Biosense Webster Israel

1
Biosense Webster Israel
2
A Bit About Us

• Founded 1994 - Shlomo Ben-Haim, M.D.
• Acquired by JJ - 1997

3
A Bit About Us

• Our headquarters Tirat HaCarmel

4
A Bit About Us

• Biosense Webster about 700 employees worldwide
• About 100 employees in Israel (mostly RD)
• Worldwide sales of about 300 million USD
• Profits of about 40 million USD
• Commands about 80 of the intracardiac navigation
  devices market

5
What Are We Doing

• It all began with an EP catheter

6
EP Overview

• Typical EP procedure consists of

Inserting catheter
Reaching the heart
7
EP Overview

• And

Navigating inside the heart
8
However

• The main (and only) instrument for knowing
  whats going on inside the heart is fluoro.

9
However

• In addition to emitting harmful radiation, it
• produces images that are hard to interpret

10
However
Especially when the heart is beating
11
Location Technology

• We place a number of transmitters under the
• patient table

12
Location Technology

• and a receiver in the catheter tip

13
Location Technology

• and triangulate our position!

14
Mapping

• Now we know the location of the catheter tip with
• respect to the table. So what?

X 11.34 Y 533.89 Z 45.78
15
Mapping

• We can map the heart from the inside and find the
• location of the catheter tip with respect to the
  map.

16
Mapping

• The map is also very useful in displaying
• electrical activity of the heart.

17
Mapping

• Still there is one problem left heartbeat. We
• can either synchronize with ECG

18
Mapping

• or try to build a dynamic model of the heart

19
Questions So Far

• Any Questions?

20
What Else Are We Doing

• Remote Magnetic Navigation - Stereotaxis

21
What Else Are We Doing

• Stereotaxis performing EP procedure

22
What Else Are We Doing

• Integration of pre-acquired images (MRI, CT, etc).

23
What Else Are We Doing

• Ultrasound catheter

24
What Else Are We Doing

• Different catheters (Quick, Flower, etc).
• Research versions
• Trying to analyze hearts electrical activity
• New applications (neurosurgery, orthopedy, etc.)
• Etc, etc, etc.

25
And Last But Not Least

26
And Last But Not Least

• Biosense Webster Wants You!
• (well, maybe)
