How Computers Work

1

• Chapter 1
• How Computers Work

2
Objectives

• In this chapter, you will learn
• That a computer requires both hardware and
  software to work
• About the many different hardware components
  inside and connected to a computer

3
Hardware Needs Software to Work

• Hardware the computers physical components
• Software the set of instructions that directs
  hardware to accomplish a task
• Software uses hardware for input, processing,
  output and storage
• All letters and numbers are stored in a computer
  as a series of bits

4
Hardware Needs Software to Work (continued)
5
Hardware Needs Software to Work (continued)
6
Hardware Needs Software to Work (continued)
7
PC Hardware Components

• Hardware Used for Input and Output
• Hardware Inside the Computer Case
• The Motherboard
• The CPU and the Chip Set
• Storage Devices
• Motherboard Components Used for Communication
  Among Devices

8
PC Hardware Components (continued)

• Interface (Expansion) Cards
• The Electrical System
• Instructions Stored on the Motherboard and Other
  Boards
• Motherboard Configuration Settings

9
PC Hardware Components (continued)

• Hardware input, output and storage devices all
  require the following elements
• A method for the CPU to communicate with the
  device
• Software to instruct and control the device
• Electricity to power the device

10
Hardware Used for Input and Output

• Communication through wireless connection or
  cables attached at a port
• Most popular input devices
• Keyboard
• Mouse
• Most popular output devices
• Monitor
• Printer

11
Hardware Used for Input and Output (continued)
12
Hardware Used for Input and Output (continued)
13
Hardware Used for Input and Output (continued)
14
Hardware Inside the Computer Case

• A motherboard containing the CPU, memory, and
  other components
• A floppy drive, hard drive, and CD-ROM drive for
  storage
• A power supply and power cables
• Circuit boards used to communicate with devices
  inside and outside the case
• Cables connecting devices to circuit boards and
  the motherboard

15
Hardware Inside the Computer Case (continued)
16
The Motherboard

• The largest and most important circuit board
• Also called the main board
• Contains the CPU, where most processing takes
  place
• All devices
• Communicate with the motherboard
• Are either installed directly on it or linked by
  a cable

17
The Motherboard (continued)

• Processing CPU and the chip set that supports
  the CPU
• Storage RAM and cache memory
• Communication traces, expansion slots and the
  system clock
• The electrical system the power supply
• Programming and setup data Flash ROM, CMOS

18
The Motherboard (continued)
19
The Motherboard (continued)
20
The CPU and the Chip Set

• CPU a chip inside the computer that performs
  most of the actual data processing
• Chip set microchips on the motherboard
• Control the flow of data and instructions to and
  from the CPU

21
The CPU and the Chip Set (continued)
22
The CPU and the Chip Set (continued)
23
Storage Devices

• Temporary and permanent
• CPU uses temporary storage to hold both data and
  instructions while processing
• When data and instructions are not being used,
  they are kept in permanent storage

24
Storage Devices (continued)
25
Primary Storage

• Provided by devices called memory or Random
  Access Memory (RAM)
• Types include SIMMs, DIMMs, and RIMMs
• Information stored here is lost when the computer
  is turned off

26
Primary Storage (continued)
27
Primary Storage (continued)
28
Primary Storage (continued)
29
Secondary Storage

• Data and instructions permanently stored on
  devices such as CDs, hard drives, and floppy
  disks
• Cannot be processed by the CPU until copied into
  primary storage

30
Secondary Storage (continued)
31
Secondary Storage (continued)
32
Secondary Storage (continued)
33
Secondary Storage (continued)
34
Secondary Storage (continued)
35
Secondary Storage (continued)
36
Secondary Storage (continued)
37
Secondary Storage (continued)
38
Motherboard Components Used for Communication
Among Devices

• Traces, or circuits, enable data, instructions
  and power to move between components
• The bus is a system of pathways, protocols, and
  methods used for transmission
• Data path size is the width of the bus
• System clock is on the bus and is dedicated to
  timing the activities on the motherboard

39
Motherboard Components Used for Communication
Among Devices (continued)
40
Motherboard Components Used for Communication
Among Devices (continued)
41
Motherboard Components Used for Communication
Among Devices (continued)
42
Motherboard Components Used for Communication
Among Devices (continued)
43
Motherboard Components Used for Communication
Among Devices (continued)

• Three types of expansion slots
• PCI for high-speed input/output
• AGP for a video card
• ISA for older or slower devices

44
Interface (Expansion) Cards

• Mounted in expansion slots on the motherboard
• Enable the CPU connection to an external device
  or to a network
• Technology to access device is embedded on the
  card itself
• Technology to communicate with the slot, the
  motherboard and the CPU also embedded
• Port configuration can identify card function

45
Interface (Expansion) Cards (continued)
46
Interface (Expansion) Cards (continued)
47
Interface (Expansion) Cards (continued)
48
The Electrical System

• Converts and reduces energy to a voltage that the
  computer can handle
• 110 to 20 AC power from wall outlet is converted
  to a much lower DC voltage
• Older style 5 or 12 volts DC
• Newer style 3.3, 5, 12 volts DC
• Runs fan to keep temperature under 185F

49
The Electrical System (continued)
50
The Electrical System (continued)
51
Instructions Stored on the Motherboard and Other
Boards

• ROM (Read Only Memory) Chips
• BIOS Basic input/output system
• System BIOS
• Startup BIOS
• CMOS BIOS
• Flash ROM allows for overwriting software on the
  chip

52
Instructions Stored on the Motherboard and Other
Boards (continued)
53
Advanced Configuration and Power Interface (ACPI)

• Supports power-saving features
• Standards developed by Intel, Microsoft, Toshiba
• ACPI allows for powering up a system by an
  external device such as a keyboard

54
Plug and Play

• A standard allowing for easier installation of
  new hardware
• Begins the process of configuring hardware
  devices in the system
• Passes information on to the operating system

55
Motherboard Configuration Settings

• CMOS configuration chip, CMOS setup chip or the
  CMOS RAM chip
• Contains a very small amount of memory
• Holds configuration or setup about the computer
• Remembers current date and time, hard drive and
  floppy drive information and port configuration,
  and more

56
Motherboard Configuration Settings (continued)
57
Motherboard Configuration Settings (continued)
58
Motherboard Configuration Settings (continued)
59
Summary

• A computer requires both hardware and software to
  work
• Input, Output, Processing, Storage of data
• Motherboard is the most important component
  inside the computer
• Many components inside the computer are required
  for execution of the four functions of the
  microcomputer
