Introduction to Yacc

1
Lex and Yacc
COP - 3402
2
General Compiler Infra-structure
Syntactic Structure
Program source (stream of characters)
Tokens
Scanner (tokenizer)
Parser
Semantic Routines
Lex
Yacc
IR Intermediate Representation (1)
Analysis/ Transformations/ optimizations
Symbol and Attribute Tables
IR Intermediate Representation (2)
Code Generator
Assembly code
3
Lex Yacc

• Lex
• generates C code for the lexical analyzer
  (scanner)
• Token patterns specified by regular expressions
• Yacc
• generates C code for a LR(1) syntax analyzer
  (parser)
• BNF rules for the grammar

4
Lex

• lex is a program (generator) that generates
  lexical analyzers, (widely used on Unix).
• It is mostly used with Yacc parser generator.
• Written by Eric Schmidt and Mike Lesk.
• It reads the input stream (specifying the lexical
  analyzer ) and outputs source code implementing
  the lexical analyzer in the C programming
  language.
• Lex will read patterns (regular expressions)
  then produces C code for a lexical analyzer that
  scans for identifiers.

5
Lex predefined variables and functions
6
Lex Pattern Matching Primitives
7
Lex Pattern Matching Examples
8
Example Simple Calculator

• Computes the basic arithmetic operations
• Allows declaration of variables
• Enough to illustrate the basic structure of Lex
  and Yacc programs

9
Lex program structure
definitions rules subroutines
include ltstdio.hgt include "y.tab.h" int
c extern int yylval " " a-z
c yytext0 yylval c - 'a' return(LETTER)
0-9 yylval atoi(yytext)
return(NUMBER) a-z0-9\b c yytext0
return(c)
10
Pattern Matching and Action
Match a character in the a-z range
Buffer
a-z c yytext0 yylval c - 'a'
return(LETTER) 0-9 yylval
atoi(yytext) return(NUMBER)
Place the offset c a In the stack
Match a positive integer (sequence of 0-9 digits)
Place the integer value In the stack
11
Yacc

• Grammars described by rules using a variant of
  the Backus Naur Form (BNF)
• Context-free grammars
• LALR(1) parse table is generated automatically
  based on the rules
• Actions are added to the rules and executed after
  each reduction

12
Yacc Program Structure
include ltstdio.hgt int regs26 int
base token NUMBER LETTER left ''
'- left '' '/ list list
stat '\n' list error '\n' yyerrok stat
expr printf("d\n",1)
LETTER '' expr regs1
3 expr '(' expr ')'   2
expr '' expr 1
3 LETTER regs1
main()return(yyparse()) yyerror(CHAR
s)fprintf(stderr, "s\n",s) yywrap()
return(1)
definitions rules subroutines
13
Rule Reduction and Action
Action
Grammar rule
stat expr printf("d\n",1)
LETTER '' expr regs1
3 expr expr '' expr
1 3 LETTER
regs1
or operator For multiple RHS
14
Further reading

• A Compact Guide to Lex Yacc, Thomas Niemann
  (recommended)
• Lex Yacc, Doug Brown (OReily)
• Lots of resources on the web
• Check our website for some suggestions

15
Conclusions

• Yacc and Lex are very helpful for building the
  compiler front-end
• A lot of time is saved when compared to
  hand-implementation of parser and scanner
• They both work as a mixture of rules and C
  code
• C code is generated and is merged with the rest
  of the compiler code
