Irrigation

1
Irrigation
2
Water and Irrigation

• IMPORTANT ISSUES WATER QUALITY AND QUANTITY
• CONSERVATION
• TURFGRASS AND WATER
• GRASS PLANT IS 80 TO 95 WATER
• AT 60 H20 THE PLANT DIES

3
Water and Irrigation

• TURGIDITY ______________________________________
  __________________________________________
• TRANSPIRATION RATE DEPENDS UPON ATMOSPHERIC
  CONDITIONS
• TRANSPIRATION RATES ALSO VARY WITH TURF SPECIES
  AND CULTIVAR

4
Turfgrass Water Needs

• AN ACRE TURFGRASS CAN LOSE IN EXCESS OF 10,000
  GALLONS OF WATER TO THE ATMOSPHERE DAILY
• HOT, SUNNY, DRY, WINDY CONDITIONS
• TURFGRASS NEEDS 60 TO 70 GALLONS OF WATER TO
  PRODUCE 1 POUND OF DRY MATTER

5
Water Relations in Turfgrass

• WHEN TRANSPIRATION LOSSES EXCEED ROOT ABSORPTION
  THE FOLLOWING MAY HAPPEN

6
Water Relations in Turfgrass

• LESS _____________________
• REDUCED SHOOT ELONGATION
• DECREASED TURGIDITY AND SUCCULENCE
• METABOLIC PROCESSES BECOME SLOWER

7
Water Relations in Turfgrass

• SYMPTOMS OF DROUGHT STRESS IN TURFGRASS
• LEAVES ________________________________
• (OVERERHEATED, WEAK OR DAMAGED ROOT SYSTEMS, LACK
  OFWATER)
• --
• NEVER MOW, AERIFY, FERTILIZE OR DO ANYTHING TO
  TURF IN DROUGHT STRESS!
•

8
Soil And Water

•  INFILTRATION RATE THE SPEED AT WHICH A SOIL
  CAN ABSORB WATER
• INFILTRATION RATE RANGES FROM 0.1 INCH/HOUR IN
  CLAY SOILS TO AS MORE THAN 3 INCHES/ HOUR IN
  SANDY SOILS
•

9
Soil And Water

• COMPACTION
• RESULTS IN THE LOSS OF MACROPORES (Soil
  structure)
• A CONSIDERABLE DECREASE IN THE INFILTRATION RATE
  OCCURS
•

10
Soil And Water

• PERCOLATION THE MOVEMENT OF WATER DOWN THROUGH
  A SOIL
• SANDY LOAM SOIL 2 FEET IN 30 MINUTES
• CLAY LOAM 2 FEET IN 4 HOURS

11
Soil And Water

• SANDY SOIL

12
Soil And Water

• CLAY SOILS

13
TERMS TO KEEP IN MIND

• FIELD CAPACITY
•
• PERMENANT WILTING POINT
• AVALIABLE WATER

14
From http//cru.cahe.wsu.edu/CEPublications/pnw04
75/pnw0475.html
15
TERMS TO KEEP IN MIND

• ADHESION THE ATTRACTION BETWEEN WATER MOLECULES
  AND THE SURFACE OF SOIL
  PARTICLES

16
TERMS TO KEEP IN MIND

• COHESION THE ATTRACTION BETWEEN MOLECULES OF
  WATER
•
• EVAPOTRANSPIRATION

17
(No Transcript)
18
Irrigation

• FACTORS WHICH INFLUENCE THE AMOUNT AND FREQUENCY
  OF IRRIGATION WATER REQUIRED ARE
• GRASS SPECIES AND CULTIVARS
• SOIL TYPE
• LEVEL OF MAINTENANCE

19
Irrigation

• PRECIPITATION AMOUNT AND FREQUENCY
• WEATHER CONDITIONS
• HUMIDITY, WIND AND TEMPERATURE

20
Determining When Grass Needs Water And
Application Rates

• WATER WHEN SYMPTOMS OF MOISTURE STRESS APPEAR
• COLOR OF TURF---BLUE-GREEN OR GRAYISH GREEN
• TRACKING REMAINS-FOOTPRINTS OR MACHINERY TRACKS
• SOIL EXAMINATION----
• KNIFE OR SOIL PROBE
• TENSIOMETER

21
Fromhttp//lieth.ucdavis.edu/Research/tens/97/Te
nsiometer- pull of water moves gauge
22
Determining When Grass Needs Water And
Application Rates

• MOISTURE METERS WHICH MEASURE ELECTRICAL
  RESISTANCE BETWEEN ELECTRODES
• http//www.sowacs.com/sensors/gypsum.html
• NEAR INFRA RED REFLECTANCE
• http//www.sensortech.com/main_pages/moisture/infr
  ared.htm
• TIME DOMAIN REFLECTOMETRY
• http//www.sowacs.com/sensors/tdr.html

23
Determining Turfgrass Water Needs

• EVAPORATION PANS IN A SUNNY LOCATION

24
Determining When Grass Needs Water And
Application Rates

• ESTIMATE OF THE EVAPOTRANSPIRATION
• http//ag.arizona.edu/azmet/et1.htm
• COOL SEASON TURF GENERALLY REQUIRES ABOUT
• _________________________________________________
  _______________________________
• http//www.soils.wisc.edu/wimnext/water.html

25
(No Transcript)
26


• How should irrigation be applied?
• A ___________ IRRIGATION APPLIED IN
  __________________ TO AVOID RUN OFF ONCE OR TWICE
  A WEEK
• BEST IN SOILS WITH ADEQUATE WATER HOLDING
  CAPACITY AND DEEPLY ROOTED TURFGRASS

27


• SANDY SOILS SHOULD BE IRRIGATED AT LEAST TWICE A
  WEEK, OFTEN DAILY WHEN ET IS HIGH-
• SAND ONLY HOLDS ABOUT 0.1 OF WATER/ INCH OF
  SOIL!

28


• DAILY WATERING IS NOT USUALLY RECOMMENDED---SHALLO
  W ROOTING OFTEN RESULTS.
• However, on sandy soils daily irrigation is often
  required through warm dry periods.

29

• If site specific ET data isnt available,
  irrigation to replacement of 75-80 of open pan
  evaporation is usually adequate for most cool
  season turf.

30
Determining Irrigation Needs

• PROPER AMOUNT OF WATER IS THE SOIL WET TO A
  DEPTH JUST BELOW THE MAJORITY OF THE ROOT SYSTEM
  ?
• THIS IS USUALLY 4 TO 6 INCHES
• PLACEMENT OF CONTAINERS TO COLLECT WATER FROM
  SPRINKLERS----DETERMINATION OF PRECIPITATION RATE
• http//www.bae.ncsu.edu/programs/extension/publica
  t/wqwm/ag508_6.html

31
Time of Day to Irrigate

• BEST TIME
• NIGHT----DISEASE PROBLEMS MAY DEVELOP IF THE
  GRASS IS DAMP OVERNIGHT (LWD)

32
Other Water Application

• SYRINGING LIGHT WATERING LASTING NO LONGER THAN
  A FEW MINUTES
• GENERALLY DONT WANT TO __________________________
  ____________
• BEST PERFORMED EARLY AFTERNOON MOST USED ON
  GOLF COURSE TURF
•

33
Some Basics of Sprinkler Irrigation

• Length of irrigation cycle is dependent on soil
  type.
• Generally, ___________________________ are more
  effective than one long cycle.
• Many sprinkler types are available to homeowners.
  (soaker hoses, oscillating, impact, etc)

34
(No Transcript)
35
Some Basics of Sprinkler Irrigation

• Average precipitation rate with average water
  pressure is around 0.5 per hour. Test
• The more hose you put out, the greater the
  pressure loss so you must increase watering time
  in areas where more hose is needed to reach
  sprinkler.

36
Some Basics of Sprinkler Irrigation

• Precipitation rate at the edge of the pattern is
  generally ________________________________ for
  most types of sprinklers.
• Wind greatly effects distribution pattern of all
  above ground sprinkler systems.

37
Some Basics of Sprinkler Irrigation

• In ground systems should be designed with
  ________________________________to assure even
  distribution of water.

38
(No Transcript)
39
Head to head coverage
40
Some Basics of Sprinkler Irrigation

• http//www.rainbird.com/
• http//www.toro.com/landscape/irrigation/index.htm
  l
• http//www.arrosage.com/
• http//jessstryker.com/

41
Effective Coverage and Coefficient of Uniformity

• Older impact type sprinklers actually have about
  the ___________________________, however these
  heads are rarely used anymore.
• Rotor driven sprinklers are the most commonly
  used sprinklers, especially on large sites.
  Rotor driven sprinklers also have a
  ________________________________________
• Pop up fixed spray heads generally have a lower
  ________________________________________.
  However, they are still commonly used on many
  residential sites due to their low cost.

42
Fixed spray head performance.
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
