Thinner tile, Better life

1
Thinner tile, Better life
2
Factory Profile

• Environmental Friendly Product Life Circle
• High Physical Performance
• Excellent Glaze Surface

• 6mm 300x600 series
• 8mm 900x450 series

3
Company Profile
Thin Light Wall tile----- Environmental
friendly tile for a healthy and
substantial lifestyle.

• VASAIO of Lehua Group has cooperated with our
  European institution for 3 years, and now present
  a revolutionary ceramic product 6mm Thin Light
  Wall Tile. (TL Wall)

4
3 Main Sizes

• 300x600mm (Launched)

• 450x900mm (Launched)

• 350x750mm
• (Launching on Oct.,2011)

5
Thickness
6mm
6mm
8mm
300x600 mm 12x24
350x750mm 14x30
450x900mm 18x36
TL NORMAL
TL NORMAL
TL NORMAL
6mm 10mm
6mm 10mm
8mm 12mm
6
6mm TL Wall Tile
Greenleaf Certification
VASAIOs TL green thin tile is going through
Interteks Greenleaf Certification.. We
care the environment and the life...
7
6mm TL Wall Tile
Green Product Life Circle
Safer disposal 50 degrade time as traditional
tile after disposal
Lower carbon dioxide manufacture 6mm thick,
40 lighter than the normal tile Reduce 40 raw
material cost
Reduce 30 water use.
Reduce 30 CO2 emission.
Greener and better use experience 1/3
architecture weight reduced, 1/3 paving time
shortened. Directly repaving the original
building surface, easy for DIY design
Lighter carbon foot print Rail to the port,
reducing trucks gasoline consumption 2000 sqm
of one container 1/3 transportation cost saved
1/3 storage space saved
8
6mm TL Wall Tile
Green Product Life Circle
Coming up VASIAO is carrying the Green product
innovation in the future. The large size
porcelain tile will be put into the market in
2012.

• Recycle paper cupboard and easy degrade paper
  corner, recycle box and ink printing
• FSC recycle wood pallet
• cargo from factory to harbor by electronic train.

9
High Physical Performance
Excellent Glaze Surface
VASAIO is using a new ceramic body which renews
the sintering technique to produce a stronger
tile. Breaking
Strength466.6N/? Compared to the radical 4mm
tile, 6mm TL require no change in peoples using
habit.
10
High Physical Performance
THIN LIGHT CERAMICS THIN LIGHT CERAMICS THIN LIGHT CERAMICS THIN LIGHT CERAMICS
Tested Features Chinese Standard European Standard VASAIO Standard
Water Absorption gt10 gt10 gt10
Dimensional Variation gt10 gt10 gt10
Length and Width 0.5 0.5 0.4
Thickness 10 0.5 0.60.65mm
Warpage 0.3 0.6 0.2
Wedging 0.3 0.5 0.2
Linearity 0.2 0.3 0.2
Flatness 0.20.4 0.5 0.2
Bending Strength(N/mm2) 15 / 18
Modulus of rupture(N) 600 / 800
Thermal expansion coefficient(MK-1) / 9 6
Chemical Resistance not less than grade B not less than grade B grade A
Stain Resistance(Stains removed with warm running water) Not less than grade 3 Not less than grade 2 Grade4-5
6mm TL Wall Tile
11
6mm TL Wall Tile
Excellent Glaze Surface
Hyper- flatness Technique, orange skin
free Breakthrough in microstructure better
visual effect

Hyper-flatness Glaze
Normal Glaze
Particle Distribution Illustration
12
Company Intro
Lehua Group Wish Ceramics Co., Ltd. Ceramic tile,
sanitary ware, tub, shower room, kitchen
cupboard. Biggest manufacture base in China.

• Lehua is one of the biggest ceramic sanitary
  ware manufacturers in China, branding in ARROW,
  FAENZA, ANNWA and export brand VASAIO.
• VASAIO Ceramic includes rustic tile, polished
  tile, glazed tile and Thin and Light Tile,
  focusing on the development of green product

13

Factory Profile
VASAIO
-----Environmental Technology A Healthy
Lifestyle
Lehua Jingdezhen Manufacture Base The most trendy
work field with the highest production standard
in China

• Natural gas-burning kiln and energy system
• Dust smoke free workshop
• Imported equipment
• Automatic packaging equipment

14
The Largest Base in China
Factory Profile
15
Clean Factory Environment
Factory Profile
16
Smoke Free Natural Gas Energy System
Factory Profile
17
Individual Workshop Dust Free
Factory Profile

18
Individual workshop for glaze Line wet floor,
stable temperature
Factory Profile
19
Cover for glaze line
Factory Profile
20
German Imported Kiln Temperature
Control System
Factory Profile

21
Automatic Packing Machine
Factory Profile
22
Factory Profile
Pack Scene
23
6mm 300x600 size

• Mono Color

VGM00063 VGM00063M VGM00163 VGM00163M
VGM00963 VGM00963M
Marble Texture
VGM32263 VGM32363 VGM34063
VGM36363 VGM39263 VGM39463
24
6mm 300x600 size

• Marble Texture

VGM35363 VGM38263
VGM37363
25
6mm 300x600 size
Dimension
VGM17063M VGM42063 VGM18063 VGM18963 VGM04163
VGM23063 VGM16063 VGM16263 VGM17063
26
6mm 300x600 size
Wall Paper
VGM31163 VGM31163F VGM40163 VGM40363F VGM43263
VGM43363F
27
6mm 300x600 size
Free Style
VGM12063 VGM12363 VGM12763
VGM18063 VGM29063 VGM19763 VGM29363
VGM28063 VGM28063M
VGM33063 VGM33363F VGM44063 VGM44363 VGM44463
28
6mm 350x750 size
VGM0007535
VGM0017535
VGM0097535
VGM0017535M
VGM0017535M
VGM0097535M
29
6mm 350x750 size
VGM3927535
VGM3947535
VGM4827535
VGM4617535
VGM5517535
VGM5357535
30
8mm Thickness450x900 Large size Thin Tile
Free Style
VGM39494 VGM46194 VGM48294
VGM53294 VGM53594 VGM55194
31
RD System
Investment in design innovation Lehua possesses
38 patents and 100 national design patents. We
place 2 of our sales volume into the research,
and renew our product by 25 per year. Lehuas
basic research with institutions with higher
education We cooperated with Tsinghua University,
South China University of Technology and
Jingdezhen Ceramics school. Global design
VASAIO buys new tile design from Italy directly,
and cooperates with our European research
partners for development of our own design.
32
Packaging Details
600x300mm TL Item Unit Normal
Carton weight Kg/ctn 24
Carton pieces Piece/ctn 12
Carton thickness mm 6.0
Carton sqm m2/ctn 2.16
Carton corner Pcs/ctn 8
1.1x1.1m pallet ctns/plt ctns/plt 48
container plts plts 20
container sqm ? 2,073
container ctns 960
container weight KG 24,000
1.2x0.8m pallet ctns/plt ctns/plt 48
container plts plts 22
container sqm ? 2,281
container ctns 1,056
container weight KG 26,400
33
Packaging Details
450x900mm TL Item Unit
Carton weight Kg/ctn 24.5
Carton pieces Piece/ctn 4
Carton thickness mm 8
Carton sqm m2/ctn 1.62
Carton corner Pcs/ctn 4
1.1x1.1m pallet ctns/plt ctns/plt 56
container plts plts 20
container sqm ? 1,814
container ctns 1120
container weight KG 27,320
1.2x0.8m pallet ctns/plt ctns/plt 43
container plts plts 22
container sqm ? 1,532
container ctns 946
container weight KG 23,144
34
CE CERTIFICATE
