Dante Security Sales Presentation

1
Dante Security Sales Presentation

• Valley Stream, NY USA
• July 1, 2014

The Management thanks you in advance
www.dantesecurity.net
sales_at_dantesecurity.net
2
About Dante Security

• Dante Security, located in Valley Stream, NY, USA
  and 10 minutes from John F. Kennedy International
  Airport is a manufacturer of CCTV and
  Communications equipment with offerings that
  provide users outstanding, integrated Video
  Surveillance solutions. With a staff that has
  accumulated over 25 years experience in the
  design of equipment and systems, our approach is
  to
• Be Customer oriented and build strong, long
  lasting relationships
• Encourage our staff to take care of issues with
  a sense of urgency
• Focus on the design requirements and offer
  compelling technology
• Learn, listen, communicate, educate, train and
  respond with courtesy
• Deliver innovative products from sharp Research
  and Development
• Enjoy the competitive advantages of worldwide
  outsourcing

3
About Dante Security

• Dante Security outstanding products are backed by
  Training, Design Assistance, Comprehensive
  Warranty and Technical Support
• Authorized Distributors are trained in each
  country by Dante
• Representatives and at no charge at our
  Headquarters in USA
• Dante Security provides Warranty Stock of
  complete products and
• components with up to 10 Consignment to
  Authorized Distributors
• Warranty Replacement or repair of Dante Security
  products is provided
• on speedy turn around time
• Dante Security Representatives are hands-on
  Engineers who available for
• pre-sale Site Survey and post-sale Technical
  Support
• Project Design Assistance based on years of
  active participation in medium
• and large projects is the basis of our
  companys strength
• Dante Security IP System designs are based on
  latest Network centric
• technology

4
Major Markets Served

• Homeland Security
• Correctional Centers
• Petrochemical Industry
• Corporate and Banking
• Casinos and Hospitality

• Health Care Centers
• Schools and Universities
• Government and Military
• Power Generating Plants
• Traffic Surveillance (ITS)

5
Video Surveillance

• Box Style Cameras
• 1/4 23x Zoom D/N Cameras 600/680TVL with WDR
• 1/3 Low Light Day/Night Cameras 700TVL using
• SONY 960H CCD Image Sensor and EFFIO E DSP
  D-WDR
• Minimum Illumination 0.05/Lux
• 1/3 Low Light Day/Night Cameras 690TVL w/PIXIM
• Image Sensor, super WDR to 120dB range
• Minimum Illumination 0.05/Lux
• 1/3 D/N Cameras 650/700TVL OSD, true WDR
• SONY 960H CCD Image Sensor and EFFIO P DSP
  true WDR
• Minimum Illumination 0.0001/Lux
• Auto Color to Day/Night switchover
• OSD Control Functions
• Lens, Shutter, WB, BL, true WDR, Cam ID,
  Color,

6
Video Surveillance

• Mini, Vandal Eyeball Dome Cameras
• 1/3 D/N Indoor Mini Dome 700TVL, 650/700TVL
• Plastic Housing, Fixed or Vari-Focal Lens
• 1/3 D/N Vandal Dome 700TVL, 650/700TVL
• w/3 Axis Gimball, Vari-Focal Lens, IP65
• 1/3 D/N Vandal IR Dome 700TVL, 650/700TVL
• w/3 Axis Gimball, Vari-Focal Lens, IP65 18,
  35 IR LEDs
• 1/3 D/N Eyeball Dome 700TVL, 650/700TVL
• w/3 Axis, Vari-Focal Lens IR 36 LEDs
• IR Day/Night Cameras-IP66
• 1/3 IR ANPR Day/Night Camera 2MP
• License Plate Recognition

7
Video Surveillance

• High Speed Mini PTZ Domes
• 1/4 IP66 Day/Night Mini PTZ Domes
• Samsung 500TVL 10X Optical, 10X Digital Zoom
• Sony 530TVL 10x Optical, 12X Digital Zoom
• Flush Mount and Bracket Mount
• High Speed PTZ Dome Cameras-IP66
• DIP Select protocols Pelco P/D, Coaxitron, GE
  Kalatel,
• AD Manchester, Bosch Biphase
• 0 to 950 Tilt, 3D Coordinates of P/T and Camera
  Angle view
• 256 Presets, 8-24 Privacy Masking Zones
• 8 Sequences, 8 Patterns, 8 Programmable Tours
• 7 Alarms in, 2 out RJ-45 Software upgrade
• IR Illuminator Version 100m night vision
• 1/4 Indoor Color PTZ Domes
• Sony 480TVL and 600TVL, 18X Optical, 12X Digital
  Zoom
• Hitachi 480TVL, 22X Optical, 12X Digital Zoom

8
Video Surveillance

• Rugged, Shock Proof, Integrated PTZ IP67
• Camera Positioning System
• Indoor/Outdoor D/N Hitachi, Sony 26x, 30x, 35x,
  36x
• LED Version w/2 IR Illuminators 100m
• Laser Version w/2 IR Illuminators - 200m
• Integrated Pan, Tilt, Zoom Camera
• Positioning System optional IR
• D/N Hitachi 30x, 35x Sony 26x, 36x Zoom
• 3600 Continuous Pan Rotation
• -850 to 400 Tilt
• Operating Wind speed 90mph/135Km
• Built-in Multi-protocol Receiver/Driver, Pelco
  D/P
• Sunshield, Heater and Fan
• 3 Mode Wiper, Aux control of Spray
• Wall, Corner, Pole and Pedestal mount
• LED Version w/2 IR Illuminators 100m

Rugged PTZ Camera System
Rugged PTZ Cam with IR illuminators
Integrated PTZ Camera System
Integrated PTZ Cam with IR illuminators
9
Video Surveillance

• Thermal Integrated PTZ Camera Positioning System
• Dual Thermal and CCD Camera Positioning System
• Rugged, Shock Proof, IP67 Aluminum
  Pole/Pedestal
• IP66 Aluminum Vehicle mount version
• Thermal and Day/Night Sony CCD 36x Zoom
• 3600 Continuous Pan and 1250 Tilt
• Images 320x240 and 640x480 Pixels Resolution
• Uncooled LWIR Thermal Imaging Sensor
• 50mm, 100mm or 36-180mm Lens on Thermal Camera
• Hardened Germanium Glass Window
• Detects Humans up to 650m
• Detects Objects up to 5Km
• Windshield Wiper
• Aluminum Alloy Housing
• Anti-impact and anti-vibration design
• 12VDC and 24VAC/24VDC Versions

Rugged Dual Thermal CCD 36x Zoom Cam PTZ
Pole/Pedestal System
Dual Thermal CCD 36x Zoom Camera PTZ System
Thermal Cam PTZ System
10
Video Surveillance

• Matrix Switcher/Controller
• Box Style Enclosure Small Installations
• Up to 48 camera Inputs x 16 Monitor Outputs
• Matrix Switcher with CPU
• Bay Style Enclosure Enterprise Installations

• Up to 4096 Camera inputs x 512 Monitor outputs
• NTSC PAL Compatible Cross Point Switchers
• Available with Looping and Audio
• Compatible with Pelco Matrix Switchers
• LAN Networking of Switchers via TCP/IP
• Multiple Language Menu OSD
• Windows GUI System Management Software
• Multiple ASCII Communication Ports
• CPU with Bay Enterprise Version
• Password Protected Programming Menu
• Available with 120VAC/60Hz and 230VAC/50Hz

11
Video Surveillance

• Video Accessories
• Keyboard/Controller for DVR TCP/IP
• Keyboard/Controller for Matrix Switcher
• Direct Control of DVRs, Switchers, PTZ Domes
• Variable/Fixed Speed Pan/Tilt 3D Joystick
• PC USB Keyboard for Network Control of IP PTZ
• PTZ Control Code Generator/Distributor
• PTZ Control Code Data Merger
• PTZ Protocol Converter Major Brands
• Alarm Interface and Relay Interface
• Indoor and Outdoor Receiver/Drivers
• Video Video-Audio Distribution Amplifiers
• Fixed, Vari-focal Motorized Camera Lenses
• Camera Housings Mounts

12
Video Surveillance

• DLA Series H.264 DVRs Hybrid
• Standalone 4/8/16 Video, Audio, Looping D1

• Central Management Software unlimited Cameras

with 8HDD

• H.264 DVR/DVS and Hybrid DVR w/LINUX embedded OS

• G.711 Audio compression record synch. with
  video
• DVR 4/8/16 Video, Audio, Looping, 1 duplex
  Voice, 2 BNC
• Monitor outputs, 1 VGA HD (1920x1080) 1080p
• Hybrid DVR up to 16 Analog and 16 IP Video
  inputs
• Up to 8 H/D slots or 6 H/D and built-in DVD-RW
• Pentaplex functions simultaneously record,
  display,
• up to 16 playback, backup transmit over
  network
• DLA3800-3900 DVR with 2 HDD Record 480fps _at_D1
• DLA4800-4900 DVR with 4 HDD Record 480fps _at_D1
• DLA5800-5900 DVR with 8 HDD Recording 480fps _at_D1
• DLA6800-6900 Hybrid DVR 8HDD Recording 480fps
  _at_D1
• Network accessibility GigE port IE
  browser/Client Software
• 3D Intelligence, Privacy masking, Motion
  detection
• RS-485 PTZ controls via front panel /Client
  Software
• 16 Alarm Inputs and 6 Relay outputs
• 3 USB Ports (2.0) for Mouse/DVR control 1 eSATA
  Port
• Optional eSATA external Storage Bay - up to 4TB

13
Video Surveillance

• DLA Series H.264 SDI DVRs
• Standalone 4/8/16 Video, Audio, 1080p
• Central Management Software unlimited Cameras

with 4HDD

• H.264 SDI DVR/DVS w/LINUX embedded OS
• G.711 Audio compression record synch. with
  video
• DVR 4/8/16 Video, Audio, 1 duplex Voice, 2 BNC
• Monitor outputs, 1 HDMI HD (1920x1080) 1080p,
  1 VGA
• Up to 8 H/D slots or 6 H/D and built-in DVD-RW
• Pentaplex functions simultaneously record,
  display,
• up to 16 playback, backup transmit over
  network
• DLA7800-7900 SDI DVR 4HDD Recording 240fps _at_
  1080
• DLA8800-8900 SDI DVR 8HDD Recording 240fps _at_
  1080
• Network accessibility GigE port IE
  browser/Client Software
• 3D Intelligence, Privacy masking, Motion
  detection
• RS-485 PTZ controls via front panel /Client
  Software
• 16 Alarm Inputs and 6 Relay outputs
• 3 USB Ports (2.0) for Mouse/DVR control 1 eSATA
  Port
• Optional eSATA external Storage Bay - up to 4TB

14
Video Surveillance

• Hybrid PC Digital Video Recorders
• 16 and 32 Video, Audio, Looping CIF w/IP Inputs

• 16 and 32 Video, Audio, Looping 4CIF w/IP Inputs

• Central Management Software unlimited
  Cameras/Sites

• MPEG4 H.264 DVR/DVS WIN XP and 7 OS
• Audio compression record synch. with video
• 16 Video, Audio, Looping, 1 duplex Voice, 2/4
  BNC
• spot Monitor outputs, 1 VGA, 1000MBps GigE
  Ports
• 4 H/D slots built-in DVD-RW
• Pentaplex functions simultaneously record,
  display,
• playback, backup transmit over network
• DLG5816 Display/Recording 480fps _at_CIF MPEG4
• DLG5916 Display/Recording 480fps _at_4CIF H.264
• Network accessibility IE browser/Client
  Software
• Privacy masking, Intelligent Motion detection
  tied to Alarm
• RS-485 PTZ controls Client Software Web
  Server/5 Users
• 16/32 Alarm Inputs and 8/4 Relay output
• 4 USB Ports (2.0) for Mouse/DVR control Backup
• Video File Tamper Authentication Technology

15
Mobile Video Surveillance

• Vehicle Mobile Fixed Camera System
• IR Camera with 600TVL
• Vehicle Mobile PTZ Camera Positioning System
• Sony D/N 26x, 36x Optical Zoom with WDR
• LED IR Lamp, 100m Night Vision
• IP66 Rating
• Rugged Mobile PTZ Camera Positioning System
• Sony D/N 26x, 36x Optical Zoom with WDR
• Laser IR Lamps up to 200m Night Vision
• IP67 Rating

• H.264, D1 Mobile Digital Video Recorder
• Removable 2.5 HDD w/Lock 1TB Storage
• Available models with built-in GPS Tracking
• Wi-Fi communication (Edge/GPRS/CDMA/3G)
• 12VDC input power supply
• Vibration/Shock Resistance MIL-STD-810F

16
Video Surveillance

• NTSC/PAL CRTs
• 21 Flat Screen Color Monitor 500TVL
• Composite Video - 2 input/outputs, S-Video 1
  Input
• Audio 3 input/outputs, built-in Speaker
• OSD Function, 100-240VAC
• NTSC/PAL/VGA LCD - 1080p
• 15 Color LCD 1024x768
• 17 Color LCD 1280x1024
• 19 Color LCD 1280x1024
• 22 Color LCD - 1920x1080
• 24 Color LCD - 1080p 1920x1080
• 26 Color LCD - 1080p 1920x1080
• 32 Color LCD - 1080p 1920x1080
• 42 Color LCD - 1080p 1920x1080
• 46 Color LCD - 1080p 1920x1080
• 55 Color LCD - 1080p 1920x1080
• 65 Color LCD - 1080p 1920x1080
• Composite, YPbPr, VGA, HDMI, S-Video,
• OSD Function, 100-240VAC

17
Video over Fiber Systems

• Fiber Optic Transmission
• Video, Audio, Data, CC
• Standalone and Rack mount MM, SM
• Digital Series 1, 4, 8 Video
• Digital Series 1 Video/Contact Closure
• 1 Video/2 Audio
• Digital Series 1, 4, 8 Video w/duplex
• Multiprotocol Data on 1 fiber
• Digital Series 1 Video w/duplex Data and
• 10/100MBps Ethernet on 1 fiber
• Digital Series 1, 4, 8 Video w/duplex
• Audio, Multiprotocol Data and
• Contact Closure on 1 fiber

18
Video over Ethernet Fiber Systems

• Fiber Optic Transmission
• Ethernet Point to Point Media Converter
• Digital Series Fast Ethernet 1ch, 4ch
• 10/100Mbps TRX
• Digital Series Gigabit Ethernet
• 10/100/1000Mbps TRX 1ch, 4ch
• Fiber Optic Transmission
• Ethernet Switch Multi-Drop, Self-Healing,
• Managed and Unmanaged
• Digital Series Fast Ethernet
• 10/100Mbps Network Switches
• Multi-Copper Port (8 or 10)
• Self Healing, 2-4 duplex Fiber Ports,
• Redundant Ring DIN Rail Versions
• Digital Series Gigabit Ethernet
• 10/100/1000Mbps Network Switches

19
Video over Wired IP Networks

• IP Video Audio Data Decoders
• H.264/MPEG4/MJPEG IP Encoder/server
• 16ch, 28-ch rack mount Decoders at D1 resolution
• Dual Stream, each Configurable
• Highest rated Video Imaging DSP by TI
• NTSC/PAL Video with Audio/Data/2
• Variable Bit Rate/Constant Bit Rate to 4Mbps
• G.711 Audio Compression sync w/Video
• Support RTP/RTSP Unicast/Multicast
• Built-in intuitive Web Browser
• PTZ Controls via RS-422/RS-485
• Built-in Mini USB (2.0) Port
• Factory Default Reset
• Comply with CE, FCC, ROHS

20
Video over Wired IP Networks

• 1.3MP, 3M, 5M IP Video Cameras
• H.264/MJPEG TI Encoder, Dual Stream
• Color 0.1LUX/50IRE / 0.005LUX/DSS
• Supports HD1080 and HD720 Resolution
• Audio, Alarms, SD Card for Local Recording
• 12VDC and Power over Ethernet
• CE, FCC, ROHS, IP66 (Vandal Domes)
• Box Style Cameras Day/Night
• 1.3 Megapixel IP Cameras 720P HD
• 2.0, 3.0 Megapixel IP Cameras 1080P HD
• 5.0 Megapixel IP Cameras 1080P HD
• with Video out, duplex Audio, RS-485, Alarm
  In/Out
• Vandal Dome Cameras Day/Night
• 2.0 M IP Vandal Domes 1080P HD
• 2.8mm or 3.6mm DC Auto Iris Fixed-focal Lens
• 3.0 M IP Vandal Domes 1080P HD
• with duplex Audio, Alarm In/Out

21
Video over Wired IP Networks

• 3MP IP Video Cameras with IR LEDs
• H.264/MJPEG TI Encoder, Dual Stream
• Sony Exmor CMOS Image Sensor
• Color 0.2LUX / 0LUX/IR ON
• Supports HD1080 and HD720 Resolution
• RTP/RTSP Unicast/Multicast
• 12VDC and Power over Ethernet
• CE, FCC, ROHS, IP66
• IR Vandal Domes Day/Night
• 2.0, 3.0 Megapixel gt1080P
• 2.7-12mm, 3.3-12mm DC Auto Iris Vari-focal Lens
• 3 axis gimbal, 360adjustable pan/tilt
• with Video out, duplex Audio, RS-485, Alarm
  In/Out,
• USB Port, Micro SD Card Slot
• IR Cameras Day/Night with sunshield
• 3.0 Megapixel 1080P- HD
• 3.3-12mm DC Auto Iris Vari-focal Lens 20m

22
Video over Wired IP Networks

• 1.3MP, 2MP IP Zoom Cam, PTZ Domes,
• Integrated PTZ Positioning Cameras
• H.264/MJPEG Compression, dual Stream
• 1.3MP 18x Optical, 16x Digital Zoom HD 720P
• 2.0MP 20x, 30x Optical, 16x Digital Zoom HD
  1080P
• Selectable HD Video Modes, Frame Noise reduction
• Low Light with IR Cut Filter and Wide Dynamic
  Range
• Variable Bit Rate 128Kbps 4 Mbps
• NTSC/PAL Video Looping output
• 255 Presets, 8-24 Privacy Masking Zones
• 5 Auto Scan, 5 Patterns 8 Tours
• RS-422/RS-485 PTZ Data
• 7 Alarm Inputs/2 Relay Outputs
• Die Cast Aluminum Housing with Sunshield
  (outdoor)
• Ethernet and Power Surge Protection
• Compliance with CE, FCC, ROHS, IP66 (outdoor)

23
Video over IP Fiber Networks
24
Video over Wireless IP Networks

• 802.11a Advanced Access Unit
• Wireless Access Unit/CPE, 2.4-6.12GHz,
  54-300Mbps
• Large Scale IP Cameras on Wireless Networks
• Provides maximum throughput lowest installation
  costs
• Best path sequencing for advanced multipath
  resistance
• 3 Versions Access Point, Bridge, Base Station
• Support IEEE 802.11a IEEE 802.3u IEEE 802.3n
• standard and TCP/IP, IPX, NetBEUI protocol
• Wireless Drivers provide low Jitter and Latency
• lt3ms on 40Km link - no decrease in
  Performance

CPE with built-in Ant.
Bridge with built-I Ant.
Omni Ant.
Sector Ant.
Base Station
Dish Ant.
25
Video over IP Wireless Networks
26
Video over IP with Solar Power

• Solar Panels and Accessories
• 140 Watt Polycrystalline Black Frame Solar Panel

• 310 Watt Polycrystalline Black Frame Solar Panel
• 12VDC 125Ah Gel Battery
• 12VDC 225Ah Gel Battery
• 12VDC 20A Charge Controller w/ LVD indicators
• 12VDC to 24VDC Converter, Single Output 24V 2.1A
• 24VDC to 12VDC Converter, Single Output 12V 4.2A
• 12VDC-220VAC Sine Wave Inverter 200W
• 24VDC-220VAC Sine Wave Inverter 200W
• Top of Pole Mount Stainless Steel Hardware

27
Video over Wireless Video over Fiber with Solar
WIRELESS
FIBER
28
Explosion Proof PTZ Products

• Explosion Proof Integrated Camera System
• PTZ w/advanced ¼ DSP CCD Sony/Hitachi Camera
• 26x12, 30x12, 36x12 optical/digital Zoom
• Blower, Heater Wiper w/RS-422/RS-485 Control
• 12VDC, 24VAC and 85-265VAC Versions
• Stainless Steel 316L Materials
• Certified for Exd?CT6(H2)
• Designed to exceed IP67 specifications
• Integrated PTZ w/Housing and IR Lamps
• Pan 360o Continuous, Tilt -90o to 90o
• LED based Ex Proof IR Lamps, 100 meters
• Laser based Ex Proof IR Lamps, 300 meters
• Explosion Proof Camera Housings
• Optional Receiver/Driver for Zoom Module
  Cameras
• Blower, Heater Wiper w/RS-485 Control
• 12VDC, 24VAC and 85-265VAC

29
Video over Networks

• IP Video NVR/Management Software
• Enterprise WIN/OS NVR Management
• Microsoft .Net and SQL Server technology -
  Video Insight
• Unlimited number of Cameras with duplex Audio
• Client, Web Browser DVR like GUI, Digital
  Zoom-in function
• Electronic Map, Alarms, Video Authentication
  Watermark
• Rules Manager, Health Monitor, Long Term
  Storage
• Seamless interfaces with Access Control
• System available from Dante Security
• Enterprise LINUX/OS NVR Management
• Web Browser based Videonext
• Real Time Operating System
• Multiple Screens, Advanced GUI
• Unlimited number of Cameras and Monitors
• v-MX Virtual Matrix Videowall module
• Virtual Joystick and Digital Zoom Features

30
Video over Networks

• IP Video NVR Appliance/Management Software
• Enterprise NVR Management Software in Server
  Appliance
• Windows OS Version unlimited number of Cameras
• Client and Web Browser DVR like GUI, Electronic
  Map, Alarms
• Enterprise NVR Management Software
• Linux OS IP Video NVR Management, Client DVR
  like GUI
• High Performance Dual Core Microprocessor
• H.264/MPEG4 Decoding, 1080p Display
• 4, 8 and 16, 32 IP cameras inputs per NVR Unit
  DNA3000/3500 Series
• 256-ch _at_D1, 128-ch _at_1080p per NVR Unit DNA5000
  Series
• up to 6xHDMI ports(Video Audio), VGA, Audio
  in/out BNC
• 8 HDD or 6HDD, built-in CD/DVD-RW - 16ch/32ch
  16HDD - 64ch/128ch/256ch
• 5 Recording Modes including Schedule, Alarm,
  Motion and combinations
• Record 400/480fps _at_D1, 200/240fps _at_720p and
  100/120fps _at_1080p
• Record Quality CBR, VBR multi-level
• 20 Users simultaneously view, control
• Integrated, Multi-layered Facility Maps

31
Intelligent Video System

• Video Analytics/NVR Management Software
• Advanced Video Motion Detection Orwell 2Ktm
• Perimeter Security version coverage of secure
  large area
• City Surveillance version multiple
  persons/vehicles
• Traffic Surveillance version monitoring
  revenue generation
• License Plate Recognition Module (optional)
• Left Object Detection
• Stopped Vehicle Detection
• Thrown Object Detection
• Fire/Smoke Alarm Detection
• Objects/Vehicles Classification
• Wrong Lane/Speeding Vehicle Detection
• Manage hundreds of Cameras with fewer operators
• Advanced Algorithms - Lowest Rate of False
  Alarms
• Windows Based Operating System
• Virtual Matrix Switcher/Legacy Keyboard
  Interface
• Access Cameras via ID or Digital Map (imported)
