Dynamic Load Balancing in Scientific Simulation

1
Dynamic Load Balancing in Scientific Simulation

• Angen Zheng

2
Static Load Balancing No Data Dependency

• Distribute the load evenly across processing
  unit.
• Is this good enough? It depends!
• No data dependency!
• Load distribution remain unchanged!

3
Static Load Balancing Data Dependency

• Distribute the load evenly across processing
  unit.
• Minimize inter-processing-unit communication!
• By collocating the most communicating data into a
  single PU.

4
Load Balancing in Scientific Simulation
PUs need to communicate with each other to carry
out the computation.

• Distribute the load evenly across processing
  unit.
• Minimize inter-processing-unit communication!
• By collocating the most communicating data into a
  single PU.
• Minimize data migration among processing units.

Dynamic Load Balancing
5
Dynamic Load Balancing (Hyper)graph Partitioning

• Given a (Hyper)graph G(V, E).
• (Hyper)graph Partitioning
• Partition V into k partitions P0, P1, Pk, such
  that all parts
• Disjoint P0 U P1 U Pk V and Pi n Pj Ø
  where i ? j.
• Balanced Pi (V / k) (1 ?)
• Edge-cut is minimized edges crossing different
  parts.

6
Dynamic Load Balancing (Hyper)graph
Repartitioning

• Given a partitioned (Hyper)graph G(V, E).
• (Hyper)graph Repartitioning
• Repartition V into k partitions P0, P1, Pk,
  such that all parts
• Disjoint.
• Balanced.
• Minimal Edge-cut.
• Minimal Migration.

Initial Partitioning
7
Dynamic Load Balancing (Hypergraph)
Repartition-Based

• Building the (Hyper)graph
• Vertices represent data.
• Vertex object size reflects the amount of the
  data per vertex.
• Vertex weight accounts for computation per
  vertex.
• Edges reflects data dependencies.
• Edge weight represents the communication among
  vertices.

Reduce the Dynamic Load Balancing to a
(Hyper)graph Repartitioning Problem.
8
(Hypergraph) Repartition-Based Dynamic Load
Balancing Cost Model

•

9
(Hypergraph) Repartition-Based Dynamic Load
Balancing Network Topology

•


10
(Hypergraph) Repartition-Based Dynamic Load
Balancing Cache-Hierarchy

•


11
Hierarchical Topology-Aware (Hyper)graph
Repartition-Based Dynamic Load Balancing

• Inter-Node Repartitioning
• Goal Group the most communicating data into
  compute nodes closed to each other.
• Solution
• Regrouping.
• Repartitioning.
• Refinement.
• Intra-Node Repartitioning
• Goal Group the most communicating data into
  cores sharing more level or caches.
• Solution1 Hierarchical repartitioning.
• Solution2 Flat repartitioning.

12
Hierarchical Topology-Aware (Hyper)graph
Repartition-Based Dynamic Load Balancing

• Inter-Node Repartitioning
• Regrouping.
• Repartitioning.
• Refinement.

13
Hierarchical Topology-Aware (Hyper)graph
Repartition-Based Dynamic Load Balancing

• Inter-Node (Hyper)graph Repartitioning
• Regrouping.
• Repartitioning.
• Refinement.

Migration Cost 2 (inter-node) 2
(intra-node) Communication Cost 3 (inter-node)
14
Topology-Aware Inter-Node (Hyper)graph
Repartitioning

• Inter-Node (Hyper)graph Repartitioning
• Regrouping.
• Repartitioning.
• Refinement.

Migration Cost 2 (intra-node) Communication
Cost 3 (inter-node)

15
Hierarchical Topology-Aware Intra-Node
(Hyper)graph Repartitioning

• Main Idea Repartition the subgraph assigned to
  each node hierarchically according to the cache
  hierarchy.

16
Flat Topology-Aware Intra-Node (Hyper)graph
Repartition

•

17
Flat Topology-Aware Intra-Node (Hyper)graph
Repartition
P1 P2 P3
Core0 Core1 Core2
Old Partition Assignment
Old Partition
18
Flat Topology-Aware Intra-Node (Hyper)graph
Repartition
Old Partition
New Partition
19
Flat Topology-Aware Intra-Node (Hyper)graph
Repartition
P1 P2 P3
Core0 Core1 Core2
Old Partition Assignment
Core0 Core1 Core2 Core3
P1 0 4 4 4
P2 2 2 4 4
P3 4 4 0 4
P4 4 4 0 4
Partition Migration Matrix
P1 P2 P3 P4
P1 0 1 0 0
P2 1 0 3 0
P3 0 3 0 0
P4 0 0 0 0
New Partition
Partition Communication Matrix
20
Flat Topology-Aware Intra-Node (Hyper)graph
Repartition
Core1 Core2 Core3 Core4
P1 0 4 4 4
P2 2 2 4 4
P3 4 4 0 4
P4 4 4 0 4
Partition Migration Matrix
P1 P2 P3 P4
P1 0 1 0 0
P2 1 0 3 0
P3 0 3 0 0
P4 0 0 0 0
Partition Communication Matrix
New Partition

P1 P2 P3 P4
Core0 Core1 Core2 Core3
21
Major References

• 1 K. Schloegel, G. Karypis, and V. Kumar, Graph
  partitioning for high performance scientific
  simulations. Army High Performance Computing
  Research Center, 2000.
• 2 B. Hendrickson and T. G. Kolda, Graph
  partitioning models for parallel computing,"
  Parallel computing, vol. 26, no. 12, pp.
  15191534, 2000.
• 3 K. D. Devine, E. G. Boman, R. T. Heaphy, R.
  H.Bisseling, and U. V. Catalyurek, Parallel
  hypergraph partitioning for scientific
  computing," in Parallel and Distributed
  Processing Symposium, 2006. IPDPS2006. 20th
  International, pp. 10-pp, IEEE, 2006.
• 4 U. V. Catalyurek, E. G. Boman, K. D.
  Devine,D. Bozdag, R. T. Heaphy, and L. A.
  Riesen, A repartitioning hypergraph model for
  dynamic load balancing," Journal of Parallel and
  Distributed Computing, vol. 69, no. 8, pp.
  711724, 2009.
• 5 E. Jeannot, E. Meneses, G. Mercier, F.
  Tessier,G. Zheng, et al., Communication and
  topology-aware load balancing in charm with
  treematch," in IEEE Cluster 2013.
• 6 L. L. Pilla, C. P. Ribeiro, D. Cordeiro, A.
  Bhatele,P. O. Navaux, J.-F. Mehaut, L. V. Kale,
  et al., Improving parallel system performance
  with a numa-aware load balancer," INRIA-Illinois
  Joint Laboratory on Petascale Computing, Urbana,
  IL, Tech. Rep. TR-JLPC-11-02, vol. 20011, 2011.
