Reliability and Failure Analysis of Electronic Components

1
Reliability and Failure Analysis of Electronic
Components

• By
• Dr. Charles Surya, ENC
• CD 636, 6220
• ensurya_at_polyu.edu.hk

2

• For VLSI Circuits to be a useful and growing
  technology, 2 conditions must be satisfied
• Can be produced in large quantities at low cost
• Cats can perform their functions throughout their
  intended lifetime
• To lower the cost of manufacturing, one must
  determine the optimal size of the IC.
• The optimal size is a compromise between several
  competing considerations
• Partitioning of the system
• yield of good circuits
• packaging and system assembly cost
• reliability of complete system
• Large number of ICs results in high yield and
  assembly cost
• To arrive at an optimal division of the system,
  we must be able to predict the total system
  reliability as a function of the number of ICs
  of varying size

3
Mechanism of Yield Loss in VLSI

• Cause for low yield falls into 3 basic
  categories
• Parametric processing problems
• CKT design problems
• random point defects in circuits
• Processing Effects
• Often a wafer is divided into regions good chips
  and bad chips (Fig. 1 p. 614, Sze)
• This is most likely due to processing effects
  such as
• Variations in thickness of oxide or polysilicon
  layers
• Variations in resistance of implanted layers
• Variations in width of lithographically defined
  features

4

• Alignment of photomasks
• e.g. PolySi gate lengths are shorter in thinner
  polySi regions than in thicker polySi regions.
  This may cause channel lengths to be too short
  and transistors cannot be turned off. This leads
  to excessive leakage current
• Variations in thickness of deposited dielectric
  lead to variations in contact window size. This
  may lead to non-operative circuits if the
  circuits depend on having a low value of contact
  resistance.
• Variations in the doping of implanted layers
  which also leads to variations in contact
  resistance
• Also, wafer may vary in size during processing in
  excess of 20ppm. Therefore a 125 mm wafer
  changes in size by 2.5mm. This may cause
  significant misalignment.

5
Circuit Sensitivities

• Certain areas of a wafer have low device yield
  because the design of a ckt has failed to
  consider expected variations in device parameters
  and correlation between variations in different
  parameters.
• Point Defects
• A 3 ?m dust can cause a break in a metal
  conductor
• Si chunks may be knocked out of the wafer during
  processing
• Isolated oxidation induced stacking fault may
  cause excessive leakage current
• Modeling of Yield-loss Mechanisms
• We need to model IC yield in terms of fundamental
  parameters independent of particular IC and
  characteristics of the process and processing
  line because
• by accurately modeling the yield we can predict
  the cost and availability of future ckts

6

• once yield-modeling parameters are known one can
  compare processing quality of different process
  lines and indicate where improvements are
  required
• IC yield is expressed as
• YY0Y1(D0,A,?i)
• 1-Y0 fraction of bad chips due to
  processing related effects
• 1-Y1 remaining fraction of bad chips which
  is a function of density of point defects
• A is the chip area
• ?i is the parameter unique to different models of
  the yield
• Y ratio of good chips to total number of chips
  per wafer
• All models predict Y decreases monotonically as A
  increases
• Yield modeling can identify those processes and
  mechanisms that limit yield of present IC
• The process can then be improved or eliminated as
  needed

7
Uniform Density of Point Defects

• In those areas where yield not degraded by either
  processing or ckt sensitivities, the remaining
  cause of chip failure is randomly distributed
  point defects (see See p. 617, 618)
• A grid of 24 chip sites with 10 defects randomly
  distributed. In this example 16 of the 24 sites
  have 0 defects
• Of the remaining sites 6 have 1 defect no site
  has more than 2 defects
• The problem of determining the yield is identical
  to the problem of placing n balls in N cells and
  then calculating probability of a given cell
  containing k balls
• P k (n!)/k!(n-k)! ? (1)/(Nn)(N-1) n-k
• If N and n are both large n/M m remains finite
  and can be approximated as Pk e-mmk /k!
• The probability that a chip contains no defects
  is Y1 P0 e-m
• The probability a chip contains 1 defect is
• P1 me-m

8

• If the area of the chip is A, the total chip area
  in the useable part of a wafer is NA
• The density of defects is n/NA D0
• The average number of defects per chip, m, is m
  n/N D0 NA/N D0 A
• Y1 P0 exp(-D0 A)
• This Poisson estimation was used to predict yield
  in the early days in the manufacture process
• The actual yield was found to be much larger than
  predicted

9
Yield Enhancement using Redundant Circuitry

• Many large MOS memory chips are designed with
  redundant circuitry, which can be switched to
  replace defective circuit elements
• This is usually accomplished using fusible links
  which can be fused as needed using laser or other
  techniques
• The yield will then be modified as shown
• Y1 P0 ?P1
• P0 probability of chip containing no defects
• P1 probability of chip containing 1 defect
• ? probability of chip containing 1 defect and
  can be repaired by using a single redundant
  column
• Simple Non-uniform Distribution of D
• Discrepancy between measured and predicted yield
  led to investigation of non-uniform distribution
  of D0 across a wafer

10

• The yield can be expressed as
• The yield is expressed as
• Y ? exp(-DA) f(D) dD
• f(D) is the normalized distribution of defect
  density
• ? f(D) dD 1
• 3 different D0 are investigated
• Delta function Y1 exp(-D0A)
• Triangular Y2 1-exp(-D0A)/D0A2
• Rectangular Y3 1-exp(-2D0A)/2D0A
• for D0A gtgt 1 we find that
• Y1 exp(-D0A)
• Y2 1/(D0A)2
• Y3 1/(2D0A)
• Y3 is found to be most closely fit to the
  observed yield of large ICs
• The above distributions do not have any physical
  basis, therefore more physically based
  distributions need to be investigated

11
Gamma Distribution

• The Gamma distribution is more physical
• f(D) 1/?(?)?(?) ?D ?-1 exp(-D/ ?)
• ? and ? are 2 distribution parameters and ?(?)
  is the gamma function
• Average density of defects ? ?
• Variance of D ? ?2
• Consequently Y4 1/(1SD0A)1/s
• for s 0, Gamma function reduces to delta
  function and Y4 exp(-D0A)
• Using different values of s, Gamma function is a
  good approximations of Y2 and Y3 over a wide
  range of D0A
• Gamma yield functions can be used to represent a
  large variations in the shape of experimental
  yield vs area curve see Fig. 4 and 5 p. 621 and
  622 of Sze.
• Each type of defect is characterized by
• its mean defect density Dn0
• shape factor of its distribution Sn

12

• portion of total chip area An susceptible that
  defect
• Using Gamma yield function
• Yn 1/(1SnAnDn0)1/Sn
• The overall yield is the product of the yield for
  each known type of defect
• Y ? Yn for n1,2,.,N
• For a mature process in a well controlled high
  yield line, all of the major yield-limiting
  defects have probably been controlled or
  eliminated. The yield is a product of many terms
  each approximately 1.
• This means SnAnDn0 ltlt 1
• ln Y ? -(1/Sn) ln(1SnAnDn0)
• ln(1SnAnDn0) ? SnAnDn0
• Thus lnY ? -AnDn0
• Y exp(-? AnDn0)
• D (1/A) ? AnDn0
• Y exp(-AD)
• Here An is the total chip area susceptible to the
  particular defect

13
Reliability Requirements for VLSI

• It is instructive to consider examples of the
  effects of device failure
• Early discrete solid state computer systems
  typically consisted of 105 transistors per system
• If 1 device failure per month is set as the
  minimum acceptable condition then the failure
  rate
• ? lt 1/(105 ? 720 hrs)
• 14 ? 10-9 failure/device-hour
• 1 FIT ? 1 failure/ 109 device-hour
• The objective for the hypothetical system is for
  ? lt 14 FIT
• Reliability Theory (Sze p. 627)
• Useful mathematical description requires precise
  definition of the terms
• Definitions
• Reliability -- probability that an item will
  perform a required function under stated
  conditions for a stated period of time

14

• For an IC the required function is generally
  defined by a test program for an automatic test
  set
• Often initial test programs are not complete and
  the ckts are not tested under all required
  conditions
• As new device failure modes are identified, the
  appropriate tests are included in later test
  programs
• Stated Conditions -- comprise of the total
  physical environments, including mechanical,
  thermal, electrical .
• Stated period of time -- the time during which
  satisfactory operation is required
• Cumulative Distribution Function
• If the device is operational at t 0. The
  probability that the device will fail at or
  before t is given by the function F(t)
• F(t) 0 t lt 0
• 0 ? F(t) ? F(t) 0 ? t ? t
• F(t) 1 t ?

15
Reliability Function and Probability Density
Function

• The probability density function is
• f(t) dF(t)/dt
• The Cumulative distribution function is
• F(t) ?0tf(x)dx
• The reliability function is
• R(t) ?t ? f (x)dx
• Thus f(t) - dR(t)/dt

16
Failure Rate

• In many applications the quantity of most concern
  is the instantaneous failure rate
• This is often referred to as the hazard rate
• Fraction of devices that were good at time t and
  that fail by t ? is given by
• F(t ?) - F(t) R(t) - R(t ?)
• The average failure rate during the time
  interval, ?, is
• ?(t) average failure rate
• 1/ ? R(t) - R(t ? )/R(t)
• for ? 0
• ?(t) - 1/R(t) dR(t)/dt f(t)/R(t)
• f(t)/1 - F(t)
• - dln R(t)/dt
• R(t) exp- ?0t ?(x) dx

17
Mean Time to Failure (MTTF)and Common
Distribution Functions (p. 630 Sze)

• MTTF is a common measure of reliability
• MTTF ?0? t f(t) dt
• It is desirable to have a single mathematical
  model that represents the failure rate of devices
  over their entire lifetime
• ?(t) generally varies as a function of time as
  shown

• A. High early failures or Infant Mortality
  due to manufacturing defects
• B. Midlife or Steady state period of low and
  generally constant failure rate
• C. Final or wear out period

18
Exponential Distribution Function

• The simplest distribution function, exponential,
  is characterized by a constant failure rate over
  the lifetime of the device. This is useful for
  representing a device in which all early failure
  mechanisms have been eliminated
• ?(t) ?0
• R(t) exp(- ?0t)
• F(t) 1 - exp(- ?0t)
• f(t) ?0exp(- ?0t)
• MTTF ?0? t ?0exp(- ?0t) dt

19
Weibull Distribution

• ?(t) varies as a power of the age of the device
• ? (?/?)t?-1 where ? and ? are constants
• For ? lt 1 the failure rate decreases with time
  and can be used to represent early failure
• For ? 1, ?(t) is constant and can be used to
  represent steady state
• For ? gt 1, ?(t) increases with time and can be
  used represent wearout condition
• For ? 1, the failure rate is constant which is
  a special case of Weibull distribution
• R(t) exp-(1/?)t?
• f(t) (?/?) t?-1exp -(1/?)t?
• MTTF ?1/? ?(11/?) where ? 1.

which is linear. The slope of the line is ?. The
MTTF is the time when F(t) 0.5
20

• In some applications, a better fit can be
  obtained through the introduction of a 3rd
  parameter, ?, in which X t - ? is used to
  replace t in the above equations to represent
• a shift by the amount of ? in the time axis
• Physically this represents a portion of device
  lifetime is used up during manufacturing burn-in
  or device testing
• Accelerated Testing
• If the required failure rate is 100 FIT or
  less, then the time required to observe one
  failure in 100 devices is approximately 100,000
  hr (11.4 yrs)
• Thus it is impossible to test the required
  reliability under normal operating conditions
• This necessitates means to accelerate the
  mechanisms that cause devices to fail

21

• 5 common stresses are used to accelerate device
  failure
• temperature
• voltage
• current
• temperature cycling to accelerate mechanical
  failure of chips and assembly package
• In such studies, different failure mechanisms may
  be accelerated by different level of stress even
  for the same type of stress
• A device may fail at normal operating conditions
  because of 2 completely different mechanisms
• Under the applied stress, one of these failure
  modes may be accelerated much more than the other
• Thus, we only see 1 failure mode in those tests
• After successfully eliminating the mode we may
  only the failure rate by small factor under
  normal operating condition
• Adequate studies must be done under normal
  operating conditions to satisfy that no failure
  mechanism remain that were not accelerated by the
  applied stress

22
Temperature Acceleration

• Many failure mechanisms involve chemical or
  physical processes that can be accelerated by
  raising the temperature
• Ea is the activation energy
• If some parameter of IC changes as a function of
  time, and if the IC fails when the parameter
  exceeds certain value.
• The Rates at two different temperatures are
  related as
• The IC would fail when the destruction reaction
  proceeds to some value equal to the failure
  criterion
• R?tf constant
• Thus a plot of ln(MTTF) versus 1/T, the slope
  will correspond to the activation energy

23
Voltage and Current Acceleration

• Voltage and current are effective acceleration
  stresses
• Voltage stress cause failure in devices due to
• dielectric breakdown
• interface charge accumulation
• charge injection
• corrosion
• Most studies indicate that the reaction rate, Rx,
  of the failure mechanism is proportional to a
  power of the applied voltage
• where R0(T) if thermally activated
• ? varies between 1 to 4.5
• For dielectric breakdown, a different type of
  acceleration occurs
• For a given field, a certain fraction of devices
  fail in a very short time, of the order of
  seconds
• Very few additional failure occurs as the field
  is maintained
• If the applied field is increased, additional
  fraction failures occur

24

• In such cases, operation at an increased voltage
  is more in the nature of screening rather than
  accelerating the failure mechanism
• Increased current level is used to accelerate
  failures caused by electromigration in metallic
  conductors
• 1 lt ? lt 4
• Stress-Dependent Activation Energy
• ?(T) describes the temperature dependence of the
  reaction rate
• For failure accelerated by voltage or current
  stressing, the activation energy is dependent on
  the applied bias
• The Eyring model states that
• where S applied stress

25

• Q is related to the Arrhenius activation energy
• SB is the breakdown stress, the value of the
  applied stress where failure of the device occurs
  essentially instantaneously
• The reaction rate can also be expressed as
• under conditions of low stress, R reduces to
• At high stresses
• From the above expressions Reaction Rate is a
  function of the applied stress, the effective
  activation energy will decrease with increased
  rate

26
Humidity-Temperature Acceleration

• Presence of water vapor in the chip environment
  introduces a new variety of possible failure
  mechanism
• Water vapor quickly permeates plastic packaging
  material
• 1. water vapor transports contaminants from
  surface of package through the plastic
• The chip is then exposed to water vapor and
  various contaminants
• 2. Diffusion of the contaminated water vapor
  through the passivation layer of the chip
• This step can be speeded up if the passivation
  contains defects or cracks
• The penetration of water vapor through the
  passivation layer determined the reaction rate
• 3. Once water reaches the metallization level,
  electro-chemical corrosion process can occur
• The ions needed for this corrosion process can
  arise from the contaminants which diffused
  through the passivation layer.

27

• If the intermediate dielectric of the chip is a
  phosphorous-doped glass, the water vapor can
  extract the phosphorus from the dielectric
• Electrochemical corrosion is a rapid process
  leading to metallization failure
• This failure mechanism can be accelerated by
  increasing the partial pressure of water vapor in
  the environment

28
Burn-in

• For mature products, the initial reliability
  studies would have identified and eliminated
  failure processes so that steady-state failure
  rate meets or exceeds design goal
• However, the manufactured devices still show
  existence of continuing early failure
• Generally, manufacturing defects cause the infant
  mortality failures e.g. pinholes, photoresist or
  etching defects resulting in near-opens or shorts
• Contamination on the chip of the package,
  scratches, weak chips or wire bonds, partially
  cracked chips or packages
• The purpose of the burn-in procedure is to
  operate the devices for some time during which
  most of the devices that are subject to
• Infant mortality failure actually fail
• The conditions during burn-in presumably
  accelerate the failure mechanisms that contribute
  to infant mortality failure
• Studies of infant mortality under increased T
  conditions show that infant mortality have an
  activation energy of 0.37 to 0.42 eV

29
Properties of Metal-Oxide Silicon (MOS) System

• To understand the MOS system the step is to
  derive the energy band diagram
• We note that at thermal equilibrium the Fermi
  level is constant
• The energy band diagram for a separated system is
  shown below

30

• When connected the Fermi level will be constant.
  The Fermi level in Si depends on doping level of
  the Si
• For Ei - Ef 0.29 eV the band diagram is shown

31
(No Transcript)
32

• Strong inversion condition stipulates that q?P
  q?s
• Thus to turn an MOS into strong inversion -- a
  condition for the formation of a conduction
  channel or inversion layer under the gate, a
  minimum band bending of 2 q?P is required
• The threshold voltage VT is then represented by
• We can gain further insight into the MOS by
  realizing that it is basically a capacitor
• The charges in the Si of the MOS system can be
  expressed as
• The terms in the square brackets constitute the
  voltage drop across the oxide. Since part of the
  charges are associated with the dopants in the
  depletion layer, therefore free carrier
  concentration in the inversion layer is

33

• The second term is the charge in the depletion
  layer VG here is the gate bias required to
  produce a band bending of 2?P and is therefore
  equivalent to the threshold voltage
• The proof for the expression of charge in Si is

34

• Where E is the electric field in Si
• The total band bending in Si is
• From Poissons equation we have
• For xd xdmax we have ?s 2?p and
• Charge is the Si layer is qNAxdmax, thus
• The total charging voltage is
• where

35

• Substituting into the previous equation
• From Poissons equation we obtain
• Concentration of free carriers in the inversion
  layer is
• Oxide and Interface Charges
• Charges at Si-SiO2 interface and the oxide may
  influence the threshold voltage through the
  modifications of the flat-band voltage. If the
  density of charge at xx1. It induces an equal
  and opposite charges divided between silicon of
  the metal gate. The closer is x1 to xox (the
  Si-SiO2 interface), the greater will the fraction
  of induced charges at Si-SiO2 interface and the
  oxide may influence the threshold voltage through
  the modifications of the flat-band voltage. If
  the density of charge at xx1. It induces an
  equal and opposite charges divided between
  silicon of the metal gate. The closer is x1 to
  xox (the Si-SiO2 interface), the greater will the
  fraction of induced charge within the Si.
• The induced charge changes the charge stored in
  the Si at equilibrium therefore it alters the
  flatband voltage.
• The size of ?VFB can be found using Gauss law to
  obtain the value of the gate voltage that causes
  all of the oxide charge Qoxto be mirrored in the
  gate electrode.

36

• Under this condition the field is constant
  between x 0 and x x1 and 0 for x gt x1.
• For 0 lt x lt x1 we have the following
  relationship
• The result can be generalized to account for
  shift in VFB using an arbitrary charge
  distribution
• where ?(x) is the volume charge density at x
• Origins of Oxide Charges
• There are at least 4 distinct types of charges in
  the oxide-silicon system
• Qf -- fixed interface charge density
• Qot -- oxide trapped charge density
• Qit -- interface trapped charge density
• Qm -- mobile charge density

37

• Qf is positive and is located within a very thin
  (1 - 2nm) laryer fo non-stoichiometric silicon
  oxide (SiOx)
• Qot can be both positive and negative, typically
  predominantly negative. Located in traps
  distributed throughout the oxide layer.
  Distortion in the C-V curve is due to unstable
  charges at the interface.
• The trapping sites Nit (cm-2) are located at the
  Si-SiO2 interface and have energy levels within
  the bandgap with density Dit cm-2eV-1
• To relate behavior of these traps to the
  distorted C-VG, as shown in the following figure,
  consider an oxide-Si interface characterized by
  interface trapping levels at energy Es. The gate
  voltage causes the Fermi level at the surface to
  cross Es, the charge state of these levels will
  change. This introduces a voltage dependent
  term, Qit/Cox, into the equation for VFB above
  making both flatband and threshold voltages vary
  with VG that led to the distortion the C-V curve.
• For Nit gt 1010cm-2 is generally unacceptable for
  reliable device design. Using modern MOS
  technology, Nit is reduced by annealing device in
  forming gas (90 N2 and 10 H2)

38

• Mobile charge results from alkali-metal ions
  particularly sodium. They induce ?VFB.
• The alkali ions have sufficient mobility when
  relatively low gate biases are applied. The
  mobility increases with temperature and thus
  magnifies the problem of VFB instability at high
  temperatures. The ions are positively charged,
  therefore -VG draws the ions to the metal-SiO2
  intrface where their effect is minimal. VG
  pushes them to the Si-SiO2 interface where their
  effects are most significant.
• For voltage stability of 0.1V, less than
  2x1010cm-2 mobile ions can be tolerated. Mobile
  ions can be avoided by careful processing and
  oxidation in HCl that immobilizes alkali ions.
• Hot Electron Degradation
• The assessment and improvement of reliability on
  the CKT level should be based on both failure
  mode analysis and the basic understanding of the
  physical failure mechanisms.
• Processes such as electromigration and
  electrostatic discharge cause catastrophic
  changes in device characteristics

39

• Other mechanisms such as hot-electron effects
  cause non-catastrophic failures which develop
  gradually over time and change CKT performance
• Scattering of Channel Hot-Electrons into the
  Oxide
• In order for electrons to obtain enough kinetic
  energy to be injected into the oxide, it has to
• gain K.E.
• its momentum redirected towards the oxide through
  a quasi-elastic collision
• following the collision, the electron must travel
  to S-SiO2 without further collision
• These processes are statistically independent,
  the injection probability is obtained as the
  product of the probabilities of each event
• MOSFET gate current is made up of electrons
  injected into the gate oxide by quasi-elastic
  scattering
• It consists of electrons that overcome the image
  potential well in the oxide and reach the gate
  electrode

40
Hot Carrier Effects

• Advances in VLSI is achieved through down scaling
  of device dimension such as channel length,
  junction depth and gate oxide thickness without
  proportional scaling of power supply voltage
• Decrease in device dimensions results in
  significant increase of the horizontal and
  vertical electric fields in the channel region
• Electrons or holes with high K.E. may be injected
  into the gate oxide, degrading I-V
  characteristics of MOSFETs.
• This is one of the important factors that limits
  the maximum achievable device densities in VLSI
  circuits
• Hot-carrier damage results in
• trapping of carriers on defect sites in the oxide
• creation of interface states at Si-SiO2 interface
  leads to degradation in transconductance, shifts
  in threshold voltage and decrease in drain
  current capability.

41
Oxide degradation Mechanism in MOS system

• Cause by injection of high-energy electrons and
  holes into the gate oxide near the drain
• The damage is in the form of localized oxide
  charge-trapping and interface trap generation
• Recent experimental evidence shows that
  hot-carrier related degradation can occur in
  deep-submicron devices with Leff 0.15?m
• at drain voltage as low as 1.8V. Therefore hot
  electron degradation may occur even with
  significant reduction in drain voltage.
• The continuing technology thrust must therefore
  accompanied by some limitations to ensure
  hot-electron reliability
• Hot-carrier injection causes degradation in the
  transconductance, shift in threshold and decrease
  in sub-threshold drain current
• There are many disagreement concerning the
  physical degradation mechanisms due to the lack
  of a reliable and sensitive techniuqe to evaluate
  hot-carrier damage at the interface. Moreover,
  hot-carrier induced oxide damage is very
  localized, the interpretation of the analysis is
  complex

42
Injection of Hot-Carriers into Gate Oxide

• Hot-carriers are electrons and holes that have a
  much higher K.E. than average carrier population
• Es in S.C. at equilibrium mostly have energy
  about kBT above EC. At equilibrium, K.E. of
  carriers that encounter large may gain
  significant K.E. in a short distance. Thus E- EC
  kBTe where Te is the effective electron
  temperature. There are 2 distinct modes of
  electrons injection in nMOS
• Substrate hot-electron effect (SHE)
• Channel hot-electron effect (CHE)
• Substrate hot-electrons are derived from leakage
  current. Electrons generated in the channel
  depletion region or diffusing from the bulk
  neutral region of the substrate drift toward the
  Si-SiO2 interface and gain K.E. from the high
  field in the surface depletion region
• The energetic electrons may overcome surface
  energy barrier and inject into the gate oxide.
• Some of the injected electrons are trapped in the
  oxide, resulting in a relatively uniform oxide
  charge accumulation that shifts the threshold
  voltage over time.

43

• The SHE is observed mainly in long-channel
  MOSFETs. As channel length decreases, SHE
  decreases since a large fraction of the
  hot-electrons generated in the substrate region
  are swept into the source and drain regions
  instead of the device surface
• CHE is more pronounced at large VDS. Electrons
  reaching Si-SiO2 interface with large K.E. may
  surmount the energy barrier. Electrons and holes
  generated by impact ionization also contribute to
  charge injection into the oxide. Hot-electron
  current and oxide degradation occurs mainly at
  the drain end. From the figures, the increased
  density of equipotential lines leads to larger
  horizontal field. Hot-electrons and hot-holes
  can be injected into the oxide interface with the
  aid of the vertical field or with their K.E.
  energy alone.
• Injected current density is
• Where n(x,y) is the local electron concentration
  at (x,y)
• pinj(x,y) is the spatial distribution of
  injection probability
• pinj(x,y) depends on several events that provide
  the electron with a momentum directed towards the
  oxide interface and with a K.E. sufficient to
  overcome interface potential barrier.

44

• Injection of hot carriers occurs mainly in a
  narrow injection zone at the drain end of the
  device where lateral field reaches maximum.
• In log channel MOSFETs, the spatial extent of
  injection region and magnitude of electric fields
  near the drain are largely independent of the
  channel length, L.
• For short channel devices, the heavier dopin or
  shallower junctions increase the electric fields
  in the drain region. Due to short channel
  effects the channel current entering the drain
  increases more rapidly than 1/L.
• Thus, devices with smaller geometries will be
  more sensitive to hot-carrier related
  degradation.
• Oxide degradation in the form of charge trapping
  which occurs in a short distance of about 0.1 ?m.
  However, a large percentage of the electrons
  entering the oxide are either scattered in the
  oxide and/or returned to Si substrate by the
  opposing field.
• The charges that do not reach the gate electrode
  degrades the oxide by charge trapping and
  interface trap generation.

45
Impact Ionization by Hot-Electrons

• In saturation region a high exists in the
  channel depletion region. Electrons will,
  therefore, be accelerated by the field. Some
  move horizontally and creates electron hole pairs
  (EHP) by impact ionization near the drain.
• Impact ionization process creates an avalanche
  plasma consisting of generated EHP in the
  pinch-off region
• The holes created are collected by the substrate
  constituting the drift component of the substrate
  current
• The drain current that contributes to impact
  ionization substrate current is a function of
  lateral electric field in pinch off region and
  VGS and L

46

• Some electrons and holes in the avalanche plasma
  can gain sufficient K.E. to surmount Si-SiO2
  potential barrier and become injected into SiO2.
  Majority of the holes generated constitute
  substrate current of MOSFET. Therefore,
  substrate current is considered a reliable and
  convenient monitor of the amount of hot-carrier
  degradation in n-MOSFETs
• To create EHP, hot-electrons must have K.E. gt
  (impact ionization energy). Thus
  is the distance the electrons must travel in
  to gain energy ?i.
• The probability of an electron travelling a
  distance to gain the required K.E. or more is
• where ? is hot-electron mean-free path. Since
  IDS is the total electron flow in the channel.
  Rate of supply of hot-electrons with K.E. gt ?i is
• where C1 is a weak function of the max. channel
  field Em.

47
Oxide Traps and Charge Trapping

• Concentration of oxide trapped charges and
  interface trapped charges are changed by capture
  of excess electrons or holes by existing traps in
  the oxide.
• The oxide charge distribution can also be changed
  by impact release of the trapped electron or hole
  by a hot-carrier. The electron or hole traps in
  the gate oxide are mainly Si dangling bonds.
  The dangling bonds give rise to the electron and
  hole traps.
• Interface Trap Concentration
• Interface trapped charge arises from a.)
  structural, oxidation-induced defects b.) metal
  impurities c.) defects caused by radiation or
  hot-carriers
• Unlike other trapped charges, interface trapped
  charges are in electrical communication with the
  underlying Si. Thus, influence of interface
  trapped charge on electrical characteristics of
  MOSFETs depends on its bias conditions.
• Generation of new interface trap is the primary
  cause of degradation of MOSFETs. New traps
  generated by hot-electrons and hot-holes through
  breaking

48

• Si-Si and Si-O bonds
• breaking of H bonds at interface, releasing H and
  leaving dangling Si- or O- bonds
• H released by hot-carrier impact migrates towards
  Si-SiO2 interface and is then trapped by proton
  traps.
• Bias Dependence of Degradation Mechanism
• Oxide degradation takes place by carrier trapping
  in oxide due to hot-electron carrier injection
  and interface trap creation
• These are the two most significant degradation
  mechanism, but there is no clear consensus on
  their relative contribution Hot-carrier related
  device degradation reaches maximum when VGS
  VDS/2. This coincides with max. of substrate
  current, thus it is often linked to impact
  ionization.
• When VTH shift is plotted as a function of gate
  voltage, the degradation exhibits 2 local maxima
• First peak electron injection into SiO2 is max.
  resulting in charge trapping
• Second peak at VGS VDS/2, corresponds to
  impact ionization of electrons and holes.

49

• For VTH VDS/2, ?VTH(t) Atn where 0.5 lt n lt
  0.7
• A depends on ISUB, IDS and processing parameters
• Effects of Hot-Carrier Damage on Device
  Characteristics
• Trapped charges in gate oxide influence surface
  potential and thus local flat band voltage
• C-V measurement can be used to measure total
  amount of trapped charge in SiO2. Accumulating
  negative charge shifts the local VFB to positive
  direction.
• Influence of interface traps generated by
  hot-carriers depends on the instantaneous bias
  conditions. Since interface traps are in
  electrical communication with the underlying Si
  substrate, occupation of the traps depends on the
  Fermi level at the Si-SiO2 intface and energy
  distribution of interface traps and the physical
  nature of NiT (whether the trap is acceptor or
  donor type).
• In n-MOS most generated NiT are acceptor type,
  mostly located at the drain end. Traps will
  start to be charged by electrons from substrate
  as the surface is biased from accumulation into
  weak inversion, ant then into strong inversion

50

• Once all traps are filled, their influence is
  similar to fixed oxide charge, which is the case
  because for all practical purposed the device are
  in strong inversion
• Surface mobility is decreased due to increased
  surface scattering
• Significant reduction in ID in linear region
• Less effect on ID in saturation region because
  once in saturation ID is governed by the channel
  region between the source and pinch off point
• Asymmetry between forward and reverse I-V curves
  also due to localization of oxide damage near the
  drain end
• as ?n decreases gm decreases
• ID/ID0 decreases
• ?VT increases
• Radiation Induced Interface Traps
• The major effect of ionization radiation on MOS
  devices is the generation of positive oxide
  charge resulting from hole-trapping at Si-SiO2
  interface.

51

• Radiation consists of high energy particle such
  as electrons, neutrons, protons and energetic
  x-ray and gamma ray
• Photons with E gt EG of SiO2 can generate EHP.
  Some of the generated carriers recombine. Most
  are driven toward the electrode by the oxide
  field. Electrons rapidly drift toward the
  positive electrode and flow out of the circuit.
  Holes drift much more slowly towards negative
  electrode.
• Once holes reach Si-SiO2 interface a fraction
  becomes trapped constituting the radiation
  induced positive oxide charge

52
Latchup in CMOS Circuits

• CMOS (Complementary MOS) is a very important
  class of circuits in VLSI technology
• Advantages of CMOS circuits includes low power,
  high speed logic circuits
• In bulk CMOS CKTs both n- and p-channel MOSFETs
  exist side by side. This is achieved by starting
  with a Si wafer of one type and creating in it
  regions of the opposite type. In so doing, FETs
  are not the only structures fabricated, pnpn
  devices consisting of parasitic bipolar
  transistors are also created.

53

• Under normal operation the circuit performs as an
  inverter and the bipolar portion can be ignored.
  However, if the bipolar circuit switches from its
  normally high impedance state to its low
  impedance state, the power supply sees a low
  impedance path to ground.
• If the current from the supply is not limited
  somehow, there might be irreversible damages done
  to the circuit.
• However, even if the circuit is protected, the
  pnpns low impedance state can still cause the
  circuit to malfunction.

54
Switching Mechanism (Streetman p. 401)

• The operation of a CMOS circuit can be understood
  using a two-transistor analogy

• Thus the parasitic bipolar transistors in a CMOS
  inverter can be viewed has two interconnected
  BJTs
• Each BJT can be modeled by Ebers Moll model

55

• The Ebers-Moll model uses the diode equations for
  the emitter and collector plus extra terms that
  provide coupling between the emitter and
  collector.
• For a forward biased diode, the excess carriers
  is
• Thus the emitter current is
• Thus, IC and IE can be expressed as

56
Two-Transistor Analogy

• The analysis of the 2-transistor analogy is given
  below
• where ?1,2 are the emitter-to-collector current
  transfer ratios for the transistors
• However, the sum of ic1 and ic2 is the total
  current through the device. Thus,
• As indicated in the above equations, as long as
  the sum, ?1 ?2, is small compared to unity, the
  current i is small at approximately the combined
  collector saturation currents of the 2 equivalent
  transistors. As ?1 ?2 approaches unity the
  current i increases rapidly. At this state both
  transistors become saturated and will remain in
  the low resistance state after the switching.

57
Variation of ? with Injection

• Since the 2-transistor analogy implies that
  switching involves an increase in the ?1 and ?2
  to the point that ?1 ?2 becomes unity, it is
  important to understand how ?1 and ?2 depend on
  injection for a transistor.
• ? is the product of the emitter injection
  efficiency, ?, and the base transport factor, B
  where
• At very low currents, ? is dominated by
  recombination in the transition region of the
  emitter junction
• As the current increases, injection across the
  junction begins to dominate over the
  recombination. This leads to increase in B due
  to the saturation of recombination centers as
  excess carrier concentration becomes large.

58
Forward Blocking State

• At this state the applied voltage is mainly
  across the reverse biased junction j2
• j1 and j3 are forward biased but current remain
  small because holes are injected from p1 into n1.

• If a hole recombines with an electron in n1 the
  electron must be replenished to maintain space
  charge neutrality.
• The supply of electrons is very restricted
  because j2 is reverse biased.
• As a result current through j1 is approximately
  the same as the reverse saturation current of j2.
  Similar arguments hold for current through j3.

59
Conducting State

• As ?1 ?2 1, many holes injected at J1
  survive to be swept across j2 into p2.
  Similarly, electrons injected at j3 are collected
  at j2. This is regenerative because more
  electrons injected into n1 induces more holes
  injection across j1 to maintain neutrality.
• When this happens depletion at j2 begins to
  shrink. Finally, j2 becomes forward biased.
• The overall voltage across the devices
  approximates the potential drop across 1 forward
  biased pn junction.
• The triggering of the junction is often caused
  by the breakdown of j2

60
Avoiding Latchup

• Latchup can be avoided by incorporating guard
  structures in the circuits.
• There are two types of guard structures
• minority carrier guards
• majority carrier guards
• The guard structures are used to decouple the
  parasitic bipolar transistors from each other

Minority Guard

• Minority carrier guards are used to collect
  injected minority carriers before they can cause
  a problem.
• The minority carriers injected into the substrate
  could be collected by a reversed-biased
  well/substrate junction and flow through the well
  as majority carriers.

Majority Guard

• The basic mechanism of a N majority guard ring
  in the well is to steer current away from the
  parasitic emitter.

61
Silicon on Insulator (SOI)

• Devices fabricated on SOI substrates are
  fabricated by dielectric separation
• At this point the most mature technology for
  manufacturing SOI substrates is Separation by
  IMplantation of OXygen (SIMOX)
• In this technology heavy dosage of oxygen is
  implanted into Si wafer to obtain SiO2 with a
  layer of single crystalline Si on top
• Separation of devices can therefore be
  accomplished by etching the Si layer through
• Therefore there will not be any parasitic bipolar
  transistors
