Introduction to Bioinformatics

1
Introduction to Bioinformatics
Lecture 16 Intracellular Networks Graph
theory
2
High-throughput Biological Data

• Enormous amounts of biological data are being
  generated by high-throughput capabilities even
  more are coming
• genomic sequences
• gene expression data
• mass spectrometry data
• protein-protein interaction data
• protein structures
• ......
• Hidden in these data is information that reflects

• existence, organization, activity, functionality
  of biological machineries at different levels
  in living organisms

3
Bio-Data Analysis andData Mining

• Existing/emerging bio-data analysis and mining
  tools for
• DNA sequence assembly
• Genetic map construction
• Sequence comparison and database search
• Gene finding
• .
• Gene expression data analysis
• Phylogenetic tree analysis to infer
  horizontally-transferred genes
• Mass spec. data analysis for protein complex
  characterization
• Current prevailing mode of work

Developing ad hoc tools for each individual
application
4
Bio-Data Analysis and Data Mining

• As the amount and types of data and the needs to
  establish connections across multi-data sources
  increase rapidly, the number of analysis tools
  needed will go up exponentially
• blast, blastp, blastx, blastn, from BLAST
  family of tools
• gene finding tools for human, mouse, fly, rice,
  cyanobacteria, ..
• tools for finding various signals in genomic
  sequences, protein-binding sites, splice junction
  sites, translation start sites, ..

Many of these data analysis problems are
fundamentally the same problem(s) and can be
solved using the same set of tools
Developing ad hoc tools for each application
problem (by each group of individual researchers)
may soon become inadequate as bio-data production
capabilities further ramp up
5
Data Clustering

• Many biological data analysis problems can be
  formulated as clustering problems
• microarray gene expression data analysis
• arrayCGH data (chromosomal gains and losses)
• identification of regulatory binding sites
  (similarly, splice junction sites, translation
  start sites, ......)
• (yeast) two-hybrid data analysis (for inference
  of protein complexes)
• phylogenetic tree clustering (for inference of
  horizontally transferred genes)
• protein domain identification
• identification of structural motifs
• prediction reliability assessment of protein
  structures
• NMR peak assignments
• ......

6
Data Clustering an example

• Regulatory binding-sites are short conserved
  sequence fragments in promoter regions
• Solving binding-site identification as a
  clustering problem
• Project all fragments into Euclidean space so
  that similar fragments are projected to nearby
  positions and dissimilar fragments to far
  positions
• Observation conserved fragments form clusters
  in a noisy background

........acgtttataatggcg ...... ........ggctttatatt
cgtc ...... ........ccgaatataatcta .......
7
Data Clustering Problems

• Clustering partition a data set into clusters so
  that data points of the same cluster are
  similar and points of different clusters are
  dissimilar
• Cluster identification -- identifying clusters
  with significantly different features than the
  background

8
Multivariate statistics Cluster analysis
C1 C2 C3 C4 C5 C6 ..
1 2 3 4 5
Raw table
Any set of numbers per column

• Multi-dimensional problems
• Objects can be viewed as a cloud of points in a
  multidimensional space
• Need ways to group the data

9
Multivariate statistics Cluster analysis
C1 C2 C3 C4 C5 C6 ..
1 2 3 4 5
Raw table
Any set of numbers per column
Similarity criterion
Similarity matrix
Scores
55
Cluster criterion
Dendrogram
10
Cluster analysis data normalisation/weighting
C1 C2 C3 C4 C5 C6 ..
1 2 3 4 5
Raw table
Normalisation criterion
C1 C2 C3 C4 C5 C6 ..
1 2 3 4 5
Normalised table
Column normalisation x/max Column range
normalisation (x-min)/(max-min)
11
Cluster analysis (dis)similarity matrix
C1 C2 C3 C4 C5 C6 ..
1 2 3 4 5
Raw table
Similarity criterion
Similarity matrix
Scores
55
Di,j (?k xik xjkr)1/r Minkowski
metrics r 2 Euclidean distance r 1 City
block distance
12
Cluster analysis Clustering criteria
Similarity matrix
Scores
55
Cluster criterion
Dendrogram (tree)
Single linkage - Nearest neighbour Complete
linkage Furthest neighbour Group averaging
UPGMA (phylogeny) Ward Neighbour joining
global measure (phylogeny)
13
Cluster analysis Clustering criteria

1. Start with N clusters of 1 object each
2. Apply clustering distance criterion iteratively
   until you have 1 cluster of N objects
3. Most interesting clustering somewhere in between

distance
Dendrogram (tree)
N clusters
1 cluster
14
Single linkage clustering (nearest neighbour)
Char 2
Char 1
15
Single linkage clustering (nearest neighbour)
Char 2
Char 1
16
Single linkage clustering (nearest neighbour)
Char 2
Char 1
17
Single linkage clustering (nearest neighbour)
Char 2
Char 1
18
Single linkage clustering (nearest neighbour)
Char 2
Char 1
19
Single linkage clustering (nearest neighbour)
Char 2
Char 1
Distance from point to cluster is defined as the
smallest distance between that point and any
point in the cluster
20
Single linkage clustering (nearest neighbour)
Let Ci and Cj be two disjoint clusters di,j
Min(dp,q), where p ? Ci and q ? Cj
Single linkage dendrograms typically show
chaining behaviour (i.e., all the time a single
object is added to existing cluster)
21
Complete linkage clustering (furthest neighbour)
Char 2
Char 1
22
Complete linkage clustering (furthest neighbour)
Char 2
Char 1
23
Complete linkage clustering (furthest neighbour)
Char 2
Char 1
24
Complete linkage clustering (furthest neighbour)
Char 2
Char 1
25
Complete linkage clustering (furthest neighbour)
Char 2
Char 1
26
Complete linkage clustering (furthest neighbour)
Char 2
Char 1
27
Complete linkage clustering (furthest neighbour)
Char 2
Char 1
28
Complete linkage clustering (furthest neighbour)
Char 2
Char 1
Distance from point to cluster is defined as the
largest distance between that point and any point
in the cluster
29
Complete linkage clustering (furthest neighbour)
Let Ci and Cj be two disjoint clusters di,j
Max(dp,q), where p ? Ci and q ? Cj
More structured clusters than with single
linkage clustering
30
Clustering algorithm

• Initialise (dis)similarity matrix
• Take two points with smallest distance as first
  cluster
• Merge corresponding rows/columns in
  (dis)similarity matrix
• Repeat steps 2. and 3.
• using appropriate cluster
• measure until last two clusters are merged

31
Average linkage clustering (Unweighted Pair
Group Mean Averaging -UPGMA)
Char 2
Char 1
Distance from cluster to cluster is defined as
the average distance over all within-cluster
distances
32
UPGMA
Let Ci and Cj be two disjoint clusters
1 di,j ?p?q dp,q, where p ? Ci and q ?
Cj Ci Cj
Ci
Cj
In words calculate the average over all pairwise
inter-cluster distances
33
Multivariate statistics Cluster analysis
C1 C2 C3 C4 C5 C6 ..
1 2 3 4 5
Data table
Similarity criterion
Similarity matrix
Scores
55
Cluster criterion
Phylogenetic tree
34
Multivariate statistics Cluster analysis
C1 C2 C3 C4 C5 C6
1 2 3 4 5
Similarity criterion
Scores
66
Cluster criterion
Scores
55
Cluster criterion
Make two-way ordered table using dendrograms
35
Multivariate statistics Two-way cluster analysis
C4 C3 C6 C1 C2 C5
1 4 2 5 3
Make two-way (rows, columns) ordered table using
dendrograms This shows blocks of numbers that
are similar
36
Multivariate statistics Two-way cluster analysis
37
Graph theory
The river Pregal in Königsberg the Königsberg
bridge problem and Eulers graph
Can you start at some land area (S1, S2, I1, I2)
and walk each bridge exactly once returning to
the starting land area?
38
(No Transcript)
39
Graphs - definition

• Digraphs Directed graphs
• Complete graphs have all possible edges
• Planar graphs can be presented in 2D and have no
  crossing edges (e.g. chip design)

40
Graphs - definition
0 1 1.5 2 5 6 7 9 1 0 2 1 6.5 6 8
8 1.5 2 0 1 4 4 6 5.5 . . .
Graph
Adjacency matrix
An undirected graph has a symmetric adjacency
matrix A digraph typically has a non-symmetric
adjacency matrix
41
Example application OBSTRUCT creating
non-redundant datasets of protein structures

• Based on all-against-all global sequence
  alignment
• Create all-against-all sequence similarity matrix

• Filter matrix based on desired similarity range
  (convert to 0 and 1 values)
• Form maximal clique (largest complete subgraph)
  by ordering rows and columns
• This is an NP-complete problem (NP
  non-polynomial) and thus problem scales
  exponentially with number of vertices (proteins)

42
Example application 1 OBSTRUCT creating
non-redundant datasets of protein structures

• Statistical research on protein structures
  typically requires a database of a maximum number
  of non-redundant (i.e. non-homologous) structures

• Often, two structures that have a sequence
  identity of less than 25 are taken as
  non-redundant
• Given an initial set of N structures (with
  corresponding sequences) and all-against-all
  pair-wise alignments
• Find the largest possible subset where each
  sequence has lt25 sequence identity with any
  other sequence

Heringa, J., Sommerfeldt, H., Higgins, D., and
Argos, P. (1992). Obstruct a program to obtain
largest cliques from a protein sequence set
according to structural resolution and sequence
similarity. Comp. Appl. Biosci. (CABIOS) 8,
599-600.
43
Example application 1 OBSTRUCT creating
non-redundant datasets of protein structures
(Cnt.)

• The problem now can be formalised as follows
• Make a graph containing all sequences as vertices
  (nodes)
• Connect two nodes with an edge if their sequence
  identity lt 25
• Make an adjacency matrix following the above
  rules

Heringa, J., Sommerfeldt, H., Higgins, D., and
Argos, P. (1992). Obstruct a program to obtain
largest cliques from a protein sequence set
according to structural resolution and sequence
similarity. Comp. Appl. Biosci. (CABIOS) 8,
599-600.
44
Example application 1 OBSTRUCT creating
non-redundant datasets of protein structures
(Cnt.)

• The algorithm
• Now try and reorder the rows (and columns in the
  same way) such that we get a square only
  consisting of 1s in the upper left corner
• This corresponds to a complete graph (also called
  clique) containing a set of non-redundant
  proteins

Heringa, J., Sommerfeldt, H., Higgins, D., and
Argos, P. (1992). Obstruct a program to obtain
largest cliques from a protein sequence set
according to structural resolution and sequence
similarity. Comp. Appl. Biosci. (CABIOS) 8,
599-600.
45
Example application 1 OBSTRUCT creating
non-redundant datasets of protein structures
(Cnt.)

1. Order sum array and reorder rows and columns
   accordingly
2. Estimate largest possible clique and take subset
   of adj. matrix containing only rows with enough
   1s
3. For a clique of size N, a subset of M rows (and
   columns), where M ? N, with at least N 1s is
   selected.
4. Go to step 1.

5 4 6 4 ..
1 0 1 1 1 0 0 0 1 0 1 0 0 1 1 1 0
0 1 0 1 1 1 0 1 1 0 1 0 1 1 0 0 0
0 1 . . . . . . .
?
Adjacency matrix
Heringa, J., Sommerfeldt, H., Higgins, D., and
Argos, P. (1992). Obstruct a program to obtain
largest cliques from a protein sequence set
according to structural resolution and sequence
similarity. Comp. Appl. Biosci. (CABIOS) 8,
599-600.
46
(No Transcript)
47
Some books call graphs containing multiple edges
or loops a multigraph, and those without a graph.
Other books allow multiple edges or loops in a
graph, but then talk about a graph without
multiple edges and loops as a simple graph.
48
Remarks A multigraph might have no multiple
edges or loops. Every (simple) graph is a
multigraph, but not every multigraph is a
(simple) graph. Every graph is
finite Sometimes even multigraph folks talk
about a simple graph to emphasize that there
are no multiple edges and loops.
49
Further definitions
K3,3
50
Further definitions
bipartite                               A
graph is bipartite if its vertices can be
partitioned into two disjoint subsets U and V
such that each edge connects a vertex from U to
one from V. A bipartite graph is a complete
bipartite graph if every vertex in U is connected
to every vertex in V. If U has n elements and V
has m, then we denote the resulting complete
bipartite graph by Kn,m.
K3,3
51
The Stable Marriage Algorithm

• In mathematics, the stable marriage problem (SMP)
  is the problem of finding a stable matching a
  matching in which no element of the first matched
  set prefers an element of the second matched set
  that also prefers the first element.
• It is commonly stated as
• Given n men and n women, where each person has
  ranked all members of the opposite sex with a
  unique number between 1 and n in order of
  preference, marry the men and women off such that
  there are no two people of opposite sex who would
  both rather have each other than their current
  partners. If there are no such people, all the
  marriages are "stable".
• In 1962, David Gale and Lloyd Shapley proved
  that, for any equal number of men and women, it
  is always possible to solve the SMP and make all
  marriages stable.

52
The Stable Marriage Algorithm

• Also called the Gale-Shapley algorithm (see
  preceding slide)
• Given two non-overlapping equally sized graphs of
  men (A, B, C, ..) and women (a, b, c, ), where
  each man and woman has a preference list about
  persons of the opposite sex
• A pairing denotes a 1-to-1 correspondence between
  men and women (each man marries one woman)
• A pairing is unstable if there are couples X-x
  and Y-y such that X prefers y to x and y prefers
  X to Y
• if this happens, pair X-y is called unsatisfied
• A pairing in which there are no unsatisfied
  couples is called a stable pairing or stable
  marriage
• The Stable Marriage Algorithm forms a bipartite
  graph that is stable

53
A abcd denotes the preferences of A (likes a the
most, then b, then c, while d is liked least)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
The Stable Marriage Algorithm

• The Gale-Shapley pairing, in the form presented
  here, is male-optimal and female-pessimal (it
  would be the reverse, of course, if the roles of
  "male" and "female" participants in the algorithm
  were interchanged).
• To see this, consider the definition of a
  feasible marriage. We say that the marriage
  between man A and woman B is feasible if there
  exists a stable pairing in which A and B are
  married. When we say a pairing is male-optimal,
  we mean that every man is paired with his highest
  ranked feasible partner. Similarly, a
  female-pessimal pairing is one in which each
  female is paired with her lowest ranked feasible
  partner.
• Thuis means that men pair with women higher in
  their preference list than where these men appear
  in the list of the women paired to them (on
  average)

58
Graphs - definition
0 1 1.5 2 5 6 7 9 1 0 2 1 6.5 6 8
8 1.5 2 0 1 4 4 6 5.5 . . .
Graph
Adjacency matrix
An undirected graph has a symmetric adjacency
matrix A digraph typically has a non-symmetric
adjacency matrix
59
A Theoretical Framework

• Representation of a set of n-dimensional (n-D)
  points as a graph
• each data point represented as a node
• each pair of points represented as an edge with a
  weight defined by the distance between the two
  points

graph representation
distance matrix
n-D data points
60
A Theoretical Framework

• Spanning tree a sub-graph that has all nodes
  connected and has no cycles
• Minimum spanning tree a spanning tree with the
  minimum total distance

(a)
(c)
(b)
61
Spanning tree

• Prims algorithm (graph, tree)
• step 1 select an arbitrary node as the current
  tree
• step 2 find an external node that is closest to
  the tree, and add it with its corresponding edge
  into tree
• step 3 continue steps 1 and 2 till all nodes are
  connected in tree.

(a)
62
Spanning tree

• Kruskals algorithm
• step 1 consider edges in non-decreasing order
• step 2 if edge selected does not form cycle,
  then add it into tree otherwise reject
• step 3 continue steps 1 and 2 till all nodes are
  connected in tree.

63
A Theoretical Framework

• A formal definition of a cluster
• C forms a cluster in D only if for any partition
  C C1 U C2, the closest point, from D-C1, to C1
  is from C2, in other words, the closest
  connection from the points outside C1 must come
  from within C2
• Key results

For any data set D, any of its cluster is
represented by a sub-tree of its MST
64
A Theoretical Framework

• We can use the result on the preceding slide for
  clustering using PRIMs algorithm
• The order of nodes as selected by PRIMs
  algorithm defines a linear representation, L(D),
  of a data set D
• We can plot the node distances in PRIMs minimum
  spanning tree against the order of the nodes as
  they were added by PRIMs algorithm (see earlier
  slide)

Any contiguous block in L(D) represents a cluster
if and only if its elements form a sub-tree of
the MST, plus some minor additional conditions
(each cluster forms a valley)
4
A
A
B
B
7
PRIMs
edge weight (distance)
E
E
5
3
C
C
D
D
A B E D C
65
A Theoretical Framework
So, if we first calculate all pairwise distances
in the plots below, convert the dots to a
(complete) graph, use PRIMs algorithm to
calculate a MST, and then make the plot as on the
preceding slide, we get for real-size data
Valleys correspond to clusters (red bars)
A nice clustering algorithm.... That can also be
used for signal/noise filtering
66
Take home messages

• Revise agglomerative clustering (e.g.
  nearest/furthest neighbour, group averaging)
• Learn about graphs (complete, (un)directed,
  adjacency matrix, bipartite, etc.)
• Understand the relationship between a graph and
  its adjacency matrix
• Understand the Stable Marriage Algorithm
• Understand Prims and Kruskals algorithm
• Make sure you understand the clustering method
  based on the minimal spanning tree made by Prims
  algorithm (preceding slide)
