Understanding Group Policy

1
Understanding Group Policy

• James Michael Stewart
• CISSP, TICSA, CIW SA, CCNA, MCSE NT W2K, iNet
• michael_at_itinfopros.com

2
What is Group Policy?

• A centralized collection of operational and
  security controls
• Available in Active Directory domains
• Contains items previously found in system
  policies and through editing the Registry (i.e.
  Windows NT)

Submit a question anytime by clicking on the Ask
a Question link in the bottom left corner of your
presentation screen.
3
Elements of Group Policy

• general security controls
• audit
• user rights
• passwords
• accounts lockout
• Kerberos
• Public key policies
• IPSec policies

4
Divisions of Group Policy

• Computer Configuration
• User Configuration

Submit a question anytime by clicking on the Ask
a Question link in the bottom left corner of your
presentation screen.
5
Application of Group Policy

• Group Policy Objects GPOs
• Can be applied to any AD container
• Application order LSDOU
• Local, Site, Domain, Organizational Unit
• Last GPO applied takes precedent

Submit a question anytime by clicking on the Ask
a Question link in the bottom left corner of your
presentation screen.
6
Group Policy Editors

• MMC snap-in Group Policy
• Active Directory Domains and Trusts
• Active Directory Sites and Services

Submit a question anytime by clicking on the Ask
a Question link in the bottom left corner of your
presentation screen.
7
GPO Application

• Inheritance by default
• No Override prevents other GPOs from changing
  settings in this GPO
• Disabled this GPO is not applied to this
  container
• Multiple GPOs on same container application
  order
• Disable Computer Configuration or User
  Configuration
• Set Allow/Deny for Apply Group Policy to control
  user/group application

8
GPO Limitations

• If a single user is a member of 70 to 80 groups,
  the respective GPOs may not be applied
• Problem caused by Kerberos token size 70 to 80
  groups fills the token and causes an error
• Result is no GPOs are applied

9
GPO Uses

• Local GPO
• Windows 2000, XP, .NET

Submit a question anytime by clicking on the Ask
a Question link in the bottom left corner of your
presentation screen.
10
Security Configuration and Analysis

• MMC snap-ins
• Security Configuration and Analysis
• Security Templates
• Used to customize Group Policies a.k.a. security
  templates.
• Several pre-defined security templates for
  client, server, and DC systems of basic,
  compatible, secure, and high security.
• Analyze current security state

11
GPO Password Policy

• Min max password age (0-999)
• Min password length (0-14)
• History (1 - 24 entries)
• Passwords must meet complexity requirements
• Store passwords using reversible encryption for
  all users in the domain

12
GPO Accounts Policy

• Lockout duration (0 99999 minutes)
• Failed logon attempts
• Counter reset after time limit

Submit a question anytime by clicking on the Ask
a Question link in the bottom left corner of your
presentation screen.
13
GPO Audit Policy

• Account logon events Account management
• Directory service access
• Logon events Object access
• Policy change Privilege use
• Process tracking System events
• Object level controls accessed through Advanced
  Security Properties
• Audit policy must be enabled in order for audited
  events to be recorded in the Security log

14
GPO User Rights

• To increase security settings, make the following
  changes
• Log on locally assigned only to Administrators
  on Servers
• Shutdown the System assigned only to
  Administrators, Power Users
• Access computer from network assigned to Users,
  revoke for Administrators and Everyone
• Restore files/directories revoke for Backup
  Operators
• Bypass traverse checking assigned to
  Authenticated Users, revoke for Everyone

15
GPO Security Options

• Numerous security related controls
• Previous found only as Registry edits

Submit a question anytime by clicking on the Ask
a Question link in the bottom left corner of your
presentation screen.
16
GPO misc

• Scripts
• Public Key EFS
• IPSec
• Software
• Administrative Templates
• Templates for Registry alteration

17
Using GPOs

• Group similar users
• Place similar users/groups in separate containers
  (i.e. OUs)
• Define universal GPOs at domain level
• Define specific GPOs as far down the
  organizational tree as possible
• Avoid changing default inheritance mechanism

18
Questions?
Click on the Ask a Question link in the lower
left corner of your screen to ask James Michael
Stewart a question.
