such large database require
  technological advances
• eg. Database of modest size are today stored on
  arrays of disks which are called secondary
  storage device. (compared to main memory which is
  primary storage)
• The fact that database systems routinely assume
  data is too big to fit in main memory and must be
  located primarily on disk at all times

42
Bigger and Bigger Systems

• Trends that allow database systems to deal with
  large amounts of data faster
• - Tertiary Storage-
• - tertiary storage devices perhaps storing a
  tera-byte each.
• - require much more time to access a given item
  than does a disk
• - involve transporting an object, upon which
  the desired data item is stored to a reading
  device

43
Bigger and Bigger Systems

• - Parallel Computing
• - the ability to store enormous volumes of data
  is important but it would be of little use if we
  could not access large amounts of data quickly
• - thus very large databases also require speed
  enhancers.
• - parallel Computing handle such problem

44
Client Server and Multi-Tier Architectures

• Client server architecture (Two-Tier) a
  request by one process (the client) are send to
  another process (the server) for execution
• N-Tier DBMS continues to act as a server, but
  its client is typically an application server.

45
Client Server and Multi-Tier Architectures

• Application server in a N-Tier manage connections
  to the database, transactions, authorization and
  other aspects.
• Application Servers in turn have clients such as
  Web servers, which support end-users or other
  application.

46
Summary

• The worlds of Database Systems
• The evolution of Database Systems
• Early Database Management Systems
• Relational Database System
• Smaller and Smaller Systems
• Bigger and Bigger Systems
• Client Server and Multi-Tier Architecture
