Title: Transmission Machine Components


1
Transmission Machine Components
2
Gears
  • Gears simply change the parameters of mechanical
    power

Pitch-Line Velocity
P
r1
r2
gear
pinion
3
Tooth Forces
T1
r1
F1
4
(No Transcript)
5
Normal velocity must match. Using similar
triangles
v2 cos?2     v1 cos?1       where
  v1  ?1 . O1C         v2  ?2 . O2C
Want constant rotation rate ratio
?2 /?1     v2 . O1C/v1 . O2C
O1C.cos?1 /O2C.cos?2
O1 C1 /O2 C2     O1 P / O2 P
Point P must be fixed
6
(No Transcript)
7
Effect of Errors
Shafts farther apart than spec.
Shafts at spec. distance
8
Involute Tooth Profile
  • The two curved surfaces of mating teeth, contact
    as a line

9
Types of Gears
  • Spur Gears
  • Teeth are parallel to rotation axis
  • Transmit power between shafts with parallel axes
  • Helical Gears
  • Teeth inclined to the axis of rotation
  • Used for the same applications as spur gears, but
    have less noise due to gradual tooth engagement

10
Types of Gears, cont.
  • Bevel Gears
  • Teeth on a conical Surface
  • Used with intersecting shafts
  • Worm Gears
  • Similar to a screw
  • Used with non-parallel and non-intersecting
    shafts typically with high speed ratios

11
Rack and Pinion
  • A rack is an unwound spur gear
  • Turns rotary motion in to linear motion

12
Anatomy of a Gear
  • Pitch Circle
  • Theoretical circle upon with all calculations are
    based
  • Diametral Pitch
  • Module
  • Pressure Angle
  • For gears to work together they must have the
    same pitch (or module) and pressure angle

13
Multiple Gear Stages
  • Gear ratios from a multi-stage gear train
    multiply together

T3
T2
T4
T1
21 reduction
21 reduction
21 reduction
Overall a 81 reduction
14
Efficiency
  • In reality gears are not 100 efficient
  • Good quality spur gears are typically in the 90
    efficiency range
  • This can be a problem with multiple (large) gear
    reductions

Each a 21 reduction with 95 efficiency
Overall a 321 reduction, but only 77 efficient
15
Belts and Chains
  • Belts are essentially the same as spur gears but
    they have the ability to have large offsets

P1
P2
16
Slip
  • Belts rely on friction and to prevent slip
    tension must be maintained
  • Chains and timing belts that have teeth with
    positive engagement can help prevent slip

17
Shafts
Energy used to overcome the forces resulting from
misalignment will reduce the overall efficiency
of your system
Parallel misalignment
Angular misalignment
This is the key to doing well in the transmission
contest
18
Pins
  • Pins hold two parts together based upon the shear
    strength of the pin
  • Pins are good when the joint must take both
    thrust and shear
  • Pinned joints are easy to analyze and reliable
  • Pinned joints can be used as a mechanical fuse
  • Pinned joints are difficult to assemble and
    disassemble because pins are typically press fit
    into place

shaft
gear
pin
19
Keys
  • Keys transmit torque in shear across the length
    of the key
  • Keys have all the advantages of pins, but they
    are easy to install in remove
  • Keys do not take any axial load

Woodruff key Used to reduce stress concentrations
in the shaft
20
Clamp Fit
  • Clamps depend upon friction and the bolted
    connection between two parts (or a single part
    with a flexure) to develop the clamping force
  • Clamped connections can be easy and reliable for
    low torque applications

21
Press (Interference) Fits
  • Two parts can be pressed together if the hole is
    manufactured smaller than the shaft that is
    installed
  • The load between these two parts is taken in
    friction developed by the strain of the press fit
  • Manufacturing tolerances are very tight for this
    type of connection
  • For a 0.25 diameter shaft with a class FN2 fit
  • Shaft 0.2510 0.2514
  • Hole 0.2500 0.2506
  • Difficult to disassemble without damage to the
    parts

22
Splines
  • Splines are essentially matching internal and
    external gears used to transmit torque
  • Splines are extremely reliable and efficient
  • Splines are difficult to manufacture

23
Retaining Rings
  • Retaining rings are used to constrain things
    axially in one direction on a shaft
  • Installed by machining a groove into one of the
    mating parts
  • Can be made external or internal

External
E-Style External
Internal
24
Shaft Connections
Coupler transmits torque and allows for
misalignment
Key or set screw transmits torque
25
Couplers
  • Bellows
  • Spider Coupling
  • Helical
  • Universal Joint

26
Bearing and Bushings
27
Bushings
  • Bushings have sliding contact and rely on low
    friction at the point or line of contact

r
F
28
Rolling Element Bearings
  • Replace sliding contact with rolling contact
    which is much more efficient

Outer Race
Ball
Separator (retainer)
Inner Race
Image courtesy of Barden Precision Bearing
29
Rolling Contact
?1
ri
ro
rLi
rLo
30
Spherical Bearings
  • Allows for misalignment in all rotational degrees
    of freedom
  • Constrains in all translational degrees of
    freedom
  • Good for low speed / high load applications

31
A Brief Into to SpecifyingElectric Motors
32
Electric Motors
  • Torque is proportional to current
  • Speed is proportional to voltage
  • An electric motor generates an Electromotive
    Force (back EMF) as it spins
  • A portion of the input voltage goes to doing work
    and a portion goes to overcome the back EMF

33
Kt
Ke
34
Electric Motors
For a given voltage
35
Electric Motor Power
Cant always operate here due to heat
36
Continuous Operating Range
