Shibboleth 2.0 IdP Training: Authentication

1
Shibboleth 2.0 IdP TrainingAuthentication

• January, 2009

2
Terms Authentication Mechanism

• A mechanism used to authenticate a user
• Shibboleth 2 supports the following
  authentication mechanisms
• Remote User
• Username/Password (LDAP, Kerberos)
• IP Address

3
Terms Login Handler

• An IdP component that configures authentication
  mechanisms

4
Terms Session

• Contains
• State information about the user
• Active authentication methods
• Services the user is signed into
• Created when user authenticates
• Session termination user must authenticate
  again
• Many different sessions in federated identity

5
Login Handler Configuration

• Login handlers are defined in handler.xml
• Defined by ltLoginHandlergt
• Must have a type (xsitype) and at least one
  authentication method
• Each type has its own set of configuration
  attributes

6
Login Handler RemoteUser

• Login handler that relies on the web server or
  servlet container for authentication
• REMOTE_USER is set as the users principal name
• Type
• RemoteUser
• Configuration attributes
• (none)

7
Login Handler UsernamePassword

• Login handler that prompts for a username and
  password
• Validates against a JAAS module
• LDAP Kerberos 5 supported
• Type
• UsernamePassword
• Configuration attributes
• jaasConfigurationLocation

8
Login Handler UsernamePassword

• A login page is provided and will be presented to
  the user
• /var/setup/identityprovider/resources/webpages/log
  in.jsp
• Multiple UsernamePassword login handlers can be
  defined
• Different authentication methods
• Failover in case a provider is down

9
Lab Login Handlers

• Modify handler.xml to enable the UsernamePassword
  login handler
• Configure login.config to use the training LDAP
  server

10
Login Handler Authentication Duration

• Each authentication mechanism supports an
  inactivity timeout
• After this timeout expires the mechanism is
  considered inactive for that user
• If the user attempts to access a new service
  provider that requires that authentication
  mechanism they must re-authenticate

11
Login Handler Authentication Duration

• The activity timeout is configured by setting a
  value for the authenticationDuration attribute
  for the ltLoginHandlergt element
• The value is the number of minutes of inactivity
  the default value is 30

12
Forced Authentication

• SAML 2 allows a service provider to force
  authentication of the user, even if the user has
  an existing session.
• This is supported in mechanisms that can
  re-authenticate a user
• UsernamePassword yes
• REMOTE_USER no
• The service provider will receive an error if the
  IdP cannot support forced authentication

13
References

• More information on IdP authentication can be
  found at
• https//spaces.internet2.edu/display/SHIB2/IdPUser
  Authn
