SRS Example

1
SRS Example
2
Overview of a Software Specification Document
(SRS)

• INTRODUCTIONStates the goals and objectives of
  the software, describing it in the context of the
  computer-based system.
• System Reference
• Overall Description
• Software Project Constraints

3
Introduction (contd)

• System Reference for an Inventory Control
  Subsystem The Inventory Control System (ICS)
  will work in the existing Enterprise Planning
  System (ERP) system. It will interface with the
  Purchasing, Manufacturing, Customer Order
  Entry/Shipping, and subsystems.It will be
  invoked mainly when
• purchased goods arrive from vendors,
• goods are returned to the vendor for various
  reasons,
• stock is issued to/from manufacturing,
• finished goods are entered in the Finished Goods
  Warehouse
• finished goods are shipped to the customer,
• sales persons wish to check the availability of
  products.

4
System Reference for the Inventory Control
Subsystem (contd)

• Interface with PurchasingWhen an order from a
  vendor arrives, our Purchase Order Number on the
  vendors invoice will be used to locate the the
  PO and other related documents, such as vendor
  proposals, price lists, product
  specifications.These will then be forwarded to
  Quality Control to be used in the inspection of
  the goods.An interface will be worked out with
  Purchasing subsystem currently running on Server
  PS1 so that ICS can find all documents related to
  the current purchase.

5
System Reference for the Inventory Control
Subsystem(contd)

• Interface with ManufacturingMfg requests
  materials Mfg wants to store finished goods
• Interface with Customer Order Entry/ShippingCOE
  S wants to ship goodsCOES wants to store
  returned goods
• ..........

6
Deployment Diagram
Cust.OrderEntry
Manufacturing
ICS
Purchasing
Shipping
7
Overall Description of ICS

• ICSs main objective is to keep track of all the
  parts and finished goods in the warehouses and
  all the transactions involving these parts and
  goods.An automatic purchase order generation
  when the stock levels of parts falls below the
  minimum has been contemplated but postponed to a
  future date.

8
Overall Description of ICS (contd)

• The main functions of ICS are
• Entering new parts into the inventory(see
  Interface with Purchasing)
• Issuing parts to Manufacturing(see Interface
  with Manufacturing)
• Entering finished goods to the inventory(see
  Interface with Manufacturing)

9
Overall Description of ICS (contd-2)

• Providing Sales personnel with inventory
  information
• Issuing goods to/from COES for shipping, entering
  returned goods (see Interface with Customer
  Order Entry/Shipping)
• Assisting IC Department with reconciliation of
  results of physical inventories and machine
  records (internal).
• Providing IC Department Manager and the Vice
  President of Manufacturing with management
  reports about our inventories (internal).

10
Overall Description of ICS (contd-3)

• ICS should
• Provide a user interface consistent with the
  other subsystems
• Verify user identities and access rights
• Do error checking on all inputs
• Permit users to add customized reports

11
USE CASE DIAGRAMS
12
Use Case 1 ICS Dept
ICS Manager
Chk Parts Inventory
Chk/verify Mfg Schedule
Create Purchase Requsts
ICS
Delete cancelled part records..
Add new part records
Reconcile machine and physical inventories
Create reports required by mgmt
13
Use Case 2 Customer Order Entry
Salesperson(COES)
View
ChkAvail
Chk Goods Availability
ICS
ICS
14
Use Case 3 - Manufacturing
Manufacturing Manager
Collect Mfg Requests
View/update
Create Mfg Schedule
Get/order parts
Get/order parts.
ICS
Chk mfg. progress
Mfg. Prog.
Update finished goods inventory
15
Use Case 4 - Purchasing
Analyze purchasing requests
Purchasing Manager
View/update
Analyze vendors
Purchase parts
Get bids.
ICS
Purch. Prog.
Order parts
Enter arriving parts
Return defective parts to vendor
16
Use Case 5 - Shipping
Shipping Manager (COES)
View/update
Get finished orders
Ship Order
ICS
Shipping Prog.
Ship to customer
17
Software Project Constraints

• Compatibility
• ICS software should run compatibly (i.e. under
  the same operating system, database and
  networking capabilities) with the other
  subsystems software it works together with.
• It should allow an Administrator to enroll new
  users and give them access rights required by
  their duties.
• Reliability and Availability
• Since it interfaces with Purchasing, Customer
  Order Entry and Manufacturing, it should be
  available as a minimum when any one of these
  subsystems are available.
• It should permit 1 hour per day for maintenance
  and backup activities with minimal disruption to
  users.
• Any failure should cause no more than 10-minute
  downtime, with the average not exceding 2
  minutes.
• Backup should spot-tested to ensure they are
  reliable.
• Performance
• It should allow up to 10 users to logon
  simultaneously and receive an average response
  time not exceeding 3 seconds.
• Parts received should be in the recorded in the
  system in no more than 2 hours, with the average
  under 30 minutes.

18
2. INFORMATION DESCRIPTION

• Detailed description of the problem the software
  must solve
• Information content, relationships, flow and
  structure
• Hardware, software and human interfaces are
  described for external system elements and
  internal software functions

19
ICS Information Description

• ICS will use the following data from other
  subsystems. See Class Diagrams for details. The
  formats can be found in the Design Documents of
  the related systems.
• Vendor Order Master File - Purchasing
• Vendor Order Detail File - Purchasing
• Customer Order Master File Customer Order Entry
• Customer Order Detail File Customer Order
  Entry
• Manufacturing Requests Manufacturing
• Manufacturing Schedule Manufacturing

20
INFORMATION DESCRIPTION (contd)

• ICS will create and maintain, as a minimum, the
  following files
• Part Transaction File
• Part Master File
• Part Detail File
• Part Inventory File

21
Data Flow Diagrams(DFD Level 0)
Vendor Order Master File
Part Transaction File
Vendor Order Detail File
Part Master File
Customer Order Master File
ICS
Part Detail File
Cust. Order Detail File
Part Inventory File
Manufacturing Requests
Manufacturing Schedule
22
INFORMATION DESCRIPTION (contd-3)

• Transactions to be provided by ICS
• Create New Part or Product Master
  Record(NotePart and Product Record formats can
  be obtained from Manufacturing Subsystem, File
  prd_rec_fmt )
• Edit/Delete Part or Product Master Record
• Edit/Delete Part or Product Record
• Enter New Part or Product
• Enter Returned Part or Product
• Issue Part or Product
• Re-issue Part or Product
• View Part or Product
• ......

23
DFD Level 1
Vendor Order Master File
Create New Part or Product Master Record
Part Transaction File
Vendor Order Detail File
Edit/Delete Part or Product Master Record
Part Master File
Customer Order Master File
Enter New Part or Product
Part Detail File
Edit/Delete Part or Product
Cust. Order Detail File
Enter Returned Part or Product
Manufacturing Requests
Part Inventory File
Issue Part or Product
Manufacturing Schedule
Re-issue Part or Product
All
View Part or Product
24
INFORMATION DESCRIPTION (contd-4)

• List of transactions should be expanded and
  details should be given as required.
• The transactions will use the classes described
  below as required
• Data flow and Control flow diagrams should be
  supplied.(do not have to be very detailed at
  this stage. Will be discussed in more detailed
  later.)

25
CLASS DESCRIPTIONS
26

Part Transaction Class

• It will list details of all parts entry and
  parts issue transactions, using the Transaction
  ID as the Primary Key. May be used with the Part
  ID to display all transactions for a given part.

• It will be searchable by the various portions of
  the Part ID, date of the transaction, person
  making the transaction, and the transaction type
  indicating the reason for the transaction. It
  will allow a joker character (?) to match any
  character in that position.
• The outputs can be routed to the display, a file
  or the printer.

27
Part Transaction Class (contd)(note Data
elements are stored in DB)

• Methods in class
• getPartDetail
• displayPrint PartDetail
• getPartSummary
• displayPrint PartSummary
• recordStartTime
• getUserId
• recordUserId
• getReservations
• displayPrintReservations
• updateStatus
• recordCompletionTime

• Data Elements
• Trans ID ()
• Trans type View Part
• Trans start time
• User ID
• Part ID
• View type Detail
• Amount on Reserve(may be more than one field)
• Status
• Completion time

28

• Part Inventory Class
• This class will allow viewing the inventory of
  parts by part ID or part name. It will update
  fields as required.This file will be searchable
  by Part ID in ways similar to to the preceding
  file. Its output can be directed to the display,
  a file or a printer. Its contents should be
  verified periodically by complete or partial
  physical inventories.

29
Part Inventory Class (contd)(note Data
elements are stored in DB)

• Methods in Class
• getPartInvRec
• updatePartInvRec
• displayPrintPartInvrec

• Data Elements
• partId ()
• totalInStock
• totalOnReserve
• amountOnOrder(can be one or more fields)
• amtExpectedByDate(can be one or more fields)
• lastEntryTransId
• lastIssueTransId

30
Part Master Class (note Data elements are
stored in DB)

• Methods in Class
• getPartDetailById
• getPartDetailByName
• createNewPart
• deletePart
• updatePartMaster
• displayPrintPartMaster

• Data Elements
• partId ()
• partName

31
Part Detail Class(note Data elements are
stored in DB)

• Methods in Class
• getPartDetailById
• updatePartDetailById
• displayPrintPartDetail

• Data Elements
• partId ()
• partName
• partDrawingNo
• height
• width
• weight
• price

32
3. FUNCTIONAL DESCRIPTION

• Each function is described in detail.
• Functional Partitioning - None
• Functional Description
• Processing Narrative
• Functional Constraints
• Performance Requirements
• Design Constraints
• Supporting Diagrams

33
TRANSACTION DESCRIPTIONS
34
Create New Part or Product Transaction

• Narrative Creates a new part or product type.
  After the type has been created, part or product
  instances can be entered. Permits user to enter a
  new type code and its description. The type code
  should be selected according to the Part/product
  Type Code Guidelines document. Uses PartMaster
  Class and PartDetail Class.
• Constraints Requires Product Administrator
  rights for use.Performance constraints Since
  it locks PartMaster, the transaction should
  time-out after 15 seconds and backout all
  changes.Design Constraints Must check type
  code for compliance with GuidelinesSupporting
  Diagrams See Class diagram for PartMaster and
  Part Detail classes.

35
Edit/Delete Part or Product Transaction

• Permits user to edit the description of a part or
  product or delete it. If there are any instances
  of the part or product, it can not be deleted.
  Uses PartMaster Class, PartDetail Class and
  PartInventory Class.
• Constraints Requires Product Administrator
  rights for use.Performance constraints Since
  it locks PartMaster, PartDetail and PartInventory
  Classes, the transaction should time-out after 15
  seconds and backout all changes.Design
  Constraints Must check type code for compliance
  with Guidelines. Any instances of the part or
  product are in existence, only certain fields may
  be edited.Supporting Diagrams See Class
  diagram for PartMaster and Part Detail classes.

36
Other transactions supported by ICS

• enterNewPart,
• enterReturnedPartProduct
• issuePartProduct
• re-issuePartProduct
• viewPartProduct
• (described similarly)

37
4. Behavioural Description

• Operation as a result of external events and
  internal conditions
• System States
• Events and Actions

38
5. Validation Criteria

• How do we recognize a successful implementation?
  What classes of tests must be conducted to
  validate function, performance and constraints?
• Performance bounds
• Classes of tests
• Test to be performed and expected software
  response
• Special considerations

39
6. Bibliography

• List of references used (books, reports, papers,
  web sites/pages). Make reference as specific as
  possible, including chapter/page for paper pubs
  and detailed URL for Web.

40
7. Appendices (Ekler)

• An executable prototype
• A paper prototype
• Preliminary user manual.(Represents software as
  a black-box. Emphasis is on input and output.)
