Title: LEVERS


1
LEVERS
2
Definition Concept
  • Lever is a simple machine which operates
    according to the principles of moment.
  • Lever is a rigid bar which can rotate about a
    fixed point when a force is applied to overcome a
    resistance.

3
Definition Concept
  • Lever A bar that is free to move about a fixed
    point
  • Parts of a lever
  • Fulcrum The fixed point of a lever
  • Effort Arm The part of the lever that the
    effort force is applied to (measured from the
    fulcrum to the point at which the force is
    applied)
  • Resistance Arm The part of the lever that
    applies the resistance force (measured from the
    fulcrum to the center of the resistance force)

4
(No Transcript)
5
(No Transcript)
6
Function of Lever
  • Lever perform two important functions
  • They are used either to overcome a larger
    resistance than the effort applied.
  • OR
  • To increase the distance a resistance can be
    moved through by applying greater effort than the
    resistance.
  • Note When there is no motion, the effort turning
    effect equals the resistance turning effect, and
    the lever system is said to be balanced.

7
Lever Arms
  • Lever arms are commonly defined as the portion of
    the lever between the fulcrum and the force
    point.
  • The effort arm is the distance between the
    fulcrum and the effort point.
  • The resistance arm is the distance between the
    fulcrum and the resistance point.

8
Mechanical Advantage
  • By using the length of the effort arm and the
    resistance arm we can find the ideal mechanical
    advantage.
  • Ideal Mechanical Advantage (IMA) if there were
    no energy lost due to friction the
  • IMA length of effort arm le
    .
    length of resistance arm lr

9
There are 3 types of levers
  • 1st Class Levers
  • 2nd Class Levers
  • 3rd Class Levers

10
1st Class Lever
  • The fulcrum is located between the Fe and the Fr.
    First class levers can multiply force and
    distance.
  • Examples Scissors, see-saw

11
2nd Class Lever
  • Resistance is located between the effort force
    and the fulcrum. These levers multiply the force
    but the direction stays the same.
  • Example Wheelbarrow

12
3rd Class Lever
  • The effort force is located between the fulcrum
    and the resistance. The effort arm is always
    shorter than the resistance arm so it cannot
    multiply the force and the MA is always less than
    1.
  • Examples Rake, hockey stick

13
Principle of Lever
  • A lever of any class will balance when the
    product of the effort arm and effort equal to the
    product of resistance arm and resistance.
  • This is known as principle of levers.
  • It enables us to calculate the amount of effort
    needed to balance a known resistance.

14
Cont.
  • If any three of the four values are known the
    remaining one can be calculated by using the
    following equation.
  • E x EA R x RA
  • Where E Effort
  • EA Effort Arm
  • R Resistance
  • RA Resistance Arm

15
Cont.
  • A lever whose effort arm is longer of the two
    whether it be a Ist or IInd class lever, is said
    to favor force. (Less effort is required to
    overcome a resistance )
  • Conversely, a lever whose resistance arm is
    longer, whether it be a Ist or IIIrd class lever,
    is said to favor speed and distance.

16
Relation of Speed to Range of Movement of Levers
  • In angular movement speed and range are
    interdependent.
  • For instance if two IIIrd class lever of
    different length moves through a 40 degree angle
    at the same angular velocity, the tip of the
    longer lever will be traveling a greater distance
    than the tip of the shorter lever.

17
Cont.
  • Since both the lever is traveling their distance
    in equal time the longer lever must be traveling
    faster than the shorter lever.

18
Selection of Lever
  • Skill in motor performance depends upon the
    effective selection and use of levers, both
    internal and external.
  • Long golf clubs are selected for distance and
    shorter clubs for accuracy at close range.
  • Heavy base ball bats are chosen by those with
    good strength whereas children are often taught
    tennis with short handled racquets

19
Cont.
  • In most instance the external levers are designed
    for a specific purpose and are selected
    accordingly.
  • Whereas the levers in the human body are not
    designed for one action or purpose, so the sports
    person must use his body parts as a lever as per
    the requirement.

20
Cont.
  • Shorter body levers increases angular velocity
    while the positioning of body parts to form a
    long position favor linear speed and range of
    motion.

21
Identification and Analysis of Levers
  • For identifying a lever one should find the
    following answers
  • What is the location of the fulcrum
  • Where is the effort point and where is the
    resistance point
  • What is the length of effort arm
  • What is the length of resistance arm
  • What are the relative length of effort and
    resistance arm
  • What kind of movement does it favors

22
Levers QuizUse the following slides to quiz
yourself on how how well you can match commonly
used items with their correct class of lever.
23
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class3
24
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
25
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
26
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
27
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
28
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
29
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
30
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
31
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
32
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
33
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
34
Chose the correct Lever classification for the
tool pictured below.
Class 1 Class 2
Class 3
35
END
