RSC Stormwater Management

1
RSC Stormwater Management

• Mapping

2
Agenda

• Located stormwater inlets and outfalls
  encompassing the immediate surroundings of A
  through N wings.
• Measured dimensions of inlet grates.
• Through campus map blueprints and direct
  observation, located where inlets drain to (some
  unknowns).
• Indicated whether grates were bicycle safe, had
  standing water, and how much debris was visible.
  Some retro fitting needed to comply with
  floatable standards.

3
Agenda

• Hand plotted points of inlets on rough copy of A
  through N wings.
• Developed spreadsheet of findings.
• GPS coordinates and GIS data currently pending.

4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
Outfalls

• Arts and Sciences building drains to wetlands
  below Lake Fred.
• Wings A through E drain to 3 separate headwalls
  located on Lake Fred.
• West Quad drains to adjacent wooded area on
  campus.
• Insufficient data to determine exact locations of
  outfall between N and F wings Some may drain to
  headwalls of A and E, many drain to wooded areas
  off Lake Dr., others may drain to additional
  headwall located near N wing.
